x-travel:6500/13150 mmy-travel:4000 mmz-travel:1250 mmw-axis:2250 mmtable surface area:5500/12150 x 3000 mmmax. workpiece weight:70.000/105.000 kgram head dimension:480 x 510 mmmilling spindle motor:63 kWmax. torque on the spindle:3300 Nm tool taper:DIN 39871 AD ISO 50 milling head speed:6,3 - 4000 U/minfeed speeds:1 - 24000 mm/minw-axis:1 - 6000 mm/min.distance between columns:3500 mmpassage:3000 mmtotal power requirement:120 kWweight of the machine ca.:245 tdimensions of the machine ca.:29,0 x 7,7 x 8,1 mThe machine is in mint condition and was generally overhauled in 2020!with CNC SIEMENS 840 Dautom. tool magazine for 153 tool stationsautom. milling head magazine for 6 heads milling heads - straight - straight extended length -milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm, 144 x 2,5°, ISO 50m ...
Serial number: 07400003691operating hours read: 88,040Spindle hours read: 43,558Spindle speed range: 3200/5000 rpmRotation diameter: 270 mmTurning diameter: 120 mmSpindle distance: 900 mmTravel X1: 290 mm TravelZ1: 650 mmTravel X2: 180 mmTravel Z2: 650 mmTravel Y1: +- 40 mmTravel Z3: 670 mm TravelX3: 175 mmMax. rod diameter: 100/104 mmSpindle bore diameter: 118 mmRapid traverse speed X- and Z-axis: 30 m/minRapid traverse speed Y-axis: 15 m/minNumber of driven tools per tool carrier: 12Control: SIEMENS SINUMERIK 840 D POWERLINEincl. chip conveyorwith 2 tool turrets - each with 12 tool positionsmain and counter spindles, as well as foot switchesAttention, the machine has the following defects:-the B-axis is defective (sits on turret 1)-the guides and drives are worn according to their age-X2 axle (guide rails) runs a bit crookedin the range of 0.03 mm (would have to be remeasured), sporad ...
The conception of the basic machine is characterized by the following features: - horizontal position of the workpiece spindle; vertical position of the milling cutter spindle or of the milling head - The workpiece is picked up between the workpiece headstock (left) and the tailstock (right) - The radial slide is mounted on the base (X-axis) - The axial slide moves on the radial slide (Z-axis) - The shift milling head is equipped with automatic angle adjustment (A-axis); the shift slide (Y-axis) moves tagential to the Workpiece diameter - CNC controlled - IBH control - Charging device - a lot of accessories Technical data: - Largest millable module with hobs according to DIN 8002: 4.5 mm - Largest millable module for high-performance milling: 3.0 mm - Number of teeth: 2 - 999 - Max. workpiece nozzle for manual loading: 200 mm - Max. workpiece nozzle for autom ...
automatic:Werkzeugspannung Spannk.15000 Ntotal power requirement:63 KVAweight of the machine ca.:56000 kgtable-size:22000 x 800 mmTool bore:ISO 50, DIN 69871 AD x-travel:20500 mmy-travel:1600 mmz-travel:1000 mmdimensions of the machine ca.:24 x 6 x 4 mtool piece magazine with:30 Plätze
: neu : ca. 4 Monate ab Auftragse : Taiwan : 48000 €: 916.8 €: 40 -3200 U/min: ISO 40 : 600 x 500 x 400 mm: 1000 x 500 mm: 3.75 kW: 1814 kg: 1000 mm/min: 8 : 14 x 63 mm: 300 kg: 600 mm: 500 mm: 400 mm: 0 - 600 mm/min.: 0 - 600 mm/min.: 40 - 3200 : 40 - 3200 : +/- 90° °: 100 mm: manuell : 3,75 kW: 1200 x 250 mm: 160 - 660 mm: 95 - 495 (2. T-Nut), 180 mmswiveling operating panel3 axes digital read out Fagor 400ib Innovamotor for horizontal- and vertical spindle: 3,75 kWfeed motors with inverter for X/Y/Z: 0,75 / 0,75 / 0,75 kWball screw spindles for X/Y/Z axesmanual gear box for spindle speeds1 pc. long milling arbor 27 mm3 pcs. recustion sleeves (MK1, MK2, MK3)1 pc. drawing bar ISO40 for horizontal or vertical spindlespindle protection with switchtable safety guard with doors with switchesouter arbor support for horizontal spindleLED work lampautomatic lubrication for X/X/Z guidway ...
x-travel:6000 mmy-travel:2100 mmz-travel:1500 mmControls:HEIDENHAIN iTNC 530 BASIC DESIGN:. - basic design : travelling column :. WORKING RANGE -MILLING-:. - x-axis travel:6000 mm - y-axis travel:2100 mm - z-axis travel:1500 mmFLOOR PLATE:. WORKING SPINDLE / HEAD:. - spindle type : orthogonal head :. - tilting range:360 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - tilting range (2nd axis):270 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - spindle revolutions (min):20 /min - spindle revolutions (max):4000 /min - spindle diameter:90 mm - taper fixture : ISO SK 50 :. - spindle power (continuous):32 kW - torque (max.):910 NmAXIS DRIVES:. - feed velocity (min):2 mm/min - feed velocity (max):20000 mm/min - rapid traverse:25000 mm/minELECTRICAL SPECIFICATIONS:. - total power consumption:79 kW - mains voltage:400 ...
Hermle UWF 900 Year of manufacture according to the wiring diagram: 1992 Control: Heidenhain 407 Facilities Handwheel Network connection Speed: 4,000 rpm Technical data X-travel: 600 mm Y-travel: 400 mm Z-travel: 420 mm Tool holder: SK 40 Distance spindle / table: 127 - 567 mm Spindle diameter in front bearing: 55 mm
Equipped with digital control aes and vacuum table complete with unwinding tables aes size approximately 230 x 340 cm
x-travel:600 mmy-travel:500 mmz-travel:450 mmweight of the machine ca.:3,5 t
This 3-axis Hermle C800V was manufactured in 1996. It features a SK40 spindle, capable of reaching up to 15,000 RPM, and includes tool length measuring. Ideal for precise vertical machining tasks. Contact us for more information about this machine.
This 4-axis HANNSA YL 850 B was manufactured in 2016. It features an X-axis travel of 850 mm, Y-axis travel of 500 mm, and Z-axis travel of 500 mm. The machine is equipped with a FANUC 0I-MF CNC, a spindle speed of 10,000 rpm, and a maximum table load of 500 kg. If you are looking to get high-quality machining capabilities, consider the HANNSA YL 850 B vertical machining centre we have for sale. Contact us for further details.
: gebraucht : 2004 : 4540 : ca. 2 Wochen ab Auftragse : Österreich : 19900 €: 1 : 63 - 3150 (18) U/min: 700 x 500 x 500 mm: 900 x 500 mm: 6.6 kW: 2150 mm: 2220 mm: 2120 mm: 2550 kg: 500 kg: 100 mmCNCHeidenhain TNC 41018. mech. feeds with rapid travel in X,Y,Z axesball screw spindlestoolmaker accuracyDIN 8615hyd. tool clamping with holdersSK40 vertical und horizontalvertical spindle+/- 30° swivelingswing out devicedigital 3D edge finderwork area protectioncoolant equiptmentaut. central lubricationfixed angle table with 10 t-slotschip collecting traymachine lampusers manual in GERMAN + CECOMPLIES WITH THE CURRENT INDUSTRIAL SAFETY REGULATIONS (AMVO &, UVV)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CONTROLS HEIDENHAIN TNC 128 WORKING RANGE -CUBIC- X-axis travel: 610 mm Y-axis travel: 400 mm Z-axis travel: 450 mmTABLE table surface (left-right): 800 mm table surface (front-back): 425 mm workpiece load (max): 300 kgSPINDLE / HEAD spindle revolutions (max): 4500 /min tool fixture: ISO SK 40 AXIS DRIVES traverse velocity X (max): 2000 mm/min traverse velocity Y (max): 2000 mm/min traverse velocity Z (max): 2000 mm/min rapid traverse X: 5000 mm/min rapid traverse Y: 5000 mm/min rapid traverse Z: 4000 mm/minDIMENSIONS / WEIGHTS space requirements -left/right-: 1800 mm space requirements -front/back-: 1800 mm total height: 2000 mm total weight approx.: 2300 kgATTACHMENTS coolant unit: yes closed cabin: yes European CE standards: yes Condition:- as new (barely used)- approx. 1000 spindle hours- all axes can also be operat ...
Number of T-slots: 8, rated current: 23A, controls: CONTOUR 3, with tool magazine. An on-site inspection is possible.
X-axis: 1080mm, y-axis: 710mm, z-axis: 710mm, speed range: 1-12,000/min, max. table load: 550kg, NC rotary table diameter integrated into the fixed table: 800mm, table dimensions: 1500x800mm, number of tool positions: 32, tool holder: SK 40 DIN 69872, connected load: 15kW, control system: Heidenhain TNC 430, operating hours: 63,619h, spindle hours: 22,552h, with controlled NC swivelling milling head B-axis, active cooling for the B-axis motor spindle, handwheel, operating mode 4, the hard drive drive amplifier was replaced in January 2025. An on-site inspection is possible.
x-travel: 1550 mmy-travel: 400 mmz-travel: 500 mmtable-size: 1850 x 350 mmspindle taper ISO: Sk 50 spindle turning speed range: 40 - 1800 U/minquill stroke: mmtotal power requirement: 7,5 KWweight of the machine ca.: 2,8 tdimensions: 2,4 x 2,2 x 2,1 mUniversal Milling Machine- 3-axis digital readout- Central lubrication system- Coolant system- Machine lamp- Machine leveling feet- Chip guard- Emergency stop device- Mobile workbench incl. toolsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
This 3-axis ARES-SEIKI R4530 was manufactured in 2006. It features an X-axis travel of 450 mm, Y-axis travel of 300 mm, and Z-axis travel of 300 mm. The machine includes a work table size of 600 mm x 300 mm and a maximum table load of 200 kg. If you are looking to get high-quality machining capabilities, consider the ARES-SEIKI R4530 vertical machining centre we have for sale. Contact us for further details.
This HAAS VF-2, manufactured in 2008, offers strong machining capability with 706 mm of X-axis travel, 406 mm on the Y-axis, and 508 mm on the Z-axis. Equipped with a spindle speed of 8100 rpm and a powerful 22.4 kW spindle motor, it is well suited for demanding milling applications. The visual and technical condition of the machine is very good for its age. Contact us for more information.
This HAAS VF-3 vertical machining center, manufactured in 2017, offers strong milling performance with a large 1219 Ã 457 mm table and a load capacity of 1588 kg. It is equipped with an 8100 rpm spindle and includes a chip conveyor as well as a through-spindle coolant 21 bar option. The machine is in excellent technical condition. If you are looking for high-quality milling capabilities, consider the HAAS VF-3 we have for sale. Contact us for more information.
: gebraucht : 2003 : 4544 : prompt, Zwischenverkauf v : Spanien : 13800 €: 1 : 50 - 1700 (12) U/min: ISO 40 : 600/210/400 mm: 800 x 225 mm: 1500 mm: 1350 mm: 1850 mm: 950 kg: 1,5 kWwith 3-axis digital display Fabr.FagorCooling equipmentMachine lampSwivelling universal milling head (Huron design)Horizontal milling device with counter bearingTable enclosureautomatic feeds in X and YMachine feetsUser Manual and EG Confirmation englishBUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISEWe offer you maximum security and complete transparency.• HONEST INSIGHTS: Detailed photos and functional videos of the current condition• LIVE ON-SITE CHECK: Live testing is possible at our facility• DIGITAL DEMONSTRATION: Individual live demonstration via video call• RISK-FREE PURCHASE: 14-day return policyDetails:https://www.hesse-maschinen.com/en/lp/used-machinesThe data for this ...
SERON 1328 PRO+ CNC router was built in 2023 in Poland by SERON Sp. z o.o. Sp.k. The machine was designed for precise and efficient machining of a wide range of materials, i.e. soft metals, plastics, wood and glass. Thanks to its versatility, it is ideally suited to production plants with diverse production profiles. The SERON 1328 PRO+ represents an extremely attractive combination of state-of-the-art technology and solid mechanics. The monolithic, heavily ribbed design made of high-grade steel effectively eliminates any vibration and deformation generated during even the most intensive operation. An intelligent energy recovery system further significantly reduces the machine’s operating costs. The machining process is performed by means of a brushless HITECO electro-spindle with an efficient cooling system. The inverter powered spindle reaches speeds of up to 24000 rpm, ensurin ...
AVIA FNE 50N CNC milling machine was built in 1998 in Poland by Fabryka Obrabiarek Precyzyjnych AVIA S.A. The machine is fully operational and has been regularly serviced throughout its service life. The AVIA FNE 50N was designed for precision machining of workpieces made of, e.g. steel, cast iron or aluminium. The machining process is performed inside a large work space by means of a reliable spindle with stepless rotational speed adjustment. When removed from the head, the spindle can operate both vertically and horizontally, with the same parameters. The work table with a length of approximately 1250 mm and a width of 500 mm, on the other hand, has T-slots for easy mounting of workpieces and tooling. All this is complemented by an intelligent HEIDENHAIN controller, offering convenient operation and access to many advanced functions. The AVIA FNE toolroom milling machine weighs 3000 ...
