x-travel:30000 mmy-travel:3600 mmz-travel:1900 mmmilling head speed:1 - 4000 U/minspindle taper ISO:50 feed speeds:1 - 10000 mm/minrapid traverse:25 m/minmilling spindle motor:46 kWtotal power requirement:85 kWdimensions of the machine ca.:45 x 8,7 x 5,5 ü.F. mwith CNC HEIDENHAIN iTNC 530autom. milling head indexing 2,5° floor plate field 31000 x 2500 mm ( 4 floor plates 6000 x 2500 mm + 1 floor plate 7000 x 2500 mm )2 chip conveyors, coolant attachment
x-travel:14000 mmy-travel:3100 mmz-travel:1.200 mm (220 - 1.420) mmdistance between columns:4.417 mmtable-size:14.000 x 2.500 mmworkpiece weight:15.000 kg/mdrive capacity - spindle motor:25 kWspindle cone:63 HSKspindle turning speed range:18000 rpmmilling feeds:30000 mm/mindimensions of the machine ca.:15.000 x 8.418 x 6.033 mmweight of the machine ca.:135 tCNC controller: SIEMENS 840 D universal milling head:5 Achsen mit ?C5C? Elektrospindel automatic tool changer:24 fach
x-travel:2000 mmy-travel:800 mmz-travel:800 mmtable-size:2.000 x 700 mmworkpiece weight:3500 kgdrive capacity - spindle motor:17 kWspindle cone:50 ISOspindle turning speed range:3000 U/mindimensions of the machine ca.:5265 x 3250 x 2730 mweight of the machine ca.:9 tCNC controller:HEIDENHAIN TNC-426 :manuell used universal bed type milling machine with chip conveyor, automatic 2 position (vertical/horizontal) head 3000Rpm The retrofitting jobs done in this machine, are the same than those done to all of our machines.- Completely repair of the head, replacing bearings, shafts and engaging gears.- Completely replacement of all the bearings of the machine.- Replacing the joining screws of the bodies.- Completely repair of spindles.- Adjustment and repair of axis.- Grinding and adjusting all guides, because of deterioration.- Grinding and adjusting of the guide ways of the ram.- Repairing o ...
x-travel:2000 mmy-travel:1500 mmz-travel:1460 mmmilling spindle motor:35/30 kWspindle taper ISO:50 spindle turning speed range:24 - 3000 U/mintable surface area:1350 x 1550 mmtable load:6 tfeed speeds:10 - 3000 mm/minrapid speed:10 m/mintotal power requirement:48 kWweight of the machine ca.:24 tCNC HEIDENHAIN TNC 426B-axis table roundHoriz. and Vertikal automatic positioning Milling Headdiverses accessories
x-travel:16300 mmy-travel:2600 mmz-travel:1600 mmspindle taper ISO:50 spindle turning speed range:22 - 4000 U/minrapid traverse:24 / 36 m/minmain drive:37 kWtotal power requirement:50 kWwith CNC HEIDENHAIN TNC 430automatic Universal Milling Headautomatic toolchanger 90-pocketscoolant attchament and chip conveyor
x-travel:6500/13150 mmy-travel:4000 mmz-travel:1250 mmw-axis:2250 mmtable surface area:5500/12150 x 3000 mmmax. workpiece weight:70.000/105.000 kgram head dimension:480 x 510 mmmilling spindle motor:63 kWmax. torque on the spindle:3300 Nm tool taper:DIN 39871 AD ISO 50 milling head speed:6,3 - 4000 U/minfeed speeds:1 - 24000 mm/minw-axis:1 - 6000 mm/min.distance between columns:3500 mmpassage:3000 mmtotal power requirement:120 kWweight of the machine ca.:245 tdimensions of the machine ca.:29,0 x 7,7 x 8,1 mThe machine is in mint condition and was generally overhauled in 2020!with CNC SIEMENS 840 Dautom. tool magazine for 153 tool stationsautom. milling head magazine for 6 heads milling heads - straight - straight extended length -milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm, 144 x 2,5°, ISO 50m ...
x-travel:1000 mmy-travel:1150 mmz-travel:700 mmtable-size:900 mmtable load:1500 kgspindle speeds:10.000 1/minspindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nmspindle taper:A100 HSKT-slots:18mm/7/100 mmmilling feed range:20.000 mm/minrapid traverse feeds:X/Y/Z: 24 m/mindiameter of tools max.:150 mmworkpiece length:300 mmweight of tools max.:20 kgweight of the machine ca.:15 tdimensions of the machine ca.:s. Katalog mCNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fachScales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20
x-travel:3600 mmy-travel:1250 mmz-travel:1600 mmtable load capacity:8000 kptable clamping surface::4100 x 1050 feed range:10 - 5000 mm/minrapid traverse feeds:10000 mm/minspindle motor:29 kWspindle taper::ISO 50spindle turning speed range:5 - 4000 U/mintotal power requirement:70 kWweight of the machine ca.:28 tdimensions of the machine ca.:8,5 x 5,4 x 3,2 mMachine with Heidenhain TNC 430 Steuerung- tool changer 30-fold- milling head indexable 2,5°- 4. axis turn table
x-travel:600 mmy-travel:450 mmz-travel:400 mmTable area:700 x 480 mmspindle turning speed range:10 - 3150 U/minspindle taper ISO:40 quill stroke:80 mmdimensions of the machine ca.:1,8 x 2,1 x 1,9 mtotal power requirement:8 kWweight of the machine ca.:3,5 tMachine with universal turn, sviwel and tilting table- CNC control DIALOG II- splash guards- misc. parts
automatic:Werkzeugspannung Spannk.15000 Ntotal power requirement:63 KVAweight of the machine ca.:56000 kgtable-size:22000 x 800 mmTool bore:ISO 50, DIN 69871 AD x-travel:20500 mmy-travel:1600 mmz-travel:1000 mmdimensions of the machine ca.:24 x 6 x 4 mtool piece magazine with:30 Plätze
x-travel:6000 mmy-travel:2100 mmz-travel:1500 mmControls:HEIDENHAIN iTNC 530 BASIC DESIGN:. - basic design : travelling column :. WORKING RANGE -MILLING-:. - x-axis travel:6000 mm - y-axis travel:2100 mm - z-axis travel:1500 mmWORKING SPINDLE / HEAD:. - spindle type : orthogonal head :. - tilting range:360 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - tilting range (2nd axis):270 ° - - mode of operation : automatic :. - - positioning/indexing:1 ° - spindle revolutions (min):20 /min - spindle revolutions (max):4000 /min - spindle diameter:90 mm - taper fixture : ISO SK 50 :. - spindle power (continuous):32 kW - torque (max.):910 NmAXIS DRIVES:. - feed velocity (min):2 mm/min - feed velocity (max):20000 mm/min - rapid traverse:25000 mm/minELECTRICAL SPECIFICATIONS:. - total power consumption:79 kW - mains voltage:400 V - mains fre ...
x-travel:600 mmy-travel:500 mmz-travel:450 mmweight of the machine ca.:3,5 t
x-travel:550 mmy-travel:300 mmz-travel:425 mmCNC-control:Sinumerik table-size:950 x 350 mmmax. table load:500 kgspindle taper ISO:30 spindle turning speed range:20 - 10500 U/minspindle drive motor:5,5 kWtool change unit:12 Pos. coolant:inkl. voltage:380 Vtool adaptor:Steilkegel 40 groove width:32/28 mmno. of flutes:3 rapid speed:40.000 mm/mintotal power requirement:15 kVAweight of the machine ca.:3,3 tchip conveyor:inkl. dimensions of the machine ca.:2000x 3000 x2500 mmDocuments:vorhanden - Serial Number: 186 - 78- Control: FANUC O-M- with various tool holders- coolant equipment
x-travel:500 mmy-travel:400 mmz-travel:330 mmtable-size:710 x 410 mmspindle taper ISO:40 quill stroke:100 mmcontrol:HEIDENHAIN TNC 335 B table load:180 kgno. of flutes:8 groove width:14/25 mmtool taper:SK 40 speeds::20 - 3000 U/minfeeds:infinitely variable1-1250 mm/minrapid traverse:5000 mm/mintotal power requirement:13 kWweight of the machine ca.:2500 kgdimensions of the machine ca.:2000 x 2800 x 2300 mmYear:ca. 1984 Zusatzinformationen ? Schile-Elektroschrank mit CNC-Steuerung Heidenhain TNC 355 ? Starrer Winkeltisch 710 x 400mm ? Spritzschutzverkleidung / Halbkabine ? Kopf nach Skala präzise drehbar über Kurbel ? Kopf komplett wegschwenkbar für horizontal Spindel
x-travel:800 mmy-travel:250 mmz-travel:350 mmtable-size:1130 x 250 mmno. of flutes:4 groove width:14/25 mmtaper MK:4 spindle turning speed range:56 - 2800 U/mintotal power requirement:9,5 kWweight of the machine ca.:2009 kgdimensions of the machine ca.:1400 x 1700 x 2800 mmDocuments:vorhanden
x-travel:1190 mmtotal power requirement:25 kWfeeds::3 - 2000 mm/minweight of the machine ca.:4,3 ttable-size:1600 x 400, 5 Spannbacken mmdimensions of the machine ca.:4000 x 3600 x 2200 mmspeeds:45 - 1800 U/miny-travel:530 mmz-travel:540 mmtool taper:ISO 50 control cabinet:940 kg
x-travel:700 mmy-travel:450 mmz-travel:500 mmtotal power requirement:23,4 kWweight of the machine ca.:3100 kgdimensions of the machine ca.:3200 x 4000 x 2500 mmtool taper:ISO 40 feeds:0,2 - 0,6 - 0,12 mm/Uspindle speeds::20 - 3150 , direkt programmierbar /minfeed range:1 - 3000, in B=0,01 - 3 U/minrapid traverse in x-y-z axis:6m/ min, B = 7,6 U/minwork table::NC Rundtisch(B-Achse) D=630 mm, 9T-nuten control:CNC432
x-travel:100 mmy-travel:100 mmz-travel:100 mmtotal power requirement:0,6 kWweight of the machine ca.:130 kgdimensions of the machine ca.:1600 x 1000 x 1300 mmmilling depth:0-50 mm
x-travel:630 mmy-travel:200 mmz-travel:360 mmtotal power requirement:7,5 kWweight of the machine ca.:2,5 tdimensions of the machine ca.:1500 x 1800 x 1900 mmspindle taper:SK40 table-size:250 x 1100 mm
x-travel:500 mmy-travel:400 mmz-travel:330 mmtable-size:400 x 710 mmspindle taper ISO:40 quill stroke:100 mmcontrol:HEIDENHAIN TNC 335 table load:180 kgno. of flutes:8 groove width:14/45 mmtool taper:ISA 40 speeds::20 - 3000 /28- 4000 U/minfeeds:infinitely variable1-1250 mm/minrapid traverse:5000 mm/mintotal power requirement:13 kWweight of the machine ca.:2500 kgdimensions of the machine ca.:2000 x 2800 x 2300 mmDocuments:inkl. Zusatzinformationen ? Schile-Elektroschrank mit CNC-Steuerung Heidenhain TNC 355 ? Starrer Winkeltisch 710 x 400mm ? Spritzschutzverkleidung / Halbkabine ? Kopf nach Skala präzise drehbar über Kurbel ? Kopf komplett wegschwenkbar für horizontal Spindel
x-travel:850 mmy-travel:280 mmz-travel:355 mmtotal power requirement:8 kWweight of the machine ca.:4 tdimensions of the machine ca.:2 x 2 x2.40 mrevolutions per minute: 28-1.400 U/mintable-size:1.200 x 370 mmsurface area:1.060 x 260 mmspindle taper:SK 50
x-travel:560 mmy-travel:500 mmz-travel:450 mmtotal power requirement:16,5 kVAweight of the machine ca.:2700 kgdimensions of the machine ca.:2,30 x 3,0 x 1,90 mcontrol:Grundig quill stroke:80 mmtool taper:SK 40 spindle speeds::40..4000 1/minfeed:2 .3600 mm/minrapid traverse:4000 mm/minDocuments:vorhanden
x-travel:1120 mmy-travel:345 mmz-travel:400 mmtotal power requirement:14,5 kWweight of the machine ca.:3,85 tdimensions of the machine ca.:3.500 x 2.920 x 2.710 mmtable-size:1600 x 400 mmspindle taper:SK 50
total power requirement:2,4 kWweight of the machine ca.:1150 kgdimensions of the machine ca.:1550 x 1615 x 1630 mmtable clamping surface LxW:315 x 710 mmmax. tool weight:200 kgT - slots distance:63 mmT - slots - width:12 mmtaper bore:Spindel SK 40 spindle turning speed range:56 - 1800 U/minfeed speeds:11,2 -355 mm/minDocuments:vorhanden
x-travel:600 mmy-travel:400 mmz-travel:380 mmtotal power requirement:6 kWweight of the machine ca.:1700 tdimensions of the machine ca.:1800 x 2130 x 1980 mmTable dimensions:400 x 800 mmT-slots:7 St.,14 x50 table load:300 kgspindle:SK40 turning speed range:63-250 U/minspeed steps work spindle:18 spindle speeds::50- 2500 n/minfeeds:10-500 mn/minDocuments:vorhanden
x-travel:500 mmy-travel:400 mmz-travel:340 mmwork table::800 x 400 mmcontrol:Numerik CNC - H 646 spindle turning speed - stepless:20 - 3000 U/mintotal power requirement:14 kWweight of the machine ca.:2400 kgdimensions of the machine ca.:2100 x 1800 x 2400 mm
x-travel:600 mmy-travel:500 mmz-travel:400 mmspindle diameter:90 mmspindle turning speed range:45 - 2000 U/mintable length:1250 mmtable width:200 mmgroove width:14 mmtable rotating:45 °total power requirement:4,2 kWweight of the machine ca.:2000 kgdimensions of the machine ca.:2000 x 1800 x 1550 mmYear:ca.1957 Documents:vorhanden
Manufacturer SORALUCE Model SP-8.000 Year of Manufacture 2011 CNC HEIDENHAIN iTNC 530i Table Table surface 8,000 x 1,300 mm Max. permissible weight on table 5,000 kg/m2 Tours Longitudinal Course (X-Axis) 6,500 mm Transverse Length (Y-Axis) 2,000 mm Vertical Course (Z Axis) 1,500 mm Fast Forward Axles 25,000 mm/min Head Automatic head 1º / 1º INCLUDED 5-sided machining INCLUDED ISO 50 Head Cone DIN 69871A Head speed 20 – 4,000 r.p.m. No. of ranges 2 Main Motor Power 32 kW Torque 910 Nm Automatic tool loader Tool Loader Positions 40 Additional equipment Chip evacuator INCLUDED Heidenhain HR-550 FS Wireless Electronic Steering Wheel 2 extra tables (1000×400 mm) INCLUDED Air/oil head lubrication INCLUDED User platform INCLUDED M&H 20.41 MULTI wireless probe Others Total installed power 51 kW Machine Weight 26,800 kg.
Manufacturer SORALUCE Model TR-35 Year 2018 CNC HEIDENHAIN TNC 640 Table Table surface 3,860 x 1,200 mm. T-slots 7 x 22 H12 Distance between T-slots 140 mm. Maximum weight on table 9,650 kg. Routes and advances Longitudinal Course (X Axis) 3,500 mm. Transverse Course (Y-Axis) 1,300 mm. Vertical Course (Z Axis) 1,600 mm. Feeds (X/Y/Z) 16,000 mm/min Fast Forward Axles 35,000 mm/min Head Type Automatic Head 2.5º/2.5º ISO 50 Head Cone DIN 69871 AD Speed range 20-4,000 rpm Head power 43 kW Head torque 900 Nm Automatic tool loader Positions in Tool Loader 40 Maximum tool diameter with adjacent free positions 250 mm Maximum tool diameter with adjacent positions occupied 125 mm Maximum tool length 400 mm Maximum tool weight 20 kg Equipment Integral fairing INCLUDED Double longitudinal chip evacuator INCLUDED Cross chip evacuator INCLUDED Internal cooling 20 ...
