Manufacturer:
(Category: 206)
used
Cabinet dimensions: Cabinet length- 300 - 2600 mm Cabinet height- 300 - 1350 mm Carcase width- 220 - 700 mm Pressing force: Horizontal- 1800 kg Vertical- 2300 kg Pressing elements: Vertical 7 pieces 150 x 50 mm Horizontal 6 pieces 150 x 50 mm Connection: 400 V 3 KW3800x1000x2400 mm2200 kgnever used/newloaded on truck
used
New longitudinal veneer splicer Brand: CASATI Type: LINEA 1250 Technical details: Arm length 1.250 mm Veneer thickness 0,4 - 4 mm Min. veneer length 350 mm Min. veneer width 45 mm Glue for pre-gluing: Urea and PVA Glue for integrated gluing: Urea Feed speed 10 - 40 m/min. Heating area length 1.250 mm Total connected load 7,4 kW Power consumtion approx. 6 kw Compressed air consumption 5 Nl/min Compressed air pressure 6 - 8 bar This machine permits the longitudinal splicing of veneer sheets by applying glue on their edge. Immediately afterwards the veneer will be passing through a heated zone in order to activate the glue reaction: the glue will be hardening thus bonding the veneer sheets. The integrated glueing device allows the joining by one only process. Its also possible to bond pre-glued veneer sheets Option for an extra charge: Cooling device for the glue po ...
used
Hot plate press (electric) Brand: ORMA Type: NPC 6/120 new machine Technical data: Heating plates: 3500x1300mm Cylinder: 6 pieces Press force: 120t Stroke/opening dimension: 450mm Connection value: 28.8kW (ELKOM plates) Options: - Intermediate plate - Anodized surface for ELKOM panels - Parallelism sensor á 1,000.00 EUR - Pressing mechanism from above (fixed lower plate) - Max. temperature till 150°C - Max. temperature till 200°C - 4-sided loading possible - Mylar protective film - Fiberglass Teflon protection - Hardware for Industry 4.0
used
Veneer press Brand: ORMA Type: NPC/DIGIT 6/90 New machine Technical datas: Press area: 2500x1300 mm Amount cylinder: 6 Lift & max. press opening: 400 mm Total pressure: 90t Electro-heater 18 kW for thermo-oil (up to 120°C) Optional: - Aluminium coating - 650 mm stroke - Parallelism control by sensor - Extra charge for down stroke design - Extra charge for temperature up to 150°C - Extra charge for temperature up to 200°C - Mylar protection foil 350,00 ? per panel - Pressure plate covered with glass fiber fabric Teflon - Hardware for Industry 4.0
used
Hot press Make: ORMA Type: NPC/DIGIT 6/95 New machine Technical datas: Press area: 3000x1300 mm Amount cylinder: 6 Lift & max. press opening: 400 mm Total pressure: 90t Electro-heater 18 kW for thermo-oil (120°C) Optional: - Aluminium coating for panels - 650 mm stroke - Parallelism control by sensor - Extra charge for down stroke design - 4 side loading - Max. temperature up to 150°C - Max. temperature up to 200°C - Mylar protection foil - Pressure plate covered with glass fier fabric Teflon - Hardware for Industry 4.0
used
New hot press, hydraulically Brand: ITALPRESSE Type XL/6 30-13 PEA Golden electric heating plate surface anodized to ensure high surface hardness and excellent corrision protection. - Electrical - heating plates: 3000 x 1300 mm - Total pressure: 120 to. - Number of hot plates: 2 pc. - Number of floors: 1 pc. - Stroke: 350 mm - Day light opening: 350 mm - All-round feeding - Number of cylinders: 6 pc. - Diameter of cylinder: 85 mm - Power consumption (hydraulic unit): 3 kW - Electric - combi - heating plates made out of two components: Aluminium - electric - heating plate Iso printing plate - Heating power 22 KW - High pressure isolation plates - Operating temperature: 70 - 90° C. - Max. Temperature: 120° C. - Supply: 400V/50 Hz - Safety accordance with CE standard Standard equipment: - Movement of the press table with rack and pinion parallel guidance at t ...
used
Capacity: 250 - 400 ton V ? Ring nominal force: 20 - 200 ton Counter ram nominal force: 10 - 100 ton Ram stroke: 30 - 200 mm V-Ring stroke: 40 mm Counter ram stroke: 40 mm Max. die size: 765 x 760 x 610 mm Number of strokes: 40 s.p.m. Approach speed: 120 mm / sec Return speed: 135 mm / sec Working speed: 5 - 50 mm / sec Die Weight total: 2400 kg
used
Capacity: 250 ton V ? Ring nominal force: 30 - 125 ton Counter ram nominal force: 30 - 125 ton Ram stroke: 67 mm Table surface area : 560 x 600 mm Slide area: 560 x 560 Number of strokes: 80 s.p.m. Weight of machine approx.: 14.000 kg
used
press capacity:950 kNcontrol:Siemens S7 Required air-pressure:6 barloading area:1200 x 600 mmPressure power:1000 kNtotal power requirement:18 kWweight of the machine ca.:6200 kgdimensions of the machine ca.:2600 x 1300 x 3100 mm
used
Inclination: 15°, an on-site visit is possible.
used
Working height: 300mm-1300mm, working length: 300mm-2500mm, working depth: 140mm-700mm, working table height: 500mm, max. pressure force: 12kN. Control defective. Documentation available.
used
An Impressafiner is available for dewatering in the timber industry. Operating pressure: 8bar, weight: approx. 15500kg. Documentation available. On-site inspection is possible. The machine is as good as new and is in its original packaging.
used
A fines press for dewatering for the wood industry is available. Screw diameter: 260mm, dewatering basket length: 520mm/100mm, speed: 29rpm, weight: approx. 830kg. Documentation available. On-site inspection is possible. The machine is as good as new and is in its original packaging.
used
An Andritz gluing press for the interlocking connection is available. Press dimensions X/Y: 200mm/3850mm, upper press temperature: 175°C, operating pressure: 0.6bar, pressing time: 20min, cooling temperature before dismantling: 50°C, total weight: approx. 900kg. The machine was rebuilt so that it only consists of 2 individual parts and can be moved with a forklift. The dismantled components of the machine (control, pump, etc.) are still present. Documentation available. On-site inspection is possible.
used
Two identically constructed heated Ital presses are available. Press length: 1700mm, press width: 1500mm, press height: 1400mm, press force: 800kN, total connection: 30kW, machine dimensions X/Y/Z: approx. 5400mm/2300mm/3200mm. Including piston from above, fittings for chair seats and heating. Documentation available. On-site inspection is possible.
used
Working dimensions X/Y: 3000mm/2000mm, cylinder stroke: 1000mm, height adjustment: 2000mm-2600mm, length adjustment: 3000mm-6000mm, pressing force: 2t, space requirement: 4100mm/1000mm/2450mm, weight: approx. 1500kg. Documentation available. On-site inspection is possible.
used
This WEMHÃNER KT-F-1E laminating press was manufactured in 1994. It features a short-cycle pressing line capable of handling panel dimensions up to 4405 mm in length and 1390 mm in width, with thicknesses ranging from 6 to 38 mm. The system includes roller conveyors, a double-sided feeding station, and a stacking station, ideal for efficient large-scale production. Contact us for more information about this machine.
used
Vertical press Ramarch Soldid-124CE Gluing length 4500mm Gluing height 1650mm Number of vertical clamps 12 (hydraulic) Number of frontal clamps 6 (pneumatic) Foot width 80mm CE Certified Dimensions: 460x90x227cmH
used
Code: 0024 Brand: ITALPRESSE Model: NUOVO/SP Quick setting semiautomatic case clamp Technical data Manual loading Max useful dimensions mm 2500 x 600 x 1250 Min useful dimensions mm 250 x 600 x 280 Motorized horizontal cross-beam with display Vertical beam setting N° 6 vertical cylinders N° 6 horizontal cylinders Cylinders stroke mm 70 Cross-beam stroke mm 920 Installed power Kw 0,55 Overall dimensions mm 3600 x 800 x 2550 h Weight kg 1400
used
Panel dimensions 1800 x 900 mm Electric heating 2 x 4 kw Working height 300 mm Dimensions 210x107x180 cm
used
Panel dimensions 2200 x 1100 mm
used
Code: 0017 Brand: ITALPRESSE Model: SCF/8-S Hydraulic press for hot/cold cycle for wood materials, composite materials, plastics and various materials Technical data: Platen size mm 3000 x 1500 N° 6 Drilled solid steel platens thickness mm 38/40 - Coated in aluminum N° 5 Daylight openings N° 4 intermediate platens Cylinder stroke mm 450 Press space mm 90 Platen movement from bottom to top Max working temperature 120° Platen heating by water or steam Total thrust ton 120 Specific pressure on 80% of the surface area kg/sq cm 3,3 N° 8 thrust pistons diameter mm 70 Hydraulic unit power Hp 4 Timer for timed opening Overall dimensions mm 4200 x 1800 x 2900 h Weight kg 13000 approx
used
Press: Max. press length : 2270 mm Max. press width : 1100 mm spec. Pressing pressure : 2 kg/cm² Press opening width : 140 mm Heating plate material : Aluminium 2 x 2.8 kw Press System : Fabric Hose with Compressed Air Required compressor : 8-10 bar 300 L suction power Fine cutting saw: Cutting length : 2600 mm Cutting height adjustment : 0-60 mm Saw blade diameter max. : 250 mm Speed : 6800 rpm Pneumatic pressure beam with hand valve : 4-10 bar Engine power : 2.2 kw Suction nozzle : 2 x 100/ 1 x 80 mm
new
New exhibition machine! List price: 32.665,- € complete in standard version with: Stable, torsion-free frame made of steel, in welded and screwed construction - Slat press beam TOP with 6 elements, lamella press bar SIDE with 5 elements - Lamella press beam with tried-and-tested tolerance compensation (Ganner system) for tightly pressed carcass connections - Counterpressure surfaces (side pressure wall, bottom) are 38 mm thick, coated, continuous support plates - Continuous pressing surface with a height of 95 mm on the vertical press beam at the bottom - Electromotive adjustment of the two press beams via precision trapezoidal lead screws (with increased pitch and concentricity accuracy) and high-performance running nuts with fat reservoir - The compression is electromotive, via 2 separate worm gear motors (2 x 0.75 kW) - The pressing force of the press ...
used
Hydraulic Frame Cutter with Perforated Trays Working length 3000 mm (2100 mm per station) Usable height 1000 mm, square 1400 mm Max thickness: 150 mm 8 double-acting cylinders, stroke 80 mm Pressure 150 kg/cm² Non-return valve for pressure maintenance 4 front pressers for flat panel holding 1.5 kW unit 2 control groups (1/station) Voltage: 380 V Connection: Three phase
new
New exhibition machine List price 43.380€ net PIONEER BASIC — the high-precision vacuum press with a gigantic usable area for vacuum form gluing and Vacuum veneering of bent workpieces. High-precision vacuum press incl.: -Diaphragm quick-change system -Gas pressure damper for flap opening -Highly elastic natural rubber membrane (up to +130 °C) -Stable phenolic resin worktop (up to +160 °C) -40 m³ high-performance vacuum pump (up to 900 mbar (9 t/m²)) -Optional, automatic shutdown when pressure is reached (with large vacuum volume) -Pressure regulation 400 to 900 mbar, analogue vacuum pressure display -Connection for external vacuum bag -Feet incl. smooth-running swivel castors -Holding device for vertical opening system Specifications: Voltage: 400 V Power: 1.3 kW Mains frequency: 50 Hz Metrics: Usable area: approx. 3050 x 1350 mm Inner frame dimensions: app ...
new
New exhibition machine! MOVE — the high-precision vacuum press with a gigantic usable area for vacuum form gluing and vacuum veneering of bent workpieces. With total flexibility, due to total mobility and revolutionary folding mechanism, to reduce the footprint to 45% when folded. High-precision vacuum press with flap opening including: · Revolutionary folding mechanism (reduction of the footprint to 45%) · 40 m³ high-performance vacuum pump (up to 900 mbar (9 t/m²)) · Highly elastic natural rubber membrane (up to +130 °C) · Diaphragm quick-change system · Stable phenolic resin worktop (up to +160 °C) · Gas pressure damper for flap opening · Vacuum Pressure Gauge · Connection for external vacuum bag · Smooth-running swivel castors Technical data and dimensions: · Usable area: approx. 3050 x 1350 mm · Total dimensions: approx. 3650 x 1700 x 1100 mm · T ...
used
pressing area: 2550mm x 1350mm; opening: 400mm; heating top plate: elektrisch; heating lower plate: not working; plate surface: ALU ; Emergency stop switch: nein; pressure: 100t; number of cylinder: 4; electricity: 17A; machine length: 3000 mm; machine width: 1300mm; weight: 4000kg;
new
working table size: 3000 mm x 1300 mm; emergency stop switch: no; operational vacuum: -0,85 bar; vacuum pump output: 25 m³/h; pump capacity: 0,75 kW; noise level: 70 Db; heating system temperature: max. 60 °C; heating system: 4,5 kW; machine length: 3100 mm; machine width: 1450 mm ; machine height: 1650 mm; weight: 450 kg; The membrane presses of VP series are optimal solution for woodworking and a furniture production from all types of wood.The vacuum presses are equipped with heating system which allows reduce the time of drying glue and increase productivity of production. The heating temperature monitored and maintained automatically.The membrane presses of VP series can be used for small capacities but also for professional using.ConstructionThe sturdy welded construction with a removable feet’s.Work table from 12mm HPL board. HeatingHeating system with s ...
new
Pressing area: 3000 mm x 1800 mm; Design: Wall mounting; Number of manual hydraulic cylinders: 3; Press pressure: 1500 kg; Cylinder stroke: 60 mm; Hold-down: 1; Machine length: Machine width: Machine height:
