AVIA FNE 40NC milling machine was built in 2001 in Poland by Fabryka Obrabiarek Precyzyjnych AVIA S.A. The machine is used for precision machining of workpieces with a maximum weight of 400 kg. The machining process is performed in three axes by means of a reliable spindle with stepless speed adjustment. The spindle, mounted on a swivel workhead, moves in the Z axis on precision vertical guides. All this is complemented by the easy-to-use HEIDENHAIN NC control system, in which even the most advanced programmes can be created in just a few steps. The AVIA FNE toolroom milling machine weighs 1900 kg. Technical data of the AVIA FNE 40NC metal milling machine - NC controller: HEIDENHAIN TNC 310 - feed in the X/Y/Z axis: 620/420/400 mm - rapid traverse in the X/Y/Z axis: 6000/4000/4000 mm/min - feed rate adjustment: stepless - maximum workpiece weight: 400 kg - horizontal work table ...
AVIA FNE 50N CNC milling machine was built in 2016 in Poland by Fabryka Obrabiarek Precyzyjnych AVIA S.A. The machine, designed for precision machining of workpieces with a maximum weight of 500 kg, is an excellent choice for any industrial plant. This is all due to its reliable spindle, which can work both vertically and horizontally, with the same specifications. The AVIA FNE 50N is controlled by an advanced HEIDENHAIN control system, which is distinguished by its intuitive operation and numerous useful functions. The FNE 50N toolroom milling machine weighs 3000 kg. Technical specifications of the AVIA FNE 50N CNC milling machine General data - feed in the X/Y/Z axis: 800/500/420 mm - feed in the X,Y,Z axis: 5-2000 mm/min - rapid traverse in the X/Y/Z axis: 10/10/7 m/min - maximum workpiece weight: 500 kg - spindle rotational speed: 50-4000 rpm - spindle rotational speed adju ...
Key data: 400 mm, 340 mm, 350 mm
Universal Milling Machine AVIA - FNF 32 Travel paths X - 400 x Y - 340 x Z - 350 mm Table size 800 x 400 mm Spindle holder ISO 40 Speed levels 18 - 63 to 3,150 rpm Feeds 18 steps 10 to 500 mm / min Rapid traverse 1,600 mm/min Three-axis digital display Mitutoyo Central lubrication device Coolant Setup Electrical values 400 V / 4 + 1.5 KW Space requirement L - 1,750 x W - 1,700 x H - 2,000 mm Weight approx. 1,500 kg Documentation available
used
Key data: 650 mm, 600 mm, 620 mm
From a current recycling we offer you a CNC machining center from the manufacturer AVIA, type VMC 650 V. Year of construction:2023 Condition: normal signs of wear Hours: Asking price: VHB Original price: 120.000 € Equipment / accessories / other information: x/y/z 650/600/620mm, Table 800x550mm 30 mm tool magazine Asset Manager: M. Vorkötter Phone: 0202-257273152 Mail: m.vorkoetterakf.de We will be happy to provide you with details upon request. Location: The sale is without warranty Subject to prior sale
Milling machine - Universal Make: AVIA Type: FND 25 Year of construction: 1984 Control type: conventional Country of origin: Poland Delivery period: right away Technical details x-way: 400 mm y-way: 360 mm z-Way: 400 mm Mounting table: 800x400 mm Tool holder: SK40 Quill Hub: 100 mm Speed: 40...2000 rpm Total power requirement: 4.5 kW Machine weight approx.: approx. 2.4 t Space requirements approx.: L:1.6xW:1.3xH:2.0 m
AVIA AVIATURN 35 CNC turning center was built in 2022 in Poland. The machine, designed for precision machining of workpieces with a maximum diameter of 350 mm, has been equipped with many state-of-the-art solutions and high-quality components that ensure excellent turning results. The workspace includes, among others, a 12-position turret and a reliable spindle driven by a belt drive with encoder. The AVIAturn 35 CNC lathe is also distinguished by its richly ribbed, single-piece cast iron bed. The bed, which is inclined at 35°, effectively dampens all vibrations and oscillations, resulting in, among others, improved workpiece surface quality and increased cutting tool life. The machine’s extensive equipment includes, among others, a hydraulically movable tailstock, a tool probe and a SIEMENS CNC control in its most powerful version with a wide range of built-in fixed cycles and 16 ...
x-travel: 620 mm y-travel: 420 mm z-travel: 400 mm Control: Heidenhain TNC 124 turning speed range - spindle: U/min transmission ratio: drive capacity - spindle motor: kW tension force: kN swivellable: manuell +/-45 ° max. tool diameter: 125 mm max. tool weight: 6 kg table surface area: 400 x 800 mm T-slots: 5x14x80 max. table load: 400 kg feed speeds: X/Y: 0 - 6.000 mm/min feed speeds: Z: 0 - 4.000 mm/min rapid traverse: X/Y: 6 m/min rapid traverse: Z: 4 m/min total power requirement: 11 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,9 x 3,5 x 2,0 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
total power requirement:2,4 kW weight of the machine ca.:1150 kg dimensions of the machine ca.:1550 x 1615 x 1630 mm table clamping surface LxW:315 x 710 mm max. tool weight:200 kg T - slots distance:63 mm T - slots - width:12 mm taper bore:Spindel SK 40 spindle turning speed range:56 - 1800 U/min feed speeds:11,2 -355 mm/min Documents:vorhanden
x-travel:600 mm y-travel:400 mm z-travel:380 mm total power requirement:6 kW weight of the machine ca.:1700 t dimensions of the machine ca.:1800 x 2130 x 1980 mm Table dimensions:400 x 800 mm T-slots:7 St.,14 x50 table load:300 kg spindle:SK40 turning speed range:63-250 U/min speed steps work spindle:18 spindle speeds::50- 2500 n/min feeds:10-500 mn/min Documents:vorhanden
Face plate, face plate chuck, four-jaw chuck -Chuck size: Ø 195 mm -with: T slot 10 mm -Thread intake pitch: 3 mm -Weight: 5.7 kg
x-travel: 620 mm y-travel: 420 mm z-travel: 400 mm digital readout: 3 Achsen HEIDENHAIN spindle taper ISO: 40 DIN 69871A spindle turning speed range: 50 - 4000 U/min table-size: 800 x 400 mm table load: 400 kg feeds -stepless-: max. 2000 mm/min rapid traverse: 5 / 4 m/min power capacity - milling spindle: (S1) 10,5 kW quill stroke: 80 mm coolant: voltage: 400 V total power requirement: 17,5 kW weight of the machine ca.: 1,9 t dimensions of the machine ca.: 2,00 x 2,76 x 2,05 m - Serial-No.: 90395 - Digital display HEIDENHAIN ND780 - electr. handwheel - mechanical handwheels - stepless speed control - stepless feed drives - horizontal milling spindle - coolant device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 620 mm y-travel: 420 mm z-travel: 400 mm control: TNC 320 HEIDENHAIN spindle taper ISO: 40 spindle turning speed range: 50 - 4.000 U/min table-size: 800 x 400 mm table load: 400 kg feeds -stepless-: 0 - 8000 mm/min rapid traverse: 8,0 m/min power capacity: 6,0 kW quill stroke: 80 mm coolant: voltage: 400 V total power requirement: 17,0 kW weight of the machine ca.: 2,1 t dimensions of the machine ca.: 1,90 x 2,70 x 2,05 m - Fabr.No.: 90288 - Control: TNC --- - electrical hand wheel - Horizontal milling spindle - Coolant equipment The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Weight: 1,5 t serial number: 4193 : ja vice: ja x-travel: 500 mm length: 1200 mm width: 1300 mm height: 1789 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 620 mm y-travel: 420 mm z-travel: 400 mm Control: Heidenhain TNC 124 turning speed range - spindle: 50 - 4.000 U/min transmission ratio: 2 drive capacity - spindle motor: 6 kW tension force: 10 kN swivellable: manuell +/-45 ° max. tool diameter: 125 mm max. tool weight: 6 kg table surface area: 400 x 800 mm T-slots: 5x14x80 max. table load: 400 kg feed speeds: X/Y: 0 - 6.000 mm/min feed speeds: Z: 0 - 4.000 mm/min rapid traverse: X/Y: 6 m/min rapid traverse: Z: 4 m/min total power requirement: 11 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 2,9 x 3,5 x 2,0 m Includes: Heidenhain TNC124 point-to-point control Electrical documentation available Coolant system 2 work lights Machine vise Various tool holders Various SK40 tools Enclosure with 2 sliding doors available, pictures to follow The data for this ad was created with ModulMWS - the software solution of ...
x-travel: 620 mm y-travel: 420 mm z-travel: 400 mm Control: Heidenhain TNC 410M table surface area: 800 x 400 mm tool taper: ISO 40 spindle turning speed - stepless: 50 - 4000 U/min main drive motor: 5,5 kW total power requirement: kW weight of the machine ca.: 2,1 t dimensions of the machine ca.: m CNC control HEIDENHAIN TNC 410M Coolant equipment Machine lamp The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
