strapping machines used for sale

Automatic pallet packing press MOSCA KPK-121 Year of Make: 2002 With integrated slewing ring roller conveyor (diameter: 1,800 mm) For Euro and industrial pallets, pallet runners in the direction of travel Pallet dimensions: Length: min. 1,000 mm / max. 1,600 mm Width: min. 800 mm / max. 1,000 mm Height: 145 mm Pack size incl. pallet: Length: min. 800 mm / max. 1,600 mm Width: min. 800 mm / max. 1,400 mm Height: min. 500 mm / max. 2,000 mm The following pallet dimensions are possible for cross strapping: Length: min. 800 mm / max. 1,200 mm Width: min. 1,200 mm / max. 1,200 mm Dimensions of the packing press: Max. passage height: 2,200 mm Max. passage width: 1,400 mm Pressure plate length: 1,600 mm Press force: up to max. 50,000 N, selectable via potentiometer Pressing speed: 75 mm/s Pallet Packing Press Performance: For 2-fold strapping: max. 120 pallets/ho ...

Automatic strapping machine horizontal strapping type H40U-C Year of Make: 2017 Manufacturer: Strapex Strapping: Cycle time: approx. 10 seconds per strapping Vertical Speed: Approx. 200 mm/s Automatic stop of vertical movement in case of obstacles Band tension: 200–2200 N, adjustable via potentiometer, electronically controlled The floating strapping head ensures even strap tension around the package Indexing head: Horizontal stroke: Max. 320 mm Speed: approx. 100 mm/s Closure technology: Heat welding closure system for PP and PET, easy adjustment Strapping heights: 250–2100 mm Control panel: Human-Machine Interface (HMI): Main switch and emergency stop button Buttons for various start functions Machine mode and program selector switch Potentiometer for selecting strip tension Indicator lights for machine status Numerical display for machine s ...

Specifications: SIGNODE Pallet strapping machine with press type MODULEX 3 •Turnstile • Strapping without/with pressing pressure (for corrugated board industry) • With MD strapping head 9 -13 mm 2000 Newton  • Belt guide system with 4 belt channels (3 bayonets), of which 1 movable strapping head • AutoFeed belt circulation system • Quick-change belt dispenser • Strapping possible without bayonets (strapping is done by the fixed strap guides) Electrical connection data: 3-pole circuit breaker 25A Control: Siemens PLC S7 controller Connection voltage: 415V, 3Ph, N, PE, 50 Hz Power consumption: 7 kW Control voltage: 24 V, DC Transport weight: approx. 7,000 Belt guide systems: Rated operating current: 20 A Number of guided tours: 4 Number of bayonets: 4 Belt spacing: 425 / 610 / 795 mm Parcel dimensions Width: max. 2,500 mm (free flo ...

Sander Vario Master 9480 strapping machine Manufacturer: Sander  Type: Vario Master  Model: 9480  Type: Vertical Strapping Machine  Operating voltage: 400 V Power: 2 kW Control voltage: 24 V

Cyklop XZE-311 Strapping Press Year of construction: 2003 Passage width: max. 2200 mm Passage height: max. 2200 mm Belt guide distance: 625 / 440 Roll pitch: 60 mm Strapping speed: 2.9 m/s Strapping force of the strapping unit: adjustable up to 2000 N Press force: adjustable from 5 to 48 kN Aggregate Type: CFH 1

MOSCA Pallet Packing Press Automatic Pallet Packing Press, Model KPK-121-18 Year of manufacture: 1999 The control system is S7. The strapping machine is equipped with 2 strapping heads, the second strapping head can be moved laterally. The press has an upstream, walk-in centering roller conveyor with turnstile. There is another turnstile under the press, which can be used to rotate the pallet before strapping. Occupancy dimensions including pallet: Length: 1,200 mm Width: 1,200 mm Height min. 500 mm max. 1600 mm Specifications: Infinitely adjustable belt tension: 200 – 2,000 N Belt guide speed: 4.6 m/s Closure Type: Friction Weld Closure Dimensions of the control panel: Width = 1,200 m, depth = 650 mm, height = 850 mm Dimensions of the packaging press: Max. vertical clearance: 1,600 mm Max. throughput width: 1,500 mm Length of the printing plate: 1,600 mm Pr ...

width of the strips: 5 - 15,5 mmtension force: 70 - 500 NCyklop strapping machine from 2007- Strap width: 5-15.5 mm- Output: 10-20 straps/min- Connection voltage: 230 VThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

large-roll magazine Busch GRS; 30mm belt width; suitable for Busch TB series. Big roll magazine Busch GRS; band width 30mm; used for Busch TB machines.

High performance ultrasonic banderoling machine, arch size 700 X 750 mm, 30 mm band wideness. The US-2000 AST-MDM enables high perfomance. With the dynamic high-speed band feeding and the withdrawal by a brushless motor, the machine processes up to 30 bandings/min. Thanks to the packet height detection, the product memory and the band cen- tering, the banding happens very gentle and on the exact position. Postal packages can thus be banded very tight and without dama- ging the edges. The AST aggregate operates wear-free. Checked and serviced.

High performance ultrasonic banderoling machine, arch size 700 X 750 mm, 30 mm band wideness. The US-2000 AST-MDM enables high perfomance. With the dynamic high-speed band feeding and the withdrawal by a brushless motor, the machine processes up to 30 bandings/min. Thanks to the packet height detection, the product memory and the band cen- tering, the banding happens very gentle and on the exact position. Postal packages can thus be banded very tight and without dama- ging the edges. The AST aggregate operates wear-free. Checked and serviced.

High performance ultrasonic banderoling machine, arch size 900 X 750 mm, 30 mm band wideness. The US-2000 AST-MDM enables high perfomance. With the dynamic high-speed band feeding and the withdrawal by a brushless motor, the machine processes up to 30 bandings/min. Thanks to the packet height detection, the product memory and the band cen- tering, the banding happens very gentle and on the exact position. Postal packages can thus be banded very tight and without dama- ging the edges. The AST aggregate operates wear-free. Checked and serviced.

A Cyklop continuous pallet strapping machine is available. Throughput width: 2700mm, throughput height: 2900mm, strapping speed: approx. 100 pallets/h, min. pallet dimensions X/Y/Z: 600mm/600mm/500mm, max. pallet dimensions X/Y/Z: 2000mm/2450mm/2000mm, machine dimensions X/Y/Z: approx. 2000mm/7200mm/4300mm, weight: approx. 4000kg. Including additional strapping unit, sealer and various motors. Documentation available. On-site inspection is possible.

Year of construction 2021 Strapping machine Photocell Foot switch Mobile substructure max. 25 cycles / min. (idle) Working width / height approx. 70 x 75 cm Delivery date: immediately Price on request. We supply and install worldwide.

Label shrink tunnel for shrinking labels on bottles, cans or jars. Version without conveyor belt and with removable frame. The chamber can be installed on existing conveyor belts, allowing the shrink tunnel to be optimally integrated into your packaging line. Powerful air blowers ensure a smoothly shrinking of the labels without corrugations. - Specifications: Max. product size: ? 140xH350mm | tunnel size: L1600xW150xH400mm | max. output: 200 containers/minute | power: 380V, 14kW | machine dimensions: L1600xW1005xH2100mm | weight: 350kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All ma ...

LABELshrink tunnel. Fully automatic version with circle conveyor for smoothly shrinked full labels on bottles/cans/glasses without any corrugation. Air blow controllable by sections. - Specifications: max. product size: ? 200xH300mm | tunnel size: L3000xW250xH350mm | machine dimensions: L5600xW680xH1770mm | output: up to 200 bottles/min | power: 380V, 32kW.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

Shrink tunnel for shrinking labels onto bottles, jars, containers. Evenly shrinking of the labels without wrinkling due to the steam process. ? Specifications tunnel: max. product size: ? 100xH220mm | max. Output: 166 container/minute | compressed air: 1bar | power: 220V, 900W | machine dimensions: L2450?W500?H1600mm | weight: 120kg. ? Specifications steam generator: capacity and steam output: 27l, max. 34,4kg/h | steam temperature: 170?C | max. 24kW | compressed air: 7bar | power: 380V | dimensions: 660x420x1230mm | weight: 120kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines ...

Label shrink tunnel for shrinking labels on bottles, cans or jars. Version without conveyor belt and with removable frame. The chamber can be installed on existing conveyor belts, allowing the shrink tunnel to be optimally integrated into your packaging line. Powerful air blowers ensure a smoothly shrinking of the labels without corrugations. - Specifications: Max. product size: ? 110xH250mm | tunnel size: L1500xW120xH300mm | max. output: 200 containers/minute | power: 380V, 14kW | machine dimensions: L1500xW1005xH2100mm | weight: 300kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All ma ...

Label shrink tunnel for shrinking labels on bottles, cans or jars. Basic version with conveyor belt. Powerful air blowers ensure a smoothly shrinking of the labels without corrugations. - Specifications: Max. product size: ? 140xH350mm | tunnel size: L1600xW150xH400mm | max. output: 200 containers/minute | power: 380V, 14kW | machine dimensions: L1900xW600xH1665mm | weight: 300kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

LABELshrink tunnel. Basic version with conveyor for smoothly shrinked labels on caps only. For bottles/cans/glasses without any corrugation. Two blowing motors for low and turbo air blowing. - Specificationen: max. product size: ? 120xH400mm | tunnel size: L1000xW150xH400mm | machine dimensions: L1530xW400xH1300mm | output: up to 200 bottles/min | power: 380V, 9.0kW.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

LABELshrink tunnel. Basic version with conveyor for smoothly shrinked full labels on bottles/cans/glasses without any corrugation. Air blow controllable by sections. - Specificationen: max. product size: ? 100xH280mm | tunnel size: L1500xW120xH300mm | machine dimensions: L1800xW600xH1550mm | output: up to 200 bottles/min | power: 380V, 9kW.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

Label shrink tunnel for shrinking labels on bottles, cans or jars. Basic version with conveyor belt. Powerful air blowers ensure a smoothly shrinking of the labels without corrugations. - Specifications: Max. product size: ? 110xH250mm | tunnel size: L1500xW120xH300mm | max. output: 200 containers/minute | power: 380V, 14kW | machine dimensions: L1800xW600xH1665mm | weight: 250kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks for customized machines. Deviations from the sample photo are possible. - All machines are available with full warranty.

Carton Box Filling and Sealing Machine for e.g. filling of tubes in carton boxes, 1 item each. The fully automatic packaging process includes feeding of the products, erecting of the folding boxes, insertion of the product, closing and out feeding of the box.- Specifications: Dimensions of the folding box: L(55-220)xW(20-120)xH(12-70)mm | requirement carton/paper thickness of the box (min-max): 250-350g/m? | max. cycle of the machine in neutral: 80 cycles/min | power supply: 220V, 3P | compressed air and compressed air consumption: 5-7bar, 0,2m? | dimensions of the machine LxWxH: 3100x1100x1550mm | weight: 1200kg.Please note that our new prices are often below the usual used prices. Please feel free to inquire and tell us your packaging task. - Usually 30-50 different new machines are available immediately from stock. In addition, we have very short delivery times from approx. 3 weeks fo ...

Strapex SMG65 strapping machine Serial: 651451 2013, high performance strapping machine designed for large and heavy packages, up to 65 packages per minute, mobile, 1Ph

Professional strapping machine with internal frame dimensions of approx. width 850 x height 800 mm from a renowned manufacturer, designed for high speed and trouble-free operation. Equipped with an ergonomic and uncomplicated bobbin changing and threading system. -Band width 12 mm. -Equipped with ergonomic casters on the table surface. -Strapping release alternatively possible manually or automatically. -Up to approx. 25 straps per minute. -Strap tension adjustable. -Closure type: Welding in the heating wedge method. -Electronic temperature control. -The machine can be moved via castors. The machine can be demonstrated under power.

There are four Strapping Machines M.J. Maillis available, 2x TH-E-2, 2x TH/E, year of construction: 1x 2008, 3x 2017.

Connected load: 3kW, weight: 415kg, with backstop, automatic belt feed, belt detection and belt sling ejection, the conveyor belt is defective.

Frame dimensions: 550x400mm, package dimensions: 180x180-500mm, package height: 10-380mm, max. package weight: 25kg, height: 885-930mm, weight: 350kg.

A semi-automatic strapping machine with a transport box is available. Strap width: 9mm-15mm, max. strap tension: 70kg, power: 30rpm, working height: 820mm-920mm (adjustable). Dimensions X/Y/Z: 1200mm/600mm/1540mm, weight: 110kg. Including transport box. On-site inspection is possible.

Packaging material: stretch film, max. pallet height/weight: 2100mm/1500kg, turntable diameter: 1500mm, turntable speed: 10rpm, weight: approx. 500kg, control: conventional.

Strapping capacity: 28/h, strap width: 12mm, strap tension: 100N-3500N, frame dimensions X/Y: 800mm/800mm, working height: 810mm, machine dimensions X/Y/Z: 1430mm/620mm/1540mm. On-site inspection is possible.
