Used machine DMU 40eVo linear
Machine Type: CNC 5-Axis Milling Center
Model: DMU 40eVo linear
Manufacturer: DMGMORI
Control:CELOS Siemens 840D sl Operate
Year of Make: 2022
#001431
Location: Germany
Technical data
Travel range X-axis approx. 400 mm
Y-axis approx. 400 mm
Z-axis approx. 375 mm
C-axis 360°
B-axis -5/+110 °
Workpiece diameter approx. 450 mm
Workpiece weight max. approx. 250 kg
Speed max. approx. 20,000 rpm
Spindle motor approx. 35/25 KW
Number of tool positions approx. 120
Rapid traverse approx. 80 m/min
Pick-up taper approx. HSK63
Additional axles approx. 2 4th/5th
Compressed air bar,L/min approx. 5, 300 bar,L/min
Power consumption approx. 32 kVA
Footprint L x W x H approx. 2.05x2.85x2.53 m
(without pallet pool)
Machine weight approx. 7,500 kg
Facilities
Dynamic Package for DMU 40 eVo linear - Motor Spindle speedMASTER®
HSK-A63 RPM 20-20,000 min-1 -NCSwenkrottisch
- Tool magazine 120 places -Scraper chip conveyor -Internal coolant
supply (IKZ)
20-80bar - Coolant temperature control for lKZ system - Double
changeover filter - Programmable coolant nozzles -
Advanced chip flushing -Blowing air through the spindle center
-Rotating viewing panel -Oil and
Emulsion Mist Separator Mechanical - Probe Infrared PP60 - Laser Tool
Measurement BLUM NT -
Preparation 3D quickSET - Signal light, four-colour - Sensor package
i4.0: - DMG MORI automation interface M65 -
Free M-Functions (M180-M189) - Tropical Package Dynamic Variant -
Preparation for Robot-Side Control
(Changes and errors in the technical data, specifications and prices
as well as prior sale reserved!)
This offer is subject to change and non-binding. Changes, errors and
prior sale expressly reserved.
