used CNC Portal Milling Machines for sale

Key data: 2400 mm, 1500 mm, 810 mm

CNC control HEIDENHAIN iTNC530, travels: X-axis 2400 mm, Y-axis 1500 mm, Z-axis 810 mm, max. 12000 rpm., with retrofitted 4th axis, table with vacuum plate and extraction system Fabr. BORNEMANN, Type 960

x-travel: 5000 mmy-travel: 2500 mmz-travel: 1500 mmControl: Typ Fidia C20/6H-SB total power requirement: 90 kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

First commissioned: 2006 Control: Fidia C20 incl. handwheel X-axis: approx. 7,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,751 mm A-axis: + 125° / - 95° C-axis: ± 275° Clamping table Clamping surface: approx. 6,000 x 2,000 x 400 mm Head Spindle power: 20 kW Spindle speed: max. 20,000 min-1 Tool holder: HSK 63A Tool tensioning: hydraulic Drives Linear axes Feed speed X-, Y-, Z-axis: 65 m/min Axle acceleration X-, Y-, Z-axis: 5 m/s2 Connection data Connected load: approx. 150 KW Dimensions, weights Space required Machine with protective cabin Dimensions: approx. 12,200 x 6,300 x 5,800 mm Total weight: approx. 105,000 kg Auxiliary - 20-fold tool changer - Engine room surveillance (camera) Options at extra cost: - Renishaw RMP60 probe - Fidia HMS System Condition of the machine Fully functional, very good condition

x-travel: 6000 mmy-travel: 2500 mmz-travel: 950 mmdistance between columns: 2400 mmHeight of spindle: 1200 mmbed width: 2115 mmbed length: 6000 mmtable load: 4 t/m2rapid travel x/y/z: 10000 mm/minfeeds infinitely variable: 1-3000 mm/minRated capacity of drive motor: 20 kWCross cut of slide: 320x340 mmPositioning increment: 2.5 °Turning speeds stepless: 10-3200 U/minTool tapers: ISO 50 tool piece magazine with: 20 Control: NUM 1060 total power requirement: 60 kVAdimensions of the machine ca.: - mweight of the machine ca.: - tequipped with:- CNC - Control NUM 1060- ATC with 20 tools(ISO 50)- 2-Axis Milling Head 2,5° x 2,5°- Covering- Cooling through Spindle 15bar- Chip ConveyorThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3.073 mmy-travel: 1.549 mmz-travel: 279 mmControl: Haas CNC turning speed range - main spindle: max. 15.000 min/-1power capacity - main spindel: 11,2 kWmax. Torque: 65 Nmtool taper: SK 40 work table:: table surface area: 3.099 x 1.346 mmmax. table load: 2.722 kgdistance between columns: 1.575 mmTool-Presetter:: number of toolpositions: 20 pos.max. tool diameter: 89 mmmax. tool weight: 5,4 kgfeeds:: rapid traverse ( X / Y / Z ): 20,3 / 53,3 / 27,9 m/minfeed: 20,3 m/minFeed force ( X / Y / Z ): 11,2 / 4,5 / 9,1 kNtotal power requirement: - kWweight of the machine ca.: 8,8 tdimensions of the machine ca.: 6,0 x 4,2 x 2,7 mDocuments: CNC Gantry Milling MachineHAAS - GR 510The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3000 mmy-travel: 4000 mmz-travel: 1500 mmControl: Heidenhain TNC 430 M total power requirement: 120 kVAweight of the machine ca.: tdimensions of the machine ca.: m3/5 axes CNC portal milling machine with integrated C-axisand changeable milling heads.The machine had a purchase price of € 1.4 million in 2002.An inspection in the sellers plant under power is possible afterprevious appointment.Condition:The machine was overhauled in 2018, costs of over € 100.000,-.- Drives of the X-axis renewed- New hydraulic power unit- Complete electrical wiring renewed- Spindle cooling unit new- 2 pieces longitudinal conveyors new- Coolant pump new- Cover complete X-axis new- Bellows Y-axis new- Exchange measuring ruler X-axis- Fork head spindle bearing newBelleville spring assembly newDrive motor A-axis newSpindle cone ground- Overhaul milling gear (2020)Working rangeTravelsX-axis 3000 mm ...

x-travel: 6000 mmy-travel: 4000 mmz-travel: 1250 mmw-axis: 1500 mmControl: Fidia max. workpiece weight: 60000 kgControl unit for tool magazine/tool changer: Siemens turning speeds: 6,3 - 4000 U/minsurface area: 2500 x 4500 mm: 48 St.tool taper: SK50 daylight between the side columns: 3700 mmrapid traverse: 30000 m/mintotal power requirement: 63 kWweight of the machine ca.: 150 trequired space: 16,8 x 10,3 x 7,9 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 7187 Type: Varimat VD 2000 Producer: KOLB Created: 1995 Parameters: Operating system: SIEMENS Sinumerik Axis X: 6000 mm Axis Y: 2400 mm Z axis: 1100 mm Weight: 83000 kg

x-travel: 6200 mmy-travel: 1500 mmz-travel: 508 mmControl: Mazatrol type: M 32 workpiece height: 708 mmTool changer: 60 spindle taper ISO: 50 table surface area: 6200x750 mmtotal power requirement: kWweight of the machine ca.: tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3200 mmy-travel: 1400 mmz-travel: 508 mmtable surface area: 3000x1250 mmcolumn daylight: 1500 mmturning speeds: 35-5000 U/minspindle taper ISO: 50 control: Mazatron M PlusTable load: 5000 kgTool changer: 30 chip conveyor: The tech. Data are manufacturer or operator information and therefore for usnot binding. We reserve the right to prior sale, it applyonly our businessand conditions of sale.About Usmore than 400 own machines in stockover 12000 m² storage area, crane capacity 70 tmore than 10000 articles accessories for your workshopYou want to sell machines, production lines or your company,Then contact us.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 5000 mmy-travel: 3600 mmz-travel: 710 mmw-axis: 1250 mmMain spindle:: turning speed range - main spindle: 12000 min/-1power capacity - main spindel: 45 kWtool taper: HSK work table:: table surface area: 2100 x 4000 mmmax. workpiece weight: 43 tcolumn daylight: 2750 mmdistance table - lower edge spindle: 1880 mmTool-Presetter:: number of toolpositions: 60 pos.tool taper: HSK feeds:: 8000 mm/minrapid traverse ( X / Y / Z ): 30/30/30 m/minrapid traverse: W: 3 m/mincontrol: Mazatrol SmoothX ram head dimension: 450 x 450 mmb-axis: -100 / +100 °c-axis: +/- 180 °total power requirement: 105 kVAweight of the machine ca.: 65 tdimensions of the machine ca.: 7,6 x 12,6 x 6,65 mDouble-column, 5-Axis simultaneous Machining Center equipped with:- CNC-Control Mazatrol SmoothX- simultaneous 5 Axis Control Function- Relocation Detectro- Chip Conveyor- Hi-Pressure Coolant / Coolant through  ...

X-axis: 13,000 mm Y-axis: 4,500 mm Z-axis: 1,000 mm Distance between stand: 6,500 mm C-axis: 190º A-axis: 110º Rapid speed XYZ: 15,000 mm/min. Rapid response AC: 10 tpm CNC control: Siemens 840D Spindle mounting: HSK A63 Spindle speeds: 30,000 rpm. Spindle power: 20 kW Tool changer: 20 positions Torrestool tables: 16 pieces X-axis: 11,500 mm Y-axis: 3,500 mm Z-axis: 750 mm Country of origin Spain Machine dimensions LxWxH: 19,000 x 11,000 x 6770 mm Machine weight: 70,000 kg

x-travel: 31000 mmy-travel: 4310 mmz-travel: 1500 mmcolumn daylight: 4000 mmMain spindle:: turning speed range - main spindle: 16000 U/minpower capacity - main spindel: 34 / 44 kWtool taper: HSK A63 c-axis: +/- 360 °A-Axis: +/- 110 °Distance table surface - crossbeam bottom: 2570 mmwork table:: table surface area: 30000 x 3000 mmmax. workpiece weight: 16 tTool-Presetter:: number of toolpositions: 120 pos.tool taper: HSK A63 rapid traverse ( X / Y / Z ): 20 / 20 / 16 m/mincontrol: Heidenhain iTNC 530 total power requirement: - kVAweight of the machine ca.: 100 tdimensions of the machine ca.: 32 x 7,3 x 6,5 munused 5 Axis Gantry Machining Center with moving Portal.The direct driving method using a torque motor eliminates precision problemscaused by wear over time and by installing encoders on the torque motor side ofthe A and C axes, the actual turning angle can be accurately controll ...

Table Surface 3.000 X 1.250 mm Longitudinal Traverse (X Axis) 2.500 mm Cross Traverse (Y Axis) 2.500 mm Vertical Traverse (Z Axis) 1.000 mm Distance Between Columns 2.000 mm. Rapid Traverse (X Axis ) 15 m/min. Rapid Traverse (Y ,Z Axis) 12 m/min. Max. Working Feed 5 m/min. Head Type ORTOGONAL UDG-40 Orthogonal Milling Head indexing every C Axis Indexing 2.5º B Axis Indexing 2.5º Taper ISO-50 / DIN 69871 A Spindle Speed 50- 2.000 r.p.m. Range Speeds 2 Ranges ATC INCLUDED Nº Positions ATC 10 TOOLS Coolant Through Tools 15 BAR INCLUDED Spindle Motor 30 KW. Total Power Requirement 44 kW Year 1997 CNC Heidenhain TNC 426 Carrying Load Table 10.000 Kg. Machine Weight 24.000 Kg. Portable Handwheel HEIDENHAIN HR 410

Manufacturer NICOLAS CORREA Model FP 40/40 Year 1997 CNC HEIDENHAIN TNC 426M Table Surface 4.000 x 1.250 mm T slots 8 x 22 mm. Distance between T slots 150 mm. Max weight allowed on table 10.000 kg. Longitudinal Traverse (X Axis) 3.500 mm Cross Traverse (Y Axis) 2.500 mm Vertical Traverse (Z axis) 1.000 mm Distance Between Columns 2.300 mm Rapid Feed (X Axis) 15.000 mm/min Rapid Feed (Y,Z Axis) 12.000 mm/min Max. Working Feed 5.000 mm/min Taper ISO-50 Direct Output Head Speed 5.000 r.p.m. Speed Head 45º 3.000 r.p.m. Main Engine Power 22 kW Speed Ranges 2 Manual Support Hidden at the Right Side for Head 45º INCLUDED Chip conveyor INCLUDED Portable Handwheel INCLUDED Total power 37 kW Machine Weight 23.700 kg

Manufacturer NICOLÁS CORREA Model FP50/80 New in Year 2010 CNC HEIDENHAIN iTNC-530 5 ejes Table Surface 8.500 x 2.500 mm Max weight allowed on table 35.000 kg. Travels (X/Y/Z) 8.000/3.800/1.250 mm Distance between columns 3.100 mm Max distance table to under bridge 2.100 mm Min/max distance table to spindle 500-1.750 mm Rapid feed (X Axis) 10.000 mm/min Rapid feed (Y,Z Axis) 12.000 mm/min Max. Working Feed 7.000 mm/min Automatic head C5 E INCLUDED Number of continuous axis 2 B-Axis head swivel ± 190º C Axis head rotation ± 360º Spindle taper ISO 50 Spindle speed 4.000 r.p.m. Spindle motor 37 Kw Spindle Torque 718 Nm Speed Range 2 Automatic tool changer INCLUDED ATC positions 30 Portable Handwheel INCLUDED Thermal growth compensation system INCLUDED Machine dimensions 19.370 x 5.850 x 5.970 mm. Machine Weight 93.000 g.

Manufacturer NICOLAS CORREA Model RAPID50 New in Year 2.005 CNC FIDIA C20 Table Table Surface 5.000 x 2.000 mm Number of T slots 11 T slot width 22 mm Max weight allowed on table 30.000 kg. Travels and feeds Longitudinal traverse (X Axis) 5.000 mm Cross travel (Y Axis 3.100 mm Vertical travel (Z Axis) 1.200 mm Distance between columns 2.800 mm. Rapid feed (X Axis) 20.000 mm/min Rapid feed (Y, Z Axis) 30.000 mm/min Head Automatic head UAD INCLUDED Head UAD II positioning 0.1º / 0. 1º Main spindle speed 6.000 rpm Speed ranges 2 Main spindle power 32 kW Taper ISO 50 Tool clamping Hidraúlico Head 2 – Vertical INCLUDED Accessories Automatic tools changer INCLUDED ATC positions 30 Automatic head changer INCLUDED 2 longitudinal chip conveyors INCLUDED 1 cross chip conveyor INCLUDED Internal coolant 20 INCLUDED Portable handwheel INCLUDED Laser tool pres ...

Key data: 5000 mm, 1600 mm

Multifunctional panel and panel machining center These are two CNC machines integrated into a compact multifunctional machine – designed for the production of rear-ventilated facades – for prefabrication in drywall and acoustic construction, for aluminium and wood panel processing. Sawing + drilling + milling (also V - groove milling with a separate milling unit) + brushing + grinding + polishing, all with a single multifunctional machine. CNC – controlled, very compact, multifunctional inclined table machining centre with a small footprint – for the processing of plates and panels made of all (easily) machinable materials such as aluminium plates and aluminium sheets, non-ferrous metal plates and non-ferrous metal sheets, composite materials – such as Alucobond – Reynobond® – Dibond® and others, fibre cement panels – such as Eternit®, synthetic resin panels –  ...

5 axis CNC – portal profile machining center for all materials - aluminum - steel - stainless steel - plastics - non-ferrous metals. Drilling + tapping, flow drilling, milling + thread milling, as well as sawing at free angles – for example, steel profile saws up to 6 mm wall thickness Largest saw blade diameter 500 mm Largest machining length 7,000 mm Largest workpiece cross-section 650 x H 300 mm Working range in five-axis operation 6,400 mm x 480 x H 300 mm Spindle drive power 17 kW at 100% ED Milling spindle speeds up to 24,000 rpm Moving tool magazine for 12 tools Tool holder HSK 63 Rapid speeds up to 100 m/min / acceleration 2.5 G Space requirement (including control cabinet and control panel) approx. 9 m x 2.5 m x H 2.6 m Weight approx. 5,000 kg. equipment: - OSAI® CNC control - YASKAWA® feed drives and feed controllers - HITECO® milling spindle wit ...

x-travel: 13500 mmy-travel: 6500 mmz-travel: 1500 mmw-axis: 6000 mmtable-size: 18000 x 4500 mmdistance between columns: 5200 mmworkpiece weight: 300 tspindle turning speed range: 4 - 600 U/minspindle taper ISO: ISO 60 spindle motor: 62,5 (x2) kWfeeds x/y/z -stepless: 1- 10000 / 3000 mm/minControl: Siemens 840D PL ram diameter: 700 x 700 mmtotal power requirement: - KVAweight of the machine ca.: - tdimensions of the machine ca.: - mModernization in 11/2014- CNC control Siemens 840 D pl- Coolant system- 5 headsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Warehouse number: 3686 PROCESSING Manufacturer: Takumi , Type: B8 Machine NO.: P0127, Year of construction: 2002 Specifications: Table size 1320 x 800 mm Longitudinal movement (X) 1200 mm Transverse movement (Y) 800 mm Vertical movement (Z) 500 mm Spindle speeds 20,000 rpm Spindle motor 15 Kw Tool changer 20 places Tool holder HSK-60A Rapid traverse XYZ 30 m/min Control Siemens 840D Fabr. Controlled in axes 3 Portal Type Accessories: Cooling water system. Length: 3550 mm, Høhe: 2770 mm, Width: 2260 mm, Weight: 6.850 kg

x-travel: 3.000 mmy-travel: 1.600 mmz-travel: 1.200 mmcontrol: HEIDENHAIN iTNC530 HSCI B-axis (swivelling head): +/- 100 °C-axis (milling head rotation axis): +/- 240 °feed and rapid traverse: : Rapid traverse B- and C-Axis: 50 rpmrapid feed Y,X,Z: 40.000 m/minAccelerations (X, Y and Z): 4 m/s²Machine table:: : Clamping surface: 3.500 x 1.750 mmT-slots: 27 x 22 mm H12 T-slot - distance: 125 mmmax. workpiece load: 7.000 kg/m2Max. distance table to spindle nose: 1.356 mm2-Axis Fork Milling Head T21C: turning speed range:: 10- 24.000 min-1Drive power (S1/S6):: 42/50 KWTorque (S1/S6):: 67/84 NmTool bore: HSK-A 63 tool magazin:: : number of tools: 50 tool holder: DIN 69873 HSK A63 Max. Ø tool: 115 mmmax. tool-Ø adjacent slots free : 125 mmmax. tool length: 300 mmmax. tool weight: 12 kgcoolant equipment: : tank capacity: 1.400 lconnected load: voltage: 3x 40 V 50 Hz power requirement:  ...

x-travel: 22000 mmy-travel: 7500 mmz-travel: 1750 mmw-axis: 4400 mmdistance between columns: mmtable load: 500 tmilling slide: 105 kWspindle turning speed range: 2000 U/minmax. torque on the spindle: 13 kNmtool taper: feed in x - axis: 10000 mm/minfeed in y - axis: 10000 mm/minfeed range Z-direction: 10000 mm/mintable-size: 22000 x ? mmcontrol: Siemens 840C ram head dimension: 600 x 600 mmworkpiece height max.: 5300 mmtotal power requirement: - kVAweight of the machine ca.: - tdimensions of the machine ca.: - mPortal milling machine equipped with:- CNC control Siemens 840C- tool magazine- Head changing station with X-stations- Coolant system with paper belt filterThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 12200 mmy-travel: 4400 mmz-travel: 1000 mmw-axis: 2320 mmdistance between columns: 3700 mmtable load: 200 tmilling slide: 120 kWspindle turning speed range: 6 - 750 U/minmax. torque on the spindle: kNmtool taper: ISO 50 / 60 feed in x - axis: mm/minfeed in y - axis: mm/minfeed range Z-direction: mm/mintable-size: 11000 x 3200 mmcontrol: Siemens 840C ram head dimension: 600 x 600 mmworkpiece height max.: mmtotal power requirement: - kVAweight of the machine ca.: - tdimensions of the machine ca.: 33 x 12 x 7,1 mPortal milling machine equipped with:- CNC control Siemens 840CThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 15300 mmy-travel: 4950 mmz-travel: 1000 mmw-axis: 3682 mmdistance between columns: 5100 mmtable load: 400 tmilling slide: 120 kWspindle turning speed range: 5 - 600 U/minmax. torque on the spindle: kNmtool taper: ISO 50 / 60 feed in x - axis: mm/minfeed in y - axis: mm/minfeed range Z-direction: mm/mintable-size: 15000 x 4500 mmcontrol: Siemens 840C ram head dimension: 600 x 600 mmworkpiece height max.: mmtotal power requirement: - kVAweight of the machine ca.: - tdimensions of the machine ca.: 41 x 13,7 mPortal milling machine equipped with:- CNC control Siemens 840C- Head changing station with X-stations- Coolant systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 19000 mmy-travel: 7600 mmz-travel: 2000 mmw-axis: 5000 mmtable surface area: 18500 x 5000 mmtable load: max. 500 tdistance between columns: 5500 mmpower capacity - milling spindle: 110 kWtool taper: CAT #60 Control: FANUC 15i MB total power requirement: - kWweight of the machine ca.: 650 tOverhauled & modernized in 2007equipped with:- CNC control FANUC 15i MB- 5 headsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 11200 mmy-travel: 3130 mmz-travel: 1000 mmControl: NUM 1060 W A-axis: +- 120 °c-axis: +215/-210 °spindle motor: 15 kWspindle taper: HSK-F63 turning speeds: 24000 U/mintable width: 1500 mmtable length: 9400 oder 2x3000 mmtotal power requirement: kWweight of the machine ca.: 20 tdimensions of the machine ca.: 14,6x5,0x4,225 mUse:e.g. for processing aluminum panels, drilling profiles, advertising (signsmilling, etc.), mold construction (prototypes) and processing of light steel frames / -beams using HSC millingThe vertically arranged high-frequency milling spindle for automaticTool change is mounted in a fork head on the Z-axis plate. TheSpindle can be moved with the fork head in 2 NC axes, in the A axisand the C-axis. The vertical movement is carried out via the Z-axis.Liquid cooling via a cooling unit.Tool magazine: moving plate changer in the potal, outside theWork areaMinim ...

Key data: 3050 mm, 2050 mm, 180 mm

Year of manufacture 2012, S/N 5.32.180.12.687, machine weight 1,350 kg, max. permissible tool diameter 20 mm, travels x/y/z axis 3,050 x 2,050 x 180 mm, with 16-fold tool changer, control module, cooling device, with side channel compressor

Manufacturer ZAYER Model TEBAS-5000 Year 2013 CNC HEIDENHAIN iTNC-530 HSCI Table Table Surface 5.200 x 2.200 mm. Max. weight allowed on table 25.000 kg. Max distance from 45º head nose to table in vertical position 1.410 mm. Max distance from 45º head nose to table in horizontal position 1.465 mm. Max distance from direct exit head nose to table in vertical position 1.420 mm. Travels and feeds Longitudinal Traverse (X Axis) 5.000 mm. Transversal Traverse (Y Axis) 3.750 mm. Vertical Traverse (Z Axis) 1.250 mm. Distance between columns 3.000 mm. Rapid Traverse 50.000 mm/min Max. Working Feed 30.000 mm/min Headstocks Universal Auto Indexing Head 45º 0.001º/0.001º Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 Spindle speed 6.000 rpm Speed ranges 3 Main spindle power 43 kW Direct output head reduction 1-2,29 INCLUDED Taper DIN 69871 AD 50 Spud ISO 7388-2 B 50 S ...

First commissioning: 2016 Control: Heidenhain iTNC 530 incl. handwheel HR 520 X-axis: approx. 2,500 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,250 mm A-axis: ± 110° C-axis: ± 300° Clamping table Clamping surface: approx. 2,500 x 3,250 x 400 mm 2-axis milling head VH30 Spindle power: 60 kW Spindle speed: max. 22,000 min-1 Torque: 95 Nm Tool holder: HSK 63A Tool tensioning: hydraulic Coolant supply: outside and inside Blowing air: Outdoor Drives Linear axes Feed speed X-, Y-, Z-axis: up to 60 m/min Axle acceleration X-, Y-, Z-axis: up to 5 m/s2 Connection data Connected load: 190 kVa Fuse: 315 A Dimensions, weights Space requirement machine with peripherals: approx. 10,000 x 9,000 x 5,650 mm Total weight: approx. 55,000 kg Colour Housing, portal, control cabinet: RAL 7035 light grey Milling head and applications: RAL 6038 luminous green  ...
