extruders used for sale (450)

Key data: 35 mm, 25 , 103 U/min

Used extruder 35mm - 25 l/d with 5.6 kW drive 3-zone auger 3 heating/cooling zones on the cylinder + 1 tool zone Mass pressure sensor 500 bar All machine cables designed to be plugged in Control cabinet with main switch, motor controller, mass pressure indicator and 4 pieces of temperature controller Function-tested

Key data: 30 mm, 28 , 110 U/min

Used Filament Line Single Screw Extruder 30mm 28L/D 2 meter water bath Trigger AB50 Winder W250 Machines from PMH GmbH

Key data: 35 mm, 25 , 107 U/min

used REIFHÄUSER single screw extruder with screw size: diameter 35mm / 25 ld The extruder is in very good condition Type RT 78-1-35-25 New control cabinet with new motor AC -7,5kW Year of construction 1994 Quickly available

Key data: 65 mm

Qty. 1 Second-hand 3-Layer Co-Extruder Line Brand & Model: MACCHI 3-layer co-extruder Built: 2012 Materials to be processed: LLDPE/LDPE/LLD/HDPE Extruders: 65 mm + 80 mm + 65 mm Infrared heaters 3 pcs plate filters Head: 3 Layer blown film Die head TE5303-IBC-350/500 Dies diameter 350 and 400 mm IBC Die Gap: 1.8 mm Output: Up to 800 kg/hour depending on material formulation Air ring: Dual flow air ring carbon fibre Take off: Take off 2400 mm wide Oscillating nips Motorised side gusseting Rewind: Double winder, fully automatic back-to-back rewinder Winder, fully automatic roll change Reels diameter up to 800 mm Winding width 2350 mm Accessories: Tower Web guide E&L Components blander Shini Gravimetric weight control system Piovan/Doteco Dosing units Doteco Automatic Thickness control Kundig/K-Design Profile gauge control system Calibrating basket Corona-treat ...

This REIFENHÄUSER BI Trudes 115 was manufactured in 2013. Ideal for pipe extrusion, this machine represents a robust addition to any production line. Contact us for more information.

Brand: Hans Weber Maschinenfabrik GmbH Model: NE 5 Serial nr. NE 5 038 Type Screw: Single screw Year of manufacturing: 2000 Machine hours: 35.615 hours Screw diameter: 50 mm L/D ratio 30 L/D Motor power: 83 kW Weight 1.600 kg

Brand: Cincinatti Milacron Model: CMS 60-25 BL Serial nr. 2008877/10 Type Screw: Single screw Year of manufacturing: 1995 Machine hours: 60.269 hours Hfjbn Sm Hjyaa S Ssqvob Screw diameter: 60 mm L/D ratio 25 L/D Motor power: 28 kW

FIMIC RAS 325 SCRAPER, fully automatic screenchanger, screening surface 77.900 mm², Throughput: up to 600 kg/h depending on material and contamination, with scraping system, suitable for extrusion lines with capacity up to ca 500 kg/h or more depending on screening, Just disconnected, excellent conditions, constructed in 2023, immediately available, We can supply spare screens for this machine at competitive prices., Laser screen from 80 to 300 µ - Mesh from 180 to 50, Punched screen from 400 to 2.000 µ - Mesh from 40 to 10, capacity: 600 kg/h depending on material and mesh, availability: immediate, type: fully automatic

x-travel: 3000 mmy-travel: 2500 mmz-travel: 1000 mmControl: Siemens type: Sinumerik 840 DFeed: 5-30.000 mm/minTable area: 2000x2170 mmtable load: 1500 Kg/m²T-slots: 22 H9distance between uprigths: 2500 mmspindle turning speed range: 6000 U/minspindle drive: 36 kWspindle taper: HSK 100Tool changer: 30 Rotary table: 2000 mmspeeds: 250 U/minturning diameter: 2500 mmtable load: 10 tTorque: 33000 Nmtotal power requirement: kWweight of the machine ca.: 45 tdimensions of the machine ca.: 8x6,4x4,4 mGentry gantry milling machine with carousel rotary tableHead change stationTool changerThe tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories ...

Extruder for the production of packaging chips Year of manufacture: 1994 Screw: four-course Cylinder: 2-pass Nozzle plate "FLIPS/balls diameter 4mm/1-fold Cutting device with 4-blade cutter head Dosing and suction device Machine is electrically connected, dry running possible Spare parts: 2 4-pass screws, 1 nozzle plate

Reduction and transfer case for conical twin screw extruder Cincinnati Titan 58 Manufacturer: Eisenbeiss on behalf of Cincinnati Extrusiontechnik General overhaul included: • Checking the sprockets for damage with a special camera • New sealing of the drive and output shaft • New shaft bearing • New oil filling • Repainting Condition: overhauled, fully functional

Leda Mattiello Extrusion line 160 mm 50 LD 2 degassing pumps, under refurbishing, ENERGY SAVING IR heaters, for PP PS PE ABS PC, etc., Very good quality extruder, 3 m3 ca. storage silo, crammed vertical screw for light materials with adjustable speed,, extruder with 160 mm. screw, 50 L/D, n.8 Infra Red Petrelli Heaters x 11 kw each V.380 - for great energy saving, 315 kw a.c.Sever drive with inverter (about 60% power used in work), Gefran inverter, n.2 vacuum degassing pumps, semi-automatic screen-changer 400 mm Ø screens (possible configuration with fully automatic scren-changer), horizontal water ring pelletizer, drying centrifuge, closed water cycle, Zambello gearbox with oil recirculating pump, oil-water heat exchanging unit, Control cabinet for managing the whole line including thermoregulators, etc., Nominal throughput rate 800-900 kg./h depending on material., The extruder is o ...

Prealpinaa 180 mm. 35 L/D (under reconditioning), for HDPE LDPE LLDPE PC PP PS ABS, Offered totally reconditioned with warranty, The line includes:, (OPTIONAL - Buffer silo with agitators and feeding auger), forced feeding unit, extruder with NEW barrel and 180 mm NEW screw 35 L/D, vacuum degassing system, 397 kw d.c.drive, semi-automatic screen-changer with 300 mm diam. screens. (can be fitted with fully automatic screen-changer), water ring pelletizing unit, heat exchanging units on pelletizer and gearbox, drying centrifuge, vibro-classifier, NEW electric cabinet with PLC and touch screen display (or traditional commands, if preferred), throughput rate 1.000-1.400 kg/h depending on scraps and feeding rate, installed power 650 kw, used 420 ca in work, Users manuals, drawings, CE., Delivery : about 13 working weeks for total reconditioning, See how we recondition [HERE](.germanplast.eu/p ...

Gamma Meccanica 105 mm 40 L/D, for LDPE HDPE PP ABS PC PS, Nominal throughput rate 300-400 kg/h depending on feeding rate and material, Average energy consumption : 0,23-0,28 kWh/kg including buffer-silo feeding auger crammed feeder extruder with 105 mm screw 40 LD, vacuum degassing pump 110 kw a.c.drive with inverter non-stop hydraulic screenchanger (can be fitted with a [fully automatic screenchanger](.germanplast/listings/7610249-used-fimic-ras-325-automa tic-screenchanger)) water ring pelletizer drying centrifuge electrical cabinet user’s manuals and drawings constructed in 2000 offered RECONDITIONED, Total length 11.000 mt., Possible addition of upstream and downstream equipment., options available: fully automatic used screenchanger, capacity: 300-400 kg/h with only 0,23-0,28 kWh per kg produced, conditions: reconditioned, type: buffer silo+crammed feeder, Location: IT- 11020 Iss ...

BANDERA TWIN SCREW PVC PIPES EXTRUDER, for pipes with min/max diam.40/200 mm., extruder with n.2 parallel counter-rotating screws Ø 90 mm, Throghput rate 400 kg/hr, missing of screenchamger (can be added separately), n.2 dies available 40 to 125 mm + 125 to 200 mm., Tooling from 40-200 mm (available diam. 100 mm for O-Ring), Bandera 6 mt.long vacuum calibration tank, IPM haul off unit, IPM saw, IPM belling unit, constructed in 1998, totally refurbished in 2006 by Plasco, machine now disconnected, offered RECONDITIONED., availability: immediate, working width: 40-200 mm Ø, capacity: 400 kg/h, conditions: disconnected, type: pipes extrusion line

This Krauss Maffei KME 45 XS single screw extruder was manufactured in 2016. It features a screw diameter of 45 mm and a length of 1350 mm, with a drive power of 23 kW and a maximum speed of 2486 rpm. The machine includes five heating/cooling zones and can handle a maximum air flow of 5 × 630 m³/h. If you are looking to get high quality extrusion capabilities consider the Krauss Maffei KME 45 XS machine we have for sale. Contact us for more information.

This SWISS CAB KMV was manufactured in 2001. It is a pipe extruder designed for plastic-metal composite pipe systems. More technical details will follow soon. Consider the opportunity to buy this SWISS CAB KMV pipe extruder. Contact us for more information.

CDM PREALPINA REGRANULATING LINE 130 mm 2xdegassing, for PE PP PS PP PC ABS (it has been working with clean scraps only), extruder with 130 mm. screw Ø 40L/D, including buffer silo with agitators, horizontal extraction screw, crammed feeding unit synchronized to extruder screw, a.c. 283 kw drive, n.2 degassing pumps, semi-automatic screen changer 230 mm diam.screens , water ring pelletizing unit, stainless steel drying centrifuge, vibrating screen, electric cabinet, blower + pipings, vertical mixer, machine reconditioned, can be fitted with a [FIMIC RAS](.germanplast/listings/5241333-refurbished-fimic-ras-400-automatic -screenchager-reconditioned) fully automatic screenchanger, installed power - used power in work: about 60-65% : 435, capacity: 500-600 kg/h, availability: 5 weeks time, options available: fully automatic screenchanger, conditions: refurbished, type: double degassing fo ...

CDM PREALPINA RECYCLING EXTRUDER, Materials PE PP PC PS ABS PA, extruder with 130 mm. screw diam., Constructed in 2006, crammed feeding unit, extruder 130 mm., a.c. 283 kw drive, total installed power 406 kw, one degassing pump 5,5 kw, semi-automatic, non-stop hydraulic screen changer 230 mm diam.screens, hydraulic power station, water ring pelletizing unit, drying centrifuge, heat exchanging unit, vibrating screen, electric cabinet, machine reconditioned, installed power - used power in work: about 60-65% : 283, options available: different pelletizer, with or without buffer silo, with blower + bag filling station with vertical mixer, capacity: 500-600 kg/h depending on material and feeding rate, conditions: reconditioned (or as is)

EREMA INTAREMA 1309 TVE plus SD, Complete regranulation line for LDPE LLDPE HDPE PP PS, Throughput rate 480-750 kg /h depending on materials, Including_, loading conveyor belt, tunnel metal detector, compacting unit, extruder with 90 mm.screw Ø, double piston, backflush screen-changer, double degassing unit,, water ring pelletizer, stainless steel centrifugal dryer, closed cycle water flow, electric cabinet for full management, 3 years of work with commercial LDPE washed and dried yielding 500-600 kg/h, Users manuals, CE compliance declaration, Electrical drawings available, capacity: 480-750 kg/h depending on materials, conditions: very good conditions - now disconnected , type: compact line from scraps to granule

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

A twin screw extruder is offered. Drive: ASEA electric motor type ACA 200-6L, 50.5kW, 1460rpm. Inspection possible by prior arrangement.

Brand: Hans Weber GmbH Model: ZE 20 Type Screw: Single screw Year of construction: 1999 Screw diameter: 20 mm L/D ratio 20 L/D Motor power: 3 kW Control Voltage: 200 V Dimensions (LxWxH): 3100 x 1200 x 1280 mm Weight: Approx. 300 kG Other: – Including swivel mounting arm – Including extra connection box

Key data: 172 U/min

We offer directly on behalf of the owner : Make : COPERION ( Werner & Pfleiderer ) Gearbox make : P.I.V Type : ZSK 170 W 1920/1750 Year of construction : 2021 / 2002 / 1986 Screw diameter : 172 mm Screw speed : 4.9 – 49 min-1 Max. torque: 17,500 Nm Main motor : 216 kW In the last 3 years, a total of over 420,000 € has been invested in new components and factory overhauls ( some of which have not been used so far ) The extruder was in use until Aug / 2023 and is already dismantled ready for transport. The components are partly redundant and date from the years 1986 - 2021. The scope of delivery consists of : Twin Screw Degassing Coperion DSE 180 - 1 x BJ 2021 ( 180 T€ ) Main Gearbox P.I.V - 1 x 2002, factory overhauled ( 233 thousand € ) in 2021, unused - 1 x BJ 1986, factory overhauled in 2016, 2021 – 2023 in service Main motors Sieme ...

NGR S-GRAN 65 VHD, Constructed in 2011, offered checked for good conditions, including:, loading conveyor belt, tunnel metal detector, densifier, extruder with 65 mm Ø screw, degassing point, hydraulic screenchanger, water ring pelletizer, drying centrifuge, extraction vent with cyclon and bag supporting structure., conditions: used, checked, type: compact recycling line

Key data: 22 mm, 60

Single screw extruder 60 with renewed PMA control in 2010 - was replaced by double screw 5 years ago. Works after oil and belt change

VACUREMA type 120 T-VS for the processing of rPET, technically qualified overhauled, Built in 2004, capacity up to 650 kg/h, with approval according to the standards of the F.D.A. (USA) and ESFA (EU) for direct contact of food of manufactured rPET products. Electrics European standard. Delivery Time: Short Term. Also Folien + Technik e. Kfm. D-73728 Esslingen Official agent for EREMA GmbH A-Ansfelden Phone +49 1577 5329827

GENERAL DESCRIPTION: The Macchi 3-Layers E18 is a high-capacity blown film co-extrusion line intended for production of general-purpose films with high width and output demands. It processes LLDPE, LDPE, mLLDPE, MDPE, HDPE, and in upgrade configuration also PP. The system uses a 700 mm 3-layer die head and reaches an output capacity of up to 900 kg/hour, depending on formulation. EXTRUSION GROUP: • Extruders: 80 mm + 100 mm + 80 mm • Infrared heating • Hydraulic screen changers Detailed upgrade specification: • One extruder Plastex 100/30D (middle layer B) • Two extruders Plastex 80/30D (layers A and C) • Bimetallic barrels • Nitrided screws • Water-cooled grooved feeding sections • 5 heating zones with IR heaters and blowers •Engine: - 150 kW DC motor (100 mm extruder) - 100 kW DC motors (80 mm extruders) • AC motor application with digital control  ...

ICMA SAN GIORGIO TWIN SCREW EXTRUDER CO-ROTATING, used for elastomers TPE TPU SBS,.., Extruder with co-rotating segmented screws 2 x 140 mm 36 L/D, Screws speed 178 rpm, Reinforced gearbox, Siemens 430 kW drive, degassing pump, semi-automatic hydraulic screenchanger, hydraulic pack, Dry pelletizing unit, Electric panel overhauled in 2015, added touch control, Constructed in 1997, CE compliance declaration, electric drawings.
