Manufacturer:
(Category: 105)
Equipped with saw blade/power cable missing
ELU ALUMINUM MITRE SAW DOUBLE MINIMAL LUBRICATION SPEED 2 SPEEDS 2100/3800/MIN
With automatic stop and measuring system AMS200.
In pvc storage case Complete with 2x battery and 1x battery charger
Industrial disc hacksaw, IMAK brand, model D315, pedestal mounted with drip tray. Machine designed for cutting metal profiles (steel, aluminum, etc.), equipped with a robust clamping vice with manual adjustment and orientation for angular cuts. Downward cutting head with protective guard and control via remote electrical panel. Presence of a lubrication system for cutting cooling (visible piping). Closed metal frame mounted assembly with integrated tank. ⚙️ Technical characteristics (visual and general) Brand: IMAK Model: D315 Type: Disc Hacksaw (Industrial Chainsaw) Disc diameter: ± 315 mm (machine type corresponding to this range) Swivel vise for corner cuts Manual head lowering Integrated lubrication system Electric control with emergency stop Power supply: industrial plug (to be checked) Base with drip tray Industrial hacksaws of this type allow precise and repetitive cuts in d ...
weight of the machine ca.:1750 kgsawing motor:2,2 kWtotal power requirement:5 kWcutting speed:17 - 90 m/mincutting diameter:320 mmcutting range max.:320 x 320 mmsaw band length:4.930 x 34 x 1,1 mmfeed length:max 9x 600 mmdimensions of the machine ca.:2,6 x 2,4 x 1,40 mBandsaw automatic, straight cut,min. cutting diameter 10mm,min. cutting length 6mm,min. offcut 15mm (automatic 80mm),max. weight of material 400kg/m,coolant box 60l, pump 16l/min,clamping pressure 20-60bar,dimensions:chipconveyor 2.400x 950mmroller track 2.200 x 950mm,5pcs. saws (new) 4.930 x 34 x 1,1mm operating manual,
cutting diameter:320 mmsaw band length:3280 mmcutting width:320 320 mmtotal power requirement:3,8 kWweight of the machine ca.:1150 t- columm guidance- roll-conveyer 4000mm / 1000 mm lenght- cutting speed 15 - 105 m / min- mitre cutting up to 60°
"Max. cutting width: 500 mm Max. cutting height 550 mm" On pallet
Manual control is missing, pallet and lashing strap not included.
Serial Number: 44650046 Blade length: 4570 mm Cutting Capacity: Round material: ⌀ 406 mm Square Material: Width: 400 mm Height: 400 mm Max. loading capacity: Machine: 2500 kg Roller conveyor: 2000 kg/m Min. workpiece remaining length to ensure the clamping edge of 10 mm: 76 mm Min. workpiece residual length for no workpiece detection: 30 mm Saw blade dimensions: 41 x 1.3 x 4570 mm Velocities: 15 to 90 m per minute (50 Hz) 17 to 90 m per minute (60 Hz) Section length: 10 - 5040 mm (possible in steps of 0.1 mm) Single feed: 570 mm With technical documentation as shown in the pictures With additional roller conveyor Support length: approx. 2000 mm Total support length: approx. 5040 mm
With saw band welding device
Including inlet/outfeed roller conveyor, machine size approximately 850x750x1560mm.
