paper converting: slitter rewinders used for sale

450 Automatic Die Cut and Turret Rewinder 450mm Rotary Die Cutting unit: -Unwinder with auto web guider -Auto Tension Control system -Pressure meters for die cutting unit -Standard slitting unit with 6sets blades -Standard matrix removing system -Magnetic Powder system,mechanical speed 100meters/min -Max unwinding diameter 700mm, web width 330mm -Standard connection component to 330 turret rewinder 450 Auto Turret rewinder: -Automatic paper core bowl feeder -Automatic tail glue unit -Automatic paper core conveyor -Pressing paper swing arm -Automatic cut unit -Automatic finished roll ejection -Automatic brush press paper unit -Automatic core glue unit -Air expanding shaft 4sets each sizes 1’’, 1.5’’ and 3’’ -Labeling System (optional): Included Features: Speed: 60-100 m/min Max. Rewinding Diameter: 350mm Max. Web Width: 450mm Min. Rewinding W ...

Rewinder type: Back to back // Web Width max.: 1700 mm

Working width: 1400 mm Masch. Item no.: 1116 with 5 pairs of knives 1x Retractor

Max web width : 330mm Unwind roll max diameter : 700mm Speed : up to 35 meters/min Unwinder with ultrasonic web guide 1 rotary flexo station 1 lamination unit Semi rotary die cutting station Magnetic cylinder of semi-rotary die : Z-120. Slitter Rewinder

Duplex Slitter rewinder Web width: 1400mm Unwind diameter: 800mm Rewind diameter: 500mm Maximum speed: 300m/min Integral unwind station with 76mm and 152mm air shafts Hydraulic roll lift and disc brake on unwind BST CLS Pro web guide unit for edge and line guiding Tension control via load cell mounted we path roller Infeed driven nip unit 3 motor dc drive system with analogue drive control Razor in grooved roller slitting station with several knife holders Edge trim removal fan Duplex cantilevered rewind with differential slip adapters Full width lay on roll assemblies with pneumatic application Side opening door for roll off loading with guard inter locks Off loading roll capstan unit Control panel with digital display and digital counter Electrical diagrams

Max width: 1400 mm Machine speed: 600m/min Material width: 1400 mm Max. reel diameter unwinder: 1100 mm Rewinder type: double shaft Max reel diameter rewinder: 610 mm Max. unwinding tension: 785 N Max. contact pressure 5,00 Bar Max. rewinding tension: 500 N Max. diferential tention: 5,00 Bar Max. linear tention: 0,500 N/mm Laser positioning Pneumatic rotary knifes Automatic knife positioning system Friction rewinding shafts Pneumatic tension roller Web controlling systems Turning rack for unloading of ready rolls Materials: Films, Laminates, Paper, Aluminium

cutting plotter OKI/Graphtec FC 8600-130; Cutting surface 1372mmx50m; Max. Roll width 1529mm, min.50mm; Max. Cutting force 600g in 48 steps. Cuttin plotter OKI/Graphtec FC 8600-130; cutting area 1372mmx50m; max.roll width 1529mm, min.50mm; max.cutting force 600g in 48 steps.

Shaftless Unwind Monomatic Typ MD 107 (150 mm core diameter) FIFE side edge control max. roller diameter 1,070 mm Web tension control device Multiple breaking device Trimming station Cutting accuracy +/-0.2 mm Automatic angle adjustment Automatic sheet length adjustment without gear change Working width up to 1250 mm min. Working width 600 mm, cutting length from 550 to 1500 mm Materials from 60 g/sqm to 150 g/sqm (unwinder max. 120 g/m2) Ionisation device Waste ejection station Shingled delivery Belt delivery extended to the end of the stack Counting device Pile delivery with jogger max. mechanical output 300 m/min Cerutti embossing station - suitable for surface embossing (steel - paper 1 : 1.85) Embossing calender output max. 250 m/min

Qty. 3 Second-hand winders Mfc.: Maxson Built: 1997 Roll width: max. 1,700 mm, min. 450 mm Maximum roll diameter: 1,650 mm The width of the core is: 70, 76, 120, 152, 300 mm

Special offer: for sale by owner 1600 mm German slitter rewinder suitable for paper & film can be shown in operation equipped with circular knives web guide with photocell materials: paper, films dancing roller for control of web tension unwinder diam 1000 mm rewinder: double rewinder diam. 600 mm included also: antistatic bars rollers with needles for perforation Special price, dismantling & loading included in the price Machine offered subject to unsold

For sale: Bragernes aut. coreless rewinder, year 1981, web width 1000 mm, Unwind dia. 1000 mm. Can make rolls from 5 m up to outside dia. 50 mm With web guide and tension control.Available: Now

Working width: 1300 mm

Special offer: 1000 mm Schiavi used duplex slitter-rewinder very compact machine- it needs very little sapce and can be put next to the wall can be shown in operation FILM: unwinder diam. 1000 mm rewinder double web guide with photocell rewinder: easy removing of the finished rolls thanks to cantilevered rolls Special price for quick sale Machine offered subject to unsold Best regards Joanna Laskowicz Flexo

Working width / working width 1550 mm

Abrbeitsbreite / working width 1250 mm

R26081/12 Jagenberg rewinder model: VII age: 1963 size: 1600 mm available: immediately material: paper and foil sleeve inner diameter:70 mm speedt: max. 500 m/min about 10 knives Available: sofort

working width 7.400 mmStill in operation: YesAvailable: sofort

working width 600 mmStill in operation: YesAvailable: sofort

<br><br><br>Still in operation: Yes<br>Verf Gbar: Immediately

<br><br><br>Still in operation: Yes<br>Available: immediately

R23801/12 JAGENBERG Roller cutter Model: Vari Major Built: 1974 Width: 3,800 mm Materials: - coated paper, glossy and matte, grammage from 50 to 250 g/m2. max. speed: 1,500 m/min. for paper 250 g/m2 (The speed depends on the quality and grammage of the paper.) max. unwinding diameter: 2,500 mm max. winding diameter: 1,525 mm min. cutting width: 100 mm Number of upper knives: 6 Winder: 5 Single Winder max. roll width: 1,730 mm min. roll width: 450 mm max. unwinding diameter: 1,525 mm min. unwinding diameter: 300 mm 600 mm max. roll weight: 35 kN Available: immediately

Working width 1000 mmStill in operation: YesAvailable: immediately

R23536/12 ELSNER Roller cutter "Semi Auto Rewinder" Model: MSR - 42 Built: 2004 Working width: 100 cm for secare rolls , gift wrapping paper Rolling diameter: 1000 mm Roll-up diameter: 305 mm Material: from light-weight tissue to heavy kraft paper, e.g. flower foil PP etc., newsprint, nonwoven... pneumatic crushing knives on cutting shaft Shaft for 70 he sleeve Automatic shut-off Available: immediately

R25716/12 GOEBEL Roller cutter Model: Practica H III Built: 1957 Working width: 1000 mm Rolling diameter: max. 1000 mm Shaft diameter: 70 - 76 mm Round knife Cutting width min.: 15 mm Roll-up diameter: min. 15 mm, max. 400 mm Speed: 300 m/min Available: immediately

working width 1000 mmStill in operation: YesAvailable: sofort

R25716 / 12 GOEBEL reel slitter model: Practica H III age: 1957 width: 1000 mm diameter unwinder: max. 1000 mm diameter core: 70 – 76 mm system: circular knife min. slitting width: 15 mm diameter rewinder: min. 15 mm, max. 400 mm core diameter: 12 mm speed: 300 m/min Available: sofort

R23801/12 JAGENBERG slitter rewinder model: Vari Dur age: 1974 Net width : 3.800 mm materials: - coated paper, gloss and matt, grammages from 50 to 250 g/m². max. speed: 1500 m/min. for paper of 250 g/m² (The speed depends on the quality and the grammage of the paper) max. unwinding diameter: 2.500 mm max. winding diameter: 1.525 mm min.cutting width: 100 mm N° of upper blades: 6 Unwinder: 5 singles unwinders max. width of reels: 1.730 mm min. width of reels: 450 mm max. unwinding diameter: 1.525 mm min. unwinding diameter: 300 mm (from 900 to 1700 mm of net width) 600 mm (from 450 to 900 mm of net width) max. weight of reels: 35 kN Available: sofort

for sale by owner, special price for quick sale: used Titan duplex slitter rewinder 1200 mm in operation worked with film & paper unwinder diam. 1000 mm, shafts 76 & 152 mm rewinder: double shafts on rewinder: 76 mm film: youtu.be/T949u6BQRLU Special price for quick sale only- we need space Machine offered subject to unsold

DECOIL DIA.: 1000 MM, COILER DIA.: 800 MM, WIDTH: 1000 MM, GRAMMAGE: 180 GSM,Still in operation: NoAvailable: IMMEDIATELY
