used Bed Milling Machines for sale

oven 1150 inner chamber dimensions 1 x 1 x 2m t max 1150 Celsius PLC Öfen Verzinkungsofen Ve rgüteofen Anlassofen Industrieöfen Glühofen Ovens laboratory ovens industrial furnaces industrial furnace plants Industrial Furnaces high-temperature chamber furnaces hardening furnace anlageHärteöfen Annealing furnaces Conveyor belt Abg aswäscher Abkühlungsöfen Abwärmerückgewinnung Aluminiumgiessereimaschinen Anlassofen Brennöfen Dentalofen Durchlauföfen Emaillierofen Fusingöfen Generatives Fertigungsverfahren Anlaßöfen mit Luftumwälzung Anwärmöfen Aluminium – Glühöfen Abschreckbäder Beschickungsanlagen für sbguss Druckgußmasch inen Drehherdöfen Doppelkammeröfen Draht – Glühöfen Durchlauföfen Elev atoröfen Glühöfen für verschiedene Einsatzarten Gas Nitrieröfen Härteöfen Härtebäder Herdöfen Hubbalkenöfen Herwagenöfen Haubenöfen Indu ...

x-travel: 2500 mmy-travel: 1250 (1000) mmz-travel: 1100 mmControl: Heidenhain iTNC 530 table surface area: 2700 x 850 mmtable load: 6000 kgtool taper: ISO 50 DIN 69871spindle turning speed range: 60 - 3000 U/mintransmission ratio: 2 feed range: 10000 mm/minrapid traverse: 20 m/minMotor Capacity: 24 / 38 kWtotal power requirement: 38 kVAweight of the machine ca.: 16,1 tdimensions of the machine ca.: 7,63 x 5,16 x 3,52 mCNC universal bed milling machine in good working condition.Equipment:CNC control Heidenhain iTNC 530Autom. universal milling head -180 to +177,5 deg., indexing 2,5 deg. Angular positioning automatically A and B axisElectronic hand wheelChip conveyorCoolant systemThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3.000 mmy-travel: 1.700 mmz-travel: 1.500 mmControl: HEIDENHAIN TNC 530 HSCI table-size: 3.200 x 1.100 mmT-slots: 7 T - slots distance: 150 mmT-slot - distance: 22 mmtable weight: 8.000 Kgrapid travel x/y/z: 20.000 mm/minfeed: 10.000 m/minmilling head -swivable +/-: 45° UAD/ 0.1º/0.1º °tool taper: ISO-50 DIN 69871 AD spindle turning speed range: 60 – 6.000 U/mintransmission ratio: 2 Spindle power: 38 Tools changer: 30 fach/toolsInternal cooling system: 40 barChip coveyor: Quer Chip coveyor: Längs handwheel: Inkl. total power requirement: 48 kWweight of the machine ca.: 30 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2000 mmy-travel: 920 mmz-travel: 900 mmtable surface area: 2200 x 750 mmtable load: 3 tnumber of T-slots: 6 T - slots - width: 18 mmT - slots distance: 120 mmspindle taper: ISO 50 DIN 69871-B spindle speed max.: 3000 U/mintransmission ratio: 1 speeds infinitely variable range 1: 60 - 3000 U/minweight of the machine ca.: 21,6 tfeeds longditudinal/cross/vertical: 0 - 5000 mm/minrapid traverse: 15000 mm/mintotal power requirement: 38 kwweight of the machine ca.: 11 tPull studs DIN69872-B | IKZHours:Control on: 43036 hMachine on: 41311 hProgram run 13894 hThe machine is already dismantled The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3000 y-travel: 900 mmz-travel: 900 mmControl: Heidenhain type: TNC 426 B-axis (table): 360x1° A-axis: 360x1° table surface area: 3100x800 mmTable load: 10000 kgflute distance: 125 mmgroove width: 16 rapid travel - grinding spindle: 15 m/mintool magazin:: 48 main drive motor: 29 kWturning speeds: 30-3500 U/minTool bore: SK 50 total power requirement: kWweight of the machine ca.: 16 tdimensions of the machine ca.: 8,3x4,8x2,73 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Stock number: 3845 CNC BED MILLING MACHINE Manufacturer: CME , Type: MB-3000 FLEX Reconditioned spindle Year of construction: 2006 Specifications: Spindle speeds 2200 rpm Boring Spindle dia. 150 mm

x-travel: 1300 mmy-travel: 700 mmz-travel: 700 mmControl: Heidenhain table surface area: 1700x630 mmTable load: 3000 kgturning speeds: 80-3150 U/minspindle taper ISO: 50 total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2.000 mmy-travel: 800 mmz-travel: 800 mmControl: HEIDENHAIN TNC-410 table-size: 2.000 x 700 mmrapid travel x/y/z: 12.000 mm/mintool taper: ISO 50 number of spindle speeds: 20 - 3.000 U/min/rpmspindle drive: 17 kWtotal power requirement: 24 kWweight of the machine ca.: 9 tdimensions of the machine ca.: 3700 x 2400 x 2700 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bed milling machine Manufacturer Nicolas Correa Year of construction 2003 Control Heidenhain TNC 426 Clamping surface 2000 x 700mm table load 3.500kg Travel X/Y/Z 2000/800/800mm Tool holder SK50 max speed 4,000 rpm Machine weight 9.000kg Machine is in a used good condition

x-travel: 2000 mmy-travel: 1000 mmz-travel: 1000 mmControl: Heidenhain type: TNC 430 : spindle turning speed range: 15-1450 U/minTable area: 2300x1200 mmSpindle: 200 mmspindle stroke: 200 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mNr 3762Maschine wurde überholtmachine is retofitThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

FIXED BENCH MILLING MACHINE with SWIVEL VERTICAL HEAD and PRISMATIC GUIDES. Brand : DROOP & REIN.
 Model: FS130gku.
 Table: 2200 x 800 mm. Long crossbar : 1700 mm.
 Transverse crossbar : 870 mm.
 Vertical crossbar : 800 mm.
 Spindle taper : ISO 50. THE MACHINE IS EQUIPPED WITH A VIEWER.

x-travel: 4000 mmy-travel: 2000 mmz-travel: 1300 mmControl: Heindenhain type: TNC530i : table surface area: 5200x2000 mmTable load: 30000 kgpinole diameter: 230 mmnumber of T-slots: 11 T-slot - width: 28 mmT-slot - distance: 175 mmspindle taper ISO: 50 turning speeds: 40-2000 U/minspindle motor: 30 kWtransmission ratio: 4 total power requirement: kWweight of the machine ca.: 70 tdimensions of the machine ca.: 10x5,5x5,8 mMaschine wurde überholtmachine is retofitThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 3300 mmy-travel: 2200 mmz-travel: 1300 mmw-axis: 350 mmworkpiece height: 1700 mmmilling spindle diameter: 140 mmdiameter of quill: 230 mmmilling head speed: 40-2000 U/mintransmission ratio: 4 table surface area: 4260x2000 mmT-slot - distance: 175 mmT-slot - width: 28 mmnumber of T-slots: 11 workpiece weight: 300000 kgmilling spindle motor: 30 kWFeed: 5-3000 mm/mincontrol: Fidia total power requirement: kWweight of the machine ca.: 80 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Horizontal bed milling machine make ERNAULT SOMUA type Z 1 CFabr. -No: 104470/333, built in 2/1970Table mounting surface: 1200 x 300 mmTable movement lengthwise: 700 mmY: 250 mmZ: 400 mmSpindle taperSpindle speeds Horizontal: 50 - 2500 rpmSpindle speeds Vertictal: 40 - 2000 rpmautomatic feeds f. along u. across the limit switchMotor power spindle approx.: 3 kWexternal dimensionsWeight approx: 1760 kgWith- Additional track control / cam control via connector panel- Coolant deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

x-travel: 5000 mmy-travel: 500 mmz-travel: 850 mmcontrol: Heidenhain TNC 150 spindle taper ISO: 40 main drive motor: 7,5 kWtool changer number of tools: 32 clamping surface below angle: 5000 x 550 mmspindle turning speed - stepless: 4000 U/minrapid traverse: 15 m/mintotal power requirement: kWweight of the machine ca.: 9,5 tdimensions of the machine ca.: 8,2 x 2,9 x 3,2 mtransport dimension: 8,2 x 2,4 x 2,98 mElectric 380 Volt: Cooling equipment: Boring-milling center in bed design, i. H. the stand moves lengthwise, transverse and vertical, especially suitable for drilling, but also for light milling work.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- Universal milling head - Coolant device - hardened and ground guideways - automatic central lubrication - Table cladding - CE certification - Feeds infinitely variable - Digital display X-axis - infinitely variable speeds with 2 stages - Point/route control - Horizontal milling device - hydraulic tool feeder - Drive 11 kW - Year of construction 2001 specifications: workbench: - Table clamping surface: 1500 x 360 mm - Table load: 800 kg Travel: - X-axis longitudinal: 1000 mm - Y-axis transverse: 540 mm - Z-axis vertical: 430 mm workspace: - Distance spindle nose / table: 50 - 480 mm - Distance spindle center / stand: 350 mm Feeds: - Number of feeds: infinitely variable - Feed longitudinal / transverse: 16 - 1200 mm/min - Feed vertikel: 8 - 450 mm/min - Rapid path longitudinal / transverse: 2500 mm/min - Rapid speed vertical: 1000 mm/min - Feed motors:  ...

CNC bed milling machine make HURON type FXMachine -No: 890187 built in 1989Technical specifications:Working area X: 900 mmWorking area Y: 520 mmWorking area Z: 600 mmSpindle mount: ISA 40stepless speed range: 30 - 3150 mmTable size: 1000 x 700 mmmax.table load: 1300 kgTable height: 700 mmFeed rates X Y Z: 0 - 4000 mm / min.Feed force X Y Z: 5500 Nmax.feed force: 7700 NMotor power: 11 kWDimensions approx: 3000 x 2000 x 2500 mmWeight approx: 8000 kgWith- CNC control Heidenhain TNC 355- hydraulic tool clamping- hydraulic gear switchused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

x-travel: 950 mmy-travel: 400 mmz-travel: 500 mmtool taper: ISO 50 throat: 510 mmquill stroke: 105 mmspindle turning speed range: 18 - 1800 U/minfeeds: 16 - 627 mm/minrapid traverse: 1670 mm/mintable-size: 1400 x 400 mmtable load capacity: 500 kgT-slots: 3x14x100 mmdistance spindle /table: 150 - 650 mmengine output: 9,0 kWweight: 3660 kgdimensions of the machine ca.: 2290 x 1770 x 2120 mm current new price approx. 60.000 euros Special price on requestThe heavy universal bed milling machine offers wide guides and highDrive power for superior cutting performance and is with yourExtensive equipment ideal for plant and mechanical engineeringsuitable. The heavy vertical milling head can be swiveled right and left,The quill can be moved manually and the spindle speed can be adjusted continuously regulate. The feed in the Y and X axes can be done via a robustManual transmission can be varied. A ...

z-motion: 1,000 mm, x-motion: 1,400 mm, Drive power milling head: 11.5 kW, Accessories included: No, NC rotary table: No, y-motion: 800 mm, control: Heidenhain TNC426, table surface area l x w : 1800x700 mm, tool taper: SK50, turning speed range: 40 - 3000 rpm, rapid motion: 15 m/min, weight approx.: 10,000 kg, Approx. Onsite Dimension. (l x w x h): 4,000 x 2,800 x 3,150 mm

x-travel: 1050 mmy-travel: 330 mmz-travel: 475 mmspeeds: 35 - 1800 U/mintable surface area: 1525 x 325 mmnumber of feeds: 12 feed - longitudinal/cross: 20 - 920 mm/minfeeds vertical: 6 - 276 mm/mintool taper: ISO 40 total power requirement: 5,5 kWweight of the machine ca.: 2700 kgdimensions of the machine ca.: 2,5 x 2,5 x 2,2 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: X axis travel 2500 mm Y axis travel 1500 mm Z axis travel 1300 mm Table size 2600 x 700 mm SELCA control Serial number 036274 weight approx.: 22,000 kg, Approx. Onsite Dimension. (l x w x h): 5,000 x 4,600 x 3,500 mm

Description: X axis travel 2500 mm Y axis travel 1500 mm Z axis travel 1500 mm Table size 2400 x 740 mm SELCA control Serial number J8 weight approx.: 25,000 kg, Approx. Onsite Dimension. (l x w x h): 4,400 x 5,800 x 4,200 mm

Description: X axis travel 3000 mm Y axis travel 1500 mm Z axis travel 1500 mm Table size 2680 x 720 mm SELCA control Serial number 3403A00514 weight approx.: 25,000 kg, Approx. Onsite Dimension. (l x w x h): 5,900 x 5,000 x 3,900 mm

Basic features: X axis travel: 6.000 mm Y axis travel: 900 mm Z axis travel (vertical travel): 2000 mm automatic head index 2,5° spindle speed 3.300 rpm spindle taper ISO 50 stolle floor: 7000x1500 mm - nr. 6 T-slots rotary table B axis 360 positions - 5 ton load capacity CNC Heidenhain TNC 426 chip conveyor ATC 60 Total power: 60 kW - 380 V machine in excellent conditions, ready to work. NB: The aforementioned technical data, taken from the manufacturer's technical data sheet, are to be considered non-binding and subject to change without notice.

Inv. Num. : 6944 Type: CS 8 Producer: MECOF Created: 1981 Parameters: Control system: MECOF Work table length: 8000 mm Work table width: 965 mm X-axis travel: 6700 mm Y-axis travel: 1050 mm Z-axis travel: 1600 mm Machine weight: 16600 kg

Description: CNC Heidenhain TNC 426 X = 3000 mm Y = 1000 mm Z = 1000 mm Table 3200 x 1000 mm Universal milling head manual indexing Taper ISO 50 Spindle power 22 kW Continuous spindle speeds 40 à 2500 RPM Max. admitted load on table 11 Ton Working feeds 0 to 4000 RPM Rapids 8 m/min Max. power required 40 kW  ,weight approx.: 16,500 kg, Approx. Onsite Dimension. (l x w x h): 5,000 x 2,700 x 2,800 mm

Description: S/N: 0210050 Max. workpiece weight: 13000 kg Number of T-slots: 7 T-slot dimensions: 22 mm TEKNICALDA , TC 1 1/2-150 chip conveyor Note! Head broken, ,overhaul neededz-motion: 1,000 mm, x-motion: 4,000 mm, Drive power milling head: 30 kW, Accessories included: No, y-motion: 1,000 mm, control: Heidenhain TNC 426, table surface area l x w : 4200x1000 mm, tool taper: ISO50, turning speed range: 40 - 3000 rpm, feed range: 10,000 mm/min, rapid motion: 15 m/min, total power requirement: 40 kW, weight approx.: 18,000 kg, Approx. Onsite Dimension. (l x w x h): 10,000 x 4,235 x 2,790 mm

x-travel: 2500 mmy-travel: 800 mmz-travel: 800 mmcontrol: Heidenhain TNC 426 table weight: 3500 Kgtable-size: 2500 x 700 mmnumber of spindle speeds: 50-4000 U/min/rpmPower: 22 KWtaper ISO: 50 weight of the machine ca.: 10.500 kgdimensions of the machine ca.: 6605x3315x2730 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bed milling machine make NIIGATA type 2 UMBFabr. -No: 26064S5316 Year 1973Table clamping surface: 300 x 1370 mmTable movement lengthwise = X: 870 mmTable movement across = Y: 280 mmVertical movement of the milling head = Z: 380 mmmin/max. Distance between table and clamping surface: 50/430 mmDischarge of the milling head: 330 mmSpindle mount: ISA 50Milling head can be swiveled horizontally to vertically12 spindle speeds: 40-1750 rpm9 feeds longitudinal and transversal: 20-800 mm / minvertical: 9-355 mm / minRapid traverse longitudinal and transverse: 3 m / minvertical: 1375 mm / minSpindle drive 380 V: 3.7 kWFeed drive 380 V: 1.5 kWSpace requirement: 2780 x 1750 x 1800 mmWeight: 2400 kgWith- 3-axis digital display- Cooling deviceused, ready for operationPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are no ...

Universal bed milling machine make NIIGATA type 2 UMCMachine -No: 62950 Year 1986Table size: 1370 x 310 mmTable longitudinal path = X: 870 mmTransverse travel = Y: 370 mmVertical travel = Z: 400 mmDistance table to spindle: 50 - 450 mmSpindle mount: ISA 5012 spindle speeds: 40 - 1750 rpm.9 longitudinal and transverse feeds: 20 - 800 mm / min9 vertical feeds: 9 - 355 mm / minRapid traverse longitudinal and transverse: 3000 mm / minRapid traverse vertical: 1375 mm / minDrive power: 5.5 kWFeed motor: 1.5 kWDimensions L x W x H: 1825 x 2005 x 1745 mmWeight approx: 3000 kgWith- 3-axis digital display Anilam- Milling head can be swiveled from vertical to horizontalused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and  ...

Univ. Bed milling machine make NIIGATA type 3 UMAYear 1978Table surface: 1600 x 380 mmTable longitudinal path X: 1000 mmTransverse Y: 420 mmVertical path Z: 400 mmSpindle mount: ISA 5016 spindle speeds: 45 - 1400 rpm9 feeds longitudinal and transversal: 20 - 800 mm9 vertical feeds: 5 - 200 mmRapid traverse longitudinal and transverse: 3000 mm / minxa0xa0xa0xa0xa0xa0xa0xa0xa0xa0xa0xa0 vertical: 750 mm / minMax. Table load: 700 kgMax. Distance between stand / spindle: 470 mmMax. Distance table / spindle head: 70 - 470 mmDrive power: 11 kWWeight: 3.9 tExternal dimensions: 2245 x 2280 x 1830 mmused, despite the year of construction ingood conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.B ...

Description: X axis travel 2400 mm Y axis travel 800 mm Z axis travel 600 mm Table size 2500 x 700 mm SELCA 1200 control Serial number 044011 weight approx.: 28,000 kg, Approx. Onsite Dimension. (l x w x h): 4,200 x 4,100 x 4,600 mm

CNC controller: OSP-P300M Axes X-axis travel mm: 6.700 Y-axis travel mm: 4.100 Z-axis travel mm: 800 W-axis travel mm: 1.200 Distance spindle nose - table surface mm: 1.800 Rapid traverse m/min: X: 30; Y: 30; Z: 20 Feed rate mm/min: 1 to 10.000 Crossrail traverse m/min: 3 Worktable Table dimensions mm: 3.000x6.500 Max. workpiece weight kg: 37.000 Distance between columns mm: 3.650 T-slots: 24 H 7 x 15 Height from machine bottom mm: 950 Vertical spindle, 1º Extension attachment head, L150 Spindle speed rpm: 6.000 Spindle drive power kW: 26 90º Angular Head (Y-axis limitation exists) Minimum C-axis indexing angle: 1º Gear lubrication: Oil bath Spindle speed rpm: 3.000 Spindle drive power kW: 11 Universal index head (B-/C-axis) Minimum C-axis indexing angle: 1º Minimum B-axis indexing angle: 1º Gear lubrication: Mist Spindle speed rpm: 6.000 Spindle drive  ...

Fabr. Optimum, type Opti MT8, YOC 2012, serial no. J201204014, motor power vertical 5.5 kW, motor power horizontal 4.0 kW, vertical speed max. 4,660 rpm, horizontal speed max. 1,800 rpm, weight 2,200 kg, clamping table approx. 350x1,300 mm, three-axis digital display.

x-travel: 3000 mmy-travel: 1000 mmz-travel: 800 mmControl: Heidenhain TNC 155table surface area: 3200x1000 mmnumber of T-slots: 9 0: 100 mmT-slot - width: 22 mmmilling-head swivable +/-: 180 °spindle motor: 30 kWturning speeds: 20-2500 U/minFeed: 2-6000 mm/mintotal power requirement: 38,5 kWweight of the machine ca.: 16,500 tdimensions of the machine ca.: 7,5x3,55x3,2 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bed milling machine Manufacturer: SHW Werkzeugmaschinen Type: UF 5 Travel • X-axis: 2,500 mm • Y-axis (headstock vertical): 1,300 mm • Z-axis (headstock horizontal): 750 mm Control • CNC control: Heidenhain TNC 155 B Automatic swivel head (Switch between horizontal and vertical editing) Quill 120mm Milling spindle holder SK 50 Speed 2,500 rpm Mill table • Clamping area: 1500 x 800 mm About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is in the field of tool milling machines. Our services include, among other things, spare parts deliveries, on-site customer service, machine overhauls and control system modernizations. Performances: -Machines Ilbgjd8lvl -Spares -Customer service - Machine service - Machine overhauls - Control modernization _____ Second-hand machin ...

SHW UF 5 Travel • X-axis (rotary table): 1,500 mm • Y-axis (headstock vertical): 1,300 mm • Z-axis (headstock horizontal): 750 mm Control • CNC control: Siemens 3 M Conversion to Heidenhain TNC 415 possible Automatic swivel head (Switching between horizontal and vertical machining) Pinole 120mm Milling spindle holder SK 50 Speed 2500rpm Year of construction 1994 • Refurbished in 2016 Stepless NC rotary table • Backle PKTF 55 • Clamping surface: 1500 x 1250 mm About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH, is a freelance specialist for SHW machine tools. Our main task is in the field of machine tool milling machines. Our services include spare parts deliveries, on-site customer service, machine overhauls and control modernizations. Performances: - Used machines - Spare parts - Customer service - Machine service - Machine ov ...

x-travel: 3000 mmy-travel: 1350 mmz-travel: 1400 mmspindle taper ISO: 50 turning speeds: 22-1400 U/minRotary table: 800x600 mmTable dimensions: 2500x1200 mmFeed: 5-3000 mm/mintotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bed type milling machine SHW UF 6, new in 1977, control system Siemens

x-travel: 2500 mmy-travel: 1300 mmz-travel: 900 mmControl: Heidenhain iTNC 530 total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe machine was partially overhauled in 2007Overhaul Scope:Feed motors have been overhauledNew Heidenhain control iTNC 530 with newMain spindle drive (Siemens)Retention of the control cabinet and the VS drivesGeometric overhaul of the machineTool changer overhaulDefective guideway covers were repairedor exchangedNew liveryThe milling head was completely overhauled about 3 years ago.Furnishing:CNC path control Heidenhain iTNC 530Milling head can be swiveled horizontally/verticallyCNC rotary table 800 mm diameter45-fold tool changer, max. tool weight 18 kgchip conveyorReinforced coolant device for tools withinternal coolant supply, version B.Coolant device with paper band filtertraverse paths:Machine table along X-path 2500 ...

SHW UFZ 6 Rigid Stand Travel • X-axis (bed): 3,000 mm • Y-axis (vertical): 1,600 mm • Z-axis (headstock): 1,500 mm Control • CNC control: Heidenhain iTNC 530 Feed rate • X, Y and Z axes: rapid traverse = 8,000 mm/min Universal milling head in orthogonal design • Swivel range milling head mount: 340 x 1 degree • Swivel range milling head: 180 x 1 degree • Tool holder: SK 50 DIN 69871 • Speed range: 25 – 2,240 rpm Overhaul in 2010 • Year of construction 1992 Conveyor • Feed length: 3,000 mm Automatic tool changer • Magazine for 45 tools About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is in the field of tool milling machines. Our services include, among other things, spare parts deliveries, on-site customer service, machine overhauls and control system m ...

Traveling column milling machine SHW UniForce SHW Uniforce 6 (7-Achs) Traverse X / Y / Z Clamping area 10,000 / 3100/1600 mm 11,600 mm x 3,000 mm CNC attachment rotary table 2,500 mm x 2,500 mm maximum load 30,000 kg Control system: Heidenhain i TNC 530

Inv. Num. : 6079 Type: FSQ 80 CNC Producer: TOS Created: 1990 Parameters: Control system: NS 720 Work table length: 3000 mm Work table width: 800 mm Maximum table load (uniform): 1000 kg X-axis travel: 3000 mm Y-axis travel: 1000 mm Z-axis travel: 1000 mm Total power requirement: 40 kW Spindle speed: 2500 1/min Machine height: 3400 mm Machine length: 7770 mm Machine width: 4360 mm Equipment: Tool Holder

x-travel: 3000 mmy-travel: 800 mmz-travel: 1000 mmControl: Heidenhain type: TNC 155 table surface area: 3000x800 mmturning speeds: 2000 U/minspindle taper ISO: 50 total power requirement: kWweight of the machine ca.: 16 tdimensions of the machine ca.: 7,8x3,85x3,1 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Horizontal milling machine / horizontal bed milling machineMake VEB HECKERT type FBEW 630x2000Fabr. -No: 353514, built in 1977Technical specifications:Table size: 2000 x 650 mmTable width: 750 mmMachining length X: 2000 mmMachining length Z: 800 mmConnected load: 24 kWExternal dimensions L x W x H: 5300 x 2250 x 2530 mmControl cabinet: 1000 x 850 x 1800 mmWeight approx: 7.5 twith- retractable quill- separate control cabinet- rapid traverse- Emergency stop switchused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

Machine Type: Vertical Bed Milling Machine Manufacturer: WAGNER Model: BVT 1270 2 VS Year of construction: 2012 Condition: excellent Type of offer: used machine Specifications Table: 1270 x 400 mm Range: 70 - 3800 rpm. infinitely variable, 2 gear ranges Spindle mount: SK 40 Travel range: x = 1000 mm y = 480 mm z = 590 mm Propulsion: 3.75 kW Remark; with swivelling milling head and drill quill with automatic feed, 4-axis digital display, automatic tool clamping, infinitely variable feed rate and rapid traverse in x/y/z, ball screws in x/y/z, automatic central lubrication, coolant device, Machine light, Machine feet Weight: 2400 kg The machine is in excellent condition and ready for immediate use and can be viewed and demonstrated with us. We would be pleased if you are interested in our offer. Subject to errors, changes and prior sale.

Fixed bed milling machine Zayer 2000BF. Table: 2500x700mm. Longitudinal travel: 2000mm. Cross travel: 1000mm. Vertical travel: 1000mm. ISO50. Speeds: 18. (28-1800rpm). Power: 15cv. Weight: 13000Kgs. Equipped with DRO Fagor.
