DMG used machine for sale

Key data: 880 mm, 600 mm, 580 mm

with CNC control, Fabr. HEIDENAIN, Type: ITNC530, Travels: X-axis: 880 mm, Y-axis: 600 mm, Z-axis: 580 mm, Table diameter: 600 mm, Dimensions: 1000x600 mm, with autom. Tool changer, with 60 tool positions, tool holder: SK40 and HSK63, IKZ cooling system, fleece filter system, chip conveyor and 2 pcs. clamping devices, Fabr. HILMA

Key data: 750 mm, 650 mm, 560 mm

with CNC control, Fabr. HEIDENAIN, Type: TNC640, Travels: X-axis: 750 mm, Y-axis: 650 mm, Z-axis: 560 mm, Table diameter: 650 mm, Dimensions: 800x650 mm, max. 18,000 rpm, with autom. Tool changer, with 60 tool positions, tool holder: SK40-HSK63-BT40-CRT40, IKZ cooling system, fleece filter system, Fabr. BMF & Chip Conveyor

Key data: 12 mm, 12 mm, 3200 mm

MG Gildemeister CNC longitudinal lathe SPEED 12-5 linear Year of manufacture 2004 DMG (now DMG MORI) is a high-precision CNC lathe specially designed for machining small workpieces. It belongs to the category of Swiss automatic lathes and offers excellent dynamics and accuracy thanks to the linear actuator technology. Machine number: 2001-0129 Machine duty cycle: 145113 hours Machine automatic: 117208 hours Customs tariff number / commodity tariff number: 84581141 Manufacturer: DMG Gildemaster Country of manufacture: Italy CNC control FANUC 16i-TB with 5 axes CE Declaration of Conformity Specifications - Number of axes : 5 - Number of spindles : 2 X1 axis: Transverse movement of the main slide (main spindle). Z1 axis: Longitudinal movement of the main slide (main spindle). Y1 axis: Vertical movement, often for eccentric machining. X2 axis: Transverse movement of the sub- ...

Spindle: Motor spindle technology Speed 12,000 rpm Power 15 kW Torque 130 Nm Tool holder SK40 NC swivel head: B-axis 0.001° Swivel range -91°/+12 NC rotary table: C-axis 360° Clamping surface ø800 mm Table load (max.) 500 kg General: Tool magazine 32 stations Clamping surface rigid table 1,250 x 700 mm Rapid traverse in X/Y/Z 30 m/min Equipment/accessories: Chip Management Chip Conveyor Coolant management IKZ system with paper belt filter, 20 bar Workpiece Measurement Probe, Heidenhain TS642 Setup operation Electronic handwheel Further equipment ROTO-Clear

Spindle: Motor spindle technology Speed 18,000 rpm Power 28 kW Torque 121 Nm Tool holder HSK-A63 NC swivel head: B-axis 0.001° Swivel range -10°/+180° NC rotary table: C-axis 0.001° Clamping area ø1,250 x 1,100 mm Table load (max.) 1,500 kg General: Tool magazine Chain magazine with cone cleaning station, 120 stations Rapid traverse in X/Y/Z 60 m/min Equipment/accessories: Displacement measuring system directly in X/Y/Z Chip Management Chip Conveyor Coolant management IKZ system with paper belt filter and high pressure, 40/80 bar Workpiece Measurement Infrared Probe, Heidenhain Tool Measurement Laser Emulsion Mist Extraction Mechanical Process Observation Operating Mode 4 Setup operation Electronic handwheel Other equipment ROTO-Clear, rinsing gun

Spindle: Motor spindle technology Speed 18,000 rpm Power 28 kW Torque 121 Nm Tool holder HSK-A63 NC swivel head: B-axis 0.001° Swivel range -120°/+30° NC rotary table: C-axis 0.001° Clamping surface ø800 mm Table load (max.) 500 kg General: Tool magazine 24 stations Rapid traverse in X/Y/Z 30 m/min Clamping surface rigid table 1,250 x 700 mm Equipment/accessories: Displacement measuring system directly in X/Y/Z Chip Management Chip Conveyor Coolant Management KSS Pump Workpiece Measurement Infrared Probe, Heidenhain TS640 Tool Measurement Laser, BLUM Process Observation Operating Mode 4 Setup operation Electronic handwheel Other equipment Rinsing gun

General: Built in 1999 Control Heidenhain TNC 430 Travel X/Y/Z 1,800/2,000/1,100 mm Spindle speed 8,000 rpm Tool holder HSK 100 Spindle: Motor spindle technology Speed 8,000 rpm Power max. 30 kW Torque max. 286 Nm Tool holder HSK 100 NC swivel head: Technology Automatic Swivel Milling Head B-axis 0° / 180° NC rotary table: C-axis 360° Clamping area 1,700 x 1,400 mm Table load max. 5,000 kg Tool magazine: Technology Chain Magazine Number of stations 60 pieces Tool Changer Double Gripper Tool length max. 450 mm Tool diameter max. 110 (230) mm Equipment / Accessories: Displacement measuring systems Directly in all axes Chip disposal chip conveyor Coolant supply IKZ system, 40bar Tool Measurement BLUM Laser Workpiece Measurement Infrared Probes Setup operation Electronic handwheel Process Observation Operating Mode 4 Emulsion Mist Separator Elect ...

TOOL PRESETTER DMG MICROSET UNO 20/40 Year of Make: 2015 Travel Z: 400 mm Travel X : 50 - 200 mm Measuring range: 400 mm Max. tool weight: 200 kg EXISTING TOOL HOLDERS: SK 50/REF BRAND SK50/SK40 SK 50/HSK 63 SK 50/VDI 30

Inv. Num. : 8173 Type: DMU 75 monoBLOCK Producer: DMG Created: 2021 Parameters: Control system: Heidenhain TNC 640 Switch-on hours: 12182 h Hours: 7319 h Work table length: 800 mm Work table width: 650 mm Number of Stacking Positions: 60 pieces Number of axles: 5 pieces Maximum spindle speed: 20000 1/min X-axis travel: 750 mm Y-axis travel: 650 mm Travel Z-axis: 560 mm Spindle power: 35 kW Cone: SK 40 Equipment: Workpiece Probe Tool probe 3D quickSET

Inv. Num. : 8008 Type: DMG DMU 50 eco Producer: Deckel Maho Gildemeister Created: 2010 Parameters: Control system: Siemens Sinumerick 810D Switch-on hours: 56933 h Operating hours: 25670 h Number of axles: 5 pieces Number of stacking positions: 16 Maximum spindle speed: 8000 1/min X-axis travel: 500 mm Y-axis travel: 450 mm Travel Z axis: 400 mm Equipment: ShopMill

Manufacturer DMG Model DMU 50 eVo linear Year 2008 3D CNC control HEIDENHAIN iTNC 530 Table NC Rotary Table INCLUDED Table surface 500×380 mm. Maximum weight on table 500 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) 108º Direct Measurement System INCLUDED Routes and advances Longitudinal travel (X-axis) 500 mm Cross travel (Y-axis) 450 mm Vertical travel (Z-axis): 400 mm X-axis fast feed 80,000 mm/min Fast forward Y-axis, Z 50,000 mm/min Fast forward B, C axes 18,000 mm/min Number of Controlled Axles 5 Head Head speed 18,000 r.p.m. BT-40 Head Cone Main Motor Power 30 kW Equipment Automatic tool loader INCLUDED No. of positions in tool loader 30 Internal cooling 40 Bar INCLUDED Coolant tank with paper filter INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel Other Total installed power 52 kVA Machine ...

Manufacturer DMG Model DMU 50 eVo linear Year 2008 3D CNC control HEIDENHAIN iTNC 530 Table NC Rotary Table INCLUDED Table surface 500×380 mm. Maximum weight on table 500 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) 108º Direct Measurement System INCLUDED Routes and advances Longitudinal travel (X-axis) 500 mm Cross travel (Y-axis) 450 mm Vertical travel (Z-axis): 400 mm X-axis fast feed 80,000 mm/min Fast forward Y-axis, Z 50,000 mm/min Fast forward B, C axes 18,000 mm/min Number of Controlled Axles 5 Head Head speed 18,000 r.p.m. BT-40 Head Cone Main Motor Power 30 kW Equipment Automatic tool loader INCLUDED No. of positions in tool loader 30 Internal cooling 40 Bar INCLUDED Coolant tank with paper filter INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel Other Total installed power 52 kVA Machine ...

Manufacturer DMG Model DMU 50 eVo linear Year 2008 3D CNC control HEIDENHAIN iTNC 530 Table NC Rotary Table INCLUDED Table surface 500×380 mm. Maximum weight on table 500 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) 108º Direct Measurement System INCLUDED Routes and advances Longitudinal travel (X-axis) 500 mm Cross travel (Y-axis) 450 mm Vertical travel (Z-axis): 400 mm X-axis fast feed 80,000 mm/min Fast forward Y-axis, Z 50,000 mm/min Fast forward B, C axes 18,000 mm/min Number of Controlled Axles 5 Head Head speed 18,000 r.p.m. BT-40 Head Cone Main Motor Power 30 kW Equipment Automatic tool loader INCLUDED No. of positions in tool loader 30 Internal cooling 40 Bar INCLUDED Coolant tank with paper filter INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel Other Total installed power 52 kVA Machine ...

Inv. Num. : 8243 Type: DMU 60 P Producer: DMG Generated: Parameters: Work table length: 1000 mm Work table width: 600 mm Number of axles: 5 pieces X-axis travel: 600 mm Y-axis travel: 525 mm Travel Z axis: 500 mm Speed: 12000 1/min Machine weight: 4000 kg

Manufacturer DMG-MORI Model DMF 260 Year 2011 CNC SIEMENS SINUMERIC 840D Table Table dimensions 2,900 x 700 mm. Max workpiece weight 2.150 kg. Tavels and feeds Longitudinal traverse (X Axis) 2,600 mm Cross traverse (Y Axis 700 mm Vertical traverse (Z Axis) 700 mm Rapid traverse axis (X,Y,Z) 40 m/min Feed rate (X/Y/Z) 40 m/min Acceleration in the axis 4 m/s2 Main Spindle Turning speeds 14,000 mm/min Taper SK 40 DIN 69872 Spindle power 18.4 / 14 kW Automatic tool changer ATC Positions 30 Max. tool length 300 mm Max. tool weight 6 kg. Max. tool diameter with free neighboring places 130 mm Max. tool diameter without free neighboring places 80 mm Equipment Internal coolant 40 Bar / 600 l INCLUDED Longitudinal chip conveyor INCLUDED Cleaning gun INCLUDED Portable handwheel INCLUDED Direct measuring system INCLUDED Machine hours Machine power on hours 18.859 ...

Manufacturer DMG Model DMU 160P Year 2002 CNC HEIDENHAIN iTNC-530 Table Table surface 1,500 x 1,250 mm. Max weight allowed on table 4,000 kg. Table turning range (C Axis) 0.001 º (Continuous) Travels and feeds Longitudinal travel (X Axis) 1,600 mm. Cross travel (Y Axis) 1,250 mm Vertical travel (Z Axis) 1,000 mm. Horizontal/Vertical Auto Indexing Head (A Axis) 0.001º (Continuous) Rapid Traverse 60,000 mm/min Spindle taper SK-40 DIN 69871 Spindle speed 20-18,000 rpm Main spindle power 28 kW Equipment Automatic tool changer INCLUDED ATC positions 60 Coolant deposit capacity 200 l. HEIDENHAIN optical scales INCLUDED Chip conveyor INCLUDED Portable handwheel HEIDENHAIN HR-410 3D-Rot INCLUDED Tool touch probe INCLUDED M-function for internal / external lubricant INCLUDED Ready for internal coolant INCLUDED Mode 4 operation INCLUDED Others Positioning precis ...

Inv. Num. : 8183 Type: DMU 100T Producer: DMG Created: 2001 Parameters: Control system: HEIDENHAIN Work table length: 1500 mm Work table width: 795 mm Speed: 10000 1/min X-axis travel: 1080 mm Y-axis travel: 710 mm Z-axis travel: 710 mm Machine weight: 9700 kg

Key data: 835 mm, 510 mm, 510 mm

Fully Functional CNC Milling Machine Machining Center Vertical DMG DMC 835 V Year of construction 2006 Control: SINUMERIK 840 D Powerline Spindle speed: 12,000 rpm Spindle motor: 14 kW X - Travel: 835 mm Y - Travel: 510 mm Z - Travel: 510 mm A-axis: available Rapid traverse: 30 m/min Tool holder: SK 40 Tool changing device: 30 Table load: 800 kg Clamping area: 1,000 x 560 mm Operating hours: 49,660 | 12,902 h (30.01.2025) Footprint of the machine: 2,100 x 2,700 mm Machine weight: approx. 4,200 kg Equipment SIEMENS 840D ShopMill Linear scales Electronic handwheel IKM – 25 bar / 30 l/min Conveyor Canopy Location of the machine: 76661 Philippsburg The machine can be viewed on site at any time. This is always desired. We would love to hear from you.

Manufacturer DMG Model DMU 65 monoBLOCK® Year 2012 3D CNC CONTROL HEIDENHAIN TNC 530 Table Table surface 800 x 650 mm. Tilting rotary table INCLUDED Tilting rotary table diameter Ø650 mm. Maximum weight on table 600 kg Table rotation (C-axis) 0.001º (±360º) Oscillation field (B-axis) -120 +120º Direct Measurement System INCLUDED Maximum part diameter 840 mm. Max workpiece height 500 mm. Routes and advances Travels(X/Y/Z) 735/650/560 mm. X, Y, Z axis fast feed 40,000 mm/min Work progress X, Y, Z axis 40,000 mm/min Head Head speed 24,000 r.p.m. HSK-A63 Head Cone Main motor power 24 kW Equipment Tool Charger INCLUDED No. of positions in tool loader 60 Internal cooling 40 Bar INCLUDED Tank with 500l paper filter INCLUDED Active Cooling Control Cabinet INCLUDED Heidenhain Infrared Measurement Probe Part INCLUDED Blum Laser Probe Measurement Tool INCLUDED ...

:::TECHNICAL SPECIFICATIONS::: CNC model: Heidenhain - CNC version: iTNC 430 - Tool holder: HSK 63 - Spindle power: 15Kw Number of spindle speeds: 18000 - Number of tools: 32+32 - X-axis travel: 2050mm - Y-axis travel: 520mm - Z-axis travel: 520mm Table dimensions: 1000 x 600mm Guides: roller Partition for pallet change: yes Swivel rotary table: yes Swivel rotary table type: continuous Swivel rotary table degrees: 0° - 180° Table size: 700 x 500mm High refrigerant pressure: yes Pressure value: 70bar External tank system with filter: yes Chip conveyor: belt Presetting: yes Machine equipment: Ethernet card Heidenhain TT 120 touch probe

Manufacturer DECKEL MAHO Type DMC 104 V linear Year of construction 2008 Control Heidenhain TNC 530 Tool holder SK40 x-travel 1040mm Y-travel: 600mm z-travel 500mm Speed range 12,000 rpm Max. table load 800 kg Table size 1250x600 mm Number of tools in the magazine 30 pcs. Inner coolant supply yes

Manufacturer: DMG Type NEF 400 Year of construction 2009 Control Siemens 840 D Machine weight approx. 3 t Tool holder VDI 30 Speed range 3500 1/min Turning diameter 350 mm Turning length 700 mm Chuck diameter 210 mm Tool turret - seats 8 pl. Spindle bore 52 mm

Spindle speed (max.): 12,000 rpm Equipment: Documentation/Manual Fully functional Sensor cable and tool changer new

Key data: 1250 mm, 880 mm, 800 mm

Control Heidenhain MillPlus Travel x/y/z 1,250 mm / 880 mm / 800 mm Spindle speed range 20 – 12,000 rpm Drive power of the main spindle without gearbox 10 kW Tool holder / swivel of the main spindle SK 40 / A: +45°/-30° Table diameter / max. table load 1,000 mm x 1,250 mm / 2 t NC – rotary table - B-axis / table speed range 360° / 0.001° / 8.1 rpm Number of tool positions in the chain magazine 60 Power requirement / machine weight / IKZ 44 kVA / 12.5 t / 40 bar Accessories: Chip conveyor Remarks: The main spindle was renewed in 2021, machine after Arrangement ready for demonstration, about 120,000 hours of viewing

Manufacturer: DMG Type: Sprint 42/10 Linear Year of Make: 2014 Technical data working space Max. travel X-axis: 50 mm Max. travel Y-axis: 350 mm Max. travel Z-axis: 120 mm Workpiece Max. workpiece diameter: 42 mm Max. workpiece length: 320 mm Max. bar passage: 42 mm Control: Fanuc Basic functions Sub-spindle Y-axis Accessories Bar Feeder Säneförderer Tool Holder Condition Perfect Availability Immediately after payment Terms and conditions of purchase: no guarantee, no warranty, no return Terms of delivery: Ex-works Terms of payment: 100% prepayment

CONTROL .. CNC Control HEIDENHAIN TNC426 WORKSPACE -CUBIC- .. Number of machining axes (without parallel axes): 3 .. X-axis travel: 500 mm .. Y-axis travel: 400 mm .. Travel Z-axis: 400 mm TABLE .. Clamping surface (left-right): 700 mm .. Clamping surface (front-rear): 500 mm SPINDLE / HEAD .. Speed range up to: 9000 rpm .. Tool holder: ISO SK 40 TOOL MAGAZINE .. Number of tool positions: 16 ELECTRICAL CONNECTION DATA .. Connection voltage: 400 V .. Mains frequency: 50 Hz DIMENSIONS / WEIGHTS Bsicvzmv7Vm .. Space requirement -left/right-: 5000 mm .. Space requirement -front/rear-: 3700 mm .. Total height: 2500 mm .. Total weight approx.: 4500 kg

x-travel: 350 mm y-travel: 240 mm Ucblcnl2H9 z-travel: 340 mm Speed: 20 - 4,500 1/min Table: D 400 x 280 Control: 810 D Shop mill SIEMENS Tool holder: SK 40 Rapid traverse: 5 m/min Spindle: 6.3 / 10 kW Total connected load: 15 kVA Approx. space requirement: 1.7 x 1.55 x 2.1 m Universal CNC Milling Machine, Rotary swivel table manual with angle display on the screen, El. Handwheel

Number of axes: 5 Feed speeds in the X/Y/Z axis: 500/420/380 mm Feed rates in the C/B axes: 180°/360° Dimensions of the work table (L x W): 500 x 380 mm Maximum workpiece weight: 350 kg Spindle power: 15 kW Maximum spindle speed: 18000 rpm Tool magazine capacity: 30 pcs. Overall dimensions (L x W x H): 3360 x 2550 x 2600 mm Total weight of the DMU 50 eVolution machine: 6000 kg

With Indumatik Automation x-travel 500mm Y travel 450mm z-travel 400mm Control Siemens 810 D Shopmill Main spindle: Speed Range - Main Spindle ((( 20 - 8,000 )))min/-1 Drive power - main spindle 13 / 9kW Tool holder SK 40 Max. torque 83Nm NC rotary table: Table clamping area 630 x 500mm Max. table load 200kg Swivel range -5 / +110° Rotation range 0.001° T-slots 7x 14 x 63mm Tool magazine: Number of tool locations 16pos. max. tool weight 6kg max. tool diameter 80mm max. tool diameter. with a free neighboring box. 130mm max. workpiece length 300mm Feeds: Rapid traverse 12m/min Feed force 4.5kN Feed speed 1 - 12,000mm/min Total power requirement 18kW Machine weight approx. 5.0t Space requirements approx. 4.5 x 3.5 x 2.3m

x-travel: 350 mm y-travel: 240 mm Ucblcnl2H9 z-travel: 340 mm Speed: 20 - 4,500 1/min Table: D 400 x 280 Control: 810 D Shop mill SIEMENS Tool holder: SK 40 Rapid traverse: 5 m/min Spindle: 6.3 / 10 kW Total connected load: 15 kVA Approx. space requirement: 1.7 x 1.55 x 2.1 m Universal CNC Milling Machine, Rotary swivel table manual with angle display on the screen, El. Handwheel
