Excellent condition - Fully operational - Loading / Transport possible! working area swing diameter: 185 mm slide travel X: 235 mm slide travel Z: left 270 mm; right 680 mm part size chuck parts workpiece diameter: up to 160 mm length (external machining): up to 186 mm bar parts workpiece diameter: up to 65 mm length (external machining / external machining): left 188 / 115 mm; right 160 / 115 mm headstock spindle connection DIN 55026, size: A6 spindle outer diameter in front bearing: 100 mm spindle bore: 73 mm passage in the draw tube / bar diameter: 66 / 65 mm data of the main spindle power: left 12 kW; right 9 kW max. torque: left 193 Nm; right 140 Nm speed range: 0 - 4.000 rpm speed control: stepless acceleration time 0 - 4.000 incl. chuck: 3 sec. feed drives AC motors in X and Z axis feed force Z-axis: 7,000 N feed force X-axis: 7,000 N rapid t ...
FANUC 18i-TF control, double spindle, travel X/Y/Z = 160/+40/-30/510 mm, 12-cavity tool change turret with driven tools VDI 25, speed max. 6,000 rpm, material ejection, remote control, TOP etl 8-50 bar feeder in front, BJ 2018, S/N 95692, L = 5,000 mm, RITTAL control cabinet, remote control
Key data: 350 mm, 250 mm
FANUC 18i-TB control, double spindle, travel X/Y/Z = 160/+40/-30/510 mm, 12-cavity tool change turret with driven tools VDI 25, speed max. 6,000 rpm, material ejection, remote control, TOP etl 8-50 bar feeder in front, year 2011, S/N 92230, L = 5,000 mm, RITTAL control cabinet, remote control
Control SIEMENS SINUMERIK 828d, travel distances X/Y/Z = 350/250/300 mm, weight 2,030 kg, RITTAL control cabinet, 24-fold tool changer SK30, rigid groove clamping plate, chip conveyor KABELSCHLEPP, coolant device
FANUC Oi-TF control, remote control, single-spindle, speed max. 6,300 rpm, power 13 kW, 12-fold tool changer with driven tools (VDI 25), material ejection, max. turning length/diameter = 670/220 mm, max. passage 45 mm, control cabinet RITTAL, spec. W/h = 6,500
FANUC Oi-TD control, remote control, single-spindle, speed max. 6,300 rpm, power 13 kW, 12-fold tool changer with driven tools (VDI 25), material ejection, max. turning length/diameter = 670/220 mm, max. passage 45 mm, control cabinet RITTAL, spec. W/h = 16,500
GE-FANUC Oi-TC control, remote control, single-spindle machine, speed max. 6,300 rpm, power 13 kW, 12-fold tool changer with driven tools (VDI 25), material ejection, max. turning length/diameter = 670/220 mm, max. passage 45 mm, control cabinet RITTAL, spec. W/h = 23,500
FANUC 31iB control, power 29 kW, main and counter spindle, spindle speed max. 5,000/7,000 rpm, travel distances X/Z = 260/610 mm, 12-fold tool change turret with driven tools (VDI 40), max. turning diameter/turning length = 320/550 mm, workpiece ejection, discharged. Operating hours 320 hours, NOTE: The machine was not used in production and is almost as good as new!
The machine is in good technical condition, testing is possible by prior arrangement.
The machine is in good technical condition, after prior agreement it is possible to test it. 0 Baumuller ball screws, spindle diameter 60 mm, SK 40, power 5.5kw/11 kW, torque 100Nm. Rotary tool changer 12. 3 axes and 4th axis only control board without 4th axis table..
Lathe beds, unused Compakt 5 , Compakt 8, Compakt 11, Super 11, Interchangeable Wheels , Other EMCO Parts: Clamping tables, angle tables, steady rests, lathe spindles, milling spindles, ...
To mediate on behalf of the customer. Used machine Machine Type: CNC Double Turning Center Model: EMCO TURN 420MCplus Manufacturer: EMCO Control: Siemens 840D First commissioning: 2005 #009338 Location: Poland Control Siemens 840D Turning length 120 mm Turning diameter100 mm Number of axes 2x3 Spindle speed 5000 rpm The above information was provided to us by the seller and must be checked during inspection. This offer is subject to change and non-binding. Changes, errors and prior sale expressly reserved.
Main spindle: Technology: Motor spindle Speed: 4,000 rpm Power (max.): 29 kW Torque (max.): 250 Nm Bar Passage: 76 mm Sub-spindle: Technology: Motor spindle Speed: 5,000 rpm Power (max.): 29 kW Torque (max.): 250 Nm Ejector: Pneumatic Travel in Z: 800 mm Tool carrier I (X/Y/Z): Technology: 12-station turret Tool holder: VDI30 Tool drive: 5,000 rpm, 6.7 kW, 25 Nm Travel in X/Y/Z: 260/100/800 mm Rapid traverse in X/Y/Z: 30/12/30 m/min Tool carrier II (X/Z): Technology: 12-station turret Tool holder: VDI30 Tool drive: 5,000 rpm, 6.7 kW, 25 Nm Travel in X/Z: 210/800 mm Rapid traverse in X/Z: 30 m/min Equipment/accessories: Chip management: Chip conveyor Coolant management: IKZ system with paper belt filter and high pressure, 40 bar Raw material feed I: Robot interface prepared Raw Material Feed II: Bar Feeder Interface Prepared Finished part removal ...
Emco F3 - Milling Machine - Vise - Workplace lighting - Coolant device - Tools & Machine Feet Technical data Working Range: - Slide path longitudinal: 300 mm - Slide path transverse: 200 mm - Vertical slide path: 350 mm - Quill stroke for vertical milling spindle: 45 mm - Vertical milling head swivel: ± 90 ° Clamping surface: - Table dimensions: 600 × 200 mm - 4 T-slots: 12 x 21 mm - Groove spacing: 45 mm Spindle: - Tool holder: DIN 2078 / SK30 - Tool clamping: Pull-out screw M12 - Spindle speeds: 80 / 160 / 245 / 360 / 490 / 720 / 1100 / 2200 rpm Automatic feed for longitudinal slides: - Feed force: 1600 N (160 kp) - Speed: 20 - 200 mm/min (infinitely variable) - Rapid traverse: 1200 mm/min Coolant Facility: - Tank capacity: 30 l - Flow rate: 15 l/min Three-phase motor: - Power: 1.1 / 1.4 kW (60% ED) - Speed: 1400 / 2800 rpm Dimensions: - Dimensio ...
Key data: 330 mm, 850 mm, 190 mm
Circumferential diameter over bed / support 330 / 190 mm Center width 850 mm Bore 36 mm Speed range 60 - 2400 1/min Tailstock quill MK 3 / stroke 100 mm incl. accessories: 4-fold holder, chip back panel, T-slots in cross support Tightening tube for collets (New machine was designed according to DIN 8605)
Inv. Num. : 9029 Type: TURN E65 Producer: EMCO Created: 2008 Parameters: Control system: FANUC Max. turning diameter: 500 mm Maximum turning diameter over bed: 610 mm Maximum length of travel in the X-axis: 210 mm Maximum length of travel in the Y-axis: 40 mm Maximum feed in the Z-axis: 610 mm Weight: 6500 kg
CNC machining center Emco, type VMC 600, built in 1998 incl. handwheel + 3 vices with clamping device
Tool milling machine Emco FB3 Movements in X-Y-Z = 300-200-350 mm spindle with quill ISO-30 ISO-30 horizontal spindle Angle head swivels by ±90° Feed and rapid traverse in X and Y Angle table 600 x 180 mm Digital display Heidenheim ND780 Year of Make: 2006 Cleaned and tested
EMCO Hyperturn 45 - CNC lathe - Main spindle equipped with full-clamping cylinder (operation with bar feeder not possible or loading and unloading via automatic. Swivel loader, see video) - Year of construction 2011 Technical data Working Range: - Maximum circumferential diameter over bed: 430 mm - Circumferential diameter over face slide: 300 mm - Maximum turning diameter: 300 mm - Maximum part length: 480 mm - Maximum bar passage: 45 mm - Distance main spindle - counter spindle (spindle lugs): 720 mm Carriage travel range: - Carriage travel X / X2: 160 / 150 mm - Carriage travel Z / Z2 / Z3: 510 / 510 / 510 mm Main spindle (spindle 1): - Spindle connection - DIN 55026: KK 5 - Spindle bore: 53 mm - Spindle bearing (inner diameter): 85 mm - Maximum mass inertia for clamping device and workpiece: 0.08 kgm² Main spindle clamping system: - Hollow clamping cylinder ...
For sale Emco CNC double spindle lathe type Hyperturn 45. A very complete CNC lathe with left and right spindle, as well as an upper and lower turret. Both turrets have driven tool positions! The upper turret also has a Y-axis with 70 mm travel. Tool holder attachment VDI25, rod capacity left spindle is Ø 45 mm, maximum speed 7,000 rpm. Maximum diameter is Ø 300 mm. Maximum part diameter is 480 mm. The distance between the two spindles is 720 mm. Fanuc 18i-TB control. The machine is equipped with high pressure pump, chip conveyor with right ejection, parts catcher, manual collet devices, etc. Available from stock, subject to prior sale. The machine has a light layer of soot. This can be easily removed.
Inv. Num. : 8871 Type: Emcomill E 1200 Producer: EMCO Created: 2011 Parameters: Control system: Fanuc Switch-on hours: 28317 h Operating hours: 12114 h Work table length: 1340 mm Work table width: 650 mm Maximum table load (uniform): 1500 kg X-axis travel: 1200 mm Y-axis travel: 610 mm Travel Z axis: 500 mm Machine height: 3060 mm Machine length: 3200 mm Machine width: 3350 mm Machine weight: 10000 kg 2025: New Z-axis motor Spindle overhaul
Control Heidenhain TNC 620 Travel X/Y/Z: 350 x 250 x 300 mm Spindle speed 12,000 min-1 Round and swivel table Tool magazine for 20 Wkz. ISO 30 Chip conveyor LANG Automation EcoCompact 10 Approx. 100 tool holders ISO 30
With C axis Swing over bed Ø 610 mm Swing over slide Ø 360 mm Distance between centers on tailstock version 682 mm Maximum turning diameter Ø 500 mm Maximum part length 520 mm Maximum bar diameter Ø 65 Travel in X / Z 260 / 610 mm Spindle speed 5000 rpm Number of tool on turret 12 Tool holder type VDI30 Controller FANUC Oi TF
Key data: 340 mm, 2000 mm
Emco Emcomat E-300 2-Axis Teach-In/Cycle-Controlled CNC Lathe CNC control Fagor 8055 i Power TC Turning diameter 340/570 mm Turning length 2000 mm Center height 275 mm Spindle diameter 108 mm Spindle nose D 1-8 Spindle speed 0-2,500 rpm X-axis travel 310 mm Travel Z-axis 2000 mm If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other ads for a full overview of our stock.
The machine is in good technical condition, testing is possible by prior arrangement. control system: SINUMERIK 828D Movement in X/Y/Z axes: 1200 / 600 / 500 mm Distance between table and spindle end: 100 - 600 mm Number of axes: 3 Rapid traverse in X/Y/Z axes: 30 m/min Working feeds X/Y/Z: 0 - 15 m/min Clamping area: 1300 x 630 mm Maximum table load: 1500 kg Tool change Number of tool stations: 30 Maximum tool diameter: 80 mm Milling spindle Maximum speed: Mechanical spindle 10,000 rpm, motor spindle 15,000 rpm Maximum torque: mechanical spindle (S6) 100 Nm, motor spindle (S6) 100 Nm Dimensions (length x height x width): 3370 x 2950 x 3000 mm Machine weight: 12000 kg
Operating hours: 600h Specifications: Travel in X/Y/Z: 450 / 350 / 400 mm Distance from spindle nose table: 230 - 630 mm (horizontal milling spindle) Rapid traverse speed X/Y/Z: 5000 / 5000 / 5000 mm/min Working feed X/Y/Z: 10 - 2000 mm/min infinitely variable Max. feed force in X/Y/Z: 10 / 10 / 15 kN Clamping surface: 800 x 400 mm (rigid angle table) Max. table load: 30 kg (rigid angle table) Vertical milling head: Speed range: 10 - 5000 1/min Power: 10 kW Dimensions (LxWxH), approx.: 1980 x 2030 x 1990 mm Weight, approx.: 2270kg Equipment: - Swivel control panel - Shafts and gears hardened and ground - Digital display Sinumerik 828D - Clockwise / counterclockwise rotation of the main spindle - Linear guides - Four-bearing milling spindle radial/axial - All pinch points eliminated by covers - Main motor with spindle brake
Inv. Num. : 8736 Type: TURN E65 Producer: EMCO Created: 2018 Parameters: Control system: SIEMENS Max. turning diameter: 500 mm Maximum turning diameter over bed: 610 mm Maximum length of travel in the X-axis: 210 mm Maximum length of travel in the Y-axis: 40 mm Maximum feed in the Z-axis: 610 mm Maximum main spindle power: 22 kW Maximum spindle speed: 5000 1/min Max. rod diameter: 65 mm Length: 3335 mm Width: 2315 mm Height: 2450 mm Weight: 6500 kg
Key data: 500 mm, 744 mm
CNC turning-milling center with swivel spindle With this equipment, hardly anything is left to be desired Manufacturer : Emco Type: Hyperturn 665 Plus Power Mill Control : Siemens 840 Year of manufacture : 2006 Duty cycle hours : 56000 h Spindle hours : 22722 h Availability : from stock Hultsfred / Sweden , to be visited under power Video : ww.youtu.be/Mgqd\_Lq2ciM?si=eO0RL1\_Bq2Wie-h4 Specifications Working range circulating diameter over bed : 600 mm Circumferential diameter over face slide : 500 mm Distance between the two spindle lugs : 975 mm Max. turning diameter :430 mm Max. part length : 744 mm Max. rod diameter : 65 (76.2) mm Travel X/X2 280/205 mm Travel Z/Z2/Z3 900/750/750 mm Travel Y 100 (+/–50) mm Main spindle Speed range (infinitely adjustable) 0 – 5000 (4000) rpm Torque max. 250 Nm Drive power main sp ...
Key data: 310 mm, 520 mm
Type of machine : CNC turning and milling center Manufacturer : EMCO Type EmcoTurn E65 Year of manufacture 2007 Control system Sinumerik 840 T Siemens Storage location : Hultfred / Sweden Switch-on hours : 46,000 h Automatic operation : 25,500 h Country of origin: Austria Delivery time end of May 2024 Cargo base free truck loaded Technical description Travel: X-axis : 210 mm Z-axis : 610 mm C-Axis : 360° Max. swing diameter over bed : 540 mm Max. swing diameter over face slide: 360 mm Max. turning diameter : 310 mm Max. turning length: 520 mm max. rod diameter 65 mm Center width: 650 mm Main spindle: Speed range - main spindle 60 - 4,200 rpm/-1 Drive power - main spindle 18 / 15 kW Max. torque 192 Nm Spindle head DIN 55026 / KK6 C-axis 0.001 ° Tool turret: 12 positions Tool holder VDI 30 DIN 69880 ...
Inv. Num. : 8686 Type: Emcomat FB-450 MC Producer: EMCO Created: 2019 Parameters: Control system: Siemens Sinumerik 828D Work table length: 800 mm Work table width: 400 mm Maximum table load (even): 300 kg Spindle drive power: 10 kW Maximum vertical spindle speed: 5000 1/min X-axis travel: 450 mm Y-axis travel: 350 mm Travel Z axis: 400 mm Machine height: 1990 mm Machine length: 1980 mm Machine width: 2030 mm Machine weight: 2300 kg Equipment: Horizontal support arm Handwheel Tool holders (12 pieces) Mounting pads
25.000 €
