LVD PPEB110/30 CAD-CNC 110T press brake Serial Number: 26225 Year of manufacture: 1999 Bending Length: 3050mm Servo-hydraulic bending system Precise slider positioning with a linear encoder Suitable for precise sheet metal bending A large number of tools available
LVD PPEB 135/3050 135T Press Brake Serial Number: 28414 Year of manufacture: 2002 Bending Length: 3050mm Servo-hydraulic bending system Precise slider positioning with a linear encoder Suitable for precise sheet metal bending A large number of tools available
Year of manufacture: 2006 Bending length: 4,230 mm Distance between columns: 3,760 mm Maximum Pressing Force: 1700 kN / 170 t Maximum stroke: 350 mm Weight: 14,800 kg Serial Number: HFT 170-4 L N060097
Manufacturer: LVD Model: PPEBturbo 220 Type: PPEB-EFL 220/30 Year of manufacture: 2006 Serial Number: 30494 Technical parameters: Max. Pressing force: 2,200 kN (220 tonnes) Working length: 3050 mm Distance between columns: 2600 mm Max. Slider Stroke: 450mm Max. Table-to-Slider Distance: 685 mm Outreach (throat): 450 mm X-axis travel: 600 mm Table width: 120 mm Speeds: Travel speed: 120 mm/s Working speed: 21 mm/s Return speed: 200 mm/s Drive and hydraulics: Motor power: 37 kW Power supply: 400 V Pump: adjustable Hydraulics: Bosch / Rexroth SYDFE1 Oil tank: 350 l Other data: Control: LVD Cadman CNC Noise level: 80 dB(A) Machine weight: approx. 14,500 kg Axes: Y-beam top down X-bumper approach and bending distance setting R-bumper top down 2 x Z-side and side-by-side bumper turnout Z 2 - ...
Display press only - 159h Year of manufacture: 2023 Controls: Delem Da-66T with touch screen Pressing force: 36 t Bending Length: 1300mm Stroke: 150 mm Travel speed: 150 mm/s Working speed: 10 mm/s Return speed: 150 mm/s Installed power: 21 kW Power Supply: 400V/50Hz/3~ Tool clamp pressure: 50 bar Dimensions (L × W × H): 2050 × 2050 × 2310 mm Weight: 4350 kg
Bystronic ByBend Smart Hydraulic Press Brake Serial Number: BYBEND22335SE Year of manufacture: 10/2022 Maximum pressing force: 2250 kN Working length: 4100 mm Maximum stroke: 300 mm Machine weight: 16,500 kg Equipment: tools
tube diameter: 50 mmbending angle max. +/-: 180 °bending radius max.: 350 mmbending speed: 3 U/minmotor speeds:: 2815 U/minbending radius max.: 350 mmbending angle max. +/-: 180 °tool taper: Sechskant 40 mmtotal power requirement: 2,2 kWweight of the machine ca.: 0,1 tMachine Type Electric Bending MachineModel 6000-SPower Connection 3-phase 400 VControl System JUTEC electronic, programmable bending control with display and membrane keypadOperation Foot switch for clockwise/counterclockwise rotation and bending operationDesign Mobile machine on swivel castersThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
tube diameter: ca. 60 mmtool taper: Sechskant 40 mmbending device: horizontal bending speed: 3 U/minweight of the machine ca.: 120 kgtotal power requirement: 2,2 kWElectronic bend angle controlDigital display and keypadOperated via dual foot switchesMandrel-less bendingMobile machine basePipe diameter range likely up to Ø 60 mmTool mounting via hexagonal shankThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 315 tstroke: 20-150 mmram stroke - adjustable min/max: 20 - 150 mmtable-size: 1780 x 1250 mmram surface: 1500 x 1000 mmtotal power requirement: 75 kWweight of the machine ca.: 46 t- Installation height with max. stroke at bottom adjustment at top 500 mm- Passageway in the table : 1200 x 300 mm- Milling in the table : 1300 x 400 x 80 mm- Infinitely variable stroke rate : 20 120 Hübe minThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Offered is a hydraulic press brake with 500kN pressing force. Stroke: max. 215mm. Operating pressure: max. 320bar. Stopping time: max. 95ms. Equipped with Lazer Safe laser guarding system. Inspection possible by arrangement.
pressure:250 ttable length:4000 mmtable width:3000 mmControls:SIEMENS SIMATIC C7 PRESS DESIGN:. - frame design : 4 column :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):250 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - tool weight max.:100000 kg - number of T-slots:12 - distance between T-slots:375 mm - height above floor level:390 mmRAM:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - number of T-slots:12 - distance between T-slots:375 mm - stroke:2900 mm - tool weight max.:50000 kgRAM (HYDR. PRESS):. - number of main-cylinders:1 - approximation velocity max.:180 mm/s - working velocity max.:50 mm/s - restoring force of ram:95 toTOOL ASSEMBLY DIMENSIONS:. - distance table - ram max.:2750 mm - distance between columns (H-frame):4100 mm - Free passage ...
pressure:800 tdistance between columns:2900 mmstroke:350 mmControls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 toPRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mmRAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /minRAM (MECHAN. PRESS):. - ram adjustment:350 mmTOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):256 ...
pressure:063 tthroat:250 mmstroke:8 - 100 mmno. of strokes:56 / 84 /mindistance table/ram, max. stroke up, adjustment up:415 mmtable surface area:710 x 500 mmhole in the table:320 mmtable height over floor:800 mmpassage to the back:320 mmram surface:450 x 280 mmram adjustment:63 mmweight:4,1 tdimensions (W x D x H):1,35 x 2,0 x 2,6 moverload protection in ram:mechanical
pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:51,0 kWweight:33,0 tdimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary
pressure:200 tdistance between columns:2100 mmstroke:550 mmDistance table/ram, stroke up:1800 mmtable surface area:2000 x 2800 mmtable height over floor:760 mmram surface:2000 x 2000 mmSide window:2000 mmfeed down:400 mm/spower requirement:52,0 kWweight:33,0 tDimensions (WxDxH):3,25 x 3,5 x 5,4 mHeight above floor:5,4 mfoundation pit:not necessary
pressure:1000 ttable length:4000 mmtable width:1600 mmControls:SIEMENS S7-1500F PRESS DESIGN:. - frame design : Transfer press :. - Drive type : mechnical :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. - number of tables:2 PRESS FORCES:. - total force (nominal):1000 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):1600 mm - height above floor level:600 mm - autom. tool clamping device : yes :. RAM:. - stroke:400 mmRAM (MECHAN. PRESS):. - ram adjustment:300 mm - ram adjustment:100 mm - number of strokes min:8 /min - number of strokes max:50 /min - hydraulic overload protection : yes :. TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):900 mm - shut height (stroke down, adjustment up):766 mm - distance between columns (H-frame):4250 mm - Free passage between ...
pressure:400 tdistance between columns:3250 mmdistance table/ram, max. stroke up, adjustment up:1000 mmstroke:800 mmtable surface area:3250 x 1400 mmtable height over floor:1250 mmdie cushion capacity:170 tdie cushion stroke:200 mmdie cushion area:1800 x 1000 mmdistance between cutting impact cushioning:2610 mmside window:800 mmram surface:3250 x 1400 mmreturn capacity:51 tspeed down:300 mm/sspeed up:300 mm/sworking speed:16 - 33 mm/squantity of oil:2900 lpower requirement:100,0 kWweight:70,0 tDimensions (WxDxH):4,9 x 3,1 x 7,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic
pressure:400 tdistance between columns:1250 mmstroke:250 fix mmno. of strokes:45 /mindistance table/ram, max. stroke up, adjustment up:825 mmtable surface area:1000 x 900 mmcolumn travel -side:400 x 700 mmram surface:1000 x 900 mmram adjustment:100 mmcapacity of ejector in table:40 tejector stroke:160 mmpower capacity:270,0 kWweight:44,0 tDimensions (WxDxH):2,4 x 3,6 x 7,2 mheight over floor:6,4 m
pressure:125 tstroke:25 fix mmno. of strokes:70 - 700 /mindistance between columns:1150 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:1150 x 1000 mmhole in the table:900 x 220 mmside window:650 mmram surface:990 x 850 mmram adjustment:60 mmmaterial width:250 mmmaterial thickness:2,5 mmpower requirement:46,5 kWweight:29,5 troll feed:mechanical, Schuler, WK 8-250
Pressure:080 tthroat:380 mmstroke:8 - 112 mmno. of strokes:60 /mindistance table/ram, max. stroke up, adjustment up:472 mmtable surface area:840 x 610 mmtable height over floor:800 mmpassage to the back:520 mmram surface:650 x 400 mmram adjustment:70 mmpower capacity:7,5 kWweight:6,9 tDimensions (WxDxH):1,1 x 2,15 x 3,2 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic
pressure:250 tdistance between columns:930 mmstroke:200 mmDistance table/ram, stroke up:600 mmtable surface area:900 x 860 mmdie cushion capacity:100 tdie cushion stroke:50 mmdie cushion area:350 x 400 mmtable height over floor:950 mmside window:380 x 380 mmram surface:850 x 700 mmfeed down:400 mm/sfeed up:400 mm/sworking feed:30 mm/soil volume:350 lpower capacity:45,0 kWweight:11,5 tDimensions (WxDxH):2,0 x 1,2 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary
pressure:1000 tdistance between columns:3030 mmstroke:350 mmDistance table/ram, max. stroke up, adjustment up:1400 mmtable surface area:3000 x 2000 mmtable height over floor:430 mmside window:1450 x 1400 mmram surface:3000 x 2000 mmspeed down:300 mm/sspeed up:340 mm/sworking speed:18 - 44 mm/sreturn capacity:120 toil volume:4400 lwidth with platform:4950 mmpower capacity:2 x 90,0 + 10,0 kWweight:87,0 tDimensions (WxDxH):4,35 x 3,65 x 7,55 mheight over floor:6,05 mheight beneath floor:1,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
pressure:200 tdistance between columns:1650 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1200 mmtable surface area:1600 x 1250 mmdie cushion capacity:80 tdie cushion stroke:300 mmdie cushion area:1300 x 900 mmtable height over floor:800 mmram surface:1600 x 1250 mmoil volume:ca. 2000 lpower capacity:43,0 kWweight:25,0 tDimensions (WxDxH):2,9 x 2,3 x 5,8 mheight beneath floor:0,85 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20
pressure:350 tdistance between columns:1350 mmstroke:900 mmdistance table/ram, max. stroke up, adjustment up:1300 mmtable surface area:1300 x 1000 mmpressure of drawing cushion in table:100 tstroke of drawing cushion in table:380 mmdie cushion area:350 x 285 mmcapacity of ejector in ram:25 tejector stroke in ram:200 mmtable height over floor:750 mmram surface:1300 x 1000 mmspeed down:500 mm/sspeed up:160 - 470 mm/sworking speed:16 - 44 mm/sdrawing speed:57 - 160 mm/sreturn capacity:32 toil volume:1700 lpower requirement:91,0 kWDimensions (WxDxH):3,75 x 2,8 x 7,2 mheight over floor:5,28 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:in TDC foundation pit:necessary
pressure at min. stroke:3 tthroat:150 mmstroke:- 39 mmdistance table/ram, max. stroke up, adjustment up:200 mmtable surface area:280 x 380 mmpressure at min. stroke:1,5 tno. of strokes with min. stroke:- 80 /minno. of strokes with max. stroke:- 50 /minhole in the table:45 mmtable height over floor:790 mmram surface:115 x 100 mmRequired air-pressure:4 barweight:0,2 tDimensions (WxDxH):0,5 x 0,9 x 1,4 m
pressure at min. stroke:3 tthroat:150 mmstroke:- 40 mmdistance table/ram, max. stroke up, adjustment up:200 mmtable surface area:280 x 250 mmpressure at max. stroke:1,5 tno. of strokes with min. stroke:- 80 /minno. of strokes with max. stroke:- 50 /minhole in the table:45 mmtable height over floor:810 mmram surface:115 x 100 mmRequired air-pressure:4 barweight:0,15 tDimensions (WxDxH):0,7 x 0,8 x 1,4 m
Pressure:063 tthroat:250 mmstroke:8 - 100 mmno. of strokes:120 /mindistance table/ram, max. stroke up, adjustment up:415 mmtable surface area:700 x 500 mmhole in the table:250 mmtable height over floor:800 mmpassage to the back:320 mmram surface:450 x 280 mmram adjustment:63 mmweight:4,5 tDimensions (WxDxH):1,6 x 2,0 x 2,8 moverload protection in ram:mechanical
pressure:65 tdistance between columns:930 mmstroke:1100 mmdistance table/ram, stroke up:2400 mmtable surface area:1340x700 / 930x1085 mmhole in the table:320x260 / 600x410 mmtable height over floor:850 mmside window:700 mmram surface:990 x 930 mmpower requirement:15,0 kWweight:8,0 tDimensions (WxDxH):2,8 x 2,6 x 5,2 mblank holder / ejector in ram:hydraulic side shifting device:hydraulic
Pressure:500 tdistance between columns:1550 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:900 mmtable surface area:1200 x 1300 mmpressure of drawing cushion in table:250 tstroke of drawing cushion in table:150 mmdie cushion area:950 x 950 mmtable height over floor:1245 mmside window:1250 mmram surface:1200 x 1300 mmspeed down:750 mm/sspeed up:780 mm/sworking speed:105 mm/soil volume:4000 lpower requirement:263,0 kWweight:45,0 tDimensions (WxDxH):3,3 x 3,3 x 6,1 mheight over floor:6,1 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable
Pressure:315 tdistance between columns:1350 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1000 mmtable surface area:1200 x 1300 mmtable height over floor:1245 mmside window:1250 mmram surface:1200 x 1300 mmspeed down:750 mm/sspeed up:680 mm/sworking speed:180 mm/soil volume:2000 lpower requirement:150,0 kWweight:35,0 tDimensions (WxDxH):3,3 x 3,3 x 5,5 mheight over floor:5,5 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch
