Key data: 80 t, 2600 mm
Inv. Num. : 9319 Type: CNC HAP 2680 Producer: Ermak Created: 2006 Parameters: Control system: CYBELEC Compressive force: 80 t Maximum bending length: 2600 mm Machine height: 2750 mm Machine length: 3750 mm Machine width: 1950 mm Machine weight: 6000 kg
Key data: 3100 mm, 6 mm
Hinged backgauge, manual cutting gap adjustment, lighting, cutting length adjustment, Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Sheet width: 3100 mm Sheet thickness steel: 6.0 mm Sheet thickness front: 4.0 mm Colour: grey/blue Total power requirement: 11 kW Machine weight: 900 kg Dimensions: 4000 x 2150 x 1640 mm Cutting gap adjustment: 0.05 -0.80 mm Hold-down: 14 Stroke rates per minute approx.: 19 stroke/min Cutting Angle: 1.2 Adjustable back gauge Back gauge: 1000 mm Machine number: SN20080583
ERMAK RPP 1270X30 punching machine was built in 2013 in Turkey by ERMAKSAN MAKINA SANAYI VE TIC. AŞ. The machine, which is distinguished by its high productivity and precision, is used in the machining of thin sheet metal with a maximum thickness of 6.35 mm. All machining processes are performed on a large brush table by a reliable working head, which operates with a maximum force of 30 tonnes. The brush table prevents scratches and nicks on the sheet metal surface during material feed, and also significantly reduces noise level. All this is complemented by a FANUC CNC control with an intuitive interface that allows advanced machining programmes to be created in just a few steps. The ERMAK RPP 12730 CNC punching machine weighs 11000 kg. It is also possible to purchase Metalix CAD/CAM software at an additional cost of 10500 EUR net. Technical specifications of the ERMAK RPP 1270X30 ...
ERMAK GMR 2600 X 4 mechanical guillotine shears were built in 2007 in Turkey by ERMAKSAN MAKINA SANAYI TIC. LTD. ŞTI. The machine, designed for precision cutting of workpieces with a maximum thickness of 4 mm, offers high reliability, precision and efficiency. The machining process is performed by high alloy steel cutting knives with adjustable gap between blades. Automatic hold-down system, in turn, prevent the sheet metal from sliding during machining, ensuring uninterrupted production of repeatable parts. Moreover, the operator’s daily work is facilitated by the convenient foot switch control and the intuitive NC control, which allows the creation of machining programmes in just a few steps. The GMR 2600 X 4 guillotine shears weighs 3750 kg. Technical specifications of the ERMAK GMR 2600 X 4 guillotine shears - NC control - maximum workpiece length: 2600 mm - maximum workpiec ...
ERMAK HGS 2600 X 6 guillotine shears built in 2006 in Turkey are designed for cutting sheet metal with a maximum thickness of 6 mm. The machine performs this process using precise cutting knives with an option to adjust the gap between the blades. The simple design, with an efficient drive system, further ensures trouble-free operation throughout its lifetime, while maintaining the highest cutting quality. The ERMAKSAN HGS 2606 guillotine shears weighs 5000 kg. Technical specifications of the ERMAK HGS 2600 X 6 guillotine shears - maximum workpiece thickness: 6 mm - maximum workpiece length: 2600 mm - number of strokes: 20/min - oil tank capacity: 150 l - motor power: 11 kW - power supply: 380 V - dimensions (L x W x H): 3395 x 1880 x 1550 mm - weight of machine: 5000 kg
ERMAK CNC HVR 3100 x 13 hydraulic guillotine shears built in Turkey in 2008, are designed for cutting workpieces made of among others mild steel or stainless steel. The metal sheet with a maximum length of 3100 mm and a maximum thickness of 8 mm (plain steel) or 13 mm (stainless steel), is held during machining by 14 hydraulic clamps. The angle of the cutting blade can be freely adjusted in the range from 0.5° to 2.0°. Full control over the operation of the CNC HVR 3113 machine is guaranteed by the control panel located on the guillotine shears body with installed CYBELEC DNC 60 CNC controller, allowing programming of many different machining processes. The guillotine shears is equipped with among others new cutting blades and a foot control pedal, making the operator’s work much more comfortable and simple. The total weight of the machine is 13400 kg. The total weight of the mach ...
Pressure:175 t chamfer lenght:4100 mm distance between columns:3600 mm column arm:410 mm ram stroke speed:180 mm/sec return speed:135 mm/sec working speed:10 mm/sec work stroke:275 mm oil volume:200 l dayligth:550 mm table height:900 mm table width:90 mm total power requirement:15 kW weight of the machine ca.:12000 kg dimensions of the machine ca.:5100 x 2150 x 2850 mm
sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTe ...
sheet width: 3100 mm plate thickness: 13 mm thickness at Niro-steel: 8 mm control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 2,0° ° total power requirement: 22 kW voltage: 380 V no. of strokes: 11 Hub/min weight of the machine ca.: 12.100 kg dimensions of the machine ca.: 4000x2240x2235 mm Accessories / equipment: - CYBELEC-CybTouch control panel with digital display for backgauge - hydr. Cutting gap adjustment via control - 1 side stop - 4 front lifting arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Ball rolls in the table - motorized back gauge 1.000 mm travel with recirculating ball screws, automatically start at the end of the stop - Shear knives for stainless steel cuts as standard - Photocell behind the machine - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - Operating instructions in German The data f ...
sheet width: 2600 mm plate thickness: 8,0 mm thickness at Niro-steel: 5,0 mm down holder: 12 Stück no. of strokes: 18 Hub/min oil volume: 200 ltr. cutting angle: 1,5 ° engine output: 15,0 kW weight of the machine ca.: 6.300 kg range L-W-H: 3525 x 2350 x 1700 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be folded up at max.travel, for longer cuts - 1x side stop - 2 ...
sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° : 20 total power requirement: 11 kW weight of the machine ca.: 5700 kg dimensions of the machine ca.: 4000x2100x1640 mm Accessories / equipment: - CYBELEC Cybtouch touch screen controller - NC controller for backgauge, gap adjustment, number of pieces, cutting length - 1 side stop with scale, T-groove and tilting cam - 2 front support arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Folding finger guard with limit switch - motorized back gauge 1.000 mm travel - Ball screws - Photocell behind the machine - Ball rolls in the table - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - CE mark / Declaration of Conformity - Operating manual: Machine and control in German The data for this ad was created with Modu ...
sheet width: 4100 mm plate thickness: 10,0 mm thickness at Niro-steel: 6,0 mm down holder: 28 Stück no. of strokes: 18 Hub/min oil volume: 260 ltr. cutting angle: 0,5 - 2 ° control: CYBELEC Cybtouch engine output: 22,0 kW back stop - adjustable: 1000 mm range L-W-H: 6100 x 2580 x 2460 mm weight: 15.100 kg. -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness ...
sheet width: 3100 mm plate thickness: 10.0 mm thickness at Niro-steel: 6.0 mm down holder: 14 Stück no. of strokes: 13 Hub/min cutting angle: 2.0 ° throat: 350 mm back stop - adjustable: 1000 (+) mm oil volume: 260 ltr. engine output: 22.0 kW weight: 10.575 kg range L-W-H: 4100 x 2400 x 2170 mm Demonstration/demo machine () from our exhibition (like NEW) with very few operating hours -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness Cutting line ligh ...
pressure: 60.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm back stop - adjustable: max. 800 mm oil volume: 150 ltr. voltage: 400 V engine output: 7.5 kW Weight: 4320 kg range L-W-H: 2250 x 1960 x 2750 mm Demonstration/demo machine () From our showroom (like new) With very few operating hours -------------------------------------------------- CNC press brake with special equipment Version ERGO - knee room for the operator flexible articulated arm mount for the controller increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-66T graphic/touch screen 2D graphi ...
sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l control: CYBELEC CybTouch 8 total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the ...
pressure: 80.0 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 60.0 mm/sec work stroke: 160 mm dayligth: 380 mm table height: 900 mm oil volume: 150 ltr. voltage: 400 Volt weight: 5227 kg range L-W-H: 3750 x 1950 x 2400 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - AKAS laser in front of the machine - manual crowning - Upper tool, deer foot - Lower tool, die block with 4Vs - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
pressure: 60.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm back stop - adjustable: 500 mm control: DA 66T oil volume: 150 ltr. voltage: 380 V engine output: 7.5 kW Weight: 4320 kg range L-W-H: 2250 x 1960 x 2750 mm current new price approx. 65.000 euros very rarely used! Special price on request - in checked condition - machine video - https://www.youtube.com/watch?v=KRifrqTgkVU ------------------------------------------------ SPEED BEND PRO CNC press brake: increased installation height increased cylinder stroke and increased bending beam speeds ------------------------------------------------ Equipment: - CNC electro-hydraulic press brake - DELEM CNC control model DA-66T graphics/touchscreen ...
sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° total power requirement: 11 kW weight of the machine ca.: 6.300 kg dimensions of the machine ca.: 4000x2100x1640 mm Equipment: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. can be folded up at max. Traverse path, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - fo ...
pressure: 175 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 12.0 mm/min return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm oil volume: 300 ltr. table height: 900 mm table width: 90.0 mm voltage: 400 Volt total power requirement: 15.0 kW weight: 9800 kg range L-W-H: 4150 x 2150 x 2800 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool R ...
sheet width: 3100 mm plate thickness: 6 mm rear stop: 1000 mm cutting angle: 1,2 ° down holder: 14 Stk no. of strokes: 18 Hub/min oil volume: 150 l total power requirement: 11 kW dimensions of the machine ca.: 3900 x 1900 x 1600 mm weight: 5500 kg Equipment: - Hydraulic swing cut shears - ELGO control system - Electric backgauge 1000 mm - Manual cutting gap adjustment - Cutting length limitation - Ball rollers in the table - 2x front support arms - 1x front side stop with scale - Front finger guard, hinged - Rear safety device (protective grille + light barrier) - Foot switch - Operating instructions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
sheet width: 3100 mm plate thickness: 13,0 mm thickness at Niro-steel: 8,0 mm down holder: 14 Stück no. of strokes: 11 Hub/min oil volume: 310 ltr. cutting angle: 2,0 ° throat: 350 mm table height: 900 mm total power requirement: 22,0 kW weight of the machine ca.: 12200 kg range L-W-H: ca. 4100 x 2300 x 2235 mm -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom ...
sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm distance between columns: 3100 mm no. of strokes: 18 Hub/min down holder: 14 Stück oil volume: 150 ltr. cutting angle: 1,2 ° control: CYBELEC CybTouch total power requirement: 11,0 kW weight: 6300 kg range L-W-H: 4.000 x 2.100 x 1.640 mm -------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Ca ...
pressure: 160 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/sec return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm back stop - adjustable: max. 800 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 11.0 kW weight: 7524 kg range L-W-H: 4250 x 1900 x 2550 mm Furnishing: - DELEM CNC control model DA-66T graphic/touch screen 2D graphical programming 17 TFT color screen with high resolution Bending sequence calculation Product programming and real size display USB interface intuitive, graphical entry of profiles Automatic calculation of features: tool safety zones, Press force, bending tolerance, crown setting, stretched Length, embossing force, flattening, automatic rounding calculation Radius programming Graphic tool and product library Collision mo ...
pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1050 mm column arm: 350 mm dayligth: 387 mm work stroke: 170 mm table height: 850 mm back stop - adjustable: 800 mm adjustment speed: 230 mm/min ajustment speed: 140 mm/sec working feed: 10.0 mm/sec return speed: 170 mm/sec total power requirement: 5.5 kW weight of the machine ca.: 3220 kg dimensions of the machine ca.: 2150 x 1650 x 2300 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by C ...
pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 200 mm stroke: 100 mm dayligth: 308 mm ajustment speed: 150 mm/sec working feed: 1-10 mm/sec return speed: 100 mm/sec table width: 100 mm table height: 900 mm control: DNC 60 PS oil volume: 100 l voltage: 400 V total power requirement: 5.5 kW weight of the machine ca.: 2750 kg - in checked conditions - machinevideo - https://www.youtube.com/watch?v=WRzqKruFUvY Equipment: - CNC electro-hydraulic press brake - CYBELEC DNC 60 PS CNC control Swiveling control panel, front left Tool & program library - CNC electro-motorized backgauge (X-axis) X-axis travel = 800 mm 2x manually adjustable backgauge fingers (R+Z axes) Backgauge on ball screws - CNC controlled axes Y1 - Y2 - X - Rehfuß upper tool system A with quick-change clamping Additional crowning device in the tool holder - 4V universal die block w ...
pressure: 220 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 12906 kg range L-W-H: 5100 x 2250 x 2900 mm -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135 ...
Hydraulic press manufactured in 2006. This ERMAK CNC HAP 3100x300 features a pressing force of 300 tons and a bending length of 3100 mm. It is equipped with a high-precision Cybelec CNC control system and a robust steel frame construction, making it suitable for large and thick sheet metal bending. If you are looking to get high-quality bending capabilities, consider the ERMAK CNC HAP 3100x300 machine we have for sale. Contact us for further details.
This 4-axis ERMAK CNC HAP 3100x200 was manufactured in 2007. A robust hydraulic press with a press capacity of 200 tons and a bending length of 3100 mm. It operates with an Ermak ER70 CNC control system and has a motor power of 15 kW. Ideal for heavy-duty bending tasks. Machine dimensions are 4550 × 2250 × 2850 mm, weighing 11,000 kg. Contact us for more information about this machine.
This ERMAK EPP 1270 x 30 was manufactured in 2010. It features a punching force of 30 tons, a capacity of 6 mm, and can deliver up to 700 strokes per minute. The machine has a motor power of 11 kW and an oil capacity of 300 liters. Dimensions are 4000 mm in width, 4250 mm in length, and 2330 mm in height. Contact us for more information about this machine.
pressure: 135 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 200 mm/sec work speed: 12.0 mm/sec return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 15.0 kW weight: 10800 kg range L-W-H: 5100 x 2100 x 2850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, Sy ...
