Manufacturer:
(Category: 106)
pressure:080 tthroat:300 mmstroke:7 - 100 mmno. of strokes:120 /mindistance table/ram, max. stroke up, adjustment up:450 mmtable surface area:720 x 600 mmhole in the table:300 x 120 mmtable height over floor:850 mmram surface:400 x 275 mmram adjustment:60 mmpower requirement:5,5 kWweight:6,5 tdimensions (WxDxH):1,2 x 2,0 x 2,9 mGerman Safety: permitted for manual loading:CE-sign light guard:Sick clutch:hydraulic overload protection in ram:hydraulic ram adjustment:motoric stroke adjustment:automatic
pressure: 28 tpiston stroke: 180 mmdiameter of piston: 130 mmtable-size: 300 x 550 mmworking feed: 2 - 9,8 mm/sekreturn speed: 20 mm/secMax. pressure: 200 barbending capacity - flat iron: 200 x 10 mmweight of the machine ca.: 800 kgdimensions: ca. 1150 x 1103 x 750 mmThe horizontal hydraulic press (28 ton) can be used for many different metal working jobs. The press has a piston stroke of 192 mm and can be equipped with all kinds of tooling for specific bending or straightening jobs. We supply a standard toolingset with this press including a stampholder and backgauge. However, we also produce custom-made tooling for your specific request. Thanks to the NC-control you can easily set the cylinder stroke and save up to 100 working cycles.With this horizontal hydraulic press you are able to bend, straighten, notch, cut and form. A universal hydraulic press that serves all your needs in cold ...
pressure:160 tthroat:690 mmstroke:8 - 180 mmno. of strokes:50 /mindistance table/ram, max. stroke up, adjustment up:500 mmtable surface area:1300 x 1000 mmhole in the table:400 / 120 mmtable height over floor:850 mmpassage to the back:900 mmram surface:1000 x 700 mmram adjustment:130 mmpower requirement:11,0 kWweight:19,0 tdimensions (WxDxH):2,4 x 2,8 x 3,4 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic
pressure:63 tthroat:325 mmstroke:560 mmdistance table/ram, max. stroke up, adjustment up:700 mmtable surface area:640 x 640 mmpressure of drawing cushion in table:25 tstroke of drawing cushion in table:200 mmdie cushion area:450 x 450 mmtable height over floor:800 mmram surface:560 x 560 mmoil volume:450 lpower requirement:15,0 kWweight:7,0 tdimensions (WxDxH):1,2 x 2,0 x 3,1 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic
pressure:100 tthroat:320 mmstroke:160 mmdistance table/ram, max. stroke up, adjustment up:480 mmtable surface area:630 x 550 mmhole in the table:200 mmtable height over floor:860 mmram surface:560 x 450 mmoil volume:500 lpower requirement:30,5 kWweight:6,4 tdimensions (WxDxH):1,6 x 2,0 x 2,9 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:hydraulic depth stop:mechanical
pressure:160 tthroat:480 mmstroke fix:fix 180 mmno. of strokes:25 - 70 /mindistance table/ram, max. stroke up, adjustment up:650 mmtable surface area:1100 x 900 mmHole in the table:450 mmtable height over floor:900 mmpassage to the back:700 mmram surface:900 x 600 mmram adjustment:144 mmpower requirement:30,75 kWweight:15,3 tdimensions (WxDxH):2,0 x 2,4 x 3,75 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Desch overload protection in ram:hydraulic ram counterbalance:pneumatic
pressure:100 tthroat:300 mmstroke:20 - 120 mmno. of strokes:55 /mindistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:800 x 560 mmhole in the table:310 x 180 mmtable height over floor:745 mmram surface:520 x 245 mmram adjustment:75 mmpower requirement:5,5 kWweight:5,5 tdimensions (WxDxH):1,1 x 2,4 x 2,4 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical
pressure:40 tthroat:350 mmmaterial thickness: - 12 mmstamping power-diameter at 12 mm material thickness:24 mmstamping power-diameter at 6 mm material thickness:50 mmpower requirement:2,2 kWweight:1,5 tdimensions (WxDxH):0,8 x 1,5 x 1,9 m
pressure:315 tthroat:480 mmstroke:20 - 190 mmno. of strokes:36 + 45 /mindistance table/ram, max. stroke up, adjustment up:615 mmtable surface area:1400 x 880 mmhole in the table:250 mmtable height over floor:800 mmpassage to the back:950 mmram surface:850 x 630 mmram adjustment:125 mmpower requirement:33,0 kWweight:30,0 tdimensions (WxDxH):2,0 x 3,0 x 4,4 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic overload protection in ram:hydraulic stroke adjustment:semi-automatic ram adjustment:motoric ram counterbalance:pneumatic
pressure:200 tstroke:30 - 160 mmno. of strokes:40 - 120 /mindistance between columns:1500 mmdistance between oil collecting pans:1300 mmdistance table/ram, max. stroke up, adjustment up:860 mmhole in the table:550 x 300 mmtable surface area:1250 x 1250 mmtable height over floor:1000 mmcolumn travel -side:600 x 530 mmram surface:1250 x 1000 mmram adjustment:125 mmMaterial width of feeder:30 - 500 mmMaterial thickness feeder:0,5 - 3,0 mmfeeding length:0 - 999,9 mmpower requirement:50,0 kWweight:34,0 tdimensions (WxDxH):4,0 x 1,7 x 5,2 mclutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F
pressure:40 tdistance between columns:620 mmstroke:975 mmdistance table/ram, max. stroke up, adjustment up:940 mmtable surface area:590 x 1000 mmtable height over floor:770 mmram surface:590 x 1000 mmside window:470 mmmax. tool weight:2,5 tmax. capacity of swivelling ram plate:1,5 tSpeed down:0 - 50 mm/sSpeed up:0 - 34 mm/sWorking speed:0 - 10 mm/soil volume:150 lpower requirement:9,5 kWweight:3,2 tdimensions (WxDxH):2,0 x 2,4 x 3,0 m
pressure:500 tdistance between columns:1220 mmstroke:600 mmdistance table/ram, max. stroke up, adjustment up:1000 mmtable surface area:1600 x 1200 mmpressure of drawing cushion in table:320 tstroke of drawing cushion in table:150 mmdrawing cushion surface in table:750 x 625 mmpressure of drawing cushion in ram:180 tstroke of drawing cushion in ram:100 mmdrawing cushion area in ram:750 x 625 mmram surface:1600 x 1200 mmtable height over floor:800 mmspeed down:665 mm/sspeed up:530 mm/sworking speed:34 - 100 mm/squantity of oil:2000 lpower requirement:180,0 kWweight:40,0 tDimensions (WxDxH):3,2 x 2,4 x 7,5 mDepth of foundation pit:4,1 mHeight above floor:5,55 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
pressure:125 tdistance between columns:2100 mmstroke:1000 mmDistance table/ram, max. stroke up, adjustment up:1300 mmTable area:2230 x 1300 mmdie cushion pressure in table:63 tdie cushion stroke in table:60 mmsurface of drawing cushion:1000 x 900 mmtable height above floor:1050 mmside window:1000 mmram surface:2100 x 1000 mmspeed down:50 mm/sspeed up:50 mm/sworking speed:10 mm/soil volume:410 lheight above floor:5,95 mmpower requirement:22,0 kWWeight:31,0 tDimensions (WxDxH):3,1 x 1,7 x 5,95 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic foundation pit:not necessary
pressure:63 tthroat:280 mmstroke:160 mmDistance table/ram, max. stroke up, adjustment up:360 mmtable surface area:560 x 490 mmhole in the table:125 mmtable height above floor:860 mmram surface:280 x 280 mmpower requirement:22,0 kWweight:3,6 tdimensions (W x D x H):0,8 x 1,7 x 2,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
pressure:315 tdistance between columns:1750 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:1200 mmtable surface area:1600 x 1500 mmpressure of drawing cushion in table:125 tstroke of drawing cushion in table:200 mmdie cushion area:1200 x 1400 mmtable height over floor:750 mmram surface:1640 x 1500 mmpower requirement:55,0 + 11,0 kWweight:29,5 tdimensions (WxDxH):3,2 x 4,5 x 5,8 mHeight above floor:5,1 mGerman Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 drawing cushion in table:hydraulisch cutting impact absorption:hydraulic
pressure:3500 tstroke:900 mmDistance table / ram, stroke down:1000 mmdistance table / ram, stroke up:1900 mmtable surface area:3150 x 2150 mmram surface:3150 x 2150 mmTotal Weight of Tool max.:30,0 tWeight of Tool Top Part max.:20,0 tspeed down:400 mm/sworking speed:0,9 - 9,2 mm/sHydraulic Operating Pressure:280 baroil volume:5500 lrated current:760 Avoltage:400 Vfrequency:50 Hzpower requirement:425 kWweight:231,0 t
Pressure:080 tthroat:280 mmstroke:20 - 120 mmno. of strokes:42 - 125 /mindistance table/ram, max. stroke up, adjustment up:510 mmtable surface area:700 x 560 mmhole in the table:280 mmtable height over floor:800 mmpassage to the back:320 mmram surface:560 x 350 mmram adjustment:72 mmWeight:5,2 tDimensions (WxDxH):1,6 x 1,6 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical
Pressure:63 tdistance between columns:1000 mmstroke:300 mmDistance table/ram, max. stroke up, adjustment up:850 mmtable surface area:980 x 500 mmtable height above floor:850 mmram surface:130 mmspeed down:400 mm/sspeed up:461 mm/sworking speed:14 - 97 mm/spower requirement:15,0 kWWeight:5,0 tDimensions (WxDxH):2,0 x 1,6 x 3,9 mdepth stop:mechanical foundation pit:not necessary
Pressure:080 tthroat:300 mmstroke:8 - 140 mmno. of strokes:60 / 90 /mindistance table/ram, max. stroke up, adjustment up:420 mmtable surface area:800 x 600 mmhole in the table:330 x 230 mmtable adjustable:230 mmtable height over floor:750 - 980 mmram surface:600 x 240 mmram adjustment:100 mmpower capacity:4,5 / 6,9 kWWeight:5,5 tDimensions (WxDxH):1,4 x 2,5 x 2,6 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:hydraulic
Pressure:160 tdistance between columns:1250 mmstroke:500 mmdistance table/ram, max. stroke up, adjustment up:700 mmTable area:1200 x 800 mmtable height over floor:850 mmdie cushion pressure in table:63 ? tdie cushion stroke in table:200 mmdie cushion area:780 x 650 mmside window:300 mmram surface:1000 x 800 mmspeed down:400 mm/sspeed up:400 mm/sworking speed:106 mm/soil volume:1800 lpower capacity:2 x 30,0 kWweight:16,7 tDimensions (WxDxH):2,45 x 2,35 x 4,5 m
Pressure:150 tstroke:fix 80 mmno. of strokes:30 - 150 /mindistance between columns:930 mmdistance table/ram, max. stroke up, adjustment up:400 mmtable surface area:880x1300/1500x600 mmhole in the table:760 x 180 mmtable height over floor:1270 mmcolumn travel -side:650 mmram surface:920x1000/1300x600 mmweight:27,5 tDimensions (WxDxH):3,1 x 1,8 x 4,3 mWITHOUT feeder:can be offered optionally
pressure:100 tdistance between columns:770 mmstroke:400 mmdistance table/ram, stroke up:800 mmTable area:770 x 900 mmtable height above floor:850 mmdie cushion pressure in table:40 tdie cushion stroke in table:200 mmdie cushion area in table:600 x 600 mmside window:600 mmram surface:770 x 900 mmspeed down:62 mm/sspeed up:350 mm/sworking speed:17,5 mm/soil volume:700 lpower requirement:42,0 kWweight:9,0 tDimensions (WxDxH):2,6x 2,0 x 3,8 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic
pressure:315 tdistance between columns:1800 mmstroke:400 mmDistance table/ram, max. stroke up, adjustment up:650 mmtable surface area:1800 x 1000 mmtable height over floor:900 mmdie cushion pressure in table:80 tdie cushion stroke in table:100 mmDie cushion area in table:1300 x 600 mmside window:600 mmram surface:1800 x 1000 mmspeed down:400 mm/sspeed up:300 mm/sworking speed:15 - 80 mm/soil volume:1700 lpower requirement:55,0 kWweight:27,5 tdimensions (WxDxH):3,1 x 2,2 x 4,6 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic foundation pit:not necessary
pressure:320 tdistance between columns:1530/1370 mmstroke:320 mmdistance table/ram, stroke up:830 mmtable surface area:1500 x 650 mmdie cushion pressure in table:12,5 ttable height over floor:1100 mmside window:570 mmram surface:1240 x 650 mmcapacity of ejector in table:12,5 tspeed down:450 mm/sspeed up:440 mm/sworking speed:63,6 mm/soil volume:2100 lpower requirement:2 x 45,0 kWweight:27,0 tdimensions (WxDxH):4,0 x 2,3 x 4,9 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic drawing cushion in ram:hydraulic ram interlocking:hydraulic Option: NEW electrical controls:Siemens S7-1500 F
pressure:160 tdistance between columns:1580/1360 mmstroke:320 mmdistance table/ram, max. stroke up, adjustment up:830 mmtable surface area:1460 x 850 mmtable height over floor:1100 mmside window:870 mmram surface:1400 x 850 mmspeed down:540 mm/sspeed up:520 mm/sworking speed:26 - 85 mm/soil volume:2100 lpower requirement:45,0 kWweight:22,6 tdimensions (WxDxH):4,0 x 2,3 x 4,9 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:hydraulisch
pressure:160 tdistance between columns:1600/1420 mmstroke:345 mmdistance table/ram, max. stroke up, adjustment up:830 mmtable surface area:1460 x 850 mmtable height over floor:1100 mmside window:770 mmram surface:1410 x 850 mmspeed down:540 mm/sspeed up:520 mm/sworking speed:26 - 85 mm/soil volume:2100 lpower requirement:45,0 kWweight:23,0 tdimensions (WxDxH):4,0 x 2,3 x 4,9 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:hydraulisch
pressure:025 tthroat:200 mmstroke:8 - 80 mmno. of strokes:60 - 180 /mindistance table/ram, max. stroke up, adjustment up:330 mmtable surface area:560 x 400 mmhole in the table:150 mmtable height over floor:800 mmpassage to the back:240 mmram surface:355 x 220 mmram adjustment:50 mmweight:3,0 tdimensions (WxDxH):1,0 x 1,4 x 2,2 minfinitely variable drive:Stöber overload protection in ram:mechanical NEW electrical controls:Pilz
pressure:300 tdistance between columns:1800 mmstroke:1000 mmDistance table/ram, max. stroke up, adjustment up:1300 mmTable surface area:1600 x 1200 mmTable height above floor:1080 mmRam surface:1600 x 1200 mmWeight:24,0 tDimensions (WxDxH):2,8 x 2,1 x 6,0 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
pressure:100 tthroat:360 mmstroke:500 mmdistance table/ram, max. stroke up, adjustment up:800 mmtable surface area:900 x 560 mmtable height over floor:710 mmram surface:630 x 400 mmspeed down:200 mm/sspeed up:200 mm/spower requirement:17,0 kWweight:5,0 tDimensions (WxDxH):1,2 x 1,9 x 3,3 mGerman Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2
pressure:400 tdistance between columns:1100 mmstroke:250 mmno. of strokes:25 - 75 /mindistance table/ram, max. stroke up, adjustment up:900 mmtable surface area:1100 x 965 mmcapacity of ejector in table:30 tejector stroke of ejector in table:80 mmcapacity of ejector in ram:3 tstroke of ejector in ram:60 / 70 mmram surface:980 x 800 mmcolumn travel -side:800 mmram adjustment:20 mmpower capacity:80,0 + 5,5 kWweight:47,0 tDimensions (WxDxH):3,5 x 3,3 x 6,0 mweight of switch cabinet:1,4 tdimensions of electrical cabinet (WxDxH):4,9 x 0,5 x 2,6 mejector in ram:hydraulic
