Inv. Num. : 8437 Type: 50-VE Producer: IMS Created: 2002 Parameters: Compressive force: 50 t Maximum stroke rate per minute: 145 1/min Stroke: 80 mm Adjusting the ram: 75 mm Machine weight: 2300 kg
Serial No.: 1704 Punching capacity: Ø 28 x 16 Available with special tools: Ø 100 x 4 Year of construction: 1997 Country of origin: Italy
used
Compressive force max.: 55 kN Projection: 175 mm Punching stroke adjustable: 0 - 28 mm Number of strokes at 15 mm stroke: 30 Adjustable notch stroke: 0 - 60 mm Hydraulic drive: 380 V, 3 kW Required space: 1170 x 620 x 1470 mm Weight: 930 kg
Pressure:040 t throat:180 mm stroke:0 - 76 mm no. of strokes:145 /min distance table/ram, max. stroke up, adjustment up:350 mm table surface area:600 x 360 mm hole in the table:110 mm table height over floor:800 mm ram surface:270 x 175 mm ram adjustment:65 mm power capacity:2,2 kW weight:1,75 t Dimensions (WxDxH):1,1 x 1,2 x 2,1 m German Safety: permitted for manual loading:CE-sign clutch:pneumatic
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 50 to PRESS TABLE table surface (left-right): 700 mm table surface (front-back): 450 mm SLIDE table surface (left-right): 440 mm table surface (front-back): 360 mm spigot hole diameter: 40 mm stroke: 90 mm stroke rate (max.): 70 /min SLIDE (MECHAN. PRESS) slide adjustment: 70 mm stroke min.: 0 mm stroke max.: 90 mm main drive power: 3 kW TOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 300 mm DIMENSIONS / WEIGHTS space requirements -left/right-: 700 mm space requirements -front/back-: 1295 mm total height: 2360 mm total weight approx.: 3000 kg
PRESS DESIGN drive system: eccentric / crank PRESS FORCES total force (nominal): 80 to PRESS TABLE table surface (left-right): 850 mm table surface (front-back): 550 mm SLIDE table surface (left-right): 560 mm table surface (front-back): 376 mm spigot hole diameter: 50 mm stroke: 110 mm stroke rate (max.): 60 /min SLIDE (MECHAN. PRESS) slide adjustment: 80 mm stroke min.: 0 mm stroke max.: 110 mm TOOL ASSEMBLY DIMENSIONS shut height (stroke down, adjustment up), BDC: 360 mm DIMENSIONS / WEIGHTS space requirements -left/right-: 855 mm space requirements -front/back-: 1635 mm total height: 2640 mm total weight approx.: 5400 kg ATTACHMENTS (PRESSES) 2-hand engagement: yes foot engagement: optional European CE standards: yes
