other wood working machines used for sale (1,379)

COMPLETE WASTE WOOD DISPOSAL LINE RUDNICK & ENNERS – built in 2011 For sale is a complete waste wood disposal plant of the Rudnick & Enners brand, built in 2011. The line consists of 20 positions and was used for the automatic removal, sorting and processing of rinds, chips and waste wood in a sawmill. The plant has a modular design, dismantled, in very good condition and immediately available. Technical Overview – Items 1 to 20 01 – TKF offset by reducer, W 600 mm 02 – Viborinne 1 trimming line, L 13.0 m, W 650 mm 03 – Viborinne 2-trimming line, L 15.0 m, W 650 mm 04 – Viborinne creel line, L 8.50 m, W 500 mm 05 – Viborinne 1-gang line, L 10.0 m, W 500 mm 06 – Viborinne 2-creel line, L 9.0 m, W 500 mm 07 – Viborinne creel roller table, L 7.50 m, W 500 mm 08 – Viborinne resawing line, L 11.0 m, W 650 mm 09 – Viborinne recut li ...

Packing system loaded onto trucks Timber length 3-5m (5.5m) Composed of: Tilting table Alignment roller conveyor Board Splitter Layer conveyors Handovers (5 pieces) Lift table Transport... (Without control cabinet)

Technical data sheet: Esterer EHS-F tensioning car (built in 1990) Application: Automatic feeding of sawmills with round timber 1. Key features Type: EHS-F (semi-automatic, rail-guided) Year of Make: 1990 Condition: [Good/Refurbished/Technically perfect – please adjust] Application: Sawmills, wood industry 2. Performance data Load capacity: 5–8 tons (depending on trunk diameter) Conveyor length: 10 m (standard, adaptable to creel length) Conveying speed: 0.1–0.4 m/s (infinitely adjustable) Trunk diameter: Ø 200–800 mm Drive & Control Drive: Electro-hydraulic (400 V / 50 Hz) Hydraulic pump: 25 l/min (pressure: approx. 160 bar) Control: Relay-controlled (option: retrofitting with modern PLC possible) Operation: Button panel with emergency stop Mechanics & Safety Clamping system: Hydraulic grippers (jaws replaceable) Chassis: Precision rail guide with ...

Pinomatic cross conveyor for a planing and sawing line Year of construction 2001 Manufacturer Pinomtatic OY Type POS 9+10 S/N P1033 motorised cross conveyor with 7 chain hoists length of the arms: : 6000mm Width of the cross conveyor up to 4000mm ( variable adjustable ) Height: 900mm 6 chain hoists fixed mounted 1 chain hoist can be variably adjusted Voltage 230/ 400VAC

A CMS CNC woodworking center is available. Axes: 5, travel X/Y/Z: 3500mm/2200mm/300mm, spindle power: 15kW, speed: 24000rpm, tool holder: HSK-F63, tool places: 20, table type: matrix vacuum table, control: Osai S10. The system control was modernized in 2006. Documentation available. On-site inspection is possible.

A Trima CNC gantry machining center is available. Workpiece dimensions X/Y/Z: 2500mm/1100mm/80mm, spindle power: 7.5kW, speed: 24000rpm, tool positions: 10, traversing speed X/Y/Z: 55m/35m/15m/min. Machine dimensions X/Y: approx. 4400mm/2500mm, weight: approx. 3200kg, control: Siemens Sinumerik. The machine has a control defect. The reference run is aborted. Documentation available. On-site inspection is possible.

Morsoe miter punch, in good condition, immediately available. If you are interested, we will also be happy to inform you about other machines in our company. You are welcome to visit the machine in our house by prior appointment.

Feed speed: 18-25m/min, with FK11 max. 20m/min, working height: approx. 950mm, max. workpiece thickness: 60mm, edge banding material rolls: approx. 0.3-3mm, edge banding material strips: approx. 0.4-6mm, max. roll diameter: 830mm, machine length: approx. 7845mm, operating hours: 25724h, feed operating hours: 3371h, machining time: 412h, control system: HOMAG powerControl PC22. Annual production: between 15000 and 22000 linear meters per year. Equipment: Top/bottom release agent spraying unit, joint trimming unit, glue application unit, 2-roll edge banding magazine, pressure zone, end trimming unit HL81, pre-milling unit BF10, profile trimming unit FK11, profile scraper PN10, finishing unit with glue joint scraper and buffing unit, preparation for HOMAG laserTec, powerControl PC22 with touchscreen, automation packages. In addition, scrapers for both 2mm and 1mm edges are available. Equipm ...

Drum crusher with hydraulic pusherKnife drum width: 800 mmMouth 800 x 1200 mmMotor: 18,5 kWextraction connection diameter 200 mm

Semi-automatic

Max working width: 1300mmMax working thickness: 140mmMax. machining width: 1300mmMotorized feed rollers2 brushing units

Workpiece thickness: 8 - 50 mmEdge thickness: Coil edges 0.4 - 3 mmFeed speed 10 m/minEquipment:manual height adjustment.Joint milling unit, 2 motors Panel edge heatingGluing area Pressure zone 1 driven and 2 non-driven rollersEnd trims, 2 x 0,8 kW motors, straight and chamfer 15°Top and bottom trimmingProfile scraping unit for PVC edgingGlue scrapers

Panel thickness: 8 - 50 mmThickness of the edges: 0,4- 3 mmFeed speed 8 - 11 m / minPU pressure rollersEquipment:Squaring unit, 2 motors 2,2 kWPanel edge heatingEdge magazine for coil and stripsHot melt application with rollerAirtec AT4510 unitThe Airtec aggregate is positioned so you can use Airtec or the standard glue potMotorized side pressure unitEnd trims, 2 motors, pneumatic positioning straight and with chamfertrimming unit above / belowContour trimming unitProfile scraping unitGlue scraping unitPolishing unitDetergent spray systemcentral lubrication

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Single sided edge bander with hot melt, fixed side at the right, pre-milling unitEdge thickness: 0,4 to 12 mmWorkpiece thickness: 8 - 60 mmFeedspeed 8-20 m/min (limited to 10 m/min using the contour trimming)Workpiece transport by chain, top pressures with rubber rollersSound enclosure over all trimming motorsEquipment:Adjustable fencePre-milling with 2 shapers, each 2,2 kWCoil and strip magazine Hot melt unit, Quickmelt type Pressure zone with1 driven and 2 non-driven pneum. Loaded rollersEnd trims, 2 x 0,35 kW motors, straight and chamfer 15°Top/bottom trimming, motors 2 x 0,35 kWRadius trimmmingContour trimming unit, leading and following edge, 2 x 0,35 kWRadius scraping unitGlue scrapersBuffing unitControlls PC 20+

Workpiece thickness: 8 - 90 mm, electronically adjustableFeed rate: 18-32 m/min frequency controlledEdge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mmEquipment:Inlet guide automatically adjustable via the control, extension 500 mmJoint milling unit: 2 x 3.0 KWworkpiece preheatingGluing unit A34edging magazine for rollPressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the controlCutting unit WK14, straight, 2 motors 0.8 kWPre-milling unit: 2 x 1.5 KW, pneumatic adjustmentForm milling unit FF 12 automatic, 2 motors 0.4 kWradius/phase milling unit FF12 automatic 4 motors 0.4 KWuniversal milling aggregate controlled UF11, 4 kWProfile scrapers PN20Glue scrapersNozzles for detergent and anti-stickPolishing unitControl: Power Control PC22

Fixed side at the leftFeedspeed 18 - 25 m/minWorking width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mmPanel overhang 30mmPanel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations)Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mmCoil diameter 830 mmEquipment:Sprayers release agentSquaring device with 2 motors each 3 kWEdge heatingEdge magazine for 2 coils, guillotine for edges up to 3 mmGlueing part A20 with quickmelt applicationLateral pressure zone K, 1 driven and 6 after pressing rollersEnd trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kWContour trimming, 2 exchange unitsProfile scraping PN10Flat scrapers FA11Sprayers cleaning agentBuffingAutomation package straight/chamfer:-Automatic adjustment infeed fence-Automatic setting of pressure rollers-Pneumatic setting of end trims-Pneumatic setting of rough trims-Automatic setting of chamfer/ra ...

Fixed side at the leftPanel thickness min/max: 16/45 mmMin. panel width: 150 mmLateral panel support for panel width up to 900 mmMin/max. panel length: 700 / 3100 mmMax. laminate overhang: 110 mmMax. laminate thickness: 0,8 mmRadius min/max: 6 / 22 mm (depends the laminate)Feedspeed max. 18 m/minTop pressure by beltEquipment:Infeed fence, adjustable, defines the panel overhang2 x trimming unit 0,4 kW, HSK 25 toolholder1 x PVAc glue application5 x glue nozzle, adjustable1 x hot air blower3 x IR heating on top (55 cm length), 3 x bottom (90 cm length)Postforming zone 1,8 m. lengthVarious pre-installed profiling sets 1 x top trimmer 0,4 kW

Machining center in vertical design with automatic returnWorkpiece dimensions:Length: 200 to 3050 mmWidth: 50 to 1250 mmThickness: 8 to 80 mmweight max 60 kgPerformance- 2x vertical drilling unit separately controllable with variable speed. right left V10/32mm. 2.3 kW. Drill length 70 mm, D= max 35 mm- 2x horizontal drilling unit, 6 spindles in X direction, variable speed. right left can be controlled separately. Drill length 70 mm, D= max 20 mm- 2x horizontal drilling unit, 2 spindles in Y direction, variable speed. right left can be controlled separately. Drill length 70 mm, D= max 20 mm- Grooving saw unit X-Y can be swiveled 0°/90° saw diameter 125 mm, rpm 1500-7500 frequency controlled- Dowel insertion station for automatic insertion of dowels on the two transverse workpiece edges 1x left side / 1x right side glue pump, vibrating guide for dowels 8 x 35/40 mm- plausib ...

4-axis machining centerworking area: X Y Z : 3060 x 1080 x 155 mmMovement speed X 100 m/min, Y 100 m/min, Z 30 m/min14 vertical spindles4 horizontal spindles in X direction2 horizontal spindles in Y directionGrooving saw 0° - 90°toolchanger 7 positionstoolchanger 10 positionsRouter 7,5 kW, ISO 30 , 1000 - 24000 r/min, c-axislock milling aggregate available in option

Gantry-type, 3-axis CNC machining centreWorking area (type 2132): approx. 3300 x 2100 mmVacuum table with multiple switchable zonesInput: AES lifting table for automatic sheet loadingOutput: conveyor belt with label printer (labels are printed and applied manually)Main spindle: HSD ES929, HSK-F63 mount, 7.5 kW (9 kW), speed up to 24,000 rpm, 800 Hz, 380 VMain spindle overhauled in 2023Drilling unit with 16 spindles: 6 vertical spindles in X, 4 vertical spindles in Y, 2 double horizontal spindles in X, 1 double horizontal spindle in YSlotting sawTool changer with 12 positionsVacuum: Becker vacuum pumps, system approx. 500 m³/hControl: OSAI control system with AES ProcessController, operation via console with touchscreen and keyboardOperating hours: approx. 2,100 h (machine life), main spindle overhauled at approx. 1,360 h

Working area: X 5005 x Y 1520 mm x Z 200 mmMain spindle travel: X 5910 mm, Y 1815 mm, Z 655 mm.Travel speed: X 80 m/min, Y 80 m/min, Z 25 m/min8 workpiece consoles with automatically positioning vacuum cupsEquipment:Drilling unit with 19 spindles, 7 vertical spindles in X, 6 vertical spindles in Y, 2 double horizontal spindles in X, 1 double horizontal spindle in Y Slotting sawMilling motor 12 kW, 1000–24,000 rpm, HSK-F 63 mounting, liquid-cooled, 5-axis controlledTool changer with 22 positions Vacuum pumps with 2 x 100 m³/h capacityPC controlMasterwork software Integrated waste conveyor

Bridge type Capacity for all units: 3300 x 1100 mm(alternating: 2 x 1025 x 1100 mm)Capacity for routing with tooldiameter 25 mm: 1550 mmWorkpiece thickness up to 300 mm (stroke Z-axis 600 mm)Speed in X and Y: 60 m/min, Z: 25 m/min, Vector: 85 m/min6 Support rails with LED positioning indicationVacuum: 100/140 m3/hControlls: Powercontrol PC85Waste/chip removal belt in machine baseMachine pneumatically prepared to take pneumatic clamps, 3 pcs clamps includedDrilling unit V9/H4, 13 spindles, motor 2,2 kWMain spindle DRIVE5C+, 5-axis, 10 kW, HSKF63 taper, speed 1000 to 24000 r/min, tooldiameter up to 180 mm for routing, 350 mm for cutting14-fold rotary toolchanger and pick-up place for a sawbladeWoodwop software

Working field: axis x: 3200 mm, axis y: 944 mm, axis z: 110mmMax programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/minDrill holder: diameter 10 mmSpindle speeds: 4000 rpmGrooving saw: diameter 120 mmDrill spindles: 24 horizontal spindles in X,10 vertical spindles in X lineWorking pressure air pressure: 6 barInstalled power: max 25 kWCapacity of vacuum tools: 40 m³/hCNC:screen: monochromatic 9”Floppy disk unit

Working area: X 5200 x Y 1260 mmHeading of main spindle: X 5709 mm, Y 1650 mm8 workpiece consolesEquipment:Drilling unit with 18 spindles, 12 vertical spîndles, 6 horizontal spindles (4 in direction X , 2 in direction Y )Grooving sawMilling motor 11 kW, 20000 rpm max, HSK-F 63 take-up, liquid-cooled, 5-axis controlledTool changer with 16 positionsLaterally positioned changer with 8 positions PC control

Working field: axis x: 2310 mm, axis y: 628 mm, axis z: 90mmMax programmable speed: axis x: 100 m/min, axis y: 75 m/min, axis z: 15 m/minDrill chuck: diameter 10 mmSpindle speeds: 4000 rpmGrooving saw: diameter 120 mmDrill spindles: 4 horizontal spindles in X,12vertical spindles in X lineWorking air pressure: 6 barMax consumption of compressed air: 0,75 NL/cycleInstalled power: max 7.5 kWCapacity of vacuum tools: 40 m³/hCNC:screen: monochromatic 9”Floppy disk unitPLC for control of the machine cycle

X=3700mm Y=1440mm, Z=150mmMoving speed: X: 80 m/min, Y: 80 m/min, Z: 20 m/min8 supports with vacuum cups, pneumatic clamping8 fences at the rear8 fences in front2 left fences and 2 right fences6 rails for panel loading with pneumatic liftingPositioning the vacuum cups using a laser1 connection for templatesVacuum pump with flow rate 100 m3/hConfiguration V25,H8X/6Y, N1 X-Y 90°, F1-HSK63-15KW,F1-HSK63-9KW, C axis, W14 rearMain motor 15 kW, 1250-24000 rpm, air-cooled, 360° C-axis, C-axis interpolation axis, HSK 63 mountingC axis extension for flex-5 aggregateMain motor 9 kW, 1250-24000 rpm, air cooled, HSK 63 mountingTool changer operating in X direction with 14 positions, rear mounted2 x 4 vertical X drilling pins, 2 x 3 vertical Y drilling pins14 horizontal drilling spindles90° groove saw X-Y directionPC 85 power control software with:Woodwop: workshop-oriented programming systemImpor ...

Workpiece sizes: Length 180 - 2500 mm, width 150 - 800 mm, thickness 12 - 40 mmFixed side at the left, motorised width adjustment of the right side Working height/ transport height: 920 mmWorkpiecetransport with belts, infeed belts can lift upVariable feed speedEach side has got 5 glue injectors and 8 dowel inserters (Type 34)Doweldiameter: 8 mm, dowellength 30 mm, dowelprojection 7-14 mm, dowelcenters min. 32 mm, max. 736 mmEach side with dowel hopper feed with shaker and separatorsControll mirrorGlue pump 1:1 Glue injection controlls type ELC

Working width 180 - 3200 mm, electronic setting Sieb & MeyerFixed side at the leftChain transport, 80 mm wideInfeed for panels of about 1 m.Top pressure by driven beltsMax. workpiece thickness: 80 mmFeedspeed 7 - 35 m/min, motor 2,2 kWPop-up dogs every 1m10Equipment left / right:1 st postFront: 1+1 Jump scorer, motor 1,5 kW, 100 Hz, joined to 1+1 Hogger, motor 3 / 4,4 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 Hz2nd postFront: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzRear: 1+1 Fixed milling, tilting, motor 2,2/3,3 kW, 50/100 Hz3th postFront: 1+0 Jump milling, tilting, motor 2,2/3,3 kW, 50/100 HzRear: 1+1 Jump milling, tilting, motor 1,5 kW, 100 HzAll units with horizontal/vertical adjustment and Siko read-outOutfeed chain approx. 80 cm lengthSound and safety enclosures
