TECHNICAL DATA: Usable width: 1160 mm Installed power: 0.50 kW
Kuper FW 1150 veneer splicer Working width 1150mm Veneer thickness 0.4-3mm Feed speed 10-30m/min Zigzag stitching Year of manufacture 1997 CE mark Weight 520kg Net price
Code: 0240 Brand: KUPER Model: FW /J 900 Veneer thread splicer Technical data : Throat depth mm 900 Feed speed mt 15/min Thickness of veneer 0,4 - 2 mm Motor 0,18 Kw Overall dimensions: mm 1350 x 580 x 1600 h Weight kg 300
KUPER FW-920 Zig-Zag Veneer Gluer Passage width max. approx. 920 mm, veneer thickness approx. 0.4 - 2 mm, feed speed approx. 15 m/min
Code: 0599 Brand: KUPER Model: FW 1200 Thread splicer for veneer Reach mm 1200 Veneer thickness from 0,3 mm to 3 mm Feed speed from 10 to 50 mt/min Worktop height mm 925 Electrical connection 1,5 Kw Overall dimensions: mm 2150 x 750 x 1650 h Weight kg 425
Code: 0487 Brand: KUPER Model: 630 Thread splicer for veneer with base Technical data: Throat depth mm 630 Thickness of veneers 0,4 - 2 mm Feed speed 7 mt/min Volt 220 single-phase Overall dimensions : mm 950 x 500 x 1180 h Weight kg 95
SPECIFICATIONS: Working width: 420 mm Feed speed: 6 m/min Voltage: 230 V
thread splicer machine for veneer model KUPER FW 1150 second hand machine volt. 380/50
I sell the veneer assembly machine KUPER FLI. Built in 2007. Very good condition. Available the same.
Kuper FWM 630 ST Veneer gluing machine Column projection 630 mm Driving equipment Feed rate approx. 7 m/min Drive electric motor 25 watts / 230 V Heating head approx. 75 watts G&-5106-O0691
Zig - Zag Veneer Splicing Machine Kuper Type: FW-Pimus (special model) Year of construction 2008 Nominal current 4 A Voltage: 230 V Specifications: Stand projection: 920 mm Working height: 950 mm Veneer thickness: approx. 0.4 to 2.0 mm (also thick veneer) Feed in 3 stages: approx. 10 to 23 m/min 3 K heating system. The new temperature control ensures optimal melting results of the adhesive thread and thus ensures a perfect connection. Discus discs with tolerance compensation mechanism Electrically controlled thread tear-off roller new heating system with standstill control Frequency converter controlled drive Space requirement: approx. 1,400 x 560 x 1,470 mm Incl. accessories
Fabr: Kuper Type: FW Machine No: 0371 Year: 1966 Stand projection: 1150 mm Throughput speed: approx. 10 - 30 m min. Propulsion: Brake motor 0.55 kW 380 V, optionally 220 V three-phase current Total connected load: 1.8 kW Heating: 7 V 120 W Weight: 630 kg Space requirement: 2300 / 800 mm Crate dimensions: 2450 / 1450 / 900 mm Ship space: 3.2 m³
Fabr: Kuper Machine type: ST/I-1200 Machine number: 7560 Year: 1991 Power: approx. 51kW Working width: 1200mm PROVIDER
Veneer assembly machine model FWL 1200, Joining, gluing, thread and white gluing
Kuper Veneer Zigzag Veneer Composition Machine, Type FW/ 1200-E Year of manufacture 1995 S/N 3508 3179 Special features of the KUPER FW 1200 E: high feed speed of 60 m/min. electronically infinitely adjustable zigzag width of the glue thread cutting device veneer thickness : 3.0 mm min. veneer thickness : 0.3 mm Glued thread with hot air heating Compressed air generation Discus for transporting the veneer over the veneer table Control via foot pedal Feed Speed: 35-60m/min Voltage: 400 V, 50 Hz Total power 1.35 kW Working height 915mm Bzunfcilke Weight approx. : 440 kg Dimensions : 2,12m x 0,73m x 1,55m
Longitudinal Splicer Manufactured by Kuper Model: FL/Rapid
Longitudinal Splicer Manufactured by KUPER Model: FL/I-1000 - FL/INNOVATION
Number of spindles: 6 St. Working width: 230 mm Working height: 150 mm Length of the planing table: 2000 mm Feed motor: 5,5 kW Feed speed: 7-36 m/min. uper SWT 23 XL-6 Four-Sided Planer ----------------------------------------------- Machine fully functional tested! ... Working width min/max: 18 - 230 mm Working height min/max: 8 - 150 mm Spindle configuration: 1st Spindle - bottom ----------------------------------------------- Power: 5.5 kW Speed: 6,200 rpm, incl. brake Spindle diameter: 40 mm Spindle length: 240 mm Pulley diameter: 160 mm Adjustment: axial and radial, manual 2nd Spindle - right ------------------ Power: 5.5 kW Speed: 6,200 rpm, incl. brake Spindle diameter: 40 mm Spindle length: 160 mm Pulley diameter: min. 110 mm - max. 200 mm Adjustment: axial and radial, manual, via mechanical digital display Adjustment: vertical 35 mm below Table 3rd Spindle - Left --------------- ...
Working width: 260 mm; Working height: 130 mm ; Working waves: 5; Spindle arrangement: down, right, left, up, down; Slot bed: yes; Motor power shaft bottom: 5.5kW; Motor power shaft right: 5.5 kW; Motor power shaft left: 7.5 kW; Motor power shaft top: 7.5 kW; Motor power shaft bottom: 7.5 kW; Adjustment shaft bottom: crank; Adjustment shaft right: crank; Adjustment shaft left: crank; Adjustment shaft top: crank; Planer heads: Centrolock; Feed speed: infinitely variable; Feed roller pressure: pneumatic; Current consumption: 50A; Current consumption: 71.7A;
Veneer splicing machine manufactured in 2007. This KUPER FLI model is designed for precision veneer splicing. It operates at a voltage of 400 V and a rated current of 14.5 A. If you are looking to get high-quality veneer processing capabilities, consider the KUPER FLI Veneer splicing machine we have for sale. Contact us for further details.
voltage: 220 V collets: 8mm Motor output: 1,8 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Number of spindles: 4 St. Working width: 15 - 230 mm Working height: 10 - 125 mm Feed speed: 6 - 24 m/min. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Number of spindles: 5 St. Working width: 250 mm Working height: 160 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 6-24 m/min. control: K2 Basic 7-Touch KUPER SWT XL-5 AUTOMATIC PLANER AND MOULDER ------------------------------- LIKE NEW, showroom machine ! - 5 spindles: bottom, right, left, top, bottom - Speed: frequency-controlled 4,000 - 6,000 rpm, spindle 4.5 to 8,000 rpm - Width and height motor-controlled: left spindle radial upper spindle axial - Feed carrier motor-controlled - Additional motor-controlled positioning: right spindle radial and axial left spindle axial - working width 250 mm TECHNICAL DATA ------------------------------- Working width (perimeter of tools 163 mm) 15 - 230 mm Working height(perimeter of tools 163 mm) 10 - 150 mm (perimeter of tools 123 mm) 10 - 160 mm Min. workpiece length: single piece: min. 800 mm piece by piece: min. 300 mm Th ...
Number of spindles: 5 St. Working width: 230 mm Working height: 160 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 6-24 m/min. Control: K2 Basic 7-Touch KUPER SWT XL-5 AUTOMATIC PLANER AND MOULDER ------------------------------- LIKE NEW, showroom machine ! - 5 spindles: bottom, right, left, top, bottom - Speed: frequency-controlled 4,000 - 6,000 rpm - Width and height motor-controlled: left spindle radial upper spindle axial - Feed carriage motorized adjustment TECHNICAL DATA in Detail ------------------------------- Working width (for tool diameter 125-163 mm): 15-230 mm Working height (for tool diameter 125 mm): 10-160 mm (Tool diameter up to 163 mm): 10-160 mm Min. workpiece length: single piece: min. 800 mm piece by piece: min. 300 mm The processing of the work pieces is depending on the following operating parameters: material, wood moisture, tools, diameter ...
