turning diameter over bed:340 mmturning diameter over slide rest:190 mmturning length:700 mmspindle bore:50 mmshaving-spindle speed range:40 - 3.000 U/mindimensions of the machine ca.:2 x 1 x 1,6 mtotal power requirement:6 kWweight of the machine ca.:1,2 t
turning diameter:1070 mmturning length:8500 mmtotal power requirement:62 kWturning diameter over slide rest:800 mmspindle bore:128 mmmax. workpiece weight between centers:8000 kgmax. workpiece weight:12000 kgbore spindle turning speed range:1,120-01120 U/mintailstock quill diameter:200 mmdimensions of the machine ca.:12 x 2,8 x 2,4 mMachine equiped with Alan Bradley 9 series CNC control- SAUTER 6-postiion revolving head- 360 mm seld centering steady rest- 385 mm rotary work rest (used for gun barrels)- faceplate 800 mm- chip conveyor
Automatic bar loading magazine for single spindle automatic lathe / short lathe, newTEST the new DB-EVO bar loader4 WEEKS, NON-BINDING, FREE OF CHARGE (conditions on request)very high speeds even with profile materialManufacturer: Giovanni CucchiMachine type: Automatic bar loading magazine for single-spindle / short turningType: DB-EVODesign: Surface loading magazine or bundle loading magazinediameter range: 20-110mmDB-EVO at a glance:Scope of delivery and optionally orderable functions:- oriented loading of the bar material possible (e.g. edge upwards) - optional feeding of saw cuts and short parts possible - optional- Monitoring and fault diagnosis (touch screen)- Surface magazine- Bundles and other variants possible- automatic loading of short bars- Trays for tools- low power consumption (start/stop function)- Available in versions for 1.5, 1.8, 2.5, 3.3, 4.2 and 6.1 meter rod length ...
turning diameter:830 mmturning length:4.000 mmturning diameter over bed slide:540 spindle bore:130 mmturning speed range:2 - 1.600 U/minrapid speed:4/5 m/minfeed speeds:1 - 2.000 mm/mintotal power requirement:55 kWdimensions of the machine ca.:7 x 2,2 x 2 mweight of the machine ca.:7,5 t
Bar loading magazine for multi spindle automatic lathe, newManufacturer: Giovanni CucchiMachine type: Bar loading magazine for multi-spindleType: CMSP/CMSPFDesign: Side loader as surface loading magazine or bundle loading magazineCMSP / CMSPF at a glance:Proven technology - in use for decadesThe material feed of this loader generation is carried out by the loading magazine. Bar loading magazines CMSP/CMSPF are mounted on rails, so they can be easily disconnected from the machine at any time by unlocking them at the quick release.These magazines do not require bar tubes on the machine and are screwed directly to the machine. It is possible to work in automatic mode as well as in manual mode.The magazine is mounted on rails, so it can be easily disconnected from the machine at any time by the operator by unlocking it on the machine. To change bar diameters, only the clamping sleeves of the ...
LINEAR AXLE:. - Number of moving slides:2 DIMENSIONS / WEIGHTS:. - space requirements length:15000 mm
x-travel:1270 mmy-travel:460 mmz-travel:660 mmMachine hours: 58,355Spindle speed: 8,000 rpm
LINEAR AXLE:. - Number of moving slides:2 DIMENSIONS / WEIGHTS:. - space requirements length:7000 mm
x-travel:1020 mmy-travel:510 mmz-travel:510 mmTable 1,200 x 530 mmMax. table load 800 kgSpindle mount ISO 40 Spindle speeds 10,000 rpmDrive power 14.5 kWTool changer 20-position Coolant system External coolingChip conveyor YesThe Y-cover is leaking (see photos)
LINEAR AXLE:. - Number of moving slides:1 DIMENSIONS / WEIGHTS:. - space requirements length:10000 mm
total power requirement:2,2 kWdimensions of the machine ca.:2,15 x 1,47 x 2,24 mJAESPA V 380 DG /DGHS Vertical Mitre Band SawThis machine is a vertical double-mitre band saw designed for professional use in the metal, steel and mechanical engineering industries. In addition to straight 90° cuts, this band saw also enables mitre cuts to the left and right. The mitre range is up to 60° on one side and up to 45° on the other. This makes the machine particularly suitable for cutting profiles, tubes and solid material. The cutting speed and hydraulic saw feed can be adjusted to suit the material being cut. The machine is equipped with a coolant system.Technical specifications:·Saw motor: 2.2 kW·Hydraulic pump: 0.37 kW·Coolant pump: 0.18 kW·Belt speed: 17?100 m/min·Saw blade dimensions: 4,250 × 34 × 1.1 mm·Workpiece support height: 1,000 mm·Coolant tank: 50 litresRobust industrial ...
Erodiermaschine, gebrauchtBaujahr: 1989Bitte kontaktieren Sie uns für weitere Informationen und Bilder über mail(at)tar-mc.com oder www.tar-mc.com
LINEAR AXLE:. - Number of moving slides:1 DIMENSIONS / WEIGHTS:. - space requirements length:5000 mm
x-travel:1400 mmy-travel:400 mmz-travel:500 mmtotal power requirement:ca. 7,5 kWweight of the machine ca.:ca. 2,7 tdimensions of the machine ca.:ca. 2,60 × 2,30 × 2,20 mThe KNUTH KB 1400 is a conventional bed-type milling machine designed for precise milling, drilling and threading operations on medium to large workpieces. The robust bed construction ensures high rigidity and machining accuracy, even for demanding machining tasks. Thanks to its robust construction, the machine is ideally suited for use in mechanical engineering, toolmaking, maintenance, and in single-part and small-batch production.Technical data ·X-axis travel: 1,400 mm ·Y-axis travel: 400 mm ·Z-axis travel: 500 mm ·Table size: 1,700 × 400 mm ·Table load capacity: approx. 800 kg ·Spindle chuck: SK 40 (DIN 69871) ·Spindle speed: 40?2,000 min?¹ ·Main drive: 7.5 kW ·Machine weight: approx. 2,700 kg ·Footpr ...
LINEAR AXLE:. - Number of moving slides:3 DIMENSIONS / WEIGHTS:. - space requirements length:16000 mm
x-travel:800 mmy-travel:300 mmz-travel:400 mmtotal power requirement:ca. 4,0 kWweight of the machine ca.:ca. 1,7 tdimensions of the machine ca.:ca. 2,10 × 1,90 × 2,00 mThe Klopp FWUE 8 is a conventional universal tool milling machine designed for precise milling, drilling and threading operations in toolmaking, mechanical engineering, maintenance, and single-part and small-batch production. Thanks to its horizontal and vertical milling capabilities, the machine offers versatile machining options for a wide variety of workpieces. The robust cast iron construction ensures high rigidity and machining accuracy, even during demanding milling operations.The machine is fitted with a 3-axis digital readout (DRO) and features automatic feeds along the X, Y and Z axes, selectable feed rates and a rapid traverse function. This enables convenient operation and precise positioning of the axes. The ...
LINEAR AXLE:. - Number of moving slides:1 DIMENSIONS / WEIGHTS:. - space requirements length:12000 mm
turning diameter:1600 mmturning length:6200 mmspindle bore:130 mmturning speed range:5 - 710 U/minturning diameter over bed slide:1250 total power requirement:37/52 kWweight of the machine ca.:16 tdimensions of the machine ca.:12 x 4 x 2 mCNC SIEMENS Sinumerik3-jaw chuck SCHUNK Rota Plus, diameter 630 mm3 x fixed liners (1200 / 570 / 400 mm)Coolant system and chip conveyorMiscellaneous accessories
LINEAR AXLE:. - Number of moving slides:1 DIMENSIONS / WEIGHTS:. - space requirements length:5000 mm
honing diameter:45-200 mmstroke:330 mmcentre height:350-700 mmMotor output:1,5 kWDrill rods: Ø 60mm ? 3000mm long Ø 50mm ? 2600mm long Ø 42mm ? 1920mm long Ø 40mm ? 1920mm long Ø 26mm ? 1270mm long Ø 24 mm ? 1,000 mm long Ø 20 mm ? 2,000 mm longTypical featuresFeed: Infinitely variable in both directionsDrive: Separate control of spindle rotation and vertical movementCentring: Manual or via dial gauge centring bridgesGeometry & working range (approximate values based on the BO series)Drilling range (Ø): approx. 24 mm to 150 mm (depending on the drill rods andcutter heads used)Distance from table to centre of spindle: Variably adjustable (typically approx. 350 mm to over 700 mm forlarge commercial vehicle engine blocks)
LINEAR AXLE:. - Number of moving slides:3 DIMENSIONS / WEIGHTS:. - space requirements length:24000 mm - total weight approx.:10100 kg
Arntz Blue Line saw bladeLength: 5800 mmSpecification: 41 x 1.3 mm 2/3 KCarbide band saw blades with pre-cutting and post-cutting geometry for machining non-ferrous metals and graphite.The specialist for:- Aluminium alloys - Aluminium bronzes - Copper alloys - Sand-cast aluminium and magnesium castings - Graphite
LINEAR AXLE:. - Number of moving slides:3 DIMENSIONS / WEIGHTS:. - space requirements length:19000 mm
x-travel:3500 mmy-travel:2500 mmz-travel:1250 mmweight of the machine ca.:50 tJOBS JO?MACH 241 ? CNC gantry machining centreThe JOBS JO?MACH 241 is a high-performance CNC gantry machining centre designed for the precise machining of large, heavy and complex workpieces. The robust design, featuring a fixed gantry and a movable worktable, ensures high rigidity and stable machining conditions.With travel ranges of 3,500 mm on the X-axis, 2,500 mm on the Y-axis and 1,250 mm on the Z-axis, the machine offers a generous working area. The clearance between the columns is approximately 2,200 mm. The worktable, measuring approximately 3,000 × 1,500 mm, is designed to accommodate workpieces weighing up to 12,000 kg.The two-axis, swivelling milling head enables the machining of complex contours and hard-to-reach surfaces in multiple spatial directions. This makes the JO?MACH 241 particularly suita ...
LINEAR AXLE:. - Number of moving slides:2 DIMENSIONS / WEIGHTS:. - space requirements length:7000 mm
spindle diameter:130 mmx-travel:5000 mmy-travel:3000 mmz-travel:2000 mmThe TOS Varnsdorf WHQ 13 CNC is a high-performance CNC-controlled horizontal table drill press fitted with a Siemens Sinumerik 840D CNC control system, designed for the precise machining of large and heavy workpieces. The machine is suitable for drilling, boring and milling complex components and is typically used in heavy machinery manufacturing, plant engineering, toolmaking, and in the energy and heavy industries.With generous travel ranges of 5,000 mm on the X-axis, 3,000 mm on the Y-axis and 2,000 mm on the Z-axis, the machine offers an extensive working area. The worktable, measuring 2,500 × 1,800 mm, can accommodate workpieces weighing up to 20 tonnes.The horizontal spindle achieves a speed of up to 3,000 rpm. In combination with the supplied milling head, even demanding milling operations and various machinin ...
LINEAR AXLE:. - Movement:3500 mm - Number of moving slides:1 DIMENSIONS / WEIGHTS:. - space requirements length:5000 mm
x-travel:60 mmThe RIMAC BETAMATIK is a specialised collector mica milling machine for the manufacture and repair of electric armatures and commutators. It is used for the precise milling or undercutting of the mica insulation between the individual copper lamellae of a collector.The mica joints are detected by a laser optical system. A stepper motor then automatically positions the armature from lamella to lamella. The milling cutter is automatically raised during the return stroke. According to the data sheet, the machining time is approximately 0.8 to 1.3 seconds per lamella.The machine can process armatures up to a diameter of 100 mm, collectors up to 70 mm in diameter and shafts up to 500 mm in length. The maximum milling length is 60 mm. The milling spindle reaches 8,000 rpm.The machine, originally purchased around 1983/1984, was extensively modernised and mechanically overhauled in ...
LINEAR AXLE:. - Movement:2500 mm - Number of moving slides:1 DIMENSIONS / WEIGHTS:. - space requirements length:4000 mm
