Coordinate Measuring Machines used for sale (20)

Inv. Num. : 9022 Type: CRYSTA APEX C9206 Producer: Mitutoyo Created: 2006 Parameters: Axis X: 2000 mm Axis Y: 900 mm Axis Z: 600 mm Max. workpiece weight: 400 kg

A deposit of €800.00 is required in order to submit a bid on this lot. To receive the bank details necessary for the transfer, please contact the auction representative at alessandro.icardi@surplex.com. Granite top size 1915x1070 mm Tables, accessories and measuring instruments included. Note: The functionality of the goods has not been verified. They are sold in their existing state, without warranty of operation. Auction-ID: A7-43861-13

Software Zeiss Calypso Measuring head RDS VAST XXT Measuring range 1000,1600,600 mm Max Workpiece size 1220,1935,620 mm

Reading hours reading 9845 HR, equipped with granite table + upper frame, control panel, 2x screen, various documentation, Auction-ID: A1-43992-35

3D coordinate measuring machine XM 1600 control unit Measuring range on the table 200 x 200 x 200 mm Maximum measuring range 2000 x 1200 x 1000 mm Accuracy: +/- 7μm Repeatability: +/- 3μm

Measuring range: 1.000 mmerror limit 20°C +/- 1°C: 3 + L(mm) / 300 µmrepeatability: 2sec: 2 µmResolution: 0,01 / 0,001 mmadjustment speed: max. man. 1 m/sPower: 0,7 - 1,6 Ntemperature: +10 .. +40 °Ctotal power requirement: 15 Wweight of the machine ca.: 15,0 kgdimensions of the machine ca.: 0,4 x 0,4 x 1,30 mDocuments: Transmission: RS 232 Height Measuring DeviceTRIMOS - V 1002+- Application area: 1.235mm- Max. angularity deviation: 12µm- Autonomy with air cushion: 30h- Autonomy without air cushion: 100hThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Faro Gage Plus 6-axis measuring arm Measuring arm length 4ft (approx. 1.2m) Accuracy 5+8L/1000μm with trolley, accessories and associated transport case Incl. software and operating instructions Never used/Unused - Mint

x-travel: 1600 mmy-travel: 4000 mmz-travel: 1200 mmworkpiece weight: 3500 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MITUTOYO Crysta Apex CRT-A910 coordinate measuring machine was built in Japan by Mitutoyo Corporation. This extremely advanced machine, characterised by the highest accuracy and objectivity, is used for highly accurate workpiece measurements. Workpiece measurements are performed using the contact or non-contact method, which are then represented as a set of coordinate points. The use of this method makes it possible to measure parts with very complex shapes, which cannot be measured with ordinary measuring instruments. The MITUTOYO Crysta Apex CMM measuring machine is offered with a PC with software. Technical specifications of the MITUTOYO Crysta Apex CRT-A910 measuring machine - measuring range in the X/Y/Z axis: 900/1000/800 mm - measuring resolution: 0.1 µm - measuring speed: 300 mm/s - PC with software - compressed air pressure: 0.4 MPa - compressed air consumption: 50 l/m ...

Serviced and calibrated by Studenroth on 24.07.2024Equipment/accessories:-Software-monitor and computer-Technical documentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Mitutoyo 3D CNC Measuring Machine Manufacturer: Mitutoyo Model No.: BN706 Code No. 3700M-312 Type: Coordinate Measuring Machine Granite Measuring Plate Measuring range: X-axis: 700 mm Y-axis: 600 mm Z-axis: 600 mm Table size: 850 x 1200 mm Dimensions: (W x L x H) 1600 x 1800 x 2600 mm Not function-tested More items - new and used - can be found in our shop! International shipping costs on request!

Control: / The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ADCOLE 1200 SH cylindrical coordinate measuring machine was built in 1990 in the United States by ADCOLE CORPORATION. The machine is used for measuring tight tolerances on camshafts, crankshafts and other cylindrical parts. The patented laser interferometer technology ensures the realisation of precise radial measurements with an accuracy of up to 0.5 μm. The ADCOLE Model 1200 coordinate measuring machine, including all components, weighs 5325 kg. Technical specifications of the ADCOLE 1200 SH crankshaft and camshaft measuring machine - machine dimensions (L x W x H): 1075 x 1195 x 2890 mm - peripheral table dimensions (L x W x H): 715 x 465 x 825 mm - control cabinet dimensions (L x W x H): 800 x 800 x 1800-2000 mm - machine weight: 3525 kg - total weight of the machine including all components: 5325 kg

Measuring range X,Y,Z 1200,1800,1000 mm Software calypso Measuring head 5 axis Vast XXT

Key data: 508 mm, 406 mm, 406 mm

Coordinate measuring machine X 508 mm Y 406.4 mm Z 406.4 mm Software: CMM Manager or Verisurf Probing System: Renishaw PH10T/TP20 Controller Type: Mitutoyo UCC200 All information without guarantee Attention: The measuring machine has PC damage, but otherwise the structure is perfect. Dongle is available Sold as a defect! New price was approx. 38,000.00 euros

Camera, hand button with display Max. gauge length 10000/3500/3500 mm Certified measuring range 3000/1500/1500 mm Triple camera Integrated probe camera Measurement accuracy ±(28 + 5 L/1000) μm Repeatability ±10 μm

Dear Ladies and Gentlemen, We are looking for a buyer for an image-guided 3D coordinate measuring machine, make Keyence, XM series. Date of purchase 2018, but virtually unused. License would have to be transferable, there doesn't seem to be any restriction of Keyence here. Please feel free to contact us if you need more information. We look forward to your offer.

Inv. Num. : 7182 Type: Crysta Plus M544 Producer: Mitutoyo Created: 2012 Parameters: Table dimensions: 860 x 638 mm Axis X: 505 mm Axis Y: 405 mm Z axis: 405 mm Max. workpiece weight: 180 kg Machine dimensions: 2185 x 1082 x 1078 mm Machine weight: 440 kg

DEA GLOBAL S 07.05.05 coordinate measuring machine was manufactured in Italy in 2004. The machine performs fast and highly accurate measurements of workpieces with complex shapes using the contact or non-contact method, represented as a set of coordinate points. The excellent quality and precision of the process is guaranteed thanks to the mounted in the DEA GLOBAL S 07 05 05 CMM machine an indexable RENISHAW PH10MQ measuring head with a RENISHAW SP25M scanning probe, performing measurements in the X,Y,Z axes with feeds of 700 mm (X axis), 500 mm (Y axis) and 500 mm (Z axis). The DEA GLOBAL Status 07.05.05 measuring machine is also equipped with the highly advanced metrology software PC-DMIS 2019 R1, performing detailed geometric measurements. Technical specifications of the DEA GLOBAL S 07.05.05 measuring machine - maximum permissible error of length measurement MPEe: ± 2.3 + 3L/10 ...

Control UCC lite-2 Measuring range 700 x 450 x 350 mm Measuring heads (MH20i, PH1, PH6) Various touch probes
