Die-Sinking Spark Erosion Machine Tools used for sale (24)

Inv. Num. : 9172 Type: EDNC 65 Producer: MAKINO Created: 1998 Parameters: Max. travel length of the X-axis: 650 mm Max. travel length of the Y-axis: 450 mm Max. travel length of the Z-axis: 350 mm Maximum electrode weight: 100 kg

Powerful die-sinking EDM machine Elotherm P1F with a large working area and extensive peripheral system. The machine has a CNC control system with screen operation, integrated keyboard and additional Elotrace hand control unit. Large-sized working pool with approx. 1900 × 1300 × 500 mm pool size. Extensive filter, pump and dielectric system available. The system was used productively in tool and mould making. Equipment: · CNC control with screen control · Control panel with integrated keyboard · Elotrace hand control unit · Working range approx. X 1200 mm / Y 950 mm / Z 550 mm · Large work basin approx. 1900 × 1300 × 500 mm · Extensive peripheral system with pump and filter system · Filtertechnik Franken Filtertechnik KG Type RF 70 · Filter volume 250 l · Multi-stage filter unit · Pipeline and hose system available · Integrated CO₂ extinguishing system · 400 V / 50 Hz ...

Die-sinking EDM machine Manufacturer: Exeron Type: 312 Year of Make: 2004 Control MF10 Travel paths X/Y/Z: 450 x 300 x 300 mm Work table: 820 x 400 mm Working container: 900 x 520 mm Distance table / quill: 150 / 450 mm Max. electrode mass: 30 / 150 kg Max. workpiece weight: 800 kg Filling height work basin: 300 mm 20-fold tool changer Generator current: 60 A Power supply: 400 V Three-phase current: 50 Hz Power consumption: 8 kVA Overall dimensions W/D/ H approx.: 1,910 x 1,798 x 2,300 mm

Technical data Engine COBRA-B Work table (w × d)500 × 360 mm Work container (w × t)800 × 500 mm Max. distance to the working head to the work table450 mm Travel (X, Y)300 × 200 mm Max. workpiece weight300 kg Drilling diameter0.5 – 3.0 mm Option0.3 – 4.0 mm Max. feed speed250 mm/min. Machine weight900 kg Dielectric system Fuel tank capacity35 litres Power consumption1.0 kVA Auction-ID: A7-48332-800

Key data: 1000 A, 760 , 60

Refurbished OPS Ingersoll Gantry 800 Eagle die-sinking EDM machine – technically and visually in top condition The machine has been comprehensively and professionally overhauled in our company and is in very good condition, both technically and visually. In the course of the overhaul, more than 70% of the machine was dismantled. All relevant wear parts were carefully checked and replaced if necessary, including ball rollers and drive spindles. This was followed by a complete geometric measurement, alignment and additional control using a laser measuring system. The machine bed and the entire base were thoroughly cleaned. All pumps were disassembled, cleaned and overhauled. All hoses, including hydraulic and compressed air hoses, have been completely renewed. In addition, the machine has been completely repainted and also presents itself visually in a very neat condition.  ...

Large-format CNC die-sinking EDM machine AEG ELOTHERM P1 in heavy-duty industrial design with solid casting machine bed and gantry design. The machine is particularly suitable for tool and mould making as well as for machining large workpieces and dies. Travel distances X 992 mm, Y 807 mm and Z 561 mm. Pool dimensions approx. 1260 × 1060 × 550 mm. Operating hours according to the display approx. 72,180 h. Equipment: · Original ELO/AEG CNC control with digital display · Separate control panel with keypad and control console · Heavy work table with T-slots · Electrode holder on the Z-axis · Multiple filter system with several filter containers · Dielectric system with pump units · Integrated CO₂ extinguishing system · Servo Driven Axes · Large work basin for large-format workpieces Notes: · Age-related signs of wear present · Visible contamination in the area of the auxili ...

Key data: 1000 A, 760 , 60

Refurbished OPS Ingersoll Gantry 800 Eagle die-sinking EDM machine – technically and visually in top condition The machine has been comprehensively and professionally overhauled in our company and is in very good condition, both technically and visually. In the course of the overhaul, more than 70% of the machine was dismantled. All relevant wear parts were carefully checked and replaced if necessary, including ball rollers and drive spindles. This was followed by a complete geometric measurement, alignment and additional control using a laser measuring system. The machine bed and the entire base were thoroughly cleaned. All pumps were disassembled, cleaned and overhauled. All hoses, including hydraulic and compressed air hoses, have been completely renewed. In addition, the machine has been completely repainted and also presents itself visually in a very neat condition.  ...

CONTROLS  CNC controls TECHNICAL SPECIFICATION  Case size: 860 mm  .. x: 620 mm  Adjustment of  x-axis: 350 mm  Adjustment of  y-axis: 250 mm  Erosion stroke: 350 mm  Max. dist. table-electr.clamp.surf.: 520 mmELECTRICAL SPECIFICATIONS  mains power supply: 8.3 kVA  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2700 mm  space requirements -front/back-: 1900 mm  total height: 2600 mm  total weight approx.: 3000 kgDescription- Work container can be lowered- C axis for rotation, indexing and erosion- AGIEVISION control incl. TECTRON, AGIESETUP 2D- USER SEQUENCE, SPACETRACK, AGIEPATH with GEOEDITOR- Electrode changer 28 times- Incl. EROWA pneumatic chuck

Key data: 750 mm, 650 mm, 60 A

Refurbished OPS Ingersoll Gantry 500 Eagle die-sinking EDM machine – technically and visually in top condition The machine has been comprehensively and professionally overhauled in our company and is in very good condition, both technically and visually. In the course of the overhaul, more than 70% of the machine was dismantled. All relevant wear parts were carefully checked and replaced if necessary, including ball rollers and drive spindles. This was followed by a complete geometric measurement, alignment and additional control using a laser measuring system. The machine bed and the entire base were thoroughly cleaned. All pumps were disassembled, cleaned and overhauled. All hoses, including hydraulic and compressed air hoses, have been completely renewed. In addition, the machine has been completely repainted and also presents itself visually in a very neat condition.  ...

CHARMILLES TECHNOLOGIES ROBOFORM 50Control:Charmilles CNC control (Mark series, graphical interface)Table / Working Area:Table size: approx. 500 x 400 mmMax. workpiece weight: approx. 500 kgAutomation equipment:Erowa ITS rotary changer (carousel, approx. 16–24 positions)Automatic electrode changingPrepared for unattended operatioDielectric tank with filter systemCharmilles generatorControl panel with screen and keyboardHandheld control device / Clamping system

Key data: 1770 A, 1220 , 70

The OPS INGERSOLL EDM machine GANTRY 1200 HSJ / 64 bit, built in 2006, has been comprehensively and professionally overhauled in our company and is in very good condition, both technically and visually. In the course of the overhaul, more than 70% of the machine was dismantled. All relevant wear parts have been carefully checked. The following overhaul work was carried out on the above-mentioned machine: Replacement of ball screw and ball bearings of the X, Y and Z axis. Replacement of all (4) ball screws of the tank drive. Inspection and test of the C-axis for tightness and accuracy Geometric verification of all axes according to OPS INGERSOLL protocol. Basic cleaning of the complete machine base. Cleaning of the complete working tank including replacement of the felt scrapers. Complete painting of the machine. Overhaul of the dielectric pumps.  ...

CONTROLS  CNC controls TECHNICAL SPECIFICATION  current generation (max): 3600 A  Table-size         : 660 mm  Table-size         : 540 mm  Working head: electr.clamping surf.: 375 mm  .. x: 545 mmDIMENSIONS / WEIGHTS  space requirements -left/right-: 2200 mm  space requirements -front/back-: 2560 mm  total height: 2870 mmThe precision electrochemical metal machining (PECM) process is the further development of electrochemical countersinking. High-precision tools can also be machined from super alloys (Inconel, Hastelloy, etc.) and PM steels without process-related tool wear.Natural granite machine frameWorking area 800 mm x 640 mm (W x D)Machine table 660 mm x 540 mm (W x D)Maintenance-free precision work axis with direct driveFixture attachment via 6 T-slot rails (M10) in the machine tableReal-time system for process control and short-circuit detecti ...

We are selling our die-sinking EDM system here because of a new acquisition. This is a machine that was sold by the company MATRA at that time. This is a DECKEL DE35C. In the meantime, the company Exeron has taken over the service. The travel is: X=600mm Y=400mm Z=400mm The die-sinking EDM system has a 4-fold electrode changer The control system on the machine was recently overhauled, the power supply and the UPS were renewed. The machine was also otherwise continuously checked and maintained by the Exeron company in the event of malfunctions. Machine is running and is still on the power for a possible test. Operating hours are: 33196 hours. Various tool holders can be part of the price negotiation.

table length: 840 mmtable width: 600 mmampere: 60-120 Atotal power requirement: 15-23 kVAweight of the machine ca.: 2,75 tdimensions of the machine ca.: 2760 x 1110 x 1840 mWith controlled C-axis and 16-position tool changer.WORKTABLETable size: 840 x 600 mmDielectric above table: 360 mmMaximum workpiece weight: 1000 kgT-slots: 4 x 10 mmDistance table to quill without chuck (max / min): 595 / 180 mmWORKHEADX - Y travel: 565 x 400 mmZ travel: 415 mmX - Y - Z resolution: 0.001 mmC-axis resolution: 0.001 deg.Rapid traverse speed: 800 mm/minMax. electrode weight without rotation: 100 kgMax. electrode weight with rotation: 15 kgDIELECTRIC SUPPLYTank volume: 400 litersPaper candle filters: 4 piecesGENERATORDimensions (height x width x depth): 1800 x 600 x 920 mmWeight: 300 kgRated current: 60 – 120 APower rating: 15 – 23 kVADimensions (height x width x depth): 2760 x 1110 x 1840 mmWeight:  ...

2 x die-sinking EDM machines ZK Genius 700 BJ 1010 and 2019

CONTROLS  CNC controls WORKING RANGE -CUBIC-  X-axis travel: 250 mm  Y-axis travel: 160 mm  Z-axis travel: 250 mmTECHNICAL SPECIFICATION  Table-size         : 480 mm  Table-size         : 330 mm  Adjustment of  x-axis: 250 mm  Adjustment of  y-axis: 160 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 1200 mm  space requirements -front/back-: 1200 mm  total height: 2500 mm  total weight approx.: 1000 kgEquipment:-Agietron Compact 1 30A/C-axis / DAI 1-P-AGIE Fuzzytron-14 color screen-Fire extinguishing system-3-compartment electrode magazine-Micro-machining variant-lots of accessories

Control PC-NC Dialog Travel X/Y/Z: 1000/1510/700 mm C-axis 30-fold electrode changer Hirschmann clamping system Bearing surface WxD 1140/1640 mm Load capacity 7500 kg Filter system Fire extinguishing system

table length: 780 mmtable width: 500 mmampere: - AControl: Heidenhain 121 total power requirement: - kWweight of the machine ca.: 3,5 tdimensions of the machine ca.: 2 x 2 x 2 mNo. 1564Die-sinking EDM machine HANSEN 750 Smax. workpiece weight 100 kgWorking area: 500 x 300 x 375Control: Heidenhain TNC-121 Eropuls NC-2000Table 780 x 500 mmSpace requirement approx. 2 x 1.5 mWeight approx. 3.7 tonsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

X, Y, Z Travel :600x400x400 mm Machine dimentions WxDxH : 1600x2700x2858 mm Machine weight :440 kg Workpiece dimentions WxDxH :1000x700x400 mm Max. electrode weight :100kg Max. Workpiece weight 1000 kg

Key data: 572 mm, 400 mm, 32 A

Die-sinking EDM machine x 350 mm y 250 mm z 315 mm Distance table - quill 550 mm Chuck 3R Macro Erosion Power Module EPO Fire extinguishing system Data Dielectric 250 liters extracted Length 1.75 m Width 2.10 m Height 2.53 m

Key data: 750 mm, 500 mm, 64 A

Inv. Num. : 5897 Type: Roboform 54P Producer: Charmilles Created: 2000 Parameters: Table dimensions: 750x500 mm Maximum operating current: 64 A Max. travel length of the X-axis: 600 mm Max. travel length of the Y-axis: 400 mm Max. travel length of the Z-axis: 450 mm Container dimensions: 1200x775x385 mm Machine weight: 3000 kg New Source

Inv. Num. : 6445 Type: BF 74 Producer: CDM ROVELLA Generated: 2008 Parameters: Workpiece length: 800 mm Workpiece width: 550 mm travel length of the X-axis: 700 mm Travel length of the Y-axis: 400 mm Travel length of the Z-axis: 350 mm Maximum table load: 2000 kg Maximum electrode weight: 90 kg Tank dimensions: 1200 x 750 x 505 mm Weight: 4400 kg

Capacity: 120 Amp. – 19 kVA X-axis: 800 mm Y-axis: 600 mm Z-axis: 400 mm Table dimensions: 1,100 x 700 mm Distance head - table: 950 mm (max) Oil retainer: 1,700 x 1,000 x 650 mm Workpiece weight: 4,000 kg (Max) Control: CNC Datic S120

Year of manufacture 2001 generator multi pulse - 70 amp + 100 amp booster Control Mitsubishi 32 bit - CNC travel (X, Y, Z) 900 x 1,780 x 550 mm Bowl (W x D x H) 1300 x 2200 x 730 mm workpiece clamping table (B x T) 1150 x 2050 mm accessories 13-fach pick-up linear changer, CO2 fire extinguishing status completely overhauled
