FARO Titanium Arm 7-Axis 3D Coordinate Measuring Arm Portable 3D coordinate measuring arm (CMM) from the FARO brand from the proven Titanium series. The device is characterized by high flexibility and precision directly in production or quality assurance. It was developed by FARO Technologies to perform precise, tactile measurements directly in manufacturing environments or for quality control. Key Features & Technical Details Technology: Manual, articulated measuring arm with internal encoders for precise detection of points in space. Areas of application: Ideal for initial sample inspections, component comparisons against CAD data and the measurement of sheet metal components and fixtures. Combination of mobile measuring arm (FARO Titanium) and welded assemblies 1. Initial situation and system advantages The integration of the Titanium FaroArm® into ...
Wenzel RS 1012 CNC 3D Coordinate Measuring Machine The Wenzel RS 1012 is a CNC 3D coordinate measuring machine (CMM) in horizontal arm design, which is designed for the precise measurement of medium- to large-volume workpieces such as components and assemblies. The machine concept is based on a stable cast iron or granite base plate as a measuring table with a side-mounted guide system, which enables open loading from three sides. Technical Core Components & Specifications Machine Type: Horizontal Arm 3D Coordinate Measuring Machine (CMM) Manufacturer: WENZEL Präzision GmbH Model / Year of manufacture: RS 1012 / 2002 Serial Number: 023116 Measuring volume (X/Y/Z): 2,000 mm × 1,000 mm × 1,200 mm Probing system: Renishaw PHC10-3 PLUS (interface/control for motorized rotary/swivel head PH10) Design: Horizontal arm measuring device (column measuring machine) with integrated ...
Steinheil KONTUR 408-2/D optoelectronic contour and shaft measuring system High-precision optoelectronic contour and shaft measuring system Steinheil KONTUR 408-2/D with high-quality Jenoptik optics The system is used for contactless, high-precision and fast measurement of rotationally symmetrical components (e.g. shafts, camshafts, turned parts) The device scans the measuring object without contact according to the shadow image principle. Rotational measurements are recorded with up to 1440 measuring points on the circumference per measuring point. The evaluation and quality control is carried out directly via an integrated SPC software (Statistical Process Control) based on Windows NT with clear tolerance bars and diagrams The system is housed in a closed aluminium profile housing with a transparent protective structure and is protected by professional safety light curtains ...
CNC Thread rolling and gear burnishing machine, ESCOFIER P440 CN, CNC Siemens, New 2004 - like new, 2-roll, 2 moving heads, 4000 daN rolling pressure, workpiece diameter: 100mm max., tool diameter: 180-245mm, Swivelling: +/-6°,, forward speed: 0.1-20mm/s, reverse speed: 0.1-30mm/s, motor power: 8.6kW, New: 2004, Condition: like new, under power in our warehouse, Mimu Machine Tools (Italy)
working area:10700 mmTube length:300-11000 mmmin. workpiece diameter:80 mmmax. workpiece diameter:260 mmPower:120 KWdimensions:21,5 x 5 x 3,8 m mmweight:90.000 kgpre-turn capacity:200 cdm/minHS Code: 8461 90 00Description of the systemManufacturer / Type Vario 1200-11000 Year of manufacture 1999Intended use peeling machine for pipes and solid material with ultrasonic measuring system for detection of wall thickness deviations and correction of the same.Machine control SIEMENS 840 D - 6 axesMax. speed on the scraper/peeling device: n = 200 min-1
screw size:45 mminjection shot weight in Polysterol:149 g/PSclosing pressure:100 kN
swing diameter:80 mmworkpiece length:450 mmweight of the machine ca.:3500 kg
table length:920 mmtable width:600 mmampere:13,2 Aweight of the machine ca.:6 tdimensions of the machine ca.:2,46 x 2,24 x 2,33 mX-axis:600 mmy-axis:400 mmZ-axis:260 mmmax. table load:1500 kgThe dimensions for transport are: wide 2240 mm x high 2330 mm x deep 2460 mm weight approx. 6000 kg.
