KASTOtec AC 5 for bi-metal or carbide The KASTOtec AC was developed for the optimal use of the tool technologies bi-metal, bi-metal plus, carbide and carbide plus offered on the market. ! Machine is currently being refurbished ! Cutting Area Round (mm): 530 Max workpiece height (mm): 530 Max width workpiece (mm): 630 Max. Rectangular Dimension (mm): 530x630 Max. dimension square (mm): 530x530 Max. material feed length, single stroke (mm): 600 Multiple feed rate (mm): 9999 Shortest Section Length (mm): 6 Shortest off-piece length (mm): 35 Dimensions saw blade (LxHxW mm): 7675x54x1.6 Saw Blade Speed (m/min): 30-300 Motor power (kW): 15 kW Machine dimensions (LxWxH mm): 2,235 mm x 5,335 mm x 2,820 mm Machine weight (kg): 6550 All prices are net plus VAT. VAT We expressly reserve the right to prior sale and errors Brokerage offer for RG-Tools GmbH
Offer 26155 Technical data: - E.-Hydr. Lifting-lowering of the saw bracket - Saw blade dimensions 400 x 30 x 1.5 mm - Cutting range at 90° round approx. 210 mm - Flat approx. 240 x 190 mm - Square approx. 210 x 210 mm - Cutting range at 45° round approx. 150 mm - Flat approx. 150 x 100 mm - approx. 130 x 210 mm - Square approx. 145 x 145 mm - Lifting speeds + cutting speeds adjustable - Stroke rates 62 / 125 m/min - Average cutting speed 16 / 32 m/min - Mitre adjustment Vise with opening width up to 260 mm - E.-Mot. Coolant Setup - Drive 400 V / 1.1 kW - Space requirement approx. W 500 x H 1250 x D 1200 mm - Weight approx. 180 kg
KASTO U 10 / Metal circular saw with material support -CE marking -Year of construction 2012 -Cutting area / Round 90 degrees /100x100mm -Cutting area / Flat 90 degrees / 90x90mm -Cutting area / square 90 degrees / 170x90mm -Mitre cutting device -Coolant device -Vise with counter-clamping device for burr-free cutting -Infinitely adjustable saw feed -2x saw cutting speeds -Dimensions circular saw blade 350x2.5x32mm -Saw motor 1.8 KW Dimensions: LxWxH 1.2x0.8x1.9 meters / Weight 500 kg
380 V 1.5 KW Length 0.6 m Width 0.5 m Height 1.40 m Color: Gray Weight 98 kg Unaudited Hobbyist object
Cutting range at 90° Round: 210 mm Square: 210 mm Flat: 240 x 190 mm Cutting range at 45° Round: 150 mm Square: 150 x 100 mm flat: 150 x 100 mm Saw blade dimensions: 400 x 30 x 1.5 mm 2 lifting speeds by pole switching. Motor: 16 & 32 m/min Drive motor: 380 V, 0.9 kW Weight: 170 kg Space requirement: 1190 x 480 x 1300 mm
Key data: 430 mm
Fully automatic band saw machine Manufacturer : Kasto Type: Twin A4 Bauahr: 2010 Condition: gebraucht / used Location : Warehouse Sweden Technical data Cutting range: Cutting range around 430 mm Cutting area square H x W 430 x 430 mm Cutting area flat H x W 430 x 430 mm Clamping range 0 – 430 mm Smallest dimension to be sawn: 10 x 10 mm Smallest section length 6 mm Shortest residual piece length in automatic mode (only possible for geometrically flawless surfaces) 35 mm Shortest offcut length in single cut 10 mm Dimensions and weights: Length approx. 2,140 mm Width incl. chip conveyor 4,610 mm Height (saw frame lowered) approx. 2,195 mm Height (saw frame in maximum position) approx. 2,410 mm Material support height 700 mm Coolant: Coolant tank volume 150 l, Pump capacity at 3 m head 25 l/min Paintwork: Machine light grey RAL 7035 textured paint Saw ...
Technical data: Cutting range: 90° round: 260 mm 90° flat: 300 x 260 mm 90° square: 260 x 260 mm +45° round: 200 mm +45° flat: 200 x 240 mm +45° square: 200 x 200 mm +60° round: 165 mm +60° flat: 160 x 120 mm +60° square: 150 x 150 mm -45° round: 200 mm -45° flat: 200 x 240 mm -45° square: 200 x 200 mm Shortest offcut length: 35 mm Total connected load: 2.0 kW Saw motor, power frequency controlled: 1.5 kW Cutting speed infinitely variable at frequency controlled: 20 - 110 m/min Saw blade dimensions: 2910 x 27 x 0.9 mm Dimensions and weight: Length, approx.: 1020 mm Width, approx.: 1830 mm Height, upper part lowered, approx.: 1460 mm Height, top in maximum position: 1900 mm Material support height: 950 mm Total weight, approx.: 510 kg Equipment: - Stepless cutting speed - Saw blade guides made of carbide, replaceable - Hydraulic cutting feed - ...
Offer 25326 Technical data: - Saw blade diameter up to 400 mm - Cutting range at 90° around 130 mm - Square 120 m - Rectangle 300 x 40 - or 240 x 80 mm - at 45° about 130 m - Square 110 mm - Rectangle 245 x 40 mm - Mitre adjustable Li + Re each 0 - 90 ° - 2 Cutting speeds - Drive 400 V / 1.26 / 2.5 kW - Feed speed of the saw blade hydr. Infinitely variable - Coolant device - Space requirement approx. W 1100 x H 1980 x D 1210 mm - Weight approx. 950 kg - Feed + discharge roller conveyor with dimension stop 6000 mm
Key data: 1060 mm
Band saw Kasto HBA 10×12 built in 2007 Cutting areas: Cutting range around 1,060 mm Square cutting area 1,060 x 1,060 mm Cutting area flat 1,060 x 1,260 mm Clamping range 300 – 1,260 mm Smallest dimension to be sawn approx. Ø 300 mm Smallest section length 10 mm Minimum offcut length single cut 20 mm Minimum off-piece length automatic operation 100 mm Table load maximum 50to Travel table 6100mm Total drive power 20 kW Saw motor 11 kW Continuous cutting speed at 50 and 60 Hz 12 – 90 m/min Automatic feed length single 2,100 mm Clamping force machine vise 50,000 N Saw blade dimensions 11,430 x 80 x 1.6 mm Cutting feed: infinitely variable Material feed: hydraulic Material tension: hydraulic Saw blade guide: carbide, replaceable Saw blade tension: hydraulic Saw blade cleaning: by easily replaceable brush, motor-driven ...
Offer 25071 Specifications: - E.-Hydr. Lifting-lowering of the saw bracket - Saw blade dimensions 400 x 45 x 2.0 mm - Cutting range - 90° round approx. 250 mm - Flat approx. 250 x 130 mm - Square approx. 220 x 220 mm - Max. opening width of the vice 405 mm - Lifting speeds + cutting speeds adjustable - Mitre-adjustable vise - E.-Mot. Coolant Setup - Drive 380 V / 2.0 kW - Space requirement approx. W 550 x H 1270 x D 1700 mm - Weight approx. 380 kg
Machine type: Automatic band saw - Horizontal Manufacturer KASTO Type KastoTwin A4 Year of construction 2002 Country of origin Germany Delivery time by arrangement Freight base from location Technical details Cutting diameter 400mm Saw blade length 5,090mm Cutting width 1.3mm Cutting range at 90 degrees: around 400mm Cutting area at 90 degrees: square 400 x 400mm Smallest diameter 10mm Smallest section length 6mm Feed length 750mm Cutting speed 20 - 110m/min Clamping pressure 20 - 60bar Saw blade dimensions 5,090 x 41 x 1.3mm Total power requirement 7.0kW Machine weight approx. 1850 kg Space requirements approx. 2400 x 2500 x 1700mm
Specifications: - E.- Hydr. Lifting-lowering of the saw bracket - Saw blade dimensions 400 x 30 x 1.5 mm - Cutting range at 90° round approx. 210 mm - Flat approx. 240 x 190 mm - Square approx. 210 x 210 mm - Cutting range at 45° round approx. 150 mm - Flat approx. 150 x 100 mm - approx. 130 x 210 mm Square approx. 145 x 145 mm - Lifting speeds + cutting speeds adjustable - Stroke rates 62 / 125 m/min - Average cutting speed 16 / 32 m/min - Mitre adjustment Vise with opening width up to 260 mm - E.-Mot. Coolant Setup - Drive 400 V / 1.1 kW - Space requirement approx. W 600 x H 1250 x D 1300 mm - Weight approx. 250 kg
Qty. 1 Second-hand plate storage system Mfc.: Kasto Maschinenbau GmbH Type: UNITOWER B1.5 Built: 2018 Still in operation! Number of storage spaces: 86 Pallets size: Usable dimensions: 3000 x 1500 x 90 mm – L x W x H External dimensions: 3290 x 1616 x 160 (70) mm – L x W x H Payload per pallet: 1500 kg Use for surface elements made of wood, polycarbonate, etc. Only about 300 movements have taken place since 2018 - one movement takes about 2 minutes. The system is regularly serviced by the manufacturer. Speeds Hoist: 16.0 m/min. Pull and push device: 20.0 m/min. System dimensions approx.: 8855 x 5900 x 5730 mm – H x L x W
Key data: 400 mm, 180 mm
Max. diameter or cutting width 180 mm, smallest dimension to be sawn D 10 mm, automatic feed 600 mm, max. feed length several times 1800 mm, minimum offcut length for single cut 20 mm, minimum remnant length in automatic operation 110 mm, Table turning area for mitre cutting 135 degrees, Total drive power 3.2 kW, Weight without roller tracks 1100 kg, coolant system, the saw is still electrified, Function video available, Operating manual with circuit diagrams and spare parts lists.
Horizontal Band Saw Machine Fabr. KASTO Type HBA 340 AU Specifications: Cutting range 90° round 340 mm Cutting area 90° flat 340 x 380 mm Saw blade length 5334 x 32 x 1.06 mm Table height 700 mm Feed length 600 mm Multiple feed 1800 mm infinitely variable cutting speed 20 - 130 m/min. Drive power 6.5 kW External dimensions L x W x H approx. 2200 x 2600 x 2000 mm Weight approx. 2.1 t with-chip conveyor used, in good condition All information to the best of our knowledge but without guarantee until the order confirmation The machine can be demonstrated at the site near Aachen.
Key data: 200 mm, 250 mm
Saw blade length 400 mm Power 0.53 / 0.78 kW Cutting speed approx. 15 / 30 m/min Vise opening width 190 mm Cutting area approx. approx. 200 mm approx. flat 240 x 190 mm
Alternativ Saw KASTO PSB 280 U Blades dimensions: 450 mm x 40 mm x thickness 2 mm Cutting capacity in the round: 280 mm Square cutting capacity: 240 x 240 mm Rectangular cutting capacity: 280 x 160 mm Cutting capacity at 45°: 170 mm Automatic descent 2 speeds rotation Swivel jaws from 0 to 45° Jaws length : 350 mm x Height 150 mm Maxi jaws opening: 310 mm Lubricant pump Voltage: 380 V Dimensions (L x W x H): 1800 x 800 x 1300 mm Weight: approx 1 T
Specifications Tower storage system for sheet metal Manufacturer: KASTO Type: UNITOWER B3.0 Year of construction: 2008 Number of magazines: 49 Pull-out trolley on rail
Metal Circular Saw Cold Circular Saw Manufacturer Kasto Type GKS400P YOC 1998 Saw blade 400mm coming from below automatic hydraulic vice for material expansion Top condition, ready for immediate use.
Overhauled: 2018 Year of construction: 1991-20167 Band saw blade 250-285 mm Motor output 5.5 KW Cutting speed 35-160 m / min Square maximum working range: 15-60 mm Round maximum working range: 15-70 mm Saw feed 2-100 mm / s adjustable Section length 5-250 mm Nachschubgeschw. Max. 1000 mm / s (Saw) approximate weight: 1500 kg (Magazine), approx.: 800 kg Dimensions Lxwxh (saw) approx.: 1100 x 1600mm x 2300mm (Magazine) about: 7500mm x 1400mm x 1600mm The machine is suitable due to their facilities and construction for mass editing of steel and is the predecessor of KASTOwa C7 or C9 KASTOspeed. The plant will be located after overhaul (retrofit) in like new condition, which is also guaranteed by our House. The machine will be overhauled on request in our House. Among other things, following points are renewed: -New PLC control Siemens S7 -Conversion to Siemens HMI - ...
Overhauled: 2018 Year of construction: 1985-2017 Saw band 275-315 mm Engine power 11.0 KW Cutting speed 225-1200 m / min Square maximum working range: 15-80 mm Round maximum working range: 15-90 mm Saw feed 2-100 mm / s adjustable Section length 5-250 mm Nachschubgeschw. Max 1000 mm / s (Saw) approximate weight: 1500 kg (Magazine) about: 1000 kg Dimensions Lxwxh (saw) approx.: 1100 x 1600mm x 2300mm (Magazine) about: 5500mm x 1400mm x 1600mm The machine is suitable facilities and construction for mass editing of non-ferrous metals and is the predecessor of KASTOwa M9 KASTOspeed M9. The saw line is currently in preliminary line status and can be visited only in original condition without function. The plant will be located after overhaul (retrofit) in like new condition, which is also guaranteed by our House. The machine will be overhauled on request in our House. Amon ...
KASTO SSB 260 VA ist eine Bandsäge für Präzision, hohe Genauigkeit und Zuverlässigkeit. Schnittbereich rund 10-260 mm, vierkant 260×260 mm; Schnittlänge 5-680 mm; Vorschublänge 680 mm; Bandgeschw. 15-125 m/min; Band 4115×41×1 mm. Anschluss 3×380 V 50 Hz; Leistung 4/6,5 kW; Gewicht ~1915 kg; Maße L2125×B1930×H2100 mm. Zubehör: automatischer Vorschub, Materialauflage 1 m, Rollenbahn, Kühlung, Späneförderer. Erreicht enge Toleranzen; Branchen: Automotive, Maschinenbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr
KASTO SSB 260 VA ist eine Bandsäge, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Schnittbereich: rund/quadratisch bis 260 mm; Durchmesser min. 10 mm; Schnittlänge 5–600 mm; Reststück min. 10 mm. Technische Daten: Bandlänge 4115 mm, Bandbreite 41 mm, Bandstärke 1 mm; Bandgeschwindigkeit stufenlos 15–125 m/min; Sägemotor 4 kW; Leistung 8 kW; Anschluss 3x380 V 50 Hz; Gewicht ca. 2200 kg; Abmessungen L2400×B1600×H2500 mm. Zubehör: automatischer Vorschub, Eingangsauflage 1 m, Rollenbahn, Kühlmitteleinrichtung, Späneförderer. Erreicht enge Toleranzen; Einsatz in Automotive, Präzisionsmechanik, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr
cutting diameter:260 mm band length:450 x 4 x2 mm total power requirement:22,6 kW weight of the machine ca.:1024 kg dimensions of the machine ca.:1500 x 2310 x 955 mm square:240 x 240 mm flat material:260 x 180 clamping capacity:40 bar Documents:vorhanden
CONTROLS CNC controls KASTO TECHNICAL SPECIFICATION max. cutting height: 430 mm sawband length: 6830 mm sawband width: 1.3 mm chucking capacity min: 6 mm clamping diameter max.: 430 mm ELECTRICAL SPECIFICATIONS total power consumption: 22 kW mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 2200 mm space requirements -front/back-: 4750 mm total height: 2602 mm total weight approx.: 4500 kg Precision, hydraulic, high-performance, with roller conveyor Ausstattung: Rollenbahn mit Quertransport am Eingang der Anlage und Förderband mit Abschiebetisch am Ausgang der Anlage
Metal Band Saw manufactured in 2023. This KASTO win A 3.3. features a maximum cutting capacity of 330 mm for round materials and 330 x 350 mm for square profiles. It has a robust design with dimensions of 1300 x 2350 mm and a weight of approximately 2200 kg. If you are looking to get high-quality cutting capabilities, consider the KASTO win A 3.3. machine we have for sale. Contact us for further details.
cutting diameter: 15 - 560 mm : 560 x 630 mm dimensions of saw-band: 7.400 x 54 x 1,60 mm Control: KASTO material feed - single: 900 mm multiple feeding length: max. 9.999 mm cutting length min.: 6,00 mm sawing motor: 5,50 kW cutting speed: 13 - 127 m/min height of material-table: 700 mm total power requirement: 12,00 kW weight of the machine ca.: 6,00 t dimensions of the machine ca.: 3,70 x 2,50 x H2,50 m Automatic two-column band saw with KASTO Compact Control, frequency-controlled saw band drive, chip conveyor, infeed roller-conveyor electrically driven (6m), 3x roll-conveyor 1m and outfeed roller 2m, Machine can be inspected under power. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
cutting diameter: 280 mm band length: 450 mm capacity 90 degrees: square: 240 x 240 mm capacity 90 degrees: flat: 280 x 160 mm capacity 45 degrees: round: 180 mm dimensions of saw-blade: 450 x 40 x 2.0 mm engine output: 2.6 kW height of material-table: 500 mm weight of the machine ca.: 495 kg range L-W-H: 1500 x 600 x 1340 mm Furnishing: - stepless hydraulic lowering - manual vice - Miter adjustment ü. vice - coolant device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Saw blade diameter: 350 x 2,5 x 32 mm capacity 90 degrees: square: 90 x 90 mm capacity 90 degrees: round: 100 mm capacity 90 degrees: flat: 170 x 90 mm Motor output: 1,8 kW machine weight ab.: 500 kg dimensions: 1200 x 800 x 2000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
