new
Semi-automatic circular sawing machine with radial cut for cutting aluminium, non-ferrous metals, wood and various plastics Clean, burr-free cut edges as if polished. Saw blade diameter Ø 600 mm Saw blade drive power 4 kW Saw blade travel forward for sawing - backward for empty stroke Mitre adjustment range infinitely variable from 20° to 125° Digital display for mitre angle Sawing range 90° - approx. 230 x H 180mm or 300 x H 120 mm Sawing range 45° - approx. 160 x H 180 mm or 210 x H 120 mm Saw blade feed speed infinitely variable by means of a handwheel. Automatic spray mist lubrication Compressed air requirement 6 to 8 bar Dimensions approx. 1.55 m x 0.96 m x H 1.65 m Weight approx. 670 kg
new
Semi-automatic undercounter circular sawing machine for cutting aluminum, non-ferrous metals, wood and various plastics Clean, burr-free cut edges as if polished. Saw blade diameter Ø 600 mm Saw blade drive power 3 kW Saw blade path upwards for sawing - downwards for empty stroke Mitre adjustment range infinitely variable from 10° to 170° - with grid dots at + 45° and – 45° Pneumatic saw table clamping Digital display for mitre angle Sawing range 90° - approx. 400 x H 135mm or 460 x H 100 mm Sawing range 45° - approx. 190 x H 60 mm or 120 x H 150 mm Saw blade feed speed infinitely variable by means of a handwheel. Adjustment range material stop forward and backward approx. 180 mm Automatic spray mist lubrication Compressed air requirement 6 to 8 bar Dimensions approx. 1.1 m x 1.2 m x H 1.65 m Weight approx. 310 kg
used
Offer 23168 Specifications: - Notching options + mitres in 3 levels - right-angled, single-sided + two-sided + three-sided oblique. - Can be used as a slate-cutting cut-off saw - Pneumatic profile clamping machining with semi-automatic sawing units - Saw blade dimensions - vertical 500 x 3.5 x 40 mm positive - horizontal 500 x 3.5 x 40 mm negative - Notching width / notching height at 90° 300 / 285 mm - vertical saw blade 60° - 90° - 25° mot. Positioning with digital display - Swivel range saw blade horiz. With the vert. Saw blade - 45° - 90° - 45°, motorized positioning with digital displays - Notching height adjustment with digital displays - Profile stop shoulder manually swivel 30° - 90° - 45° - pneumatic coolant spraying device - Air connection 6 bar - Drive 400 V / 2 x 3 kW - Space requirement approx. W 2400 x H 2000 / D 1400 mm ...
