(1986) 600t Gräbener Knuckle-Joint Press Fully Automated High-Precision Short-Stroke Forming This knuckle-joint press delivers a nominal force of 600 metric tons, designed for high-precision forming applications requiring controlled force near bottom dead center. Technical Details Machine Type: Knuckle-Joint Press Model: GK 600 Nominal Force: 600t Year of Manufacture: 1986 Rated Force Travel (Pressing Path): 1.7 mm Nominal Work Capacity: 10,200 Nm Stroke: 100 mm Stroke Rate: 45 strokes/min Shut Height (Max. Die Space): 360 mm Tool Holder Adjustment: 50 mm Clearance Between Uprights: 580 mm Table Area (Width x Depth): 550 mm x 430 mm Tool Holder Shank Hole (Ø x Depth): 65 mm x 105 mm Motor Output: 15 kW Motor Speed: 1,500 rpm Pneumatic Connection Pressure: 5.5 bar Operating Voltage: 3x 380V / 220V, ...
(1979) 630t Gräbener Knuckle-Joint Press Industrial Knuckle-Joint Press for High-Force Cold Forming This Gräbener press utilizes a knuckle-joint mechanism to deliver exceptional force, making it highly effective for precision coining and embossing. With a massive 27,000 kg frame and a 28 kW motor, it provides the stability required for heavy-duty metalworking operations. Technical Details Machine Type: Knuckle-Joint Press Manufacturer: Gräbener Model: GK 630 NS Year of Manufacture: 1979 Nominal Capacity: 630t Stroke Rate: 45 strokes/min Shut Height: 420 mm Tool Holder Adjustment: 80 mm Clearance Between Uprights (Frame Width): 820 mm Table Area (Width x Depth): 800 mm x 850 mm Motor Output: 28 kW Motor Speed: 1,475 rpm Operating Voltage: 3x 380V / 220V, 50Hz Total Weight: 27,000 kg Overrun Time (Stopping Time): 160 ms Safety Distance: 266 mm
(1978) 630t Gräbener Knuckle-Joint Press Industrial Knuckle-Joint Press for High-Force Cold Forming This Gräbener press utilizes a knuckle-joint mechanism to deliver exceptional force, making it highly effective for precision coining and embossing. With a massive 27,000 kg frame and a 28 kW motor, it provides the stability required for heavy-duty metalworking operations. Technical Details Machine Type: Knuckle-Joint Press Manufacturer: Gräbener Model: GK 630 NS Year of Manufacture: 1978 Nominal Capacity: 630t Stroke Rate: 45 strokes/min Shut Height: 420 mm Tool Holder Adjustment: 80 mm Frame Width: 820 mm Table Area (Width x Depth): 800 mm x 850 mm Motor Output: 28 kW Motor Speed: 1,475 rpm Operating Voltage: 3x 380V / 220V, 50Hz Total Weight: 27,000 kg Overrun Time: 206 ms Safety Distance: 330 mm
(1976) 250t Berrenberg-Pressen Eccentric Press Heavy-Duty Eccentric Press for High-Capacity Industrial Forming This Berrenberg model is a powerful mechanical press engineered for high-tonnage applications, featuring an impressive 640 mm shut height to accommodate large and complex tooling setups. Technical Details Machine Type: Eccentric Press Manufacturer: Berrenberg Pressen Model: LEPr 250 355 Year of Manufacture: 1976 Nominal Capacity: 250t Stroke Rate: 45 strokes/min Ram Stroke (Adjustable): 40 – 180 mm Ram Adjustment: 80 mm Shut Height (Die Space): 640 mm Overrun Time (Stopping Time): 0.152 seconds Safety Distance: 284 mm Motor Power: 18.5 kW
(1980) 200t Paul Müller Eccentric Press Heavy-Duty Eccentric Press for Cold Forming This Paul Müller press delivers a robust 2,000 kN pressing force and features a versatile adjustable stroke range of 20 to 140 mm. Technical Details Machine Type: Eccentric Press Manufacturer: Paul Müller Model: EXP 200 R Machine Number: 11380 Year of Manufacture: 1980 Nominal Force: 200t Throat Depth: 400 mm Stroke Rate: 40 strokes/min Adjustable Stroke Range: 20 – 140 mm Ram Adjustment: 80 mm Max. Distance (Table to Ram): 530 mm Table Dimensions (W x D): 1,120 x 780 mm Ram Surface Area (W x D): 700 x 400 mm Bed Hole (Bolster Opening): 360 x 230 mm Motor Output: 18.5 kW Operating Voltage: 380 V Total Weight: 12,500 kg
(1997) 160t Ruhrmann Eccentric Press High-Precision Eccentric Press for Heavy Industrial Production This Ruhrmann eccentric press is a robust industrial machine featuring a 160-ton nominal capacity and a versatile stroke range of 20 to 160 mm. Technical Details Machine Type: Eccentric Press Manufacturer: Ruhrmann Model: E 160 R Machine Number: 14 340 Year of Manufacture: 1997 Nominal Force: 160t Continuous Stroke Rate: 25 – 50 strokes/min Ram Stroke Range (min/max): 20 – 160 mm Ram Stroke Adjustment: 120 mm Shut Height (Einbauhöhe): 660 mm Max. Tool Dimensions: 630 x 500 mm Max. Tool Weight: 120 kg Flywheel Speed: 200 rpm (clockwise rotation) Max. Clutch Engagements: 16 per minute Electrical Connection: 17.2 kW Pneumatic Requirement: 6 bar air pressure Clutch-Brake Pressure: 5.5 – 6 bar Overrun Time (Stopping Time): 214 ms Safety Distance ...
(1965) 125t Müller-Weingarten Eccentric Press Heavy-Duty Single-Column Press for Robust Metal Forming This Müller-Weingarten model is a reliable industrial workhorse capable of processing heavy-gauge sheet metal up to 13 mm in thickness. Technical Details Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model Type: ER 125 Year of Manufacture: 1965 Nominal Force: 125t Maximum Material Thickness: 13 mm Stroke Rate: 50 strokes/min Ram Stroke (Adjustable): 20 – 120 mm Ram Adjustment: 100 mm Overrun Time (Stopping Time): 0.34 seconds Safety Distance: 500 mm Motor Power: 11.0 kW
(1979) 100t Müller-Weingarten Eccentric Press High-Utility Eccentric Press for Flexible Stamping and Forming Operations This Müller-Weingarten model is a versatile single-column (C-frame) press designed for high-speed production with a stroke rate of 60 per minute. It features a comprehensive range of 11 adjustable stroke settings, making it highly adaptable for various industrial metalworking tasks from shallow blanking to deeper forming. Technical Details Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ARP 100 Year of Manufacture: 1984 Nominal Force: 100t Stroke Rate: 60 strokes/min Throat Depth (Projection): 375 mm Body Passage (Front to Back): approx. 570 mm Max. Distance (Table to Ram): 384 mm (at bottom of stroke, adjustment at top) Adjustable Ram Stroke: 8 mm – 137 mm Intermediate Strokes: 8, 23, 43 ...
(1984) 100t Müller-Weingarten Eccentric Press High-Speed Single-Column Eccentric Press with Versatile Stroke Adjustment This Müller-Weingarten press is a highly adaptable industrial machine, featuring a 100-ton nominal force and an impressive stroke rate of 60 per minute. Technical Details Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ARP 100 Year of Manufacture: 1984 Nominal Force: 100t Stroke Rate: 60 strokes/min Throat Depth (Projection): 375 mm Frame Passage (Front to Back): approx. 570 mm Max. Distance (Table to Ram): 384 mm Adjustable Ram Stroke: 8 mm – 137 mm Intermediate Strokes: 8, 23, 43, 63, 81, 97, 111, 122, 130, 135, 137 mm Ram Adjustment: 80 mm Ram Clamping Surface (W x D): 700 mm × 450 mm Ram Shank Hole (Ø x Depth): 50 mm × 85 mm Ejector Travel: 55 mm Table Clamping Surface (W x D): 920 mm × 660 mm Tabl ...
(2013) 400t Müller Knuckle-Joint Press Precision Knuckle-Joint Press for High-Speed Forming This year-2013 Müller press provides a 4,000 kN pressing capacity and a high-efficiency 55 strokes per minute cycle rate. Engineered for modern industrial precision, it features safety response times suitable for high-volume production environments. Technical Details Machine Type: Knuckle-Joint Press Manufacturer: Müller Model Type: KNP 400 Machine Number: 2703 Year of Manufacture: 2013 Nominal Force: 400t Work Capacity: 13 kJ Ram Stroke: 70 mm Ram Adjustment: 45 mm Stroke Rate: 55 strokes/min Shut Height (Table to Ram): 380 mm (Stroke down, adjustment up) Ram Surface Area (W x D): 500 mm x 400 mm Table Surface Area (W x D): 500 mm x 500 mm Motor Output: 15 kW Operating Voltage: 400 V Safety Distance: 190 mm Limit Value (Stopping Time): 95 ms Total Weight: 1 ...
(2000) 1000t Müller Knuckle-Joint Press High-Capacity Precision Knuckle-Joint Press This modern model represents a significant leap in pressing power, offering a massive 10,000 kN capacity and it is designed for large-scale precision operations. Technical Details Machine Type: Knuckle-Joint Press Manufacturer: Müller Model: KNP 1000 Machine Number: 2912 Year of Manufacture: 2000 Nominal Force: 1000t Work Capacity: 33 kJ Ram Stroke: 100 mm Ram Adjustment: 65 mm Stroke Rate: 40 strokes/min Shut Height (Table to Ram): 400 mm Ram Surface Area (W x D): 700 mm x 500 mm Table Surface Area (W x D): 700 mm x 750 mm Motor Output: 30 kW Operating Voltage: 400 V Safety Distance: 225 mm Limit Value (Stopping Time): 97 ms Total Weight: 42,000 kg Machine Dimensions (W x D x H): 2.3 m x 3.4 m x 4.1 m
(1974) 160t Edelhoff Eccentric Press Eccentric Press for Heavy Stamping and Forming This 1974 Edelhoff mechanical press offers a robust 160-ton capacity and a highly adaptable stroke range, making it suitable for a wide variety of industrial metalworking applications. Technical Details Machine Type: Eccentric Press Manufacturer: Edelhoff Model: AZR 160 Machine Number: 8069 Year of Manufacture: 1974 Nominal Force: 160t Stroke Adjustment: 30 – 160 mm Ram Adjustment: 75 mm Stroke Rate: 45 strokes/min Electrical System: 380 V
(1973) 180t Gräbener Knuckle-Joint Press Precision Knuckle-Joint Press for Detailed Cold Forming This 1973 Gräbener model utilizes a knuckle-joint mechanism to deliver high pressing force with controlled ram speed, making it ideal for precision coining and embossing tasks. It features a compact design with a 180-ton capacity and is equipped with a 5.5 kW motor for reliable industrial operation. Technical Details Machine Type: Knuckle-Joint Press Manufacturer: Gräbener Model: GK 180 Year of Manufacture: 1973 Nominal Force: 180t Stroke: 50 mm Stroke Rate: 40 strokes/min Shut Height: 305 mm Tool Holder Adjustment: 40 mm Clearance Between Uprights: 390 mm Table Area (Width x Depth): 370 mm x 450 mm Tool Holder Mounting Surface (Width x Depth): 360 mm x 200 mm Tool Holder Shank Hole (Ø x Depth): 40 mm x 75 mm Motor Output: 5.5 kW Motor Speed: 1,450 ...
(1985) 630t Gräbener Knuckle-Joint Press High-Performance Knuckle-Joint Press This 1985 Gräbener knuckle-joint press is a high-capacity machine engineered for applications requiring extreme force at the bottom of the stroke, such as coining and cold forming. Technical Details Machine Type: Knuckle-Joint Press Manufacturer: Gräbener Model: GKN 630 Year of Manufacture: 1985 Nominal Force: 630t Stroke: 112 mm Stroke Rate: 55 strokes/min Shut Height: 800 mm Tool Holder Adjustment: 80 mm Motor Output: 25 kW Pneumatic Connection Pressure: 5.5 bar Operating Voltage: 3x 380V / 220V, 50Hz
(1970) 200t Müller-Weingarten Eccentric Press Heavy-Duty Eccentric Press for High-Capacity Industrial Forming This powerful 1970 mechanical press is engineered for heavy-gauge metalworking, offering a significant 200-ton pressing capacity and a maximum sheet thickness of 28 mm. Technical Details Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: AR 200 Year of Manufacture: 1970 Nominal Force: 200t Max. Thickness: 28 mm Stroke Rate: 32 strokes/min Ram Stroke: 40 – 180 mm Ram Adjustment: 110 mm
(1963) 100t Müller-Weingarten Eccentric Press High-Precision Mechanical Press This Müller-Weingarten model is a versatile industrial workhorse featuring a variable stroke and a high-performance 11 kW motor. Designed for heavy-duty applications, it can process material thicknesses up to 12 mm with a consistent operating speed of 55 strokes per minute. Technical Details Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ER 100 Year of Manufacture: 1963 Nominal Force: 100t Maximum Material Thickness: 12 mm Stroke Rate: 55 strokes/min Ram Stroke (Adjustable): 8 mm – 112 mm Ram Adjustment: 80 mm Shut Height Range (Die Space): 355 mm – 407 mm Overrun Time (Stopping Time): 0.154 Seconds Safety Distance: 246 mm Motor Power: 11 kW
(1961) 100t Müller-Weingarten Eccentric Press High-Precision Mechanical Press This Müller-Weingarten model is a versatile industrial workhorse featuring a variable stroke and a high-performance 11 kW motor. Designed for heavy-duty applications, it can process material thicknesses up to 12 mm with a consistent operating speed of 55 strokes per minute. Technical Details Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ER 100 Year of Manufacture: 1961 Nominal Force: 100t Maximum Material Thickness: 12 mm Stroke Rate: 55 strokes/min Ram Stroke (Adjustable): 8 mm – 112 mm Ram Adjustment: 80 mm Shut Height (Die Space): 355 mm – 407 mm Overrun Time (Stopping Time): 0.174 Seconds Safety Distance: 278 mm Motor Power: 11 kW
(1975) 100t IWK Eccentric Press Industrial Eccentric Press for High-Capacity Stamping This 100-ton eccentric press from 1975 features a robust electrical configuration designed for versatile industrial manufacturing. Technical Details Machine Type: Eccentric Press Manufacturer: IWK Model: PEDRS 100 Year of Manufacture: 1975 Machine Number: 22/20076/3 Circuit Diagram Number: 911 871 Nominal Force: 100t Mains Connection 1: 380 V, 3-Phase, 50 Hz, 36 A Mains Connection 2: 220 V Max. Back-up Fuse: 80 A Control Voltage: 220 V (AC) / 24 V (AC) / 24 V (DC) Lighting Voltage: 220 V
(1983) 125t Müller Eccentric Press Heavy-Duty Mechanical Press Robust Eccentric Press from 1983 with a 125 t nominal force and adjustable ram stroke, ideal for precision forming and heavy-duty production. Technical Details Machine Type: Eccentric Press Manufacturer: Müller Machine Number: 1204 Year of Manufacture: 1983 Model: EPR/R125 Normal Nominal Force: 125t Maximum Nominal Force: 135t Ram Stroke (Adjustable): 20 – 120 mm Ram Adjustability: 80 mm Weight: 8,250 kg Motor Power: 11 kW Operating Voltage: 380 V Safety Distance: 205 mm Brake System: Equipped with an Ortlinghaus auxiliary brake system
(1992) 125t Müller Eccentric Press Versatile Mechanical Forming Solution This eccentric press offers a nominal pressing capacity of 125 tons, designed for reliable and efficient mechanical forming operations. With an adjustable ram stroke range of 20–120 mm and an additional 80 mm ram adjustment, the machine provides flexible setup options for various tooling and production requirements. Technical Details Machine Type: Eccentric Press Manufacturer: Müller Machine Number: 3010 Year of Manufacture: 1992 Model: EPR/RH125ST Nominal Capacity: 125t Ram Stroke (Adjustable): 20 – 120 mm Ram Adjustment: 80 mm Total Weight: 9,000 kg Motor Power: 11 kW Operating Voltage: 380 V Safety Distance: 185 mm
pressure:600 tdistance between columns:3640 mmstroke:350 mmno. of strokes:11 - 44 /minDistance table/ram, max. stroke up, adjustment up:1550 mmtable surface area:3600 x 2500 mmsliding table:3600 x 2500 mmram surface:3600 x 2500 mmSide window:2200 mmram adjustment:400 mmmaterial width coil line:500 - 1950 mmMaterial thickness at 1200 mm material width:0,6 - 2,5 mmMaterial thickness at 1850 mm material width:0,6 - 2,0 mmMaterial thickness at 1950 mm material width:0,6 - 1,75 mmCoil weight:35,0 tcoil internal diameter:610 mmcoil external diameter:900 - 1900 mmno. of straightening rolls:13 straightening roll diameter:50 mmStack height:400 mmstacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mmstations:2 power requirement:112,0 + 35,0 kWWeight:390,0 tDimensions (WxDxH):7,3 x 5,1 x 15,0 mHeight above floor:9,1 mHeight below floor:5,9 mclutch-/ brake combination:pneumatic overload pr ...
pressure:315 tdistance between columns:1290 mmstroke:700 mmdistance table/ram, max. stroke up, adjustment up:950 mmtable surface area:1250 x 1100 mmpressure of drawing cushion in table:125 tstroke of drawing cushion in table:300 mmdie cushion area:900 x 900 mmCapacity of ejector in ram:20 tStroke of ejector in ram:250 mmtable height over floor:800 mmram surface:1250 x 1100 mmoil volume:1200 lpower requirement:40,0 kWweight:22,0 tdimensions (WxDxH):2,6 x 1,6 x 5,2 mheight over floor:4,05 mdrawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic
Pressure:40 tthroat:330 mmstroke:250 mmdistance table/ram, max. stroke up, adjustment up:450 mmtable surface area:800 x 500 mmhole in the table:100 mmtable height over floor:900 mmram surface:100 mmSpeed down:406 mm/sSpeed up:393 mm/sWorking speed:14 mm/soil volume:350 lpower requirement:7,5 kWweight:4,6 tdimensions (WxDxH):1,3 x 2,3 x 3,4 mGerman Safety: permitted for manual loading:CE-sign depth stop:mechanical
pressure:1000 ttable length:4000 mmtable width:1600 mmControls:SIEMENS S7-1500F PRESS DESIGN:. - frame design : Transfer press :. - Drive type : mechnical :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. - number of tables:2 PRESS FORCES:. - total force (nominal):1000 toPRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):1600 mm - height above floor level:600 mm - autom. tool clamping device : yes :. RAM:. - stroke:400 mmRAM (MECHAN. PRESS):. - ram adjustment:300 mm - ram adjustment:100 mm - number of strokes min:8 /min - number of strokes max:50 /min - hydraulic overload protection : yes :. TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):900 mm - shut height (stroke down, adjustment up):766 mm - distance between columns (H-frame):4250 mm - Free passage between ...
pressure:40 tthroat:300 mmstroke:630 mmDistance table/ram, stroke up:900 mmTable surface area:620 x 520 mmHole in the table:150 mmtable height over floor:600 mmRam surface:150 mmPower capacity:15,0 kWWeight:4,5 tDimensions (WxDxH):1,0 x 1,9 x 3,0 mGerman Safety: permitted for manual loading:CE-sign
pressure:400 tdistance between columns:1060 mmstroke:450 mmno. of strokes:15 - 30 /mindistance table/ram, max. stroke up, adjustment up:1160 mmtable surface area:1000 x 700 mmcapacity of ejector in table:2 x 16 tejector stroke of ejector in table:125 mmDie cushion pressure in table:120 tDie cushion stroke in table:2 mmcapacity of ejector in ram:2 x 4 tstroke of ejector in ram:100 mmram surface:1000 x 700 mmcolumn travel -side:630 mmpower capacity:55,0 kWweight:50,0 tdie cushion in table:2. station
no. of strokes:150 /minimpact energy:420 kJdistance lower die block / ram gudeway:435 mmThroat:425 mmsteel forging - rectangular up to:110 mmsteel forging - diameter up to:125 mmpower requirement:22,0 kWweight of hammer:3,9 tweight of anvil:3,0 tram hammer weight:200 kgweight:6,9 tdimensions (WxDxH):1,1 x 2,3 x 2,4 m
Pressure:080 tthroat:345 mmstroke:20 - 160 mmno. of strokes:65 /mindistance table/ram, max. stroke up, adjustment up:495 mmtable surface area:920 x 610 mmtable height over floor:800 mmHole in the table:280 mmpassage to the back:670 mmram surface:650 x 400 mmram adjustment:50 mmpower capacity:10,0 kWweight:7,7 tDimensions (WxDxH):1,5 x 2,2 x 3,15 mGerman Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric
pressure:800 tdistance between columns:1050 mmstroke:200 mmno. of strokes:8 - 25 /mindistance table/ram, max. stroke up, adjustment up:1300 mmSide window:550 mmtable surface area:1030 x 900 mmCapacity of ejector in table:15 tStroke of ejector in table:85 mmram surface:1040 x 800 mmram adjustment:120 mmCapacity of ejector in ram:12 tejector stroke in ram :80 mmpower requirement:36,0 - 112,6 kWweight:65,0 tDimensions (WxDxH):3,0 x 3,1 x 6,07 mejector in table:hydraulic ejector in ram:hydraulic
