Manufacturer:
(Category: 105)
Technical data: -Clip device -Glass Strip saw blade diameter approx. 300 mm -Pneum.. Material clamping - powered 400 V - Working pressure 7 bar -Air consumption per operation approx. 1.6 L / stroke -with: - Removal - roller conveyor with controlled positioning - level stop 3000 mm -Feed - roller 3000 mm - e - foot switch - regulator - space about B 4200 x H 1700 X 900 mm -Weight approx. 600 kg
Overhaul year: 2018 Year of construction: 2000-2008 Saw blades Carbide / HSS: 315-360 mm Power saw motor: 15 KW Infinitely variable speed: 15 - 130 min-1 Cutting speed Blade (350 mm): 16.4-142.8 m / min Saw height control adjustable: electronic Bdgmy08nkg Square 90° maximum working range: 100 x 100 mm Work area round 90° max.: 110 mm Supply length 5-970 mm (~ 9999 mm multiple hub) Supply AC servo max speed: 300 mm / s Compressed air connection provided on site: 6 bar Approximate weight saw: 1800 kg Dimensions Lxwxh: 1900mm x 1250mm x 2100mm LxB floor space: 1900 mm x 1250 mm The machine is efficiently usable by their equipment and construction methods for a wide range of applications. The HMI interface to control the machine ensures a simple and trouble-free operation of the system. The machine is completed retrofit, both technically and visually in mint condition. A ...
Technical data: -Saw blade size 300 x 3.4 x 32 mm -Blade rotation speed RPM -Section - at 90 ° round 90 mm or square 80 mm -Pneumatic chucks -Material supplies automatic position control -Easy lifting up to approx. 1000 mm -Multiple hub -Swing-arm control panel with CNC control MEP -MOT. Dust aspiration + mobile chip extraction -Drive 400 V / 1,1 kW - space requirement approx. B 2750 x H 1800 X 2000 mm -Weight approx. 600 kg
Technical data:-Roll diameter 420 mm -Throat depth 410 mm -Max volume height 265 mm -Table size 600 x 600 mm -Table li. + re. Tiltable 15 / 30 ° -Table height 1020 mm -Blade length 3150-3260 mm -Saw band width 3-16 mm -8 speeds 12-375 m / min -Drive: 400 V / 1.1 / 1.7 kW -Weight approx. 650 kg -Space requirement approx. B 900 x H 1900 X 1000 mm -with: - blade welding machine in the machine base - grinding wheel and lamp -Scissors, air pump and lighting
Technical data: -Saw blade size 300 mm -Blade rotation speed 2800 RPM -Section - 90 ° 160 x 20 mm 100 x 80 mm -at 45 ° 100 x 40 mm -Adjustable miter vise -Drive 380 V / 1,5 kW - space requirement approx. B H 400 x 1400 X 700 mm -Weight approx. 80 kg -with:-vert. -Vice - machine stand -Feed roller 2000 mm -Evacuation roller conveyor with MaÃ? attack with analog display via Handwheel movable 3100 mm
Basic refurbished 2018 Saw blade 350-400 mm Engine power 6.5 / 8.5 KW Speed 1500/3000 min-1 Saw height control: electronic Working range Max square: 120 x 120 mm Flat maximum work area: 200 x 100 mm Flat maximum work area: 250 x 70 mm (width only) Round maximum working range: 130 mm Saw speed 0-40 mm / s adjustable Section length 5-600 mm (~ 9999 mm Mehrfachhib) Nachschubgeschw. Max. 500 mm / s Weight approx. 1300 kg Dimensions Lxwxh 1800mm x1300mm x1950mm The machine is completely overhauled in our House and is then in a like-new condition. Among other things, following points are renewed: -Modification on PLC control -Conversion on Siemens HMI user interface -Conversion to ball screw with servo control -New electric components -New pneumatic lines -New pneumatic components -Conversion on Valve terminal -Optimization of the Absaugungleistung -New Menzel mi ...
Saw blades Carbide / HSS: 450 mm Power: 4,0 / 5,5 KW Speed infinitely variable 10 - 60 min-1 Cutting speed (450 mm) blade: 7-43, or 15-75/min Saw height control adjustable full electronic Square 90° maximum working range: 140 x 140 mm 45° max.: Flat workspace: 90° Max: 240 x 80 mm 45° max: work area round: 90° Max: 150 mm 45° max: supplies length easy stroke: 5-2000 mm Multiple stroke: 5-9999 mm Supply AC servo max speed: 500 mm / s Approximate weight: 3600 kg Dimensions Lxwxh: 3500 mm x 1300 mm x 2100 mm Lxw surface: 3500 x 1300 mm? Technical description of 401 k PPS / PPS 451 NA 2000 retrofit 401 k PPS / PPS 451 retrofit high-speed sawing machine for steel. The machine is efficiently usable by their equipment and construction methods for a wide range of applications. The HMI interface to control the machine ensures a simple and troubl ...
Overhaul year 2018 Year of construction 1995-2005 Saw blades Carbide / HSS 450 mm Power saw motor 5.5 KW Speed infinitely variable 10 - 60 min-1 Cutting speed Blade (450 mm) 15-75 m / min Saw height control infinitely adjustable electronic 5 Workspace square 90° Max: 140 x 140 mm Workspace flat 90° Max: 240 x 80 mm Work area around 90° Max: 150 mm Supply length 5-9999 mm Supply AC servo max speed: 500 mm / s (Saw) approximate weight: 2100 kg Dimensions Lxwxh (saw) about: 2500mm x 1300mm x 2100mm Footprint Lxw 2500 mm x 1300 mm The machine is efficiently usable by their equipment and construction methods for a wide range of applications. The HMI interface to control the machine ensures a simple and trouble-free operation of the system. Due to the construction of the sawing machine, it is possible to realize a very accurate length tolerances. The machine will be over ...
Reconditioned 2018 Control: PLC Siemens S7 Blade max: 500 mm Motor output 5.5 KW Saw blade feed: 0-40 mm / s adjustable Saw height control electronic Square 90° maximum working range: 130 x 130 mm Flat 90° maximum work area: 190 x 130 mm Round 90° maximum working range: 170 mm Supply length 2-4000 mm (Saw) approximate weight: 800 kg (Pusher) approx.: 300 kg Dimensions Lxwxh (saw) approx.: 900mm x 1200mm x 1500mm (pusher) approx.: 4800mm x 900mm x 1100mm footprint Lxw 7200 mm x 1200 mm which is machine overhauled in our House and is then in a like-new condition. Among others were renewed following points: -New PLC control -Conversion to Elgo positioning system -New electric components -New pneumatic lines -New pneumatic components -Overhaul of the valve Terminal -Built-in Menzel minimal lubrication system -Replacing common wear parts -Overhaul of cabin -Overhaul ...
Overhauled: 2018 Year of construction: 1991-20167 Band saw blade 250-285 mm Motor output 5.5 KW Cutting speed 35-160 m / min Square maximum working range: 15-60 mm Round maximum working range: 15-70 mm Saw feed 2-100 mm / s adjustable Section length 5-250 mm Nachschubgeschw. Max. 1000 mm / s (Saw) approximate weight: 1500 kg (Magazine), approx.: 800 kg Dimensions Lxwxh (saw) approx.: 1100 x 1600mm x 2300mm (Magazine) about: 7500mm x 1400mm x 1600mm The machine is suitable due to their facilities and construction for mass editing of steel and is the predecessor of KASTOwa C7 or C9 KASTOspeed. The plant will be located after overhaul (retrofit) in like new condition, which is also guaranteed by our House. The machine will be overhauled on request in our House. Among other things, following points are renewed: -New PLC control Siemens S7 -Conversion to Siemens HMI - ...
Refurbished: 2018 Year of construction: 1993-2000 PLC: Siemens S7 Blade 175-250 mm Power 1,5 KW Saw blade feed mm/min Cutting speed: 20-170 m / min (at option high speed spindle differierend) Workspace square Max: 60 mm Flat maximum work area: 40 x 80 mm Work area round: 2-70 mm Supply length 5-2000 mm Nachschubgeschw. 600 mm / sec (Saw) approximate weight: 1200 kg (Magazine), approx.: 600 kg Dimensions Lxwxh (saw) about: 3300 mm x 1000 mm x 2000mm (Magazine) about: 3900mm x 1500mm x 1300mm Footprint Lxw 4900 mm x 2000 mm The machine will be overhauled on request in our House. Among other things, following points are renewed: -Conversion to Siemens S7 -New electric components -New pneumatic lines -Ueberholte pneumatic components -New valve Terminal -Revision of the extraction -Minimum lubrication system overhaul -Replacing common wear parts -Overhaul of the lo ...
Overhauled: 2018 Year of construction: 1994-2000 Blade 560 mm Engine power 6.5 / 8,0 KW Speed 1500/3000 min-1 Cutting speed 2100-4200 m / min Saw height control: electronic Square maximum work area: 170 x 170 mm Flat maximum work area: 300 x 150 mm Work area round max.: 200 mm Saw speed 0-40 mm / s adjustable Section length 5-950 mm (~ 9999 mm multiple hub) Nachschubgeschw. maximum 300 mm / s Weight approx. 1900 kg Dimensions Lxwxh 2200mm x2700mm x1950mm The machine is both technically and optically after completed retrofit in mint condition. The machine is efficiently usable by their equipment and construction methods for a wide range of applications. The programmed HMI control system ensures easy and very profitable operation of the plant. The soundproof cabin this reduces the noise emissions to a minimum. The machine will be overhauled on request in our House. Amo ...
Saw blades: Carbide / HSS, 450 mm Power: saw motor, 4,0 / 5,5 KW Speed: stepless, 10 - 60 min-1 Cutting speed: Blade (450 mm), 7-43, or 15-75 m / min Saw height control: continuously variable, electronically Square 90° maximum working range: 140 x 140 mm 45° max: workspace flat 90° Max: 240 x 80 mm 45° max: work area round 90° Max: 150 mm 45° max: supplies length easy stroke: 5-1000 mm Multiple stroke: 5-9999 mm Supply AC servo max speed: 500 mm / s Gewicht(Säge)CA.:3100 kg Dimensions Lxwxh (saw) about: 2500mm x 1300mm x 2100mm footprint Lxw: 2500 mm x 1300 mm, the machine is efficiently usable by their equipment and construction methods for a wide range of applications. The HMI interface to control the machine ensures a simple and trouble-free operation of the system. Due to the construction of the sawing machine, it is possible to realize a ...
Overhauled: 2018 Year of construction: 2001 Band saw blade 5800 x 41 x 1,3 mm Motor power approx. 11 KW with frequency control Cutting speed 20-170 m / min Square maximum work area: 430 x 430 mm Round maximum work area: 430 mm Section length 10-600 mm (~ 9999 mm multiple hub) Nachschubgeschw. Max 400 mm / s Weight approx. 4500 kg Dimensions Lxwxh 2910mm x3600mm x2200mm The machine is both technically and optically after completed retrofit in mint condition. A visit of this saw system is possible at any time. The machine will be overhauled in our House. Among other things, following points are renewed: -Modification on PLC control Siemens S7 -Renewal of the ball screw drive -New electric components -Renewal of the pneumatic pipes -New pneumatic components -Renewal of the hydraulic pipes -Overhaul and renewal of hydraulic components -Overhaul of cabin -Overhaul of ...
PLC control: PLC B & R C220 Saw blade 350-400 mm Motor power 15 KW Speed 1500-6000 min-1 Cutting speed 1650-7500 m / min Saw height control: fully electronic Square maximum working range: 130 mm Flat maximum work area: 200 x 100 mm Round maximum working range: 130 mm Saw speed 0-40 mm / s adjustable Section length 5-900 mm (~ 9999 mm multiple hub) Nachschubgeschw. Max 350 mm / s (Saw) approximate weight: 2100 kg (Magazine), approx.: 2000 kg Dimensions Lxwxh (saw) approx.: 2000mm x 2000mm x 2200mm (Magazine) about: 7300mm x 3800mm x 1200mm Footprint Lxw 9200 x 4200 mm Fully automatic high-speed sawing machine with supply chain magazine for non-ferrous metals and plastics The machine is efficiently usable by their equipment and construction methods for a wide range of applications. The PLC control ensure a simple and very profitable operation of the system. Due to ...
Refurbished: 2018 PLC: Siemens S7 Saw blade 550 mm Engine power 11 KW Saw blade feed 0-3000 mm / min Cutting speed (SB 500 mm): 4500 m / min (SB 550 mm): 5100 m / min Square maximum work area: 170 x 170 mm Flat maximum work area: 380 x 75 mm Round maximum work area: 165 mm Supply length 10-1000 mm Nachschubgeschw. Max 350 mm / s (Saw) approximate weight: 2500 kg (Magazine) about: 1000 kg Dimensions Lxwxh (saw) about: 2800mm x 1600mm x 2200mm (Magazine) about: 3300 x 2200mm x 1800mm Footprint Lxw 6100 mm x 2200 mm The machine was overhauled 2014 in our House. Among others were renewed following points: -New PLC control -New Elgo positioning system -New electric components -New pneumatic lines -Ueberholte pneumatic components -New valve Terminal -Revision of the extraction -Overhaul Menzel minimal lubrication system -Replacing common wear parts -Overhaul of t ...
Cutting capacity round / square 90°: 255 mm / 210 x 210 mm 90° flat cutting area: 310 x 210 mm Cutting capacity round / square 45 ° R: 220 mm / 210 x 210 mm Section flat 45 ° r: 220 x 200 mm Cutting capacity round / square 45 ° L: 230 mm / 200 x 200 mm Cutting capacity 45 ° L: flat 230 x 200 mm Cutting capacity round / square 60 ° R: 135 mm / 135 x 135 mm Section flat 60 ° R: 135 x 135 mm Working height: 930 mm Band saw blade dimensions: 2750 x 27 x 0,9 mm Cutting speed: 35 / 70 m / min Coolant pump: 100 W S1 motor power output 100%: 1.5 kW Motor power S6 40%: 2.2 kW Voltage: 400 V Machine dimensions (L x D x H): 2000 x 1250 x 1900 mm Approximate weight: 350 kg Features: -Professional band saw for General workshop use, fitters... -For cutting of hollow profiles and full materials, stainless steel, tool steel,... -Twist-free, heavily dimensioned saw frame mad ...
Overhauled: 2018 Year of construction: 1985-2017 Saw band 275-315 mm Engine power 11.0 KW Cutting speed 225-1200 m / min Square maximum working range: 15-80 mm Round maximum working range: 15-90 mm Saw feed 2-100 mm / s adjustable Section length 5-250 mm Nachschubgeschw. Max 1000 mm / s (Saw) approximate weight: 1500 kg (Magazine) about: 1000 kg Dimensions Lxwxh (saw) approx.: 1100 x 1600mm x 2300mm (Magazine) about: 5500mm x 1400mm x 1600mm The machine is suitable facilities and construction for mass editing of non-ferrous metals and is the predecessor of KASTOwa M9 KASTOspeed M9. The saw line is currently in preliminary line status and can be visited only in original condition without function. The plant will be located after overhaul (retrofit) in like new condition, which is also guaranteed by our House. The machine will be overhauled on request in our House. Amon ...
Year of construction: 1992-2007 PLC: Siemens S7 Blade 60-250 mm Power 1,5 KW Saw blade feed 0-20 mm / min Cutting speed: 30-170 m / min (steel) 800 - 2400 m/min (non-ferrous metals) Workspace square Max: 50 mm Work area round: 5-70 mm Supply length 5-1000 mm 5-9999 (multiple stroke) Nachschubgeschw. Max 500 mm / sec (Saw) approximate weight: 1500 kg (Magazine), approx.: 800 kg (optional) Dimensions Lxwxh (saw) about: 2500 x 1000 x 2000mm (Magazine) about: 6500mm x 1500mm x 1300mm (optional) Footprint Lxw 2500 mm x 1000 mm The machine will be overhauled on request in our House. Among other things, following points are renewed: -Conversion to Siemens S7 PLC control -Conversion on Siemens HMI Control Panel -Replacement of pneumatic feed or replacement of ball screws -Replacement of servo motor and servo inverters -Replace the inverter for the main drive of the saw - ...
TRENNJAEGER Cold circuit saege - see pictures
Vertical band aege KOeLLE ST105, table 950/900 mm, v= 15 - 2300 m/min - table must be overhauled - see pictures
Ueberholungsjahr 2016 Baujahr 2010 Saegeblatt Hartmetall 500 mm Antriebsleistung Saegemotor 7,5 KW Drehzahl Saegemotor 2000-38000 min-1 Schnittgeschwindigkeit Saegeblatt 3100-6000 mm/min Saegeblattvorschub stufenlos Einstellbar 0-40 mm/ s Arbeitsbereich 90° max.:460 x 50 mm Nachschublaenge Pneumatisch: Einzelhub:max. 300 mm Servogesteuert: Einzelhub:max. 300 mm Mehrfachhub:max. 9999mm Nachschubgeschw. Servogesteuerte Nachschubeinheit 300 mm/s Druckluftanschluss bauseits 6 bar Gewicht(Saege)ca.: 1000 Kg Abmessungen LxBxH(Saege)ca.: 2100mm x2000mm x1600mm Hydraulikagregat) ca.: 900mm x600mm x800mm Technische Beschreibung Pressta Eisele Profilma 540 Retrofit Pressta Eisele Profilma 540 Retrofit Vollautomatischer Hochleistungs-Saegeautomat fuer NE-Metall und Kunstoffe Die Maschine befindet sich nach abgeschlossenem Retrofit sowohl technisch als auch op ...
MKS 315 N Metal cutting circular saws Motor: 1.5/2.2 of kW 50 Hz 400V Speeds: 40/80 1/min Span Vice: 120 mm Saw blade diameter: 315 mm Infeed height incl. pedestal: 1015 mm Dimensions: 1000 x 1150 x 1475 mm Weight: 165 kg G & pieces 3620303SET
Saw blade diameter: 370 mm cutting capacity at 90°: 115 mm cutting capacity at 45°: 115 mm drive motor: 380 V, 4.5 kW space: 1000 x 1200/2200 x 1500 mm weight: approx. 900 kg
Saw blade diameter: 400 mm cutting capacity at 90 ° round: 130 mm cutting capacity at 90 ° square: 200 x 80 and 315 x 40 mm cutting capacity in MITRE at 45 ° square: flat/vertically 180 x 70 / 100 x 60 mm cutting speed: 19/28 m / min drive motor: 380 V, 1.7/2,6 kW space: 1100 x 1050 x 1620 mm weight: 850 kg
Execution semiautomatic 90° diameter: 600 800 x 600 mm Engine: 14,5 kW Blade: 9000 x 67 x 1, 6 mm Min. diameter: 10 mm Working height: 630 mm Weight: 4.3 to.
Technical data: Saw blade diameter: 520mm Mitre: 90° / 45° / 30° Drive capacity: 1.6 / 2.8 kW Dimensions: WxDxH 1520x1520x1560mm Working height: 900 mm Weight: 1250kg
