new
pressure: 175 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 12.0 mm/min return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm oil volume: 300 ltr. table height: 900 mm table width: 90.0 mm voltage: 400 Volt total power requirement: 15.0 kW weight: 9800 kg range L-W-H: 4150 x 2150 x 2800 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool R ...
new
pressure: 400 t chamfer lenght: 4100 mm distance between columns: 3550 mm column arm: 510 mm ram stroke speed: 110 mm/sec work speed: 8.4 mm/sec return speed: 130 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 1000 mm table width: 240 mm back stop - adjustable: max. 800 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 26409 kg range L-W-H: 5450 x 2650 x 3470 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...
new
pressure: 220 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 185 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 930 mm table width: 200 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 11286 kg Dimensions (HxWxD): 4550 x 2250 x 2850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...
new
pressure: 175 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 12.0 mm/sec return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm oil volume: 300 ltr. table height: 900 mm table width: 90.0 mm voltage: 400 Volt total power requirement: 15.0 kW weight: 12100 kg range L-W-H: 5.100x2.150x2.850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool R ...
new
pressure: 135 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 200 mm/sec work speed: 12.0 mm/sec return speed: 190 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 15.0 kW weight: 10800 kg range L-W-H: 5100 x 2100 x 2850 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, Sy ...
new
pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 185 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm back stop - adjustable: max. 800 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 14000 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...
new
pressure: 320 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 140 mm/sec work speed: 10.5 mm/sec return speed: 150 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 240 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 17082 kg Dimensions (HxWxD): 4550 x 2450 x 3200 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...
new
pressure: 320 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 140 mm/sec work speed: 10.5 mm/sec return speed: 150 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 900 mm table width: 220 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 22064 kg Dimensions (HxWxD): 5350 x 2450 x 3150 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot ...
used
pressure: 60.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm back stop - adjustable: max. 800 mm oil volume: 150 ltr. voltage: 400 V engine output: 7.5 kW Weight: 4320 kg range L-W-H: 2250 x 1960 x 2750 mm ** Demonstration/demo machine (!!) ** From our showroom (like new) ** With very few operating hours -------------------------------------------------- CNC press brake with special equipment * Version ERGO - knee room for the operator * flexible articulated arm mount for the controller * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-66T graphic/touch scre ...
new
pressure: 200 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 100 mm/sec return speed: 75,0 mm/sec work speed: 7,0 mm/min work stroke: 180 mm dayligth: 415 mm oil volume: 200 ltr. table height: 900 mm voltage: 400 Volt range L-W-H: 4450x2050x2650 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - FIESSLER AKAS - laser protection in front of the machine - Deer foot upper tool - Universal die block - manual table crowning - Safety device: light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
pressure: 175 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec return speed: 135 mm/sec work speed: 10,0 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90,0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15,0 kW weight: 11.950 kg range L-W-H: 5100 x 2150 x 2850 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen * 2D graphic programming * 15 high definition color TFT screen * Bending sequence calculation * Product programming and display in real size * USB interface - Motorized backgauge with R-axis, on recirculating ball sp ...
new
pressure: 100 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 410 mm ram stroke speed: 200 mm/sec work speed: 9.5 mm/sec return speed: 155 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7.5 kW weight: 6850 kg range L-W-H: 3750 x 1950 x 2800 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 13 ...
new
pressure: 220 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 12906 kg range L-W-H: 5100 x 2250 x 2900 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS ...
new
pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1050 mm column arm: 350 mm dayligth: 387 mm work stroke: 170 mm table height: 850 mm back stop - adjustable: 800 mm adjustment speed: 230 mm/min ajustment speed: 140 mm/sec working feed: 10.0 mm/sec return speed: 170 mm/sec total power requirement: 5.5 kW weight of the machine ca.: 3220 kg dimensions of the machine ca.: 2150 x 1650 x 2300 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled b ...
new
pressure: 160 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/sec return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm back stop - adjustable: max. 800 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 11.0 kW weight: 7524 kg range L-W-H: 4250 x 1900 x 2550 mm Furnishing: - DELEM CNC control model DA-66T graphic/touch screen * 2D graphical programming * 17 TFT color screen with high resolution * Bending sequence calculation * Product programming and real size display * USB interface * intuitive, graphical entry of profiles * Automatic calculation of features: tool safety zones, Press force, bending tolerance, crown setting, stretched Length, embossing force, flattening, automatic rounding calculation * Radius programming * Graphic tool and product library * Co ...
new
pressure: 80.0 t chamfer lenght: 2600 mm distance between columns: 2200 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 60.0 mm/sec work stroke: 160 mm dayligth: 380 mm table height: 900 mm oil volume: 150 ltr. voltage: 400 Volt weight: 5227 kg range L-W-H: 3750 x 1950 x 2400 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - AKAS laser in front of the machine - manual crowning - Upper tool, deer foot - Lower tool, die block with 4Vs - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
pressure: 160 t chamfer lenght: 3760 mm distance between columns: 3250 mm column arm: 250 mm ram stroke speed: 90.0 mm/sec work speed: 7.5 mm/min return speed: 80.0 mm/sec work stroke: 160 mm dayligth: 395 mm table height: 900 mm oil volume: 200 ltr. voltage: 400 Volt weight: 8514 kg range L-W-H: 4910 x 1900 x 2550 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - SICK light barrier in front of the machine - Upper tool, deer foot - Lower tool, die block with 4Vs - manual table crowning - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
pressure: 175 t chamfer lenght: 3100 mm distance between columns: 2600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 135 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 90.0 mm oil volume: 200 ltr. voltage: 400 Volt total power requirement: 15.0 kW weight: 9450 kg range L-W-H: 4250 x 2150 x 2800 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphic/touch screen * 2D graphical programming * 15 TFT color screen with high resolution * Bending sequence calculation * Product programming and real size display * USB interface - Motorized backgauge with R-axis, on ball screws - X = 800 ...
new
pressure: 60.0 t chamfer lenght: 2100 mm distance between columns: 1700 mm column arm: 410 mm ram stroke speed: 160 mm/sec work speed: 10.0 mm/sec return speed: 165 mm/sec work stroke: 275 mm dayligth: 530 mm table height: 900 mm table width: 90.0 mm oil volume: 150 ltr. voltage: 400 Volt total power requirement: 7.5 kW weight: 5640 kg range L-W-H: 3250 x 1960 x 2750 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS ...
new
pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3600 mm column arm: 410 mm ram stroke speed: 180 mm/sec work speed: 10.0 mm/sec return speed: 160 mm/sec work stroke: 275 mm dayligth: 550 mm table height: 900 mm table width: 160 mm oil volume: 300 ltr. voltage: 400 Volt total power requirement: 18.5 kW weight: 13800 kg range L-W-H: 5150 x 2250 x 3000 mm -------------------------------------------------- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen * 2D graphic programming * 15 high definition color TFT screen * Bending sequence calculation * Product programming and display in real size * USB interface - Motorized backgauge with R-axis, on recirculating ball spin ...
new
Pressure:175 t chamfer lenght:4100 mm distance between columns:3600 mm column arm:410 mm ram stroke speed:180 mm/sec return speed:135 mm/sec working speed:10 mm/sec work stroke:275 mm oil volume:200 l dayligth:550 mm table height:900 mm table width:90 mm total power requirement:15 kW weight of the machine ca.:12000 kg dimensions of the machine ca.:5100 x 2150 x 2850 mm
used
used
ERMAKSAN LASERMAK 6000 6X2 laser cutter was produced in 2014. Technical parameters: – laser source: 6000 W CO2-laser GE Fanuc C6000i-Model C – RF-excitation: 2 MHz – power stability: ± 2% (power monitor) – laser wave length: 10.6 μM – beam mode: Fanuc Low Order Mode – laser shutter: mechanical safety shutter – laser gas composition: CO2 / He / N2 – gas consumption by laser: 20 l / h – cooling water flow rate: 250 l / min – maximum cutting capacity: mild steel 25 mm (during tests the maximum achieved: 30 mm), stainless steel 15 mm, aluminum 12 mm - machine activation time: 22899 h - working time: 10122 h - cutting time: 8429 h – total energy requirement: 100-120 kW – cutting head focal length: 5 “-7” -10 “inch – maximum worksheet size: 6150 x 2000 mm – maximum burden capacity: 4000 kg – machine axes: 5 axes [X, Y, Z, U (X2), V] ...
new
sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTe ...
new
sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° total power requirement: 11 kW weight of the machine ca.: 5700 kg dimensions of the machine ca.: 4000x2100x1640 mm Accessories / equipment: - CYBELEC Cybtouch touch screen controller - NC controller for backgauge, gap adjustment, number of pieces, cutting length - 1 side stop with scale, T-groove and tilting cam - 2 front support arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Folding finger guard with limit switch - motorized back gauge 1.000 mm travel - Ball screws - Photocell behind the machine - Ball rolls in the table - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - CE mark / Declaration of Conformity - Operating manual: Machine and control in German The data for this ad was created with ModulMWS ...
