used
ERMAK CNC HVR 3100 x 13 hydraulic guillotine shears built in Turkey in 2008, are designed for cutting workpieces made of among others mild steel or stainless steel. The metal sheet with a maximum length of 3100 mm and a maximum thickness of 8 mm (plain steel) or 13 mm (stainless steel), is held during machining by 14 hydraulic clamps. The angle of the cutting blade can be freely adjusted in the range from 0.5° to 2.0°. Full control over the operation of the CNC HVR 3113 machine is guaranteed by the control panel located on the guillotine shears body with installed CYBELEC DNC 60 CNC controller, allowing programming of many different machining processes. The guillotine shears is equipped with among others new cutting blades and a foot control pedal, making the operator’s work much more comfortable and simple. The total weight of the machine is 13400 kg. The total weight of the mach ...
used
This ERMAK CNC HAP 4100x400 was manufactured in 2006. It features a CYBELEC DNC 60 control system, a maximum working length of 4100 mm, and a press force of 400 t. The internal distance between columns is 3550 mm, and it includes a laser safety system. Consider the opportunity to buy this ERMAK CNC HAP 4100x400 hydraulic press. Contact us for more information about this machine.
used
This 4-axis ERMAK CNC HAP 3100x200 was manufactured in 2007. A robust hydraulic press with a press capacity of 200 tons and a bending length of 3100 mm. It operates with an Ermak ER70 CNC control system and has a motor power of 15 kW. Ideal for heavy-duty bending tasks. Machine dimensions are 4550 Ã 2250 Ã 2850 mm, weighing 11,000 kg. Contact us for more information about this machine.
new
sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the software solution of LogoTe ...
new
sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° total power requirement: 11 kW weight of the machine ca.: 5700 kg dimensions of the machine ca.: 4000x2100x1640 mm Accessories / equipment: - CYBELEC Cybtouch touch screen controller - NC controller for backgauge, gap adjustment, number of pieces, cutting length - 1 side stop with scale, T-groove and tilting cam - 2 front support arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Folding finger guard with limit switch - motorized back gauge 1.000 mm travel - Ball screws - Photocell behind the machine - Ball rolls in the table - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - CE mark / Declaration of Conformity - Operating manual: Machine and control in German The data for this ad was created with ModulMWS ...
new
sheet width: 3100 mm plate thickness: 6 mm voltage: 380 V control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 1,2 ° total power requirement: 11 kW weight of the machine ca.: 6.300 kg dimensions of the machine ca.: 4000x2100x1640 mm Equipment: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. can be folded up at max. Traverse path, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety devi ...
new
sheet width: 3100 mm plate thickness: 13 mm thickness at Niro-steel: 8 mm control: CYBELEC CybTouch down holder: 14 Stück cutting angle: 2,0° ° no. of strokes: 11 Hub/min voltage: 380 V total power requirement: 22 kW weight of the machine ca.: 12.100 kg dimensions of the machine ca.: 4000x2240x2235 mm Accessories / equipment: - CYBELEC-CybTouch control panel with digital display for backgauge - hydr. Cutting gap adjustment via control - 1 side stop - 4 front lifting arms - cut line lighting - Cutting gap adjustment - Cutting length limit - Ball rolls in the table - motorized back gauge 1.000 mm travel with recirculating ball screws, automatically start at the end of the stop - Shear knives for stainless steel cuts as standard - Photocell behind the machine - SIEMENS electrical system - BOSCH / HOERBIGER hydraulic system - Footswitch - Operating instructions in German The data f ...
new
sheet width: 3100 mm plate thickness: 10 mm cutting angle: 2 ° down holder: 14 Stück no. of strokes: 13 Hub/min throat: 350 mm oil volume: 260 l control: CYBELEC CybTouch 8 total power requirement: 22 kW weight of the machine ca.: 10.550 kg dimensions of the machine ca.: 4000x2250x2050 mm Domestic equipments: - Hydraulic swing cut sheet metal shears - Touch screen controller with digital display for backgauge - automatic kerf adjustment via the control - Backgauge control 1000 mm travel with recirculating ball screws - Vibration cutting machine with kerf adjustment - 2 support arms - 1 side stop - Photocell behind the machine - Cutting length limit - cut line lighting - Chrome steel knife - Ball rolls in the table - hinged finger guard with limit switch - Footswitch - CE mark / Declaration of Conformity - Bed instructions in German The data for this ad was created with ModulMWS - the ...
used
BRAND: ERMAK YEAR: 2005 MODEL: CNCHAP 3600X200 APPLICATION TYPE: BENDING LOCATION: LITHUANIA MACHINE TYPE: BENDING MACHINES AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MEASUREMENTS WIDTH: 2250 MM MEASUREMENTS DEPTH: 4950 MM MEASUREMENTS HEIGHT: 2850 MM MACHINE WEIGHT: 12000 KG CONTROL UNIT BRAND: CYBELEC MODEL: DNC 60 MAIN DRIVE PRESSING FORCE: 2000 KN BENDING LENGTH: 3600 MM Additional Information MACHINE BENEFITS TECHNICAL MACHINE BENEFITS: - SAFETY DISTANCE: 1500 MM
new
sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm distance between columns: 3100 mm down holder: 14 Stück oil volume: 150 ltr. cutting angle: 1,2 ° no. of strokes: 18 Hub/min control: CYBELEC CybTouch total power requirement: 11,0 kW weight: 6300 kg range L-W-H: 4.000 x 2.100 x 1.640 mm -------------------------------------------------- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. ...
used
sheet width: 3100 mm plate thickness: 13.0 mm thickness at Niro-steel: 8.0 mm down holder: 14 Stück no. of strokes: 11 - 20 Hub/min oil volume: 310 ltr. cutting angle: 0.05 - 2.0 ° throat: 350 mm table height: 900 mm total power requirement: 22.0 kW weight of the machine ca.: 13400 kg range L-W-H: 5.110 x 2.570 x 2.400 mm ** Current new price approx. 80.000 Euro ** Special price upon request - in checked conditions - machinevideo - https://www.youtube.com/watch?v=K4ymYMIJ7_Y ----------------------------------------------------------- Robust electro-hydraulic CNC sheet metal shear with slide guides * Includes CYBELEC DNC 60 CUT control system * Includes CNC electro-hydraulic cutting gap adjustment * Includes CNC electro-hydraulic cutting angle adjustment ---------------------------------------------------------- Equipment: - CNC electro-hydraulic guillotine shear with slide guides - Inc ...
new
sheet width: 3100 mm plate thickness: 6,0 mm distance between columns: 3.100 mm down holder: 14 Stück no. of strokes: 16 - 24 Hub/min oil volume: 150 ltr. cutting angle: 0,5 - 1,5 ° thickness at Niro-steel: 4,0 mm column arm: 350 mm engine output: 11,0 kW weight of the machine ca.: 7.060 kg range L-W-H: 4100 x 2200 x 2190 mm -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guiding guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, incl ...
new
sheet width: 3100 mm plate thickness: 13,0 mm thickness at Niro-steel: 8,0 mm down holder: 14 Stück no. of strokes: 11 - 20 Hub/min oil volume: 310 ltr. cutting angle: 0,05 - 2,0 ° throat: 350 mm table height: 900 mm total power requirement: 22,0 kW weight of the machine ca.: 13.300 kg range L-W-H: 5.110 x 2.570 x 2.400 mm -------------------------------------------------- heavy electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guiding shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, ...
new
sheet width: 3100 mm plate thickness: 13,0 mm thickness at Niro-steel: 8,0 mm down holder: 14 Stück no. of strokes: 11 Hub/min oil volume: 310 ltr. cutting angle: 2,0 ° throat: 350 mm table height: 900 mm total power requirement: 22,0 kW weight of the machine ca.: 12200 kg range L-W-H: ca. 4100 x 2300 x 2235 mm -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball scre ...
new
sheet width: 3100 mm plate thickness: 10,0 mm thickness at Niro-steel: 6,0 mm down holder: 14 Stück no. of strokes: 13 Hub/min oil volume: 260 ltr. cutting angle: 2,0 ° throat: 350 mm engine output: 22,0 kW back stop - adjustable: 1.000 mm weight: 10.575 kg. range L-W-H: 4,05 x 2,5 x 2,17 m -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up a ...
new
sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm down holder: 14 Stück no. of strokes: 20 Hub/min cutting angle: 1,2 ° control: CYBELEC CybTouch work height max.: 800 mm oil volume: 150 ltr. total power requirement: 11,0 kW weight: 5500 kg range L-W-H: 4.000 x 2.410 x 1.640 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folde ...
new
sheet width: 2600 mm plate thickness: 8,0 mm thickness at Niro-steel: 5,0 mm down holder: 12 Stück no. of strokes: 18 Hub/min oil volume: 200 ltr. cutting angle: 1,5 ° engine output: 15,0 kW weight of the machine ca.: 6.300 kg range L-W-H: 3525 x 2350 x 1700 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at max.travel, for longer cuts - 1x sid ...
new
sheet width: 4100 mm plate thickness: 10,0 mm thickness at Niro-steel: 6,0 mm down holder: 28 Stück no. of strokes: 18 Hub/min oil volume: 260 ltr. cutting angle: 0,5 - 2 ° control: CYBELEC Cybtouch engine output: 22,0 kW back stop - adjustable: 1000 mm range L-W-H: 6100 x 2580 x 2460 mm weight: 15.100 kg. -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thic ...
used
sheet width: 3100 mm plate thickness: 10.0 mm thickness at Niro-steel: 6.0 mm down holder: 14 Stück no. of strokes: 13 Hub/min cutting angle: 2.0 ° throat: 350 mm back stop - adjustable: 1000 (+) mm oil volume: 260 ltr. engine output: 22.0 kW weight: 10.575 kg range L-W-H: 4100 x 2400 x 2170 mm ** Demonstration/demo machine (!!) ** from our exhibition (like NEW) ** with very few operating hours -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * C ...
new
sheet width: 4100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm down holder: 18 Stück no. of strokes: 15 Hub/min oil volume: 150 ltr. cutting angle: 1,2 ° control: CYBELEC Cybtouch back stop - adjustable: 1000 mm work height max.: 800 mm engine output: 11,0 kW weight: 8.100 kg. range L-W-H: 5000 x 2410 x 1650 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws ...
new
sheet width: 2100 mm plate thickness: 6,0 mm ST 42 thickness at Niro-steel: 4,0 mm VA cutting angle: 1,2 Grad no. of strokes: 28 Hub/min oil volume: 150 ltr. down holder: 11 Stück control: CYBELEC CybTouch engine output: 11,0 kW back stop - adjustable: 1.000 mm table height: 800 mm weight: 4.500 kg range L-W-H: 3.010 x 2.100 x 1.640 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ba ...
new
sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm distance between columns: 3100 mm no. of strokes: 18 Hub/min down holder: 14 Stück oil volume: 150 ltr. cutting angle: 1,2 ° control: CYBELEC CybTouch total power requirement: 11,0 kW weight: 6300 kg range L-W-H: 4.000 x 2.100 x 1.640 mm -------------------------------------------------- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * ...
new
sheet width: 3100 mm plate thickness: 6,0 mm distance between columns: 3.100 mm down holder: 14 Stück no. of strokes: 16 - 24 Hub/min oil volume: 150 ltr. cutting angle: 0,5 - 1,5 ° thickness at Niro-steel: 4,0 mm column arm: 350 mm engine output: 11,0 kW weight of the machine ca.: 7.060 kg range L-W-H: 4,1 x 2,2 x 2,19 m -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, incl ...
used
pressure: 220 t chamfer lenght: 3720 mm distance between columns: 3020 mm column arm: 400 mm ajustment speed: 125 mm/sec working feed: 10.0 mm/sec return speed: 132 mm/sec back stop - adjustable: 800 mm stroke: 275 mm dayligth: 550 mm table height: 900 mm oil volume: 300 ltr. total power requirement: 18.5 kW weight of the machine ca.: 12800 kg. range L-W-H: 5850 x 2220 x 2820 mm ** Good condition ** Current new price approx. 100.000 euros ** Special price on request Features: - Electro-hydraulic CNC press brake - With DELEM CNC control model DA 66W * 2D graphic programming * Automatic bend sequence calculation and collision detection * High-quality color LCD screen (TFT) - Swivel control panel, front left - CNC-controlled axes: Y1 + Y2 + X + R + crowning - CNC electric motor-driven backgauge (X axis) - CNC electric motor height adjustment of the backgauge (R axis) - CNC electric motor-dr ...
used
pressure: 40.0 t chamfer lenght: 1270 mm distance between columns: 1000 mm column arm: 200 mm stroke: 100 mm dayligth: 308 mm ajustment speed: 150 mm/sec working feed: 1-10 mm/sec return speed: 100 mm/sec table width: 100 mm table height: 900 mm control: DNC 60 PS oil volume: 100 l voltage: 400 V total power requirement: 5.5 kW weight of the machine ca.: 2750 kg Equipment: - CNC electro-hydraulic press brake - CYBELEC DNC 60 PS CNC control * Swiveling control panel, front left * Tool & program library - CNC electro-motorized backgauge (X-axis) * X-axis travel = 800 mm * 2x manually adjustable backgauge fingers (R+Z axes) * Backgauge on ball screws - CNC controlled axes Y1 - Y2 - X - Rehfuß upper tool system A with quick-change clamping * Additional crowning device in the tool holder - 4V universal die block with 60 mm die shoe - 2x sliding material/support arms (Sliding System) - BOSCH/ ...
