Manufacturer:
(Category: 301)
Key data: 1800 kN
Engel e-max 440/180 / Electric machine Year of Make: 2009 Injection unit: Screw diameter: 40 mm Injection weight: approx. 199 g Spray pressure: 1950 bar Dosing volume: 220 ccm Clamping unit: Clamping force: 180 t Tiebar spacing: 520x520 mm Size of the clamping plates: 760x775 mm Ejector: electric Clamping unit: toggle lever Control: CC 200 - touch screen Additional equipment: Machine in very good technical condition, worked in clean production Electric machine: high-speed, energy-saving and very quiet Euromap 67 Robot interface Air Valve x 3 Hardened injection unit - Bimetal Parallel movements Central lubrication Automatic tool height adjustment Kistler Sensor - Tool Pressure Control Original Tool Crane Dimensions: Weight: 7200 kg Length/Width/Height: 5.87x1.42x2.00 m All offered machines are started by our service technicians before they are sold ...
Key data: 1600 kN
Engel Victory 330H/80V/160 combi Ecodrive / Production line with the Sepro SR S5-25 S3 Trans robot / Operating hours: approx. 18,000 h in automatic mode Year of Make: 2013 Injection unit: Screw diameter: 30 mm Injection weight: approx. 100 g Spray pressure: 2385 bar Dosing volume: 113 ccm Clamping unit : Clamping force: 160 t Spar spacing: 0x0 mm Size of the clamping plates: 750x750 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 - touch screen Additional equipment: 2K Injection Molding Machine with Turntable and Robot Tie-bar-less machine, hybrid: energy-saving, high-speed and very quiet Very good technical condition Operating hours: approx. 18,000 h in automatic mode Total number of operating hours: 24,312 h Euromap 67 Robot interface Air Valve x 5 Hydraulic core pull x 5 Control with hot runners x 16 Reinforced Injection Units – Bimeta ...
Key data: 1400 kN
Engel Victory 330H/200V/140 combi Ecodrive / Production line with the Sepro Multi Inject 20 robot / Operating hours: approx. 18,000 h in automatic mode Year of Make: 2017 Injection unit: Screw diameter: 30 mm Injection weight: approx. 100 g Spray pressure: 2400 bar Dosing volume: 113 ccm Clamping unit: Clamping force: 140 t Spar spacing: 0x0 mm Size of the clamping plates: 750x750 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 300 - touch screen Additional equipment: 2K Injection Molding Machine with Turntable and Robot Tie-bar-less machine, hybrid: energy-saving, high-speed and very quiet Very good technical condition Operating hours: approx. 18,000 in automatic mode Total number of operating hours: 25,369 h Euromap 67 Robot interface Air Valve x 8 Hydraulic core pull x 5 Control with hot runners x 16 Reinforced Injection Units – Bimetal M ...
Key data: 1400 kN
Engel Victory 330H/200V/140 combi Ecodrive / Production line with the Sepro Multi Inject 20 robot / Operating hours: approx. 8,000 h in automatic mode Year of manufacture: 2018 Injection unit: Screw diameter: 30 mm Injection weight: approx. 100 g Spray pressure: 2400 bar Dosing volume: 113 ccm Clamping unit : Clamping force: 140 t Spar spacing: 0x0 mm Size of the clamping plates: 750x750 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 300 - touch screen Additional equipment: 2K Injection Molding Machine with Turntable and Robot Tie-bar-less machine, hybrid: energy-saving, high-speed and very quiet Very good technical condition, the machine worked in a so-called clean room Operating hours: approx. 8,000 in automatic mode Total number of operating hours: 12,005 h Euromap 67 Robot interface Air Valve x 6 Hydraulic core pull x 5 Control with hot run ...
Key data: 1100 kN
Engel Victory 330/110 Tech / Production line with the Engel ER-HLI 41 robot and conveyor belt / machine in very good technical condition Year of Make: 2004 Injection unit: Screw diameter: 40 mm Injection weight: 190 g Spray pressure: 1670 bar Dosing volume: 201 cc Clamping unit: Clamping force: 110 t Spar spacing: 0x0 mm Size of the clamping plates: 790x680 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 100 Additional equipment: Production line with integrated Engel ER-HLI 41 robot and conveyor belt Tie-bar-less machine Hydraulic core pull x 1 Hardened injection unit - Bimetal Machine has been serviced by the authorized service Engel Machine with original protective housing for robot and conveyor belt Dimensions: Weight: 7400 kg Length/Width/Height: 5.10x1.50x2.10 m Drive: Pumps/motor: 18.5 kW Heating capacity: 9.2 kW Total power: 27.7 k ...
Key data: 1100 kN
Engel Victory 500/110 Tech Ecodrive with the Sepro S5.15 robot / Hybrid machine / Operating hours: approx. in automatic mode Year of Make: 2017 Injection unit: Screw diameter: 40 mm Injection weight: approx. 225 g Spray pressure: 2029 bar Dosing volume: 251 ccm Clamping unit: Clamping force: 110 t Spar spacing: 0x0 mm Size of the clamping plates: 740x680 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 300 - touch screen Additional equipment: Machine in very good technical condition Tie-bar-less, hybrid machine: high-speed, energy-saving and very quiet Operating hours: approx. in automatic mode Euromap 67 Robot interface Air Valve x 4 Hydraulic core pull x 6 Control with hot runners x 8 Hardened injection unit - Bimetal Main motor of the machine - Servo motor driven by inverter - Energy saving Sepro S5.15 robot Year of Make: 2016 5-axis robot: ...
Key data: 1000 kN
Engel Insert 80V/80V/100 2F/2-K Ti-bar-less Machine, Vertical / Perfect Technical Condition Year of Make: 2007 Injection unit: Screw diameter: 2 x 25 mm Injection weight: approx. 49 g Spray pressure: 1214 bar Dosing volume: 54 ccm Clamping unit: Clamping force: 100 t Spar spacing: 0x0 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 Additional equipment: Ti-bar-less machine with two vertical injection units, with turntable Air Valve x 6 Hydraulic core pull x 2 Control with hot runners x 12 Infrared protective curtains Thermoplastic and rubber injection units are available for this machine Rotary table diameter: 1200 mm The machine has been regularly serviced by the authorized service provider Engel in Germany Dimensions: Weight: 9400 kg Length/Width/Height: 4.85x1.47x2.30 m Drive: Pumps/motor: 30 kW All offered machines are started b ...
Key data: 800 kN
Engel Victory 500/80 Tech / Production line with the Engel Viper 12 robot Year of Make: 2011 Injection unit: Screw diameter: 45 mm Injection weight: approx. 295 g Spray pressure: 1598 bar Dosing volume: 318 ccm Clamping unit: Clamping force: 80 t Spar spacing: 0x0 mm Size of the clamping plates: 670x600 mm Ejector: hydraulic Clamping unit: hydraulic Control: CC 200 - touch screen Additional equipment: Tie-bar-less machine Euromap 67 Robot interface Hydraulic core pull x 3 Hardened injection unit - Bimetal Robot Angel Viper 12 Year of Make: 2014 5-axis robot: 4 axes are driven by servo motors (electric); Axis A - pneumatic Touch control panel Robot with adapter and protective housing with part separator Purchase of the robot at an additional cost Dimensions: Weight: 5300 kg Length/Width/Height: 4.57x1.48x2.38 m Drive: Pumps/motor: 15 kW All off ...
Key data: 4000 kN
Krauss Maffei KM 400-3000 GX Blue Power with the Krauss Maffei LRX 250 robot Year of manufacture: 2018 Injection unit: Screw diameter: 80 mm Injection weight: 1464 g Spray pressure: 1855 bar Dosing volume: 1608 ccm Clamping unit: Clamping force: 400 t Handlebar spacing: 920x830 mm Size of the clamping plates: 1280x1240 mm Ejector: hydraulic Clamping unit: hydraulic Control: MC5 - Touch Screen Additional equipment: Very good technical condition Operating hours: approx. h in automatic mode Euromap 67 Robot interface Min./max. tool installation height: 400/900 mm Air Valve x 4 Hydraulic core pull x 4 Control with hot runners x 36 Self-closing nozzle x 10 Hardened injection unit - Bimetal Proportional valve on the injection unit – precise injection Function for automatic pulling out of the upper spar Machine has been regularly serviced by the authorized s ...
Key data: 2500 kN
Krauss Maffei KM 250-2000 CX Blue Power with the Sepro Industrial Robot SR S5-35HL S4 Trans robot Year of Make: 2019 Injection unit: Screw diameter: 70 mm Spraying weight: 980 g Spray pressure: 1877 bar Dosing volume: 1077 ccm Clamping unit: Clamping force: 250 t Tiebar spacing: 630x630 mm Size of the clamping plates: 995x1050 mm Ejector: hydraulic Clamping unit: hydraulic Control: MC6 - Touch Screen Additional equipment: Very good technical condition Operating hours: approx. h in automatic mode Euromap 67 Robot interface Air Valve with Vacuum Measurement x 1 Air Valve x 1 Hydraulic core pull x 3 Air Core Pull x 1 Control with hot runners x 16 Hardened injection unit - Bimetal Energy-efficient machine – has a system with 3 hydraulic pumps with variable power Parallel movements Proportional valve on the injection unit – precise injection Additional ...
Key data: 2000 kN
Krauss Maffei KM 200-1400 CX with the Krauss Maffei LRX Easy Control 100 robot / Operating hours: 12,000 h in automatic mode Year of manufacture: 2018 Injection unit: Screw diameter: 60 mm Injection weight: 617 g Spray pressure: 2007 bar Dosing volume: 679 ccm Clamping unit: Clamping force: 200 t Tiebar spacing: 560x560 mm Size of the clamping plates: 915x915 mm Ejector: hydraulic Clamping unit: hydraulic Control: MC6 - Touch Screen Additional equipment: Very good technical condition Operating hours: 12,000 h in automatic mode Euromap 67 Robot interface Air Valve with Vacuum Measurement x 1 Hydraulic core pull x 3 Air Core Pull x 3 Control with hot runners x 10 Hardened injection unit - Bimetal Energy-efficient machine – has a system with 3 hydraulic pumps with variable power Parallel movements Proportional valve on the injection unit – precise injec ...
Key data: 1300 kN
Krauss Maffei KM 130-750 CX Year of Make: 2010 Injection unit: Screw diameter: 40 mm Injection weight: 228 g Spray pressure: 2500 bar Dosing volume: 251 ccm Clamping unit: Clamping force: 130 t Spar spacing: 470x470 mm Size of the clamping plates: 745x770 mm Ejector: hydraulic Clamping unit: hydraulic Control: MC5 Additional equipment: Euromap 67 Robot interface Hydraulic core pull x 1 Air Core Pull x 6 Control with hot runners x 18 Hardened injection unit - Bimetal Proportional valve on the injection unit – precise injection Dimensions: Weight: 9000 kg Length/Width/Height: 4.90x1.60x2.10 m All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request
Key data: 800 kN
Krauss Maffei KM 80-180 CX with the Sepro Industrial Robot 55 sprue picker Year of Make: 2005 Injection unit: Screw diameter: 30 mm Injection weight: 77.4 g Spray pressure: 2025 bar Dosing volume: 85 ccm Clamping unit: Clamping force: 80 t Spar spacing: 420x420 mm Size of the clamping plates: 670x670 mm Ejector: hydraulic Clamping unit: hydraulic Control: MC V - Touch Screen Additional equipment: Euromap 67 Robot interface Control with air valve Hydraulic core pull x 1 Hardened injection unit - Bimetal Sprue Picker Sepro Industrial Robot 55 Year of manufacture: 2018 It is possible to buy a Moretto raw material feeding system at an additional cost The set includes: - Screw dosing device, volumetric with container - Conveyor with proportional valve Dimensions: Weight: 3900 kg Length/Width/Height: 3.80x1.50x2.10 m Drive: Pumps/motor: 15 kW Heatin ...
Key data: 350 kN
Krauss Maffei KM 35-55 CX / Machine in very good technical condition Year of Make: 2008 Injection unit: Screw diameter: 18 mm Injection weight: 18 g Spray pressure: 2500 bar Dosing volume: 20 ccm Clamping unit : Clamping force: 35 t Tiebar spacing: 320x320 mm Size of the clamping plates: 540x540 mm Ejector: hydraulic Clamping unit: hydraulic Control: MC V - Touch Screen Additional equipment: Machine in very good technical condition Euromap 67 Robot interface Air Valve x 2 Control with hot runners x 6 Hardened injection unit - Bimetal The machine was regularly serviced by the authorized service Krauss Maffei in Germany It is possible to change the screw diameter for fi 20 mm, 22 mm Dimensions: Weight: 2600 kg Length/Width/Height: 3.50x1.40x1.70 m Drive: Pumps/motor: 11 kW Heating capacity: 3.78 kW Total power: 14.78 kW All offered machines are s ...
Key data: 3500 kN
Sumitomo Demag Systec 350/720-2300 / Production line with the Wittmann-Demag DR853 robot Year of Make: 2015 Injection unit: Screw diameter: 70 mm Injection weight: 1103 g Spray pressure: 1877 bar Dosing volume: 1212 ccm Clamping unit: Clamping force: 350 t Tiebar spacing: 720x720 mm Size of the clamping plates: 1040x1060 mm Ejector: hydraulic Clamping unit: toggle lever Control: NC5 Additional equipment: Euromap 67 Robot interface Control with air valve Control with hot runners x 5 Hardened injection unit - Bimetal Moog proportional valve on the injection unit – precise injection Parallel movements Central lubrication 3 hydraulic pumps with variable power Built-in printer Machine has been regularly serviced by the authorized service Sumitomo Demag Robot Wittmann-Demag DR853 Year of Make: 2016 6-axis robot: 5 axes are driven by servo motors (electric) ...
Key data: 3500 kN
Sumitomo Demag Systec 350/720-2300 / Production line with the Wittmann-Demag DR833 robot Year of Make: 2012 Injection unit: Screw diameter: 70 mm Injection weight: 1103 g Spray pressure: 1877 bar Dosing volume: 1212 ccm Clamping unit: Clamping force: 350 t Tiebar spacing: 720x720 mm Size of the clamping plates: 1040x1060 mm Ejector: hydraulic Clamping unit: toggle lever Control: NC5 Additional equipment: Euromap 67 Robot interface Air Valve x 5 Hydraulic core pull controlled with proportional valve x 1 Control with hot runners x 5 Hardened injection unit - Bimetal Moog proportional valve on the injection unit – precise injection Parallel movements Central lubrication 3 hydraulic pumps with variable power Built-in printer Machine has been regularly serviced by the authorized service Sumitomo Demag Robot Wittmann-Demag DR833 Year of Make: 2011 4-axi ...
Key data: 1000 kN
Sumitomo Demag Systec 100/420-310 with the Sepro SR SDR11 S3 TRANS robot / hybrid machine Year of Make: 2013 Injection unit: Screw diameter: 35 mm Injection weight: 149 g Spray pressure: 2024 bar Dosing volume: 168 ccm Clamping unit: Clamping force: 100 t Spar spacing: 420x420 mm Size of the clamping plates: 600x600 mm Ejector: hydraulic Clamping unit: hydraulic Control: NC5 Additional equipment: Hybrid machine: high-speed, energy-saving and very quiet Operating hours: approx. 38,000 h in automatic mode Robot interface Air Valve x 2 Hydraulic core pull x 1 Hardened injection unit - Bimetal Main motor of the machine - Servo motor driven by inverter - Energy saving Built-in printer Machine has been regularly serviced by the authorized service Sumitomo Demag Robot Sepro SR SDR11 S3 TRANS Year of Make: 2013 5-axis robot: 3 axes are driven by servo motors (el ...
Key data: 800 kN
Demag Ergotech System 80/420-430 Year of Make: 2006 Injection unit: Screw diameter: 40 mm Injection weight: 205 g Spray pressure: 2020 bar Dosing volume: 231 ccm Clamping unit: Clamping force: 80 t Spar spacing: 420x420 mm Size of the clamping plates: 580x590 mm Ejector: hydraulic Clamping unit: hydraulic Control: NC4 Additional equipment: Euromap 67 Robot interface Air Valve x 2 Hydraulic core pull x 3 Control with hot runners Hardened injection unit - Bimetal Built-in printer It is possible to change the screw diameter Dimensions: Weight: 4100 kg Length/Width/Height: 4.10x1.40x1.90 m All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request
Key data: 500 kN
Sumitomo Demag IntElekt 50/370-200 / Electric Machine Year of Make: 2009 Injection unit: Screw diameter: 35 mm Injection weight: 128 g Spray pressure: 1466 bar Dosing volume: 144 ccm Clamping unit: Clamping force: 50 t Tiebar spacing: 370x370 mm Size of the clamping plates: 520x570 mm Ejector: electric Clamping unit: toggle lever Control: NC5 - Touch Screen Additional equipment: Electric machine: high-speed, energy-saving and very quiet Euromap 67 Robot interface Air Valve x 4 Control with hot runners Hardened injection unit - Bimetal Central lubrication It is possible to change the screw diameter Dimensions: Weight: 4750 kg Length/Width/Height: 4.20x1.26x1.84 m Drive: Heating capacity: 5.7 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected ...
Key data: 250 kN
Demag Ergotech Compact 250-80 Year of Make: 1995 Injection unit: Screw diameter: 18 mm Injection weight: 20 g Spray pressure: 2400 bar Dosing volume: 22.8 ccm Clamping unit: Clamping force: 25 t Tiebar spacing: 280x280 mm Size of the clamping plates: 410x410 mm Ejector: hydraulic Clamping unit: hydraulic Control: NC4 Additional equipment: Air Valve x 2 Hydraulic core pull x 1 Hardened injection unit - Bimetal Original Demag tool crane: chain, electrically controlled, 2 lifting speeds Dimensions: Weight: 2600 kg Length/Width/Height: 3.20x1.30x1.80 m Drive: Pumps/motor: 7.5 kW Heating capacity: 3.7 kW Total power: 11.2 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. ...
Key data: 1000 kN
Battenfeld HM 100/525 with the Battenfeld R10S robot / Operating hours: approx. 19,000 in automatic mode Year of Make: 2008 Injection unit: Screw diameter: 40 mm Injection weight: 228.4 g Spray pressure: 2100 bar Dosing volume: 251 ccm Clamping unit: Clamping force: 100 t Handlebar spacing: 470x420 mm Size of the clamping plates: 680x663 mm Ejector: hydraulic Clamping unit: hydraulic Control: UNILOG B6 - Touch Screen Additional equipment: Machine in very good technical condition Operating hours: approx. 19,000 in automatic mode Total number of operating hours: 26,580 Euromap 67 Robot interface Air Valve x 1 Hydraulic core pull x 1 Injection unit is wear-resistant and resistant to corrosion Battenfeld R10S robot Year of Make: 2015 5-axis robot: 3 axes are driven by servo motors (electric); Axis B - pneumatic, Axis C Robot with adapter Purchase of the r ...
Key data: 1000 kN
Battenfeld TM 100/525 Year of Make: 2007 Injection unit: Screw diameter: 40 mm Injection weight: 228.4 g Spray pressure: 2100 bar Dosing volume: 251 ccm Clamping unit: Clamping force: 100 t Spar spacing: 420x420 mm Size of the clamping plates: 640x640 mm Ejector: hydraulic Clamping unit: toggle lever Control: UNILOG B2 Additional equipment: Euromap 67 Robot interface Hydraulic core pull x 1 Control with hot runners x 12 Injection unit is wear-resistant and resistant to corrosion Central lubrication Automatic tool height adjustment Dimensions: Weight: 3900 kg Length/Width/Height: 4.46x1.33x1.78 m Drive: Pumps/motor: 18.5 kW Heating capacity: 12.1 kW Total power: 30.6 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participa ...
Key data: 1100 kN
Wittmann Battenfeld EcoPower 110/350 / Electric motor / Operating hours: approx. 15,000 in automatic mode Year of Make: 2019 Injection unit: Screw diameter: 35 mm Injection weight: 153.8 g Spray pressure: 2083 bar Dosing volume: 168 ccm Clamping unit: Clamping force: 110 t Handlebar spacing: 470x420 mm Size of the clamping plates: 682x682 mm Ejector: electric Clamping unit: toggle lever Control: UNILOG B8 - Touch Screen Additional equipment: Machine in very good technical condition Electric machine: energy-saving and very quiet Operating hours: approx. 15,000 in automatic mode Total number of operating hours: 21,800 Euromap 67 Robot interface Air Valve x 1 Hydraulic core pull x 1 Control with hot runners Injection unit is wear-resistant and resistant to corrosion Central lubrication Dimensions: Weight: 4800 kg Length/Width/Height: 4.91x1.42x2.10 m ...
Key data: 1100 kN
Wittmann Battenfeld EcoPower 110/350 with the Wittmann W818 robot / Electric machine / Operating hours: approx. 16,000 in automatic mode Year of Make: 2017 Injection unit: Screw diameter: 35 mm Injection weight: 153.8 g Spray pressure: 2083 bar Dosing volume: 169 ccm Clamping unit: Clamping force: 110 t Handlebar spacing: 470x420 mm Size of the clamping plates: 680x660 mm Ejector: electric Clamping unit: toggle lever Control:UNILOG B8 - Touch Screen Additional equipment: Perfect technical condition Electric machine: high-speed, energy-saving and very quiet Operating hours: approx. 16,000 in automatic mode Euromap 67 Robot interface Control with air valve Hydraulic core pull x 1 Control with hot runners Injection unit is wear-resistant and resistant to corrosion Central lubrication Automatic tool height adjustment Parallel movements The machine was servi ...
Key data: 1500 kN
Wittmann Battenfeld HM 150/750 Servo Power / Hybrid Machine / Operating Hours: approx. 29,000 in automatic mode Year of Make: 2014 Injection unit: Screw diameter: 50 mm Injection weight: 402.2 g Spray pressure: 1714 bar Dosing volume: 442 cc Clamping unit: Clamping force: 150 t Tiebar spacing: 520x470 mm Size of the clamping plates: 760x755 mm Ejector: hydraulic Clamping unit: hydraulic Control: UNILOG B6P - Touch Screen Additional equipment: Machine in very good technical condition Electric machine: energy-saving and very quiet Operating hours: approx. 29,000 in automatic mode Total number of operating hours: 36,714 Euromap 67 Robot interface Air Valve x 1 Hydraulic core pull x 1 Injection unit is wear-resistant and resistant to corrosion Main motor of the machine - Servo motor driven by inverter - Energy saving Dimensions: Weight: 6600 kg Length/Wid ...
Key data: 1300 kN
Battenfeld BA 1300V/315 V-R / Vertical Injection Molding Machine with the Rotary Table Year of Make: 1997 Injection unit: Screw diameter: 40 mm Injection weight: 182.9 g Spray pressure: 1575 bar Dosing volume: 201 cc Clamping unit: Clamping force: 130 t Handlebar spacing: 454x740 mm Size of the clamping plates: 815x1010 mm Ejector: hydraulic Clamping unit: hydraulic Control: UNILOG 4000 Additional equipment: Air Valve x 5 Hydraulic core pull x 1 Rotary table: 1250 mm The vertical injection unit - screw diameter fi 35 mm Dimensions: Weight: 7500 kg Length/Width/Height: 3.83x2.33x4.16 m Drive: Pumps/motor: 18.5 kW Heating capacity: 8.98 kW Total power: 27.48 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live te ...
Key data: 1500 kN
Wittmann Battenfeld VM 150/525 R1280 Servo Power / Vertical Injection Molding Machine with the Rotary Molding Machine Year of Make: 2015 Injection unit: Screw diameter: 35 mm Injection weight: 175.6 g Spray pressure: 2743 bar Dosing volume: 193 cc Clamping unit: Clamping force: 150 t Spar spacing: 0x0 mm Size of the clamping plates: 1280 mm Ejector: hydraulic Clamping unit: hydraulic Control: UNILOG B6 Additional equipment: Vertical Injection Molding Machine with the Rotary Molding Machine Hybrid machine: high-speed, energy-saving and very quiet Air Valve x 5 Hydraulic core pull x 1 Control with hot runners x 12 Injection unit is wear-resistant and resistant to corrosion Rotary table diameter: 1500 mm Rotary table driven by a servo motor, controlled by an inverter Dimensions: Weight: 11300 kg Length/Width/Height: 3.83x1.50x4.07 m All offered machines ...
Key data: 2700 kN
Battenfeld HM 270/1330H/1000H / 2K machine in very good technical condition / Operating hours: approx. 10,000 h in automatic mode Year of Make: 2006 Injection unit: Screw diameter: 55 mm Injection weight: 594 g Spray pressure: 2041 bar Dosing volume: 653 ccm Clamping unit: Clamping force: 270 t Handlebar spacing: 710x710 mm Size of the clamping plates: 1030x1000 mm Ejector: hydraulic Clamping unit: hydraulic Control: UNILOG B4 Additional equipment: Machine in very good technical condition 2K machine with parallel horizontal injection units Central injection Operating hours: approx. 10,000 in automatic mode Total number of operating hours: 11,876 h Control with air valve Hydraulic core pull x 3 Reinforced Injection Units – Bimetal Proportional valves on injection units - precise spraying Parallel movements Injection unit 1000H Screw diameter: 50 mm I ...
Key data: 3000 kN
Battenfeld HM 300/2250S with the Wittmann W818 robot / Machine in very good technical condition / Operating hours: approx. 40,000 h in automatic mode Year of Make: 2007 Injection unit: Screw diameter: 55 mm Injection weight: 702.5 g Spray pressure: 2500 bar Dosing volume: 772 ccm Clamping unit : Clamping force: 300 t Spar spacing: 710x630 mm Size of the clamping plates: 1030x1020 mm Ejector: hydraulic Clamping unit: hydraulic Control: UNILOG B6 - Touch control panel Additional equipment: Machine in very good technical condition Euromap 67 Robot interface Control with air valve Hydraulic core pull x 1 Control with hot runners x 8 Injection unit is wear-resistant and resistant to corrosion Proportional valve on the injection unit – precise injection New original screw and barrel are installed in the machine Robot Wittmann W818 4-axis, high-speed robot: ...
Key data: 3000 kN
Battenfeld EcoPower SE 300/1330 / Electric Machine Year of Make: 2012 Injection unit: Screw diameter: 50 mm Injection weight: 491.4 g Spray pressure: 2470 bar Dosing volume: 540 cc Clamping unit: Clamping force: 300 t Tiebar spacing: 770x720 mm Size of the clamping plates: 1090x1170 mm Ejector: electric Clamping unit: toggle lever Control: UNILOG B6 - Touch Screen Additional equipment: Electric machine: high-speed, energy-saving and very quiet Machine in very good technical condition Euromap 67 Robot interface Air Valve x 8 Control with hot runners x6 Hardened injection unit - Bimetal Parallel movements It is possible to change the screw diameter for fi 45, 55, 65 mm Dimensions: Weight: 14100 kg Length/Width/Height: 7.20x2.04x2.20m Drive: Pumps/motor: 0 kW Heating capacity: 22 kW Total power: 0 kW All offered machines are started by our servic ...
