Manufacturer:
(Category: 301)
with Wittman robot | Control: NC4 Demag Ergotech 350/710 - 840 Year of Manufacture: 2001 Clamping Force: 350 tons (3500 kN) Tie-bar Spacing: 710 mm Injection Unit Size: 840mm Screw diameter: 60mm Auction-ID: A1-51094-4
B&A REF: 9373 TON: 780 SCREW DIAMETER: 120MM SHOT WEIGHT: 4520 STROKE VOLUME: 4976CM3 INJECTION PRESSURE: 1280AR PLATEN SIZES: 1420 X 1440MM DBTB: 980 X 980MM MIN MOULD HEIGHT: 400MM MAX MOULD HEIGHT: 980MM MOULD OPENING STROKE: 980MM MAX DAYLIGHT: 1960MM EJECTOR STROKE: 260MM CONTROLS: APC 6000 CORE PULLING: 2 AIR VALVES: 1 MOTOR: 37 + 37 HEATING CAPACITY: 58KW ROBOT INTERFACE: EUROMAP 67 SCREW DRIVE: HYDRAULIC
B&A REF: 9362 TON: 440 SCREW DIAMETER: 80MM SHOT WEIGHT: 1895 STROKE VOLUME: 2060CM3 INJECTION PRESSURE: 1540AR PLATEN SIZES: 1120 X 1120MM DBTB: 740 X 740MM MIN MOULD HEIGHT: 250MM MAX MOULD HEIGHT: 850MM MOULD OPENING STROKE: 830MM MAX DAYLIGHT: 1680MM EJECTOR STROKE: 305MM CONTROLS: SEF 100 CORE PULLING: 2 AIR VALVES: 2 MOTOR: 55 HEATING CAPACITY: 33KW ROBOT INTERFACE: EUROMAP SCREW DRIVE: HYDRAULIC
B&A REF: 9351 TON: 400 SCREW DIAMETER: 80MM SHOT WEIGHT: 1433 STROKE VOLUME: 1558CM3 INJECTION PRESSURE: 1640AR PLATEN SIZES: 1300 X 1100MM MIN MOULD HEIGHT: 450MM MOULD OPENING STROKE: 1000MM MAX DAYLIGHT: 1450MM EJECTOR STROKE: 250MM CONTROLS: CC CORE PULLING: 2 AIR VALVES: 2 MOTOR: 55 HEATING CAPACITY: 33.5KW ROBOT : ERC 23/1F SCREW DRIVE: HYDRAULIC
B&A REF: 9259 TON: 370 SCREW DIAMETER: 70MM SHOT WEIGHT: 1060 STROKE VOLUME: 1175CM3 INJECTION PRESSURE: 1700AR PLATEN SIZES: 1070 X 990MM DBTB: 710 X 630MM MIN MOULD HEIGHT: 300MM MAX MOULD HEIGHT: 750MM MOULD OPENING STROKE: 710MM MAX DAYLIGHT: 1460MM EJECTOR STROKE: 275MM CONTROLS: DIMI EL2 PLUS CORE PULLING: 2 AIR VALVES: 1 MOTOR: 37 HEATING CAPACITY: 27KW ROBOT INTERFACE: EUROMAP SCREW DRIVE: HYDRAULIC
B&A REF: 8838 TON: 820 SCREW DIAMETER: 93MM SHOT WEIGHT: 2555 STROKE VOLUME: 2777CM3 INJECTION PRESSURE: 1478AR PLATEN SIZES: 1730 X 1560MM DBTB: 1250 X 1060MM MIN MOULD HEIGHT: 350MM MAX MOULD HEIGHT: 1100MM MOULD OPENING STROKE: 1150MM MAX DAYLIGHT: 2250MM EJECTOR STROKE: 350MM CONTROLS: SEF 2000 CORE PULLING: 3 AIR VALVES: 2 MOTOR: 93 HEATING CAPACITY: 41KW ROBOT INTERFACE: EUROMAP SCREW DRIVE: HYDRAULIC
B&A REF: 9350 TON: 180 SCREW DIAMETER: 45MM SHOT WEIGHT: 329 STROKE VOLUME: 358CM3 INJECTION PRESSURE: 2116AR PLATEN SIZES: 810 X 805MM DBTB: 570 X 520MM MIN MOULD HEIGHT: 325MM MOULD OPENING STROKE: 650MM MAX DAYLIGHT: 975MM EJECTOR STROKE: 200MM CONTROLS: UNILOG B6S CORE PULLING: 1 AIR VALVES: 1 MOTOR: 30 ROBOT : WITTMANN BRIMUS 16 SERVO SCREW DRIVE: HYDRAULIC
used
B&A REF: 9356 TON: 120 SCREW DIAMETER: 35MM SHOT WEIGHT: 160 STROKE VOLUME: 192CM3 INJECTION PRESSURE: 2600AR PLATEN SIZES: 680 X 650MM DBTB: 450 X 400MM MIN MOULD HEIGHT: 150MM MAX MOULD HEIGHT: 500MM MOULD OPENING STROKE: 410MM MAX DAYLIGHT: 910MM EJECTOR STROKE: 135MM CONTROLS: DIMI EL2 PLUS AIR VALVES: 1 HEATING CAPACITY: 7.5KW SCREW DRIVE: ELECTRIC
B&A REF: 9323 TON: 100 SCREW DIAMETER: 35MM SHOT WEIGHT: 140 STROKE VOLUME: 153CM3 INJECTION PRESSURE: 2057AR PLATEN SIZES: 620 X 620MM DBTB: 420 X 420MM MIN MOULD HEIGHT: 250MM MOULD OPENING STROKE: 475MM MAX DAYLIGHT: 725MM EJECTOR STROKE: 150MM CONTROLS: UNILOG TC 40 CORE PULLING: 1 AIR VALVES: 1 MOTOR: 20 HEATING CAPACITY: 8.9KW SCREW DRIVE: HYDRAULIC
used
B&A REF: 9355 TON: 65 SCREW DIAMETER: 32MM SHOT WEIGHT: 113 STROKE VOLUME: 124CM3 INJECTION PRESSURE: 1700AR PLATEN SIZES: 610 X 540MM DBTB: 380 X 330MM MAX MOULD HEIGHT: 250MM MOULD OPENING STROKE: 425MM MAX DAYLIGHT: 625MM EJECTOR STROKE: 100MM CONTROLS: ORION AIR VALVES: 1 MOTOR: 17 HEATING CAPACITY: 6KW SCREW DRIVE: HYDRAULIC
Screw diameter; 75 mm Injectable volume: 1988 cm3 Injection pressure: 2121 bar Column passage: 1100 x 1100 mm Minimum mould thickness: 450 mm max: 1200 mm Opening stroke: 1200 mm Cores: 4 Heated Zones: 16 Robot interface :E67
Screw diameter; 150 mm Injectable volume: 12720cm3 Injection pressure: 1400 bar Column passage: H1300 x W1520 mm Minimum mould thickness: 600 mm max: 1600 mm Opening stroke: 3100 mm Cores: 4 Robot interface: E67 Options: Electric metering motor 4 cores 2 blow guns
Clamping force: 110 t (1100 kN) Year of Make: 2017 Operating hours: approx. 21,600 h Injection unit 1: 290 (horizontal), screw 35 mm, displacement 144 cm3, injection weight 132 g hp, injection pressure 2000 bar Injection Unit 2: 100 (vertical, injection into the parting plane) Control: Selogica direct with 15" touchscreen Clearance spar spacing: 470 x 470 mm Tool installation height: min. 350 mm Opening travel: 450 mm Ejector travel: 150 mm Total connection: 86.5 kW, 400 V / 50 Hz Equipment: - So far only ABS and PP processed - Hydraulic accumulator technology (pressure accumulator 100 l), injection when tool is closed - Hydraulic rotary unit control + 3 core pull controls - Hydraulic ejector, blow-out unit - 6 heating control loops for tool/hot runner - Cooling water distribution with 6 circuits - 100 mm spar extension, machine increased by 100 mm - KUKA KR6 robot (handling via Selogi ...
Wittmann Battenfeld HM 180/350H/350V ServoPower, year 2015 2-component injection moulding machine with vertical secondary unit and rotary table, ServoPower drive. Clamping force: 180 t Injection unit: 350 / 350 (aggregate A horizontal, aggregate B vertical) Screw diameter: 30 / 35 mm Spec. Spray pressure: 2,835 / 2,083 bar Spray volume: 123 / 168 cc L/D Ratio: 22 Lights spar spacing: 570 x 520 mm Tool installation height: 325 mm Ejector force: 41.2 kN Ejector travel: 200 mm Rotary table Control: UNILOG B6S Operating hours: 16,967 h, Number of shots automatic: 6,043,139 Oil filling: 400 l, cooling water: 320 l/h, sound level: 72 dB(A) Weight: approx. 11,200 kg Dimensions LxWxH: approx. 5.0 x 1.75 x 2.14 m Price on request.
Wittmann Battenfeld EcoPower 180/350/130, built in 2018 All-electric 2-component injection moulding machine with vertical second unit and turntable. Clamping force: 180 t Injection unit: 350 / 130 (aggregate A horizontal, aggregate B vertical) Screw diameter: 35 / 25 mm Spec. Spray pressure: 2,083 / 2,218 bar Injection volume: 168 / 61.4 cc L/D Ratio: 22 Size of the clamping plates: 810 x 805 mm Lights spar spacing: 570 x 520 mm Tool installation height: 225 mm (increased installation height EBH +300) Ejector force: 40 kN Rotary table: Ø 750 mm Control: UNILOG B6P, Ready for QuickLook app Operating hours: 12,869 h, Number of shots automatic: 5,409,083 Protective enclosure Dimensions LxWxH: approx. 5.5 x 2.6 x 2.4 m Price on request.
ARBURG Allrounder 220 S 150-30, built in 2001 Equipment / Condition: - Selogica control system with CF card reader - Clamping force 150 kN, injection unit 30, screw 18 mm (screw/barrel tested) - Operating hours according to control: approx. 48,000 h (pump) / approx. 43,000 h (automatic) - Very compact machine, footprint approx. 2.1 x 0.8 m - ideal for small parts - From a mold making pilot plant (sampling and 0 series), little used in recent years - Without peripherals (dryer and hopper available on request) - Inspection in operation possible - Location Southern Germany, price on request
Battenfeld HM 300/2250 Injection Molding Machine Clamping force: 300 t Year of Make: 2009 Injection unit: .../2250 Screw diameter: 65 mm Spec. Spray pressure: 2070 bar Injection volume: 1078 ccm Injection weight in hp: 981 g L/D Screw Ratio: 22 Clamping unit: 300/... Size of the clamping plates: 1030 x 1020 mm Lights spar spacing: 710 x 710 mm Tool installation height: 225 mm Max. plate spacing: 1125 mm Ejector force: 59 kN Ejector travel: 200 mm Weight: approx. 14600 kg Control: UNILOG B6S Equipment: wear and corrosion resistant plasticizing unit (PP/PPSU), high-temperature heating belt up to 450 C, 4 x hydraulic core pull (EUROMAP 13), parallel ejection via additional DFEE pump, 2 x pneumatic valve, robot interface EUROMAP 67
Specification Injection Molding Machine Demag Systec Servo 420/820-2300 General data Clamping force: 420 t Year of Make: 2015 Control: NC5 Total connected load: 78 kW Weight: 21,000 kg Dimensions (L x W x H): 8.02 x 2.21 x 2.57 m Clamping unit Size of the clamping plates: 1200 x 1200 mm Clearance spar spacing: 820 x 820 mm Tool installation height: 380 - 825 mm Opening travel: 770 mm Max. plate spacing: 1595 mm Ejector force: 96 kN Ejector travel: 230 mm Injection Unit 2300 Screw diameter: 70 mm Spray volume: 1212 ccm Injection weight in hp: 1,100 g Spec. Spray pressure: 1877 bar L/D Screw Ratio: 20 Hydr. Drive power: 51 kW Cylinder heating capacity: 27 kW Facilities Hydraulic core pull: 4 (+ 2 additional connections on the hard drive) Hydraulic cascades: 4 Hot runner control points (zones): 40 Servo-hydraulic pump drive activeDrive (energy-saving) In ...
Specification Injection Moulding Machine Demag Ergotech 650/1000-3300 General data Clamping force: 650 t Year of Make: 2005 Control: NC4 Clamping unit Size of the clamping plates: 1450 x 1350 mm Clearance spar spacing: 1000 x 900 mm Tool installation height: 450 - 950 mm Opening travel: 930 mm Max. plate spacing: 1880 mm Ejector force: 96 kN Ejector travel: 300 mm Injection Unit 3300 Screw diameter: 80 mm Injection volume: 1779 ccm Injection weight in hp: 1600 g Spec. Spray pressure: 1855 bar L/D Screw Ratio: 20 Facilities Hydraulic core pull: 4 Hydraulic cascades: 8 Hot runner control points (zones): 16 Robot Wittmann W 843 Pro, built in 2021 (Z 3,000 / Y 2,000 / X 1,200 mm, C-axis servo 180°, B-axis servo 270°) included in the scope of delivery
Specification Injection Moulding Machine Demag System 1300/1500-11500 General data Clamping force: 1300 t Year of Make: 2008 Control: NC4 Total connected load: 189 kW Weight: 86,700 kg Dimensions (L x W x H): 8.09 x 3.41 x 2.99 m + 6.25 x 2.58 x 2.99 m Clamping unit Size of the clamping plates: 2150 x 1880 mm Lights spar spacing: 1500 x 1250 mm Tool installation height: 700 - 1400 mm Opening travel: 1500 mm Max. panel spacing: 2900 mm Ejector force: 233 kN Ejector travel: 350 mm Injection Unit 11500 Screw diameter: 110 mm Spray volume: 5797 cc Injection weight in hp: 5200 g Spec. Spray pressure: 1971 bar L/D Screw Ratio: 24 Hydr. Drive power: 110 kW Cylinder heating capacity: 79.1 kW Facilities Hydraulic core pull: 4 Hydraulic cascades: 12 Hot runner control points (zones): 32 Robot Wittmann DR 853, built in 2014 (Z 3,500 / Y 2,500 / X 1,600 mm, C-axis ...
B&A REF: 9330 TON: 1600 SCREW DIAMETER: 175MM SHOT WEIGHT: 16042 STROKE VOLUME: 17438CM3 INJECTION PRESSURE: 1843AR PLATEN SIZES: 2250 X 2100MM DBTB: 1850 X 1400MM MIN MOULD HEIGHT: 700MM MAX MOULD HEIGHT: 1600MM MOULD OPENING STROKE: 2700MM MAX DAYLIGHT: 3400MM EJECTOR STROKE: 350MM CONTROLS: MC5 CORE PULLING: 4 AIR VALVES: 2 MOTOR: 200 HEATING CAPACITY: 191KW ROBOT: KRAUSS BEAM SERVO SCREW DRIVE: ELECTRIC
Specification Injection Molding Machine Demag Systec 210/580-840 (Servo) General data Clamping force: 210 t Year of Make: 2019 Control: NC5 / MC5 Clamping unit Size of the clamping plates: 860 x 860 mm Lights spar spacing: 580 x 580 mm Opening travel: 790 mm Ejector travel: 180 mm Injection unit Screw diameter: 60 mm Injection volume: 636 cc Injection weight in hp: 579 g Spec. Spray pressure: 1352 bar L/D Screw Ratio: 20 Facilities Pump drive power: 26.0 kW Servo motor drive Bimetal, wear-resistant screw Flexible clamping unit with multiple ejector and core movements Ejector with position control Injection with control pump (p+v-controlled, closed loop) Pressure return system (RSP), 3-part Reinforced oil cooling system (supply up to 35 °C) Location: Aachen, Germany
Specification Injection Molding Machine Ferromatik Milacron Magna T150 General data Clamping force: 150 t Year of Make: 2016 Clamping unit Clearance spar spacing: 510 x 510 mm Max. plate spacing: 950 mm Injection unit: 630 Screw diameter: 45 mm Location: Aachen, Germany
Screw diameter: 50 mm Injectable volume: 422 cm3 Passage between columns: 560 x 510 Moulded thickness: minimum: 200mm- max: 600 mm Opening stroke: 600 mm
Screw diameter: 65 mm Injectable volume: 1138 cm3 Column passage: 710 x 630 mm Moulded thickness: minimum: 250 mm- maximum: 750mm Opening stroke: 750 mm Robot interface: E67 Blow Guns
Screw diameter: 70 mm Injectable volume: 1077 cm3 Injection pressure: 2423 bar Passage between columns: 720 x 720 Moulded thickness: minimum: 450mm- max: 750 Opening stroke: 700 mm Number Of Cores :2
Screw diameter: 110 mm Injectable volume: 4847cm3 Injection pressure: 1892 bar Column passage: 1270 x 1100 mm Moulded thickness: minimum: 500mm- max: 1200 mm Number Of Cores :4 Robot interface: E67 Servo motor
Screw diameter: 55 mm double thread Injectable volume: 582 cm3 Injection pressure: 2200 Column passage: 780 x 780 mm Moulded thickness: minimum: 760mm- maximum: 1190 mm Opening stroke: 760 mm Number Of Cores :2 Robot interface: E67 36 heated zones
Screw diameter: 90 mm Injectable volume: 2862 cm3 Injection Pressure: 1472 Column passage: 1100 x 1100 mm Moulded thickness: minimum: 450mm- max: 1200 Opening stroke: 1200 mm Number Of Cores :0 Robot interface: E12 28 heated zones
Screw diameter: 75 mm Injectable volume: 1657 cm3 Injection pressure: 2121 bar Column passage: 820 x 820 mm Moulded thickness: minimum: 300mm- max: 850 mm Opening stroke: 950 mm Number Of Cores :3 Robot interface: E12
1.500 €
