JONWAI ASTRON180SD-II Injection molding machines

Spain2003ID 168431378

Spain2003ID 168431378

usedVerified seller
Request price Directly to the seller
JONWAI ASTRON180SD-II Injection molding machines
1 / 8

Technical data

· ID 168431378
Source: seller information

Injection molding machines

Condition
used
Year of manufacture
2003
Location
08784 Piera

Identifikation

ManufacturerJONWAI
ModelASTRON180SD-II
Item numberPFP-2

Technik

Quantity1
Technical parameter 11800kN

Description

Clamping force: 180 t; 4-column toggle system; tie-bar spacing: 480×480 mm; platen size: 720×720 mm; mold height: 150–550 mm; opening stroke: 396 mm; ejector stroke: 130 mm; screw diameter: 60 mm (to be confirmed); injection volume: 678 cm³; 4 heating zones; power supply: 3×380 V–50 Hz; installed power: 45.3 kW; machine dimensions: 5950×1400×1920 mm; weight: 6700 kg; Machine No.: ED1020.
