Manufacturer:
(Category: 301)
Key data: 3200 kN
Arburg 1500T 3200-1300 e² / Hybrid machine with a turntable Year of Make: 2011 Injection unit: Screw diameter: 60 mm Injection weight: 607 g Spray pressure: 2000 bar Dosing volume: 664 ccm Clamping unit: Clamping force: 320 t Spar spacing: 0x0 mm Size of the clamping plates: 1510 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Hybrid machine: high-speed, energy-saving and very quiet Operating hours: approx. 30,000 in automatic mode Euromap 67 Robot interface Control with air valve Hydraulic core pull x 3 Control with hot runners x 13 Hardened injection unit - Bimetal Main motor of the machine – servo motor driven by inverter Very precise rotary table, driven by a servo motor, controlled by an inverter Rotary table diameter: 1500 mm Horizontal injection unit with automatic injection height adjustment ...
Key data: 2500 kN
Arburg 630S 2500-1300 ECO / Production line with the Sepro Industrial Robot SDR 22S Year of Make: 2008 Injection unit: Screw diameter: 55 mm Injection weight: 521 g Spray pressure: 2380 bar Dosing volume: 570 ccm Clamping unit: Clamping force: 250 t Tiebar spacing: 630x630 mm Size of the clamping plates: 900x900 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: Euromap 67 Robot interface Air Valve x 4 Hydraulic core pull x 2 Control with hot runners x 15 Hardened injection unit - Bimetal Machine with cylinder / battery with compressed nitrogen (extra charge for fast working) ECO – the machine has a system for adjusting the minimum tool height Robot - Sepro Industrial Robot SDR 22S Year of Make: 2016 4-axis robot: 3 axes are driven by servo motors (electric); Axis C - pneumatic Traversing in axes: X-150 ...
Key data: 2200 kN
Arburg 570S 2200-290/100/100 / Production line with the Wittmann W823 robot / Operating hours: 20,499 h in automatic mode Year of Make: 2016 Injection unit: Screw diameter: 35 mm Injection weight: 132 g Spray pressure: 2000 bar Dosing volume: 144 ccm Clamping unit: Clamping force: 220 t Handlebar spacing: 570x570 mm Size of the clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 3-component injection moulding machine, high-speed Very good technical condition Operating hours: 20,499 h in automatic mode Euromap 67 Robot interface Air Valve x 6 Hydraulic, needle-core pull, controlled by a proportional valve x 4 Control with hot runners Hardened injection unit - Bimetal Proportional valve on the injection unit – precise injection Machine with two cylinders / battery with compressed ni ...
Key data: 2000 kN
Arburg 570C 2000-350/150 / Production line with the Arburg Multilift side robot / 2K machine Year of Make: 2003 Injection unit: Screw diameter: 40 mm Injection weight: 153 g Spray pressure: 2120 bar Dosing volume: 182 ccm Clamping unit: Clamping force: 200 t Handlebar spacing: 570x570 mm Size of the clamping plates: 795x795 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA Additional equipment: Production line with the Arburg Multilift side robot 2K Machine Air Valve x 1 Hydraulic core pull x 5 Control with hot runners Reinforced Injection Units – Bimetal Proportional valves on sprinkler units - precise spraying The vertical injection unit - screw diameter: ⌀25 mm - 49 g/hp All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine o ...
Key data: 1600 kN
Arburg 520S 1600-400/170 e² / Production line with the Geiger robot Year of Make: 2012 Injection unit: Screw diameter: 35 mm Injection weight: 141 g Spray pressure: 2500 bar Dosing volume: 154 ccm Clamping unit: Clamping force: 160 t Tiebar spacing: 520x520 mm Size of the clamping plates: 695x695 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 2K injection moulding machine with rotary table and robot Geiger Very good technical condition Hybrid machine: energy-saving and very quiet Euromap 67 Robot interface Air Valve x 4 Hydraulic core pull x 5 Control with hot runners x 12 Reinforced Injection Units – Bimetal Machine with two cylinders / batteries with compressed nitrogen (extra charge for fast work) The machine has a servo motor built into the injection unit, which is responsible for dosing the pla ...
Key data: 1600 kN
Arburg 520S 1600-290/100 / Production line with the Wittmann W823 robot / Operating hours: 20,181 h in automatic mode Year of manufacture: 09.2011 Injection unit: Screw diameter: 35 mm Injection weight: 132 g Spray pressure: 2000 bar Dosing volume: 144 ccm Clamping unit: Clamping force: 160 t Tiebar spacing: 520x520 mm Size of the clamping plates: 695x695 mm Ejector: hydraulic Clamping unit: hydraulic Control: SELOGICA - Touchscreen Additional equipment: 2K Injection Molding Machine with Turntable and Robot Very good technical condition Operating hours: 20,181 h in automatic mode Total number of operating hours: 28,473 h Euromap 67 Robot interface Air Valve x 3 Hydraulic, needle-core pull, controlled by a proportional valve x 2 Reinforced Injection Units – Bimetal Proportional valves on sprinkler units - precise spraying Machine with two cylinders / bat ...
Key data: 1500 kN
Arburg 520H 1500-290 e² / Hybrid machine / Production line with the Wittmann W818 side robot / Operating hours: 21,588 h in automatic mode Year of manufacture: 05.2016 Injection unit: Screw diameter: 30 mm Injection weight: 97 g Spray pressure: 2500 bar Dosing volume: 106 ccm Clamping unit: Clamping force: 150 t Tiebar spacing: 520x520 mm Size of the clamping plates: 695x695 mm Ejector: electric Clamping unit: toggle lever Control: SELOGICA - Touchscreen Additional equipment: Machine in very good technical condition Hybrid machine: high-speed, energy-saving and very quiet Operating hours: 21,588 h in automatic mode Euromap 67 Robot interface Air Valve x 5 Core train control Air Core Pull x 3 Hardened injection unit - Bimetal Main motor of the machine - Servo motor driven by inverter - Energy saving The injection unit is driven by the servo motor, which ...
Key data: 1500 kN
Arburg 520H 1500-800 e² / Hybrid machine / Production line with the Arburg Multilift H side robot Injection unit: Screw diameter: 55 mm Injection weight: 434 g Spray pressure: 1650 bar Dosing volume: 474 ccm Clamping unit: Clamping force: 150 t Tiebar spacing: 520x520 mm Size of the clamping plates: 695x695 mm Ejector: electric Clamping unit: toggle lever Control: SELOGICA - Touchscreen Additional equipment: Hybrid machine: high-speed, energy-saving and very quiet Euromap 67 Robot interface Control with air valve Hydraulic core pull x 1 Control with hot runners x 12 Hardened injection unit - Bimetal Main motor of the machine - Servo motor driven by inverter - Energy saving The injection unit is driven by the servo motor, which is controlled by an inverter Machine with cylinder / battery with compressed nitrogen (extra charge for fast working) Central lubric ...
Key data: 1500 kN
Arburg 520H 1500-800 e² / Hybrid machine / Production line with the Arburg Multilift H side robot Year of manufacture: 04.2012 Injection unit: Screw diameter: 55 mm Injection weight: 434 g Spray pressure: 1650 bar Dosing volume: 474 ccm Clamping unit: Clamping force: 150 t Tiebar spacing: 520x520 mm Size of the clamping plates: 695x695 mm Ejector: electric Clamping unit: toggle lever Control: SELOGICA - Touchscreen Additional equipment: Hybrid machine: high-speed, energy-saving and very quiet Control with air valve Core train control Control with hot runners x 12 Hardened injection unit - Bimetal Main motor of the machine - Servo motor driven by inverter - Energy saving The injection unit is driven by the servo motor, which is controlled by an inverter Machine with cylinder / battery with compressed nitrogen (extra charge for fast working) Central lubricatio ...
Screw diameter: 93 mm Injectable volume / Shot volume: 3138 cm3 Injection pressure : 1912 bar Column passage / Bettween tie bar: 950 x 850 mm Mold Thickness /Tickness tie bar: 300-1000 mm Opening stroke: 930 mm Ejection stroke: 350 mm 2 cores / 2 corepulling 2 blow guns / 2 air valves Robot interface
Key data: 700 , 1670 , 110
Screw diameter: 110 mm Injectable volume / Shot volume: 4750 cm3 Injectable weight / Shot weight: 4320 g Injection pressure: 1670 bar Column passage / Bettween tie bar: 900 x 1000 mm Mold Thickness /Tickness tie bar: 400-1000 mm Opening stroke: 1000 mm Ejection stroke: 350 mm 4 corepulling 4 blow guns / 4 air valves Electrical screw motor
Hydraulic injection moulding machine manufactured in 2009. This Arburg Allrounder 520 A 1500-70 Alldrive features a clamping force of 1,500 kN and a maximum injection pressure of 2,500 Bar. It has a screw diameter of 15/18 mm and accommodates molds with a maximum height of 550 mm. If you are looking to get high-quality injection moulding capabilities, consider the Arburg Allrounder 520 A 1500-70 Alldrive machine we have for sale. Contact us for further details.
Electrical injection moulding machine manufactured in 2022. This HAITIAN Mars III MA 600/130B eco features a clamping force of 600 kN and a maximum injection pressure of 1,840 Bar. It has a screw diameter of 28 mm and accommodates molds with a maximum height of 330 mm. If you are looking to get high-quality injection moulding capabilities, consider the HAITIAN Mars III MA 600/130B eco machine we have for sale. Contact us for further details.
closing pressure:6600 kNweight of the machine ca.:45,5 t
Key data: 3200 kN, 70 mm
NEGRI BOSSI V320/2000 - 320T Year: 2000 Working Hours: 85,000 h Screw diameter: 70mm Injection capacity per cycle: 1035g Opening stroke: 630mm Mold thickness (min x max): 250mm x 700mm Distance between tie bars (H x V): 630mm x 570mm Ejector stroke: 225mm 1 hydraulic core pull 1 air valve
Key data: 1600 kN, 45 mm
NEGRI BOSSI V160/610 - 160T Year: 2001 Working Hours: 72,500 hrs Screw diameter: 45mm Injection capacity per cycle: 360g Opening stroke: 460mm Mold thickness (min x max): 170mm x 550mm Distance between tie bars (H x V): 510mm x 450mm Ejector stroke: 200mm 1 hydraulic core pull 2 air valves
Key data: 550 kN, 28 mm
NEGRI BOSSI V55-200 - 55T Year: 1998 Working Hours: 51,000 hrs Screw diameter: 28mm Injection capacity per cycle: 84g Opening stroke: 255mm Mold thickness (min x max): 120mm x 350mm Distance between tie bars (H x V): 315mm x 280mm Ejector stroke: 75mm 1 hydraulic core pull 2 air valves
Clamping force: 6500kN, locking force: 7150kN, max. opening stroke: 930mm, mold height: 360-920mm, max. distance between mold mounting platens: 1850mm, mold mounting platens: 1350x1350mm, clear tie-bar spacing: 900x900mm, max. mold weight: 8.6t, max. weight on moving mold mounting platen: 5.7t, screw diameter: 110mm, L/D ratio: 17.2, injection pressure: 1270bar, shot volume: 3570cm³, shot weight (PS): 3180g, max. metering stroke: 375mm, max. nozzle stroke: 850mm, nozzle immersion depth (SVO): 70mm, nozzle contact force: 200kN, installed barrel heating capacity: 52kW, hopper capacity: 110l, the machine screw is defective. With documentation. An on-site inspection is possible.
Max. locking force: 3500kN, clear tie-bar spacing: 710x710mm, min. mold height: 380mm, max. opening stroke: 1300mm minus mold height, max. ejector stroke: 250mm, max. ejector force: 95kN, ejector retraction force: 48kN, rotary table diameter: 890mm, screw diameter K1: 60mm, K2: 35mm, nozzle radius: 15mm, max. injection pressure K1: 2000bar, K2: 2429bar, max. shot weight (PS) K1: 618g, K2: 142g, hot runner: external, core pull connection: DNP Flatface BG3 (large flat-face sealing), centering mandrel: AS + DS, weight: 16.37t, total operating hours: 74,276h, production hours: 66,341h, the second injection unit and the rotary table have not been used for five years, with documentation and linear handling system, regularly maintained in-house. An on-site inspection is possible, the machine is not connected to power.
Injection moulding machine Arburg 1500 T 2 K BJ 1999
Electrical injection moulding machine manufactured in 2005. This Husky Hylelectric H1000 RS95/80 features a clamping force of 10,000 kN and a maximum injection pressure of 2280 bar. It has a total platen size of 2070 x 1840 mm and a screw diameter of 80 mm. If you are looking to get high-quality injection moulding capabilities, consider the Husky Hylelectric H1000 RS95/80 machine we have for sale. Contact us for further details.
Electrical injection moulding machine manufactured in 2005. This Husky Hylelectric H1000 RS95/80 features a clamping force of 10,000 kN and a total platen size of 2070 x 1840 mm. It has a maximum injection pressure of 2280 bar and a screw diameter of 80 mm. If you are looking to get high-quality injection moulding capabilities, consider the Husky Hylelectric H1000 RS95/80 machine we have for sale. Contact us for further details.
For sale is an ENGEL Victory 330/80 Tech tie-bar-less injection moulding machine including 3-axis handling and conveyor belt. The machine was in ongoing production use until the CPU/controller failed and worked smoothly until then. Currently, the machine is not ready for operation due to a defect in the controller. The installed KEBA Kemro K2-200 CP 251/Z PLC/CPU controller is currently not booting and displays error message 8. Repair services and replacement devices are offered on the market for this CPU type. We did not carry out any further fault diagnosis or repair. Technical data / equipment: Manufacturer: ENGEL Model: Victory 330/80 Tech Year of Make: 2007 Tie-bar-less design Clamping force: 800 kN / 80 t Injection volume: 154 cm³ Injection pressure: 1,600 bar Mold opening stroke: 456 mm Ejector stroke: 100 mm Machine weight: approx. 5,300 kg 3-axis removal handling incl ...
Clamping force: 800kN, tie-bar spacing: 400mm, injection unit: 430, max. flow rate: 76l/min, max. hydraulic pressure: 210bar, control: CDIAS, weight: 3.6t, an on-site inspection is possible.
Clamping force: 1250kN, tie-bar spacing: 475x450mm, injection unit: 440, max. flow rate: 100l/min, max. hydraulic pressure: 190bar, weight: 6.6t, an on-site inspection is possible.
Clamping force: 1600kN, width: 1600mm, height: 2200mm, weight: 6.8t, an on-site inspection is possible.
Clamping force: 650kN, length: 4000mm, width: 1600mm, height: 2200mm, weight: 3.9t, an on-site inspection is possible.
Clamping force: 1500kN, rated current: 133A, connected load: 74kW, an on-site inspection is possible.
6.950 €
