A package of Wohlhaupter inserts is sold here. ! MINT CONDITION One package is sold here = 5x packs = 46 pieces --> Brand Wohlhaupter, Indexable Inserts 097264 CM3 --> Type: F05 HC-P25/M15/K15 R0.5 Auction-ID: A1-48479-26012
Coromant Capto - CoroChuck 970 ISO: 970-C8-40-161 Product data: - Tapping range, max. - M30 - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Fastening type cutting insert - S: clamp with screw through hole - Axial runout adjustment - ER collet (DIN6499-B) for tapping -ER40 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 80 bar - Mounting diameter - 80 mm - Holder diameter, workpiece side - 40.8 mm - Functional diameter - 40 - 55 mm - Function length - 143.7 mm - Body diameter length 1 (LB1) - 125.1 mm - Length body diameter 1 (LB2) - 155.1 mm - Speed, max. (-81, -82: Maximum speed) - 8,000 1/min - Mass (weight) - 3,448 kg per piece Auction-ID: A1-48479-24087
Tool holder: TYPE: MONOFORCE DIN69871-AD+B40 MF32.95 including 7 collets: --> 32-6 --> 32-8 --> 32-10 --> 32-12 --> 32-16 --> 32-20 --> 32-25 These chucks are intended for high-speed machining. These are precision tools from the Italian company D ́Andrea Auction-ID: A1-48483-109
Adapter Coromant Capto - Weldon ISO: C8-391.20-50 120 Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Axial run adjustment - Weldon -metric - 50 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 20 bar - Functional diameter - 55 mm - Mounting diameter - 80 mm - Mounting diameter, workpiece side - 50 mm - Angular position mounting, workpiece side - 0 deg - Clamping length - 84 mm - Functional length - 120 mm - Body diameter - 84 mm - Length body diameter - 8 mm - Speed, max. (-81, -82: Maximum speed) - 14,000 rpm - Torque - 12 Nm - Tool design - steel - Mass (weight) - 5,686 kg per piece Auction-ID: A1-48479-24131
Adapter Coromant Capto - CoroTurn SL ISO: C8-570-40-RF Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Axial running adjustment - SL (screw mounted) -angled -size 40 - Maximum cantilever length - 50 mm - Cutting direction - R - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 70 bar - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 40 mm - Cantilever length - 70.3 mm - Functional length - 50 mm - Functional width - 41 mm - Torque - 17 Nm - Tool design - steel - Mass (weight) - 2,131 kg per piece Auction-ID: A1-48479-24121
A package of indexable inserts LMT Fette is sold here. ! MINT CONDITION One package is sold here = 14x packs = 138 pieces --> Brand LMT Greases, Indexable Inserts --> LMT code SNKX 1205 AN-TR - 1052248 (LC240T) Auction-ID: A1-48479-26017
\"Tailstock Bison Type 5819-170-200\" Tailstock Bison Type 5819, with adjustable tip height - Suitable for use with bison dividing heads and rotary tables - Precise adjustment of the height from 170-200 mm possible Auction-ID: A1-48483-30
Adapter Coromant Capto - ISO 9766 ISO: C8-391.27-40 095 Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Axial Run Adjustment - Weldon -metric - 32 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 20 bar - Functional diameter - 55 mm - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 40 mm - Angular position mounting, workpiece side - 0 deg - Clamping length - 71.5 mm - Function length - 95 mm - Body diameter - 65 mm - Body diameter length - 62.8 mm - Speed, max. (-81, -82: Maximum speed) - 14,000 rpm - Torque - 40 Nm - Tool design - steel - Mass (weight) - 2,649 kg per piece Auction-ID: A1-48479-24113
Changing gear set according to pictures Interchangeable wheels - number of teeth: Z 20 / 30 / 30 / 35 /40 / 40 / 40 / 45 / 45 / 50 / 50 / 50 / 50 / 55 / 60 / 60 / 60 / 65 / 65 / 70 R / 70 R / 70 / 75 / 75 / 80 / 80 Auction-ID: A1-48483-61
Adapter Coromant Capto - CoroTurn SL ISO: C8-570-2C 50 125-40L Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Axial Run Adjustment - 40 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 70 bar - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 40 mm - Function length - 81 mm - Body diameter - 40 mm - Length body diameter - 81 mm - Torque - 17 Nm - Tool design - steel - Mass (weight) - 2.17 kg per piece Auction-ID: A1-48479-24116
Interchangeable Wheel Set for Rice Cutter UL 1800, , in wooden box Auction-ID: A1-48483-7
for workpiece clamping on lathes, grinding machines and dividing heads with High concentricity and holding force - for workpiece clamping (bar or chuck work) in conventional single-spindle lathes and CNC lathes directly in of the spindle or in the collet chuck - smooth bores are mainly drilled in the sub-spindle of the CNC lathes used - Ø 2 - 2.5 mm 1 PC - Ø 5 - 6 mm 1 PC - Ø 3 - 4 mm 1 PC - Ø 4 mm 2 PCS - Ø 13 mm 1 PC - Ø mm various Auction-ID: A1-48483-25
Clamping Bracket 1 piece LBH: 300x405x225 mm Auction-ID: A1-48483-41
Adapter Coromant Capto - Weldon ISO: C8-391.27-20 080 Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Axial clamping - Cylindrical clamping (ISO9766 drill shank) -metric: 20 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 20 bar - Functional diameter - 55 mm - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 20 mm - Angular position mounting, workpiece side - 0 deg - Clamping length - 51.5 mm - Functional length - 80 mm - Body diameter - 36 mm - Body diameter length - 43.8 mm - Speed, max. (-81, -82: Maximum speed) - 14,000 rpm - Torque - 12 Nm - Tool design - steel - Mass (weight) - 2,247 kg per piece Auction-ID: A1-48479-24110
! MINT CONDITION One package is sold here = 5x packs of 10 pieces each --> Brand Wohlhaupter, Indexable Inserts 097263 CM3 --> Type: F04 HC-P25/M15/K15 R0.5 Auction-ID: A1-48479-26010
ISO: C8-CPA-01 Product data: - Dimensions (WxDxH) - 135x95x95 mm - Tool design - steel - Mass (weight) - 1,379 kg per piece Auction-ID: A1-48479-24129
Multi Quick MQ 130 Set - (Art.-No. 130-167-2022 - Clamping force 35 kN) This infinitely adjustable clamping element is characterized by 3-fold clamping shoe and integrated bearing plate, thanks to large horizontal and vertical adjustability. The area of application is the light machining technology, due to the aluminum Tension shoe. --> large clamping force --> small starting torque --> dual stepless adjustment range --> Great adjustability due to integrated bearing plate --> high instep heights due to multiple tension shoe -> total price - 8 pieces Auction-ID: A1-48483-95
A package of Wohlhaupter inserts is sold here. ! MINT CONDITION One package is sold here = 3x packs = 30 pieces --> Wohlhaupter brand, inserts 097243 WHC10 --> Type: F103 HC-P30/K10 R0.4 Auction-ID: A1-48479-26013
Adapter Coromant Capto - CoroTurn SL ISO: C8-570-2C 60 150-40R Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 40 mm - Functional length - 150 mm - Body diameter - 60 mm - Body diameter length - 93 mm - Tool design - steel - Mass (weight) - 4.30 kg per piece Auction-ID: A1-48479-24119
Adapter Coromant Capto - Cylindrical Shank ISO: C8-131-00110-40 Product data: - Adapter interface machine direction -Coromant Capto (segment clampingonly) -size C8 - Axial clamping adjustment - Cylindrical clamping w/ flats (sleeve) -metric: 40 - Maximum cantilever length - 110 mm - Cutting direction - N - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 80 bar - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 40 mm - Clamping length 102 mm - Function length - 110 mm - Functional width - 0 mm - Functional height - 0 mm - Body diameter - 80 mm - Tool design - steel - Mass (weight) - 2.91 kg per piece Auction-ID: A1-48479-24089
Wooden box with a variety of metal parts. Among them are: -> precision steel blocks — cleanly ground, right-angled blocks with Drilling. They are usually used as stops, spacers, clamping aids or Measuring aids. -> angle and V-blocks — the large, angular parts with oblique recesses. They are used to clamp round or irregular workpieces safely. -> Clamping plates/perforated strips — long metal strips with many even grooves Drilling. Typical for flexible devices where different parts. -> Small square blocks with a central hole — presumably spacers, Centering aids or modular components for fixtures. Sorting boxes — contain screws, small parts or other clamping components. Complete Package Price Auction-ID: A1-48483-79
For sale are Bilz thread quick-change inserts manufacturer Bilz, in different sizes. The inserts are suitable for quick-change tapping chucks. Manufacturer: Bilz Type: WES Sizes: various versions (e.g. WES 2B 12×9 and others) Quantity: 2 boxes of 6 pieces each ? a total of 12 operations Box 1. - 1x BILZ WES 2 - 1x BILZ WES 2 B M9 - 3x BILZ WES 2 B M18 14x11 - 1x BILZ WESN 2 B 11x9 Box 2. - 1x BILZ WES 2 B 9x7 M12 - 1x BILZ WES 2 B 14x11 M18 - 1x BILZ WES 2 W 18x14.5 M24 - 1x BILZ WES 2 B 12x9 M 16 - 1x BILZ WES 2 M9 - 1x BILZ WES 2 W 18x14.5 M22 Condition: used, in good condition (functional) Ideal for use in metalworking and tapping technology. 2 original boxes of Bilz WES inserts, each box 6 pieces -> as a package Auction-ID: A1-48483-130
3-jaw feeder, incl. chip jaws Diameter Ø125mm Inner diameter 32mm Height 55mm Auction-ID: A1-48483-83
Adapter Coromant Capto - Weldon ISO: C8-391.20-06 070 Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Flat run adjustment - Weldon -metric - 6 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 1: axial concentric exit - Coolant pressure - 20 bar - Functional diameter - 55 mm - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 25 mm - Angular position mounting, workpiece side - 0 deg - Clamping length - 36 mm - Function length - 70 mm - Body diameter - 17 mm - Length of body diameter - 4 mm - Speed, max. (-81, -82: Maximum speed) - 14,000 rpm - Tool design - steel - Mass (weight) - 2,113 kg per piece Auction-ID: A1-48479-24104
Coromant Capto on cutter mandrel mount ISO: C8-391.05C-22 030M Product data: - Adapter interface machine direction -Coromant Capto (bolt and segmentclamping) -size C8 - Axial Run Adjustment - Arbor -ISO 6462 -A/B (center bolt/washer) -metric: 22 - Code for coolant supply - 3: axial concentric and radial entry - Coolant leakage - 4: axial concentric on circle - Coolant pressure - 80 bar - Functional diameter - 55 mm - Mounting diameter - 80 mm - Pick-up diameter, workpiece side - 22 mm - Angular position mounting, workpiece side - 0 deg - Function length - 30 mm - Body diameter - 80 mm - Body diameter length - 30 mm - Torque - 45 Nm - Speed, max. (-81, -82: Maximum speed) - 14,000 rpm - Tool design - steel - Mass (weight) - 1.86 kg per piece Auction-ID: A1-48479-24095
A package of indexable inserts LMT Fette is sold here. ! MINT CONDITION One package is sold here = 5x packs = 43 pieces --> Brand LMT Greases, Indexable Inserts --> LMT code APKT 1604 - 1067507 (LC240T) Auction-ID: A1-48479-26016
Changing gear set according to pictures Interchangeable wheels - number of teeth: Z 23 / 24 / 25 / 26 / 27 / 33 / 38 / 40 / 43 / 46 / 47 / 49 / 50 / 53 / 54 / 55 / 58 / 59 / 63 / 66 / 77 / 78 / 84 R / 90 / 95 / 96 / 100 / 102 / 104 / 108 / 110 / 112 / 116 / 124 / 128 Auction-ID: A1-48483-59
Various (HSS/KHSS) milling cutters are sold here from Sandvik Coromant as a package price. Auction-ID: A1-48479-24262
175 €
