Key data: 46 mm, 3250 mm
Year of construction 2014 Single-channel charging magazine with Vulkollan channel Remnant output into the machine room Servo drive Glass wrapping and axial displacement 1 guide channel set Vulkollan up to max. LW 46 mm incl. material slider with high-performance oil flow PLC control, integrated terminal with touch screen Manually adjustable material separation Loading area: 3250 x 370 mm Good condition
diameter: 3 - 16 mmlength: 3000 mm= bar loading magazinfor bar-ø 3 - 16 mm, bar length 3000 mm, capacity for example 23 bars 8 mmøThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
previously attached to Gildemeister TWIN 102 max. bar length 3,300 mm Material Slide Length XLL max. slide outlet 1,670 mm (with shortest intermediate tube) incl. guide channels Ø 46 + 66 mm
: ATR 3030 Hawker Life-Plus TC3-LP-10KW Smart Charger for Forklift Batteries 24The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Manufacturer: Sameca Type : MUZ.6.6 Year of construction 1996
bar material dia.: 5 - 65 mmBar length: 3000 mmfeed length: max. 3000 mmvoltage: 400 Vweight of the machine ca.: 1,2 tdimensions of the machine ca.: 5,32 x 0,95 x 1,52 mserial-no.: 32 - 201 588Loading magazine with lower storage areafrom which the bars are lifted into theFeed tube can be liftedRod diameter 5 - 65 mmFeed force infinitely variable max. 550NInsertion speed 335 mm/secfeed speed 335 mm/secReturn speed 335 mm/secLoading time for 3000 mm bars: 30 sec.The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
- For connection to multi-spindle automatic lathes - Stocking: Area magazine 4x 450 mm edition - Rod Ø: 4-52 mm (depending on the guide channel) - Ø guide channel: 44 mm - Rod length: approx. 3000-4200 mm - Dimensions LxWxH: 4600 x 750 x 1300 mm - Weight: approx. 850 kg
Was fitted on a Gildemeister Sprint 65
workpiece length - max.: 3000 mmfeed length: - mmlength: - mmpower capacity: 2 kWWeight: 1300 kgWith control panel HBG 10A guide channel, size of approx. 60 mm diameterThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
bar material dia.: max. 85 mmbar length: 3000 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Spindle circle 165 mm Interface Gildemeister GM 16 AC
diameter: 15 mmlength: 800 mm= bar loading and de-loading magazinefor bars up to 15 mmø, bar length 800 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
for material Ã?: 6-80 mm for rod lengths: 100-915 mm Recording size: 945 x 800 mm Working height: 1400 mm height adjustment: +/-200 mm Electr. Connection: 220 V Space requirements: 3420 x 1150 x 1500 mm Weight: 300 kg
