DUAL SHAFT SHREDDER for 6 T/h mixed plastics – NEW MACHINE Loading hopper and sturdy steel supporting structure Shredding chamber: 1.500 x 1.100 mm. N. 2×1.500 mm long shafts Speed: 13/17 rpm N.30 knives 50 mm thick, 1 hook (can be customized) Oil lubrication N.2 hydraulic motors x 75 kw 400 lt oil tank N.1 out-line filtering system 2,2 kw Pressure control 3 level temperature control Cycle inverting system N.2 oil cooling vents x 0,195 kw throughput estimate:
DUAL SHAFT SHREDDER HYDRAULIC constructed in sturdy steel incuding structure and loading hopper. shearing surface: 1300 x 1100 mm. rotational speed : 13/17 rpm knives : 13 knives thickess mm.:100 Hooks : 2 hydraulic motors: 2x75 kw planetary gearboxes : 2 Linde oleodynamic pumps: 2 constant power regulators: 2 HPV 165 external cooling auxiliary circuit : 40.000 Kcal/h oil/water cooling vents : 2 oil tank : 1000 lt pressure controls :2 minimum oil level control clogged filters control control system : PLC touch screen automatic shaft inversion for overload weight : about 14 Ton
DUAL SHAFT SHREDDER MORANDO T15-150B new feeding hopper shredding chamber 1.500x1.000 mm. shredding block made with 4-hook and 1-hook knives 55 mm.thick in forged and hardened steel n.2 epicyclic gearboxes, n.2 oleodynamic motors 1x75 kw + 37 kw, n.2 Bosch rexroth pumps, hydraulic power station with 4 m.piping,the 2 pumps have just been replaced new electric cabinet user's manual electric drawing weight of machine 10.000 kg.
SHREDDER VECOPLAN VAZ 200 – TOTALLY RECONDITIONED sturdy heavy duty steel structure V rotor 2.000 mm wide, 500 mm diam., 145 rpm n.62 blades size 60×60 mm 110 KW / 400 V /50 Hz 3PH motor new gearbox hydraulic pushing unit hydraulic power station loading hopper with level sensor fitted with 30 mm hole grid electric cabinet Dimensions : LxWxH 4.640 x 3.690 x 2.375 mm Total weight about 16 Ton Constructed in 2005 The machine is offered totally reconditioned including extraction belt lined in PVC size 700 mm W x 7.000 mm.long 1.680 mm (adjustable) discharging height CE mark, Declaration of conformity, user’s manual and electric drawings Average throughput 1.500/2.500 kg/h depending on materials inspection possible in 11020 ISSOGNE Italy
DUAL SHAFT SHREDDER PYTHON SH13 Made in sturdy steel Feeding hopper Oleodynamic power station with pipings (5 m.) Electric panel Shredding block made with 1-hook and 3-hook knives 30 to 35 mm thick Electric power 55 Kw ( 80 Hp) Speed 21/11 Shredding chamber mm.1300×1050 User’s manual Electric drawings Machine is offered reconditioned
FORREC SINGLE SHAFT SHREDDER sturdy supporting structure loading hopper Rotor length: .2000 mm Rotor diameter Ø: 750 mm 1.490 rpm (50 Hz) 315 kW hydrauilic drive hydraulic pack about 11.000 worked hours construction year: 2016 Applications: PLASTICS, MSW, bulky waste,and more. Rotor speed: 180 rpm (50 Hz) N.54 Rotating knives knives size: 80 x 80 x 30 mm N.4+2 Still knives Manual, drawings, etc.available Offered either AS IS, WHERE IS or RECONDITIONED
engine output: kWFeeding opening: mmginding chamber dimensions: mm--------------------------------------------------: DIMENSIONS / WEIGHTS: - space requirements -left/right-: 1200 mm- space requirements -front/back-: 1200 mm- total height: 2200 mmShreds large, bulky shaped parts made of polystyreneand polyurethane with ease to chips orcoarse grainsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: Breite/Länge mmMotor output: 22 kW: - m³Dimensions (L/W/H): 1405x1250x1970 mmWeight: 1300 kg4-shaft shredder Gross type GZ 30Feed opening: 1,250 x 1,000 mmCutting opening: 562 x 462 mmTotal number of waves: 4 piecesof which cutting shafts: 2 pcsof which clearing waves: 2 pcsSpeed of the waves: 25 rpmScreen perforation: 20 mmThroughput: 300-800 kg / hMotor power: 2 x 11.0 kWOverall dimensions: L / W / H 1,405 x 1,250 x 1,970 mmWeight: approx. 1,300 kgIncl.:-Star-Dreiek startup-CE Compliant-GS mark dust-tested(Techn.According to the manufacturer - without guarantee!)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
: 600 x 800 mmMotor output: 18,5 kW: 0,6 m³Diameter of the motor: 252 mmDimensions (L/W/H): 1800x1230x1640 mmWeight: 1300 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
High-performance choppers for branches up to a diameter of 220 mm. The machine is suitable for chopping large quantities. 2 adjustable knives Power/hour: 14-18 m3 Opening: 230 mm Weight: 1100 kg Dimensions: 2500 x 4300 mm
We offer complete recondioned Scania engines in exchange
SHREDDER / double rotor Crusher with low speed (very little in use!) Capacity 100 m3/hEingabeoeffnung 1820 x 2500 mmRotoren 2 St D = 630 mm (with interchangeable tool) rotation speed 30 rpmMotor 2 St. 90 kWEingabetasche of the crusher is with hydraulic door (manual) and a bypass inclination. Frequency converter 2 StueckRAUMASTER two-shaft shredders are especially robust machines with a capacity up to 100 t/h. A homogeneous shredding material is produced by the interaction of the two rotors with the common counter knife and the strainer or optional sieve rust. The two-shaft shredders are built as a first or secondary shredder and are suitable for use in the field of wood as well as household and commercial waste.
Small shredder for various tasks such as old cables, plastics wood, etc. With hydraulic, electronically controlled feed. Drive 18.5 + 2.2 kW (rotor + feed). Rotor shaft with connectors for connecting a cooling device (e.g. when used for NYM old cables. The machine is 1 year old and little used from our demo machine inventory. The machine is offered with a one-year used machine warranty.
We offer our 12 month old demo scissors from the demonstration pool. The scissors were used exclusively by us and only for a few works. Therefore, the scissors are in very good technical condition. The scissors have a charger, two batteries and standard knives. Other knife designs, such as cable knives, can also be added.
Double shaft shredder with low hours working Capacity 100 m3/h Feed-in 1820 x 2500 mm Rotors 2 unit. D = 630 mm (with interchangeable tools) rotational speed 30 rpm Motor 2 units a 90 kW frequency transmitter 2 Stueck Input pocket of the crusher is equipped with hydraulic door (manual) and a bypass slope. RAUMASTER double-shaft shredders are built for extreme-duty, delivering throughputs of up to 100 to/h. Unlike old-style dual-shaft shredders, the two cutting rotors on RAUMASTERS dual-shaft shredders are spaced apart from each other and cut against a fixed counter knife positioned in the bed of the cutting chamber and inbetween the two rotors. The interaction between the rotors and the counter knife, combined with the bar screens produces a homogeneous, consistently sized particle output; very well
Technical data cutting unit: Cutting chamber (mm): 500 x 380 Drive (kW): 7.5 400 V Throughput/h: 50 - 250 kg depending on the material Weight (kg): 750 kg 1 set of spare knives and scrapers incl. Incl. control cabinet and filling hopper
Untha 4-shaft crusher RS 30 4S, power 22 kW, year 1996, engine hours 4529 h Technical data: Manufacturer Untha Type RS 30 4S Built in 1996 Engine hours 4529 h Engine 22 kW Drive: Belt drive Cutting unit opening 450 x 600 mm Number of waves 4 Speed main shafts 23 Speed side shafts 34 Hole sieve diameter 30 mm Throughput up to 1 t/h Machine weight approx. 2000 kg Please note: All technical data refer to information provided by the manufacturer. We assume no liability for the information provided or any errors. The offer is subject to change, interim sale reserved and can be revoked at any time. Visits are possible by appointment. The sale against advance payment takes place ex works, without guarantee and guarantee. Any disassembly, transport and/or loading costs may not be included.
Cutting width: 9 mm Year of production: 2002 Productivity: app 35-40 sheet (DIN A4, 70g/m²) Price: to inquiry Security level: P1 Supply: 380 V/2,2 kW The machine is fully operational and after service. Englisch - Ewelina Pekala +48 696 072 985 Deutsch - Ewelina Pekala +48 696 072 985 Polnisch – Ryszard £uba +48 501 330 786
