used Flat Grinding Machines for sale

Description: - machine no.: 4977 - operating voltage: 400 V - connected load: 5,57 kW - magnet dimensions: 450 x 250 mm - grinding disc diameter: approx. 200 mm - table dimensions: 850 x 250 mmweight approx.: 1,500 kg, dimensions (l x w x h) approx.: 2,300 x 1,500 x 1,800 mm

Gr. Grinding length: 620 mm gr. Grinding width: 250 mm table size: 200 x 620 mm grinding wheel dimensions: 200 x 220 x 51 mm Electr. Supply: 380 V, 1/1.8 kW space: 1650 x 1450 x 1800 mm weight: 1350 kg

aba FF 625 Surface grinding machine ABA Precision Surface Grinding Machine FF600/25 Grinding length 600mm Scrap width 250mm Electric Magnet 600x250mm Workpiece height 400mm Diamond puller Height adjustment digital Motor 3,27 KW 400 V 50 HZ Coolant device Grinding wheels and flanges Weight: approx. 1350 kg G&-5020-M1768

grinding length: 600 mmgrinding width: 500 mmworkpiece height: 500 mmtable-size: 800x400 mmtable speeds: 1-35 m/mingrinding wheel diameter: 400 mmspindle drive: 11 kWweight of the machine ca.: 4.5 tSURFACE % PROFILE GRINDING MACHINEmagnetic plate 600x300mmDresser on tableExhausting deviceMore details on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Accessories: Various flanges and grinding wheels Table 1000 x 300 mm Workspace: X way 1200 mm Y-way 400 mm Z-way 350 mm

VERTICAL - FLAT GRINDING MACHINE ATHENA TN - 175 - 14-10-067 Shipping time: immediately Number: 14-10-067 Manufacturer: Athena Type: TN - 175 MACHINE DATA Year: circa 1975 L x W x h: approx. 1000 x 1000 x 1800 mm Weight: approx. 700 kg Good general condition TECHNICAL DATA Control: conventional Loop scope: Grinding range: approx. 300 x 180 mm Grinding height: approx. 220 mm Magnetic clamping surface: approx. 250 x 150 mm Grinding spindle: Grinding wheel dimensions: approx. Ã? 175 x 76 x 76 mm Grinding spindle - speed: approx. 2820 U/min Power: approx. 2.5 kW Z - delivery: manual Grinding movement: manual ACCESSORIES â?¢ Segment grinding wheel flange â?¢ Splash - housing â?¢ Grinding wheels - protection â?¢ Coolant system â?¢ Chuck key â?¢ Permanent ma ...

Bammesberger flat grinding machine with suction - Travel distance: - X: 400 mm - Y: 200 mm - Z: 200 mm - Height: 150 cm - Width: 110 cm - Depth: 85 cm - Weight: 380 kg Good condition fully functional can be visited and tried out on site. Shipping also abroad. Sightseeing: Basically, I would like to point out that the article, in order to avoid misunderstandings, can be viewed before the purchase and tested under electricity. Please ask questions before buying to avoid ambiguity. For general questions or an appointment for a viewing, I can be reached at any time at the telephone number below or above. Errors in the description and prior sale excepted. VAT will be shown separately on my invoices. Shipping with freight forwarder.

Description: table clamping surface: 760 x 200 mm largest grinding length: 500 mm largest grinding width: 230 mm maximum distance between table and grinding spindle centre: 520 mm Longitudinal table movement: hydraulic, infinitely variable: 0.5 - 30 m / min. Handwheel, 1 turn moves the table by: 80 mm Table transverse movement: automatic, infinitely variable: 0.1 - 16 mm / table stroke Handwheel, with adjustable scale ring and vernier, graduation: 0.1 mm with fine adjustment: 0.001 mm Quick adjustment by electric motor: rapid traverse Grinding head height adjustment Handwheel, graduation: 0.01 mm adjustable from: 0.001 - 0.01 mm Fine adjustment microtip: 0.001 - 0.02 or 0.002 - 0.04 mm Quick adjustment by electric motor: rapid traverse grinding wheel: revolutions: infinitely variable in 2 steps Grinding wheel diameter: normal: 225 mm Grinding wheel width: normal: 25 mm Grinding wheel bor ...

grinding length: 600 mmgrinding width: 400 mmweight of the machine ca.: 5 t: ca. 3200 x 3230 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 900 mmgrinding width: 400 mmworkpiece height: 350 mmtable surface area: 1330 x 300 mmmagnetic plate size: 1000 x 230 mmgrinding wheel speed: 2800 U/min.max. dia. of grinding wheel: 300 mmmax. width of grinding wheel: 80 mmtotal power requirement: 6,0 kWweight of the machine ca.: 3,4 tdimensions of the machine ca.: 2,3 x 1,5 x 2,1 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Clamping surface of the table 1,880 x 500 mm, largest grinding length 1,200 mm, largest grinding width 550 mm, largest distance between table and spindle centre 775 mm, transverse movement of the table 500 mm, longitudinal movement of the table 1,400 mm, standard size of the magnetic plate (not included) 1. 200 x 500 mm, grinding wheel speed 1,400 rpm, grinding wheel diam. 220 - 400 mm, grinding wheel width 80 - 100 mm, grinding wheel bore diam. 127 mm, table height above floor 1,075 mm, power 11 kW, incl. grinding wheelsweight approx.: 7,000 kg, dimensions (l x w x h) approx.: 4,100 x 2,000 x 2,250 mm

grinding length: 1.200 mmgrinding width: 600 mmworkpiece height: 550 mmcontrol: Ergomatic BlohmGrinding spindle:: max. spindle speed: 1.450 1/mindriving power - grinding spindle: 7,5 kWgrinding wheel diam. min/max.: 190 / 400 mmgrinding wheel wide min./max.: 30 / 80 mmgrinding wheel width: (Standard) 50 mmgrinding wheel hole diameter: 127 mmmovement areas:: x-travel: 1.300 mmy-travel: 550 mmz-travel: 560 mmwork table:: distance grinding spindle - table min./max.: 150 / 700 mmtable surface area: 1.200 x 600 mmtable height over floor: 950 mmtable adjustment - longitudinal: 1.300 mmmax. table load: 800 kgfeeds:: feed speeds: X: 30 - 30.000 mm/minfeed speeds: Y: 4 - 3.750 mm/minfeed speeds: Z: 4 - 4.000 mm/mintotal power requirement: - kWweight of the machine ca.: 5,4 tdimensions of the machine ca.: 5,8 x 4,5 x 2,5 mGrinding Wheel Holders: 1 x grinding wheel: 2 x Magnet clamping plate:  ...

table surface area: 900 x 300 mmgrinding length: max. 500 mmgrinding width: max. 350 mmthroat: 575 mmx-axis: 300 mmy-axis: 570 mmcross feed autom.: 2 . . . 65 mm/Hubtable speeds: 2 . . . 30 m/mingrinding wheel speeds: 1400 / 2800 U/mingrinding wheel diameter: 150 - 300 mmgrinding wheel width: 50 mmgrinding wheel hole diameter: 76 mmtable height over floor: 1000 mmdimensions of the machine ca.: 2200 x 1500 mmbase area: 1000 x 1025 mmWeight: ca.1800 kgtotal power requirement: 6,5 kWuser manual availableThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 700 mmgrinding width: 550 mmworkpiece height: 340 mmtable surface area: 1320 x 500 mmmax. distance betw. table and middle of spindle: 500 mmdistance grinding wheel - table: ca. 350 mmtable speeds: 2-30 m/minvertical stroke: autom. 2-65 mm/Hubtable height over floor: 1000 mmgrinding wheel size: 300 x 80 x 76 mmgrinding spindle speed: 1400 / 2800 U/mingrinding spindle capacity: 5,5 kWweight of the machine ca.: 3,9 tdimensions of the machine ca.: 3,5 x 2,1 x 2 mCondition: good, machine ready for operation: Electric 380 Volt: Electromagnetic-stretch plate: 700 x 500 x 110 mmCooling unit: Autom. adjustment vertical: Finimatic Hydr. Surface grinding machine with autom. FINIMATIC infeed.Machine dealer with own stock of 2500 m².The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 650 mmgrinding width: 350 mmworkpiece height: 500 mmMagnetic field: 600x300 mmtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

magnetic plate size: 700x300 mm, grinding wheel width x diameter: 300 mm, weight approx.: 3,000 kg, dimensions (l x w x h) approx.: 2,100 x 1,700 x 1,900 mm

Description: - Operating voltage: 220/380 V - Frequency: 50 Hz - Magnet dimensions: 800 x 400 mm - Table dimensions: approx. 1300 x 400 mm - grinding wheel diameter: approx. 350 mm - the machine is equipped with a belt filter, a cooling unit as well as various grinding wheels and a balancing scaleweight approx.: 2,500 kg, dimensions (l x w x h) approx.: 2,700 x 1,550 x 2,000 mm

Description: Working table size: 146 x 460 mm Max. grinding length - longitudinal: 457 mm Max. grinding width - crosswise: 152 mm Distance from table to centre of grinding wheel: 450 mm Logitudinal axis Max. manual feed: 482 mm Transverse axis Max. manual feed 180 mm Manual feed per revolution 3 mm Manual feed per revolution - 0.01 mm graduation Vertical axis Manual rotation - 2 mm revolution Manual rotation - 0.01 mm graduation Grinding wheel Speed 60 Hz - 3.450 rpm Power 1.5 kW Diameter 203 mm Width 12.7 mm Bore 31.75 mm Serial Number: FA3128997control: MITUTOYO KAcounter, weight approx.: 500 kg, dimensions (l x w x h) approx.: 1,118 x 874 x 1,930 mm

Precision flat grinding machine Manufacturer: COSMOS Model: Earth 1050 NC Built: New factory Grinding length: 1000 mm Grinding width: 500 mm Grinding height: 400 mm Electric magnetic release plate 1000 x 500 mm Single fitters at the table firmly assembled for straight judting with compensation Programble display 4.7 " Unseated grinding spindle drive Universal paper tape filter

Description: Workspace Distance between uprights 1500mm Distance crossbeam-table 800mm max. grinding height 700mm table max. table load 6000kg Table setup area, supports 3000 x 1200mm Longitudinal path complete 3150mm T-slots number/width 5/18mm Feed 1-40m/min Tangential wheelhead Grinding wheel dimensions 500x100x203.2mm Speed ​​of the grinding wheel, stepless 1100-2000min Grinding wheel drive power 22kW ways Cross travel 1900mm max. programmable feed 800mm/min minimum programmable increment 0.001mm rotation Head turning range +/- 110° Minimum rotation +/- 2.5° Head rotation speed 180°/min Positioning accuracy +/-2' engines Table drive 10kW Table lubrication 0.37kW Grinding wheel drive horizontal 18Nm Vertical grinding wheel drive 10Nm Grinding wheel drive rotation 6Nm Lubrication of the guideways 0.75kWgrinding length: 3,150 mm, grinding width: 1,500 mm, grinding height: 70 ...

Ref. -No.: 10233Brand: DISKUSYear of construction: 1973Type of control: KonventionellControl: N/aStorage location: Mülheim an der RuhrCountry of origin: DeutschlandSerial no.: 6984 Weight Of The Machine Ca.: 3 tFurther information:Discuss - surface grinding machine

with granite bed, BJ. 1987, with dressing apparatus, coolant system. Grinding area 650 x 375 x 375 mm SchleifscheibenmaÃ?e 300 x 50 mm Table stroke length 850 mm Table load: 320 kg Table feed 1-30 m / min. Electro magnetic Chuck 650 x 350 mm Power 9 kW total Weight 4 t

Stock number 1105-02617 Machine type flat grinding machine Make Elf Type OPTIMALLY 4250 NC-K Built in 1993 Control type NC Storage warehouse Country of origin Germany Delivery time immediately Exhibition Hall, ver free freight basis Technical details Grinding length 450 mm Grinding width 250 mm Workpiece height 375 mm Table length 800 mm Table width 250 mm maximum work-piece weight 400 kg Autom. Cross feed adjustable 3-50 mm / stroke Vertical delivery, 1 Division 0.001 - 0.06 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel diameter 36 mm Voltage 380 V Grinding spindle motor 3.7 / 4.7 kW Total power demand 9 kW Machine weight approx. 2.6 t Space requirement of approx. 2800 X 2500 2300 mm Additional information automatic delivery -Electro magnetic clamping plate with straight fine pole pitch, dimens ...

Grinding length: 500 mm Grinding width: 350 mm Grinding height: 450 / 510 mm Grinding wheel: 300 x 50 x 76 mm

Grinding length: 500 mm Grinding width: 350 mm Grinding height: 450 / 510 mm Grinding wheel: 300 x 50 x 76 mm Accesories

Description: - machine no.: 82700669 - magnet dimensions: 500 x 350 mm - grinding disc diameter: approx. 250 mmweight approx.: 1,000 kg, dimensions (l x w x h) approx.: 1,900 x 1,800 x 2,000 mm

Gr. Grinding length: 600 mm gr. Grinding width: 350 mm table - longitudinal movement: 35-600 mm grinding wheel dimensions: 300 x 50 x 76 mm wheel speeds: 1440 / 2890 RPM elect. Supply: 380 V, 5/6 kW space: 1950 x 1650 x 2200 mm weight: approx. 2500 kg

Surface grinding machine - ELB SW 624 VAI Table dimension approx. 915x255mm Caoybweooi Grinding length approx. 600mm Grinding width approx. 310mm Grinding height approx. 400mm Grinding wheel speed approx. 1300/2600 rpm Weight approx. 3200 Kg

Surface grinding machine in very good condition Manufacturer Elb Type SW3 HA Specifications Table clamping surface: 400 x 150 mm Magnetic clamping plate 300 x 150 mm Grinding length: 300 mm Grinding width: 150 mm Maximum distance from table to spindle center: 450 mm Table speed longitudinal: 7.5 / 15 m / min. Aut. Transverse feed with continuous rapid traverse: 150 mm Aut. Transverse feed infinitely variable: 0.1 – 150 mm / stroke Hand – fine adjustment = 0.005 mm vertical Grinding spindle – speeds: 2,800 rpm gr. Grinding wheels – Ø : 200 mm gr. grinding wheel width: 30 mm Drive power: 2.5 kW Weight: approx. 1,000 kg Floor space: W 1.10 x D 1.10 x H 2.00 m Machine paint in original paint RAL 6011

grinding length: 600 x 500 mmgrinding width: 550 mmworkpiece height: mmControl: total power requirement: kWweight of the machine ca.: 5,5 tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 3.000 mmgrinding width: 900 mmturning speed range - grinding wheel: 940 - 1.000 U/minsurface area: 3.000 x 750 mmtable load: 3.000 kgspindle drive motor: 48 kWVertical - Surface Grinding Machine | ELB - SWDE 30 NC-Kwith cooling water systemAdditional equipment:+ Magnetic plate installed (on-top): 3000 x 900 mmThe grinding spindle was re-stored in 2008.The grinding spindle has a power of 48 KW, so it is a verypowerful machine.The machine is in good condition.A machine video from the production plant will be shared on request.Please refer to the offer for further technical details.- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -#Tags: SWDE30 | SWDE-30The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 450 mmgrinding width: 200 mmworkpiece height: 250 mmtable speeds: 0 - 60 mm / Hubdimensions of grinding wheel: 250 mmtable:: 600 x 200 mmturning speeds: 2.600 U/minengine output: 4,0 kWweight: 1500 kg from a maintenance workshop - good condition ()Furnishing:- Magnetic clamping plate 200 x 450 mm- electric / hydraulic table adjustment (X axis) The table runs on a flat and prismatic guideway Maximum limit of the table travel via two limit switches- electrical adjustment v. Grinding spindle head (Y axis)- manual / electrical adjustment v. Cross slide (Z axis)- Dressing device for grinding the grinding wheel- Machine bed made of micro-granite- The front and back stands are made in one piece- The hydraulic unit is used for lubrication- coolant device- separate control cabinet The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Travel X/Y/Z 540/525/230 mm Coolant reservoir Balancing mandrel Grinding wheel holders

Horizontal grinding optimum surface grinders ELB - 6375 ND - PLC Second-hand machine Surface grinders - horizontal ELB optimal 6375 ND - PLC Second-hand machine overhauled 2016 Surface grinders - horizontal ELB-SCHLIFF optimal 6375 ND - PLC Second-hand machine Grinding length: 600 mm Grinding width: 375 mm Workpiece height: 375 mm Table clamping surface: 600 x 350 mm Grinding wheel dimensions: 300 x 50 mm Grinding spindle motor: 4.7 kW Table speed: 2-30 m / min Grinding wheel speed: 1450 RPM Total power: 12kW Weight approximately: 3.5 t Space requirement approx.: 2.8 x 2.5 x 2.5 m Part overtaken 2016 + 12 months warranty, condition Control with touch screen new Paper machine Magnetic Chuck 600 x 350 Automatic table dressing with compensation 1 flange Items put up Installation / commissioning / transport

Surface grinders - horizontal ELB-SCHLIFF SWBE 10 PLC Second-hand machine Mint Control cabinet, motors, wiring, control new Hydraulic new, trim, loop length: 1000 mm Grinding width: 500 (600) mm Workpiece height: 600 mm Table size: 1000 x 550 mm Grinding wheel dimensions: 400 x 100 mm Grinding spindle motor: 11 kW Table speed: 2-30 m / min Grinding wheel speed: 5-35 m / sn Total power: 18 kW Machine weight approx.: 5,5 t Space requirement approx.: 3.5 x 2.5 x 2.5 m General outrun 2019 with 12 month warranty Paper machine Levelling feet Installation included Instruction includes

Used ELB precision surface grinding machine Perfect Future BD 10 CNC-UNICON F Grinding area: 1000 x 600 x 600 mm Grinding wheel: 400 x 100 x 127 mm Year of construction: 2004 Accessories: - electric straight dresser - Grinding spindle 20 KW 1500 - 4500 RPM - automatic cooling nozzle adjustment - Universal paper belt filter system with permanent magnetic filter as pre-filter - Linear glass scales for Y and Z axis - Grinding Wheel Holder - Cooling water cooling unit - Precision round tactical, clamping surface 500 mm - lower roll-in device - Magnetic clamping plate

Description: Magnetic plate: L: 400 mm x H: 160 mm grinding length: 450 mm Sanding width: 250 mm Longitudinal table movement: hydraulic, infinitely variable: 0 - 30 m/min. Handwheel, 1 revolution moves the table by: 100 mm Revolutions: 1,400 / 2,800 rpm.weight approx.: 800 kg, dimensions (l x w x h) approx.: 1,400 x 1,750 x 1,700 mm

Surface grinding machine ELB SWBE 07 NC-K 14-10-068 Delivery time: immediately Number: 14-10-068 Machine data Year of construction: ca. 1981 L x W x H: approx. 3800 x 2500 x 2500 mm Weight: approx. 4500 kg Very good general condition Specifications Grinding range: Grinding length: approx. 700 mm Grinding width: approx. 500 mm Grinding height: approx. 400 mm Magnetic clamping surface : approx. 700 x 500 mm Grinding spindle: Grinding wheel dimensions: approx. Ø 400 x 100 x 127 mm Accessories -Magnet -Wet grinding device -Operating instructions -Grinding wheels – protection -Grinding wheel -Various clamping wrenches Other accessories on request Price and other technical data on request

Gr. Grinding length: 700 mm gr. Grinding width: 550 mm table size: 450 x 1100 mm grinding wheel dimensions: 300 x 100 x 127 mm grinding wheel rpm: 1400/2800 RPM elect. Supply: 380 V, approx. 11 kVA kW

magnetic plate size: 450x150 mm, table surface area l x w : 1100x250 mm, grinding wheel turning speeds: 2,900 rpm, weight approx.: 250 kg, dimensions (l x w x h) approx.: 1,300 x 1,300 x 1,900 mm

grinding length: 1000 mmgrinding width: 500 mmworkpiece height: 550 mmtable surface area: 1000 x 400 mmtable speed -stepless-: 1 - 40 m/mintable load: max. 940 kggrinding wheel size: ø 406 x 50 mmgrinding wheel hole diameter: ø 127 mmgrinding wheel motor: 9 kWtotal power requirement: 15 kWweight of the machine ca.: 5,2 tdimensions of machine L x W x H: 3,8 x 1,9 x 2,6 mAccessories: magnetic plate 1000 x 400 mm, grinding wheel with flange, wheel trueing attachment, wet grinding attachment with paper band filtrationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

No. 2752: 1 gebr. Flat grinding machine Fabr. FAVRETTO, type MB 100, Bu. ELCON 3, 1990 ARB.-ber.: 1000 x 400 mm, Accessories: table size 1250 x 500 mm Wet grinding device with filter system Magnetic disk

grinding length: 400 mmgrinding width: ca. 200 mmworkpiece height: max. 300 mmmax. workpiece weight: 150 kgdistance spindle center to table: 415 mmmax. dia. of grinding wheel: 225 mmgrinding wheel hole diameter: 30 mmControl: Simatic OP27 SiemensGrinding spindle:: turning speed range - grinding spindle: 1.000 - 4.000 min/-1driving power - grinding spindle: 2,6 kWwork table:: magnetic clamping plate: 400 x 200 mmelectrode spacing: 18 mmtotal power requirement: 5,0 kWweight of the machine ca.: 2,2 tdimensions of the machine ca.: 4,0 x 4,0 x 3,0 mDocuments: Coolantsystem: paper band filter: Magnet clamping plate: elektr. hand wheel: Precision-Surface- and Profile-GrindingMachineGEIBEL & HOTZ - FS 415 Z SLThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 600 mmgrinding width: 400 mmControl: Digi magnetic clamping plate: 600 x 400 mmtable load: 0,4 tgrinding wheel size: 300 x 50 x 76 mmtotal power requirement: 11 kWweight of the machine ca.: 2,1 tdimensions of the machine ca.: 3.0 x 2.6 x 2.5 mFurnishing• Electromagnetic clamping plate (600 x 400 mm)4 mm pole pitch• Cooling device• Overhead dresser with compensationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 600 mmgrinding width: 450 mmweight of the machine ca.: 2,5 ttotal power requirement: kWdimensions of the machine ca.: mworkpiece height: mmautomatic infeedelectro magnet platemanual dressing devicepaper filtering deviceTechnische Daten / technical details:max. Schleiflänge / max. grinding length 600 mmmax. Schleifbreite / max. grinding width 450 mmMagnetspannplatte / magnet clamping plate 600 x 400 mmX-Achse, Tischlängshub / X-axis table longitudinal travel 650 mmTischgeschwindigkeit / table speed 2-28 m/minZ-Achse, Querweg / Z-axis cross travel 400 mmSchleifscheibenabmessungen / grinding wheel dimensions 300x50x76,2 mmGesamtanschlussleistung / hole drive capacity 11 kWGewicht ca. / weight ca. 2500 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and descr ...

grinding length: 600 mmgrinding width: 450 mmworkpiece height: mmweight of the machine ca.: 2,2 ttotal power requirement: kWdimensions of the machine ca.: mautomatic infeedelectro magnet platemanual dressing devicecoolant deviceTechnische Daten / technical details:max. Schleiflänge / max. grinding length 600 mmmax. Schleifbreite / max. grinding width 450 mmMagnetspannplatte / magnet clamping plate 600 x 400 mmX-Achse, Tischlängshub / X-axis table longitudinal travel 650 mmTischgeschwindigkeit / table speed 2-28 m/minZ-Achse, Querweg / Z-axis cross travel 400 mmSchleifscheibenabmessungen / grinding wheel dimensions 300x50x76,2 mmGesamtanschlussleistung / hole drive capacity 11 kWGewicht ca. / weight ca. 2200 kgTechnische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich -Technical data, accessories and description o ...

Grinding range: approx. 130 x 255 mm Grinding speed: 2800 rpm Table size: 150 x 300 mm Drive motor: 380 V, 1.5 kW Space requirement: 750 x 700 x 1700 mm Weight: approx. 380 kg Pot disc Ø: 180 mm

Grinding area: 100 x 360 or 150 x 190 mm Grinding speed: 2870 rpm Table size: 150 x 250 mm Drive motor: 380 V, 3.3 kW Space requirement: 670 x 400 x 1600 mm Weight: Pot discs: 180 mm

Description: - the machine was overhauled in 2013 - Grinding length in cross grinding: 6000 mm (In beam grinding: 6200 mm) - Grinding width: 400 mm - grinding height: 250 mm - designed for alternate grinding: 2500 - 1000 - 2500 mm - Grinding motor power (22/30 hp) 18.5/22 kW - grinding motor speed: 1000/1500 rpm - Segment head: 450 mm - Segment dimensions 12 pieces: 70/64 x 25 x 150 mm - Grinding head travel speed: 0.02 - 30 m/min - Rapid traverse speed support: 450 mm/min - Infeed steps: 0.003 - 0.2 mm - Magnetic Fixed Width: 400 mm - Grinding tolerance: +/- 0.005 mm/m - Equipped with vacuum clamping tableweight approx.: 4,500 kg, dimensions (l x w x h) approx.: 9,600 x 2,300 x 2,250 mm

4-axis CNC groove grinding machine, built in 1997, with robot, control Sinumerik 840 D, dressing wheel, 2 grinding spindles. Working range diameter 8-16.5 mm (restricted) Clamping length with robot / hand 80-140 / 250 mm Swirl direction right/left/straight Swirl angle 0-42° Grinding wheel diameter 200 mm grinding length 650 mm grinding width 325 mm Grinding diameter min./max. 100/250 mm Table clamping surface 1000x287 mm Spindle speeds from 2000-6000 rpm. Power 35 kW Weight approx. 2.5 t Accessories: Machine bed extended, probe, tailstock, NC sub-apparatus, diamond dressing disc.
