JUNG D22 / Internal Cylindrical Grinding Machine -Machine suitable for inner round + surface grinding -Smallest grindable bore 14mm -Largest grindable bore 150mm -Grinding length without face grinding device 250mm -Grinding length with face grinding device -6x workpiece speeds 46-270 rpm -Spindle box right/left swivel 30 degrees -Distance of the spindle axis over the center of the table 250mm -Largest workpiece spindle/grinding support distance 935mm -Spindle box / inclined position 30 degrees each -Work table / tilt forward/backward 5 degrees each -Hand/automatic operation -Taper grinding device -Bezel -Three-jaw chuck -Replacement grinding spindles
Inv. Num. : 6614 Type: - Producer: JUNG Generated: Parameters: Equipment: DRO In good technical condition.
Key data: 400 mm, 150 mm
Year of manufacture 1983 Grinding length 400 mm Grinding width 150 mm Installation height 400 mm Table load 75 kg All feeds are infinitely variable Drive power 1.5 kw Automatic delivery Magnetic Plate 400 x 150 mm Puller Wet grinding device Machine is in good condition
used
Grinding length: 600 mm Grinding width: 200 mm Clamping surface of the table: 600 x 200 mm Greatest distance between table and grinding spindle center: 500 mm Grinding wheel dimensions: 250 x 25 x 51 mm Table longitudinal feed hydraulically infinitely variable: 1 - 24 m/min Table transverse feed per hand rotation: 4 mm Grinding spindle speed infinitely variable via DC drive: 800 - 4200 rpm DC drive: 1.5 - 5.0 kW Net weight with control cabinet approx.: 2000 kg Approx. space requirement: 3100 x 1700 x 1900 mm
Inv. Num. : 4518 Type: JA 500 A Producer: JUNG Created: 1994 Parameters: Control system: Siemens Operating hours: 10662 h Maximum grinding height of the workpiece: 375 mm Maximum spindle speed: 4200 1/min Minimum travel speed longitudinally (X-axis): 24 m/min Maximum travel speed longitudinally (X-axis): 24 m/min Grinding wheel diameter new: 250 mm Spindle power: 7.5 kW Maximum grinding length without grinding wheel extension (X-axis): 600 mm Maximum sanding length: 200 mm Machine height: 1000 mm Machine length: 3700 mm Machine width: 2100 mm Machine weight: 2,500 kg
Surface Grinding Machine Manufacturer: Jung Type: JA 500 CNC-C Year of Make: 1995 Overhauled in: 2003 Grinding length: 500 mm Grinding width: 200 mm Max. workpiece height: 250 mm Table dimensions X/Y: 600 mm / 200 mm Grinding wheel diameter: 225 mm Grinding wheel width: 25 mm Grinding wheel bore: 51 mm Speed: 4,200 rpm Machine weight: approx. 2,500 kg
Make: YOUNG Type: JF 520 Year of construction 1992 Machine weight : 2200Kg Total weight: 2600kg Location : Haiger Price: 24.000 € excl. VAT. Description: Digital display, Fabr. Heidenhain, microprocessor control, profiling device, Fabr. Diaform, Machine Lighting, Coolant System, Sine Magnetic Clamping Table, Fabr. Jung, type SM 50 Specifications: Clamping surface (L x W in mm) 600 x 200 Grindable surface (L x W in mm) 600 x 250 Magnet size max. mm 600 x 200 Grinding wheel dimensions max. mm 225 x 25 x 51 Distance table/spindle center mm 350 (+50) Table longitudinal feed pendulum m/min 1 – 20 Creep gear mm/min 0 – 500 Grinding spindle drive speed rpm 800 – 4200 Power kW (w/creep gear) 2.2 (3.5)
Universal surface grinding machine of the Jung brand suitable for tooling, fixture construction, training and mould making Bssx7D8P Travel distances : 400 x 150mm Table size : 520x150mm Grinding length 400mm Grinding width 150mm Workpiece height 240mm Table size 520x200mm Connection 50Hz 380V Motor 4.5KW Machine weight approx. 2250kg Dimensions 2500x2100x1900mm
gr. grinding length: 300 mm large grinding width: 150 mm Table movement - longitudinal movement: 2 - 20 m/min Grinding wheel speeds: 3000 rpm electr. Power supply: 380 V, 1.1 kW Dimensions: 1500 x 1100 x 1750 mm Weight: 920 kg
Key data: 500 mm, 200 mm
Automatic grinding wheel feeding, automatic transverse adjustment, Table longitudinal movement hydraulically or manually, wet grinding device, electromagnetic clamping plate, Accessories Grinding length: 500 mm Grinding width: 200 mm max. workpiece height: 250 mm Speed 2800 rpm Clamping surface: 600 x 200 mm Total power requirement: 3.7 kW Machine weight approx.: 1,6 t Operating instructions with circuit diagrams Machine can be demonstrated
Used 4 flanges fit on a JUNG, HF 50 (R or RD) Scope according to pictures ! ( 4 flanges , . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ex-lights for painting rooms: used 45-degree luminaires, recessed wall lamps, room lamps. with 2 or 3 or 4 x 58 W fluorescent tubes, for installation in painting systems. Please ask.
Optical dividing head, precision dividing head -Max. tip height: 76 mm -Max. center distance: 200 mm -with collets: 3, 4, 5, 6, 7, 8, 9, 10, 16 mm -wooden box -Total weight per box: 42 kg Quantity: 1 piece available
Magnetic plate, magnetic table, sine table, sine plate, relief grinding device, grinding machine accessories -Design: Cutting tool mold making for conically ground cutting plates or mold inserts -Angle head for surface grinding machine or measuring machine -Magnetic plate -Angle: adjustable -Wooden box -Total weight with box: 35 kg
Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Max. shaft diameter: 320 mm -Max. grinding length: 345 mm -Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg -functionally tested
Machine spindle, precision spindle, double grinder spindle, precision spindle for belt drive, belt drive spindle -Manufacturer: Jung, machine spindle -Type: MP 5z -Speed: max rpm -Recording: Dimensions see photos -Dimensions total: 460/210/115 mm -Weight: 16.2 kg
Machine spindle, precision spindle, double grinder spindle, precision spindle for belt drive, belt drive spindle -Manufacturer: Jung, machine spindle -Type: MP 10z -Speed: max rpm -Recording: Dimensions see photos -Dimensions total: 545/210/120 mm -Weight: 23.5 kg
Surface grinding machine, grinding machine -hydraulic horizontal surface grinding machine -Magnetic plate: 300 x 150 mm -Grinding wheel motor: 1.1 kW 2800 rpm -Water cooling with: filter -Grinding disc diameter: 200 mm -Transport dimensions: 1470/1170/H1920 mm -Weight: 1090 kg
Grinding dimensions X/Y: 600mm/305mm, max. workpiece height: 350mm, feed rate X: 24m/min, feed rate Y/Z: 2m/min, machine dimensions X/Y/Z: approx. 3000mm/2700mm/2500mm, weight: approx. 3200kg, control: Siemens Sinumerik. The control has a circuit board defect. Documentation vorhanden. An inspection on site is possible.
CONTROLS electronic controls WORKING RANGE SURFACE GRINDING grinding length: 600 mm grinding width: 200 mm TABLE (SURFACE GRINDING) magnetic table: yes MAGNETIC TABLE length: 600 mm width: 200 mm weight: 100 kg SPINDLESTOCK GRINDING SPINDLE spindle revolutions (max): 4200 /min GRINDING TOOL type of grinding tool: wheel diameter (max): 250 mm borehole: diameter: 51 mm width: 25 mm ELECTRICAL SPECIFICATIONS total power consumption: 7.5 kW mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 3000 mm space requirements -front/back-: 2540 mm total height: 1850 mm total weight approx.: 2000 kg
grinding length: 600 mm grinding width: 200 mm workpiece height: 250 mm table surface area: 700 x 200 mm table load: 250 kg grinding wheel size: 200 x 16-25 / 51 mm grinding wheel speeds: 2800 U/min longitudinal feed of the table: 1 - 20 mm with vertical adjustment: 290 mm total power requirement: 1,5 kW weight: 1300 kg range L-W-H: 1,6 x 1,2 x 1,9 mm partly overhauled in 2022 - (Control panel still need to be electrically completed!) - magnetic clamping plate 510 x 200mm - autom. cross feed - Hydraulic table movement, infinitely variable - Manual fine adjustment (0,01 / 0,005mm) - Grinding wheel extractor - Central lubrication - VENTI Dust-Suction - 5 grinding wheels The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
centre height: 76 mm centre distance: 190 mm spindle bore: 21 mm taper MK: 3 weight of the machine ca.: 40 kg dimensions of the machine ca.: 720 x 210 x 215 mm collets: tailstock: dead centres: Barely used Jung optical dividing head with tailstock in a wooden box with 9 collets: 3, 4, 5, 6, 7, 8, 9, 10, 11 mm. Reduced special price. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
1 surface grinder, manufacturer Jung, type JF520, built in 1990, control unit, digital display for V/Y/Z, grinding wheel diameter approx. 250 mm, electromagnetic clamping plate, manufacturer SAV, approx. 150 x 600 mm, spindle speed approx. 4,200 rpm, separate control cabinet, cooling/lubricant treatment, belt filter, Find more here - / Contact us at -
grinding wheel dia. x width: ca. 200 x 25 mm magnetic clamping plate: ca. 450 x 170 mm cross feed of the table: 200 mm revolutions of grinding spindle: 3000 U/min grinding wheel hole diameter: 51 mm weight: ca. 1300 kg : 0,001 - 0,013 mm grinding length: 600 mm Surface grinding machine Includes extractor 1 additional grinding wheel holder Machine was in occasional use until recently The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
workpiece diameter: 300 mm workpiece weight: 999 kg workpiece height: 999 mm grinding length: mm grinding width: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Ausstattung: -Digitalanzeige senkrecht Achse -Automatische Zustellung -Automatische Endabschaltung programmierbar -Schleifspindelantrieb mit stufenloser, elektronischer Drehzahlregelung -stufenlos regelbarer Quervorschub, und Tischdrehung -24V Magnetspannplatte 300 mm -diverse Arbeitsschutzeinrichtungen z.B. Schutzhaubenüberwachung, Betriebszustandsanzeige per Ampel -Schmierölstandsüberwachung -die Maschine wurde 2015 generalüberholt, damals Austausch der gesamten Elektrik auf SPS-Steuerung und 24V Steuerspannung -Papierbandfilteranlage speziell für diese Maschine passend Folgende Arbeiten wurden nun noch durchgeführt: -Austausch Faltenbalg und Riemen -Schleifspindel neu gelager ...
workpiece diameter: 350 mm workpiece weight: 99999999 kg workpiece height: 240 mm Control: total power requirement: 7,5 kW weight of the machine ca.: 2 t dimensions of the machine ca.: m Seltene Gelegenheit: Teilüberholte Hochpräzisions-Rundtischflachschleifmaschine Mit komplett neuem Schaltschrank und neuer Steuerung mit BEMA Schleifsoftware Rundtisch-Durchmesser 380mm Magnet-Durchmesser 350mm Schleifscheibenabmaße 300x25x76,2mm Tischdrehzahl variabel max. 200U/min Schwenkwinkel des Tisches +-3 Grad Schleifspindeldrehzahl 800-4200 U/min Leistung Schleifspindelantrieb 5KW Verfahrweg quer max. 225mm Verfahrweg vertikal max. 480mm Abstand zwischen Magnetspannfutter und Spindelmitte, max. 390mm Automatischer Kopfabrichter AF65: zum zylidrischen Abrichten der Schleifscheibe im CD-Abrichtverfahren (Abrichten während de ...
grinding length: 500 mm grinding width: 200 mm workpiece height: 300 mm total power requirement: 3 kW weight of the machine ca.: 1,6 t dimensions of the machine ca.: 2,621,7 m Package 5 x JUNG HF 50 EXW near Frankfurt The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CONTROLS CNC controls SIEMENS SINUMERIK WORKING RANGE SURFACE GRINDING grinding length: 880 mm grinding width: 510 mm TABLE (SURFACE GRINDING) table surface (left-right): 800 mm table surface (front-back): 430 mm workpiece load (max): 800 kg MAGNETIC TABLE length: 800 mm width: 400 mm SPINDLESTOCK GRINDING SPINDLE spindle revolutions (min): 1500 /min spindle revolutions (max): 3500 /min GRINDING TOOL type of grinding tool: wheel diameter (min): 210 mm diameter (max): 400 mm borehole: diameter: 127 mm width: 100 mm ELECTRICAL SPECIFICATIONS mains power supply: 30 kVA DIMENSIONS / WEIGHTS space requirements -left/right-: 3150 mm space requirements -front/back-: 2350 mm & ...
A CNC surface grinding machine Jung, overhauled in 2003, is available. Grinding length: 500mm, grinding width: 200mm, max. workpiece height: 250mm, table dimensions X/Y: 600mm/200mm, grinding wheel dimensions X/Y/Z: 225mm/25mm/51mm, speed: 4200rpm, weight: approx. 2500kg, operating hours: approx. 16602h. Documentation available. An on-site inspection is possible.
