ELB ELB Super Rubin 020 VA II CNC surface grinder High-precision horizontal surface grinder, specialized for profile punches grinding. With 4 added digital axes CNC Control Wireless Handwheel Bluetooth control Magnetic Table 600 x 300 mm Movements axis X/Y/Z: 650/300/250 mm 4th axis- rotational Grinding wheel: -Dia 300 mm -width 40-50 mm -bore size 76,2 mm Spindle speed 1400-2800 rpm Total power requirement 5,5 kW Weight of the machine ca. 3,4 t 4th axis devices: -Punch former PF350 V-block -Punch former PF650-ER20 -Punch former PFD-ER40 -Punch grinder PGAS- centreless Accessories: Collets Radius and angle dresser RDC Sinusoidal-table for devices SPF 50 Balancing rack for wheels LBS 14 surface grinder High-precision horizontal surface grinder, specialized for profile punches grinding. With 4 added digital axes CNC Control Wireless Handwheel Bluetooth c ...
Machine : Grinding Wheel Flange Make : Grinding wheels and grinding wheels Type: Inner cone holder Pos. Text pcs. φ φ H- Schleifsφ Schl. B φ A 3 58 74 83 400 approx. 320 B ELB 4 50 62 60 127 30-50 170 C ELB 4 44 60 68 127 20-40 180 D 1 45 60 70 127 30-60 190 E 2 27 34 44 approx. 85 -30 130 F 1 45 60 75 127 -50 190 G 1 29 35 44 Ca.85 -30 146 H 1 45 60 75 Ca.135 -60 180 I 2 45 60 75 127 30-60 180/190 J 2 27 43 56 127 -40 175 K 3 32 32 55 127 20 158 S Grinding wheel : NEW – for a centerless cylindrical grinding machine, Dilvmit+Kircher D- 10C 100/8 hp V03 , 406x200x203mm ( 270x25x25) Price: € 200,-
Surface grinding machine, used, Grinding area: 450x200x250mm, with magnetic plate, puller, holders, coolant device, ...
ELB PERFEKT BD10 SPS surface grinding machine was built in 2004 in Germany by ELB-Schliff Werkzeugmaschinen GmbH. The machine is used for precision grinding of workpieces with a maximum weight of 1000 kg. The machining process is carried out fully automatically on a large magnetic plate or directly on the work table. The grinding head, consisting of a spindle and grinding wheel, moves along guide rails to ensure an even and accurate surface finish. The ELB SCHLIFF PERFEKT BD10 SPS magnetic surface grinding machine is also equipped with, among others, a cooling system with a belt paper filter, which cleans the coolant after machining and allows it to be reused in the next process. The total weight of the machine is 6300 kg. Technical specifications of the ELB PERFEKT BD10 SPS grinding machine - magnetic plate dimensions (L x W): 1000 x 750 mm - maximum grinding dimensions (L x W x H) ...
Key data: 600 mm, 375 mm
ELB Optimal 6375 SPS, year of construction 1995, grinding area 600 x 375 mm, the machine has been overhauled by us currently, the guide tracks are scraped in tolerance of a new machine, the bearings of the grinding spindle have been changed, accessories: Electric Perm magnetic clamping plate 600 x 350 mm, automatic straight dresser for the grinding wheel mounted on spindle box, with dressing compensation, coolant tank with paper belt filter. The machine is functionally tested and can be viewed at our premises under power, we are also happy to take over the installation and training on site, as well as the service in the future
Magnetic table 455 x 170 mm Digital Water tank Pulling device Wet grinding device
ELB Perfect BD 10 750, grinding area 1000 x 750 mm, year of construction 2004, grinding spindle 10 KW, grinding wheel 400 x 100 mm, automatic dresser with compensation, electric perm magnetic clamping plate 1000 x 750 mm, partial enclosure with suction, water tank with paper belt filter, the machine is partially overhauled, geometry according to the standard of new machine, we are happy to take over the installation / training on site, as well as the subsequent service.
ELB Perfect BD 15 PLC surface grinding machine, grinding area 1500 x 550 mm, grinding wheel 400 x 100 mm, electric perm magnetic clamping plate 1500 x 550 mm, automatic dresser with compensation, paper belt filter, the machine is overhauled, grinding spindle rebeared, guideways are scraped, meets the tolerance of a new machine. We are happy to take over the installation / training on site, as well as the subsequent service
Manufacturer: ELB Type: SWN 6 VA2 Year of construction: 1982 Grinding length: 600 mm Grinding width: 320 mm Workpiece height: 525 mm Table clamping surface: 600x300 mm Magnetic plate: 600x300 mm Machine dimensions: 2600x1500x2000 mm Machine weight: ca. 2t
Code 4925 Description Surface grinding machine Make ELB Model OPTIMAL 1 VA II Serial No. 180730982 Year 1982 Tablesize 900 x 250 mm Table grinding size L x B x H 600 x 300 x 250 mm Magnetical plate size L x B 500 x 250 mm Speed table movement 1 – 25 m/min. Rapide vertical movement 0,15 m/min Max. distance table – centre grinding wheel 500 mm Grinding stone dim. Stone x Wide x Taper 300 x 50 x Ø 75 mm Spindel power 3,7 and 4,5 kW Spindel speed 1400 and 2800 rpm Weight 3500 kgs Motor power 3,7 and 4,5 kW – 380 Volt Accessoiries Elec. Magneticplate 500 x 250 mm Coolant with paperfilter 2 x DRO Grinding stones, etc. Condition Machine is in good condition
Code 0776 Description Surface grinding machine Make ELB Type SWBD 030 MCNC82 Machine No. 18.346.0383 Manufacturing date 1983 Control MCNC / 82-PC Tablesize 3520 x 600 mm Table grinding size L x B x H 3000 x 600 x 600 mm Magnetical plate size L x B 3000 x 400 mm Speed table movement 0,2 – 6 m/min. Max. distance table – centre grinding wheel 850 mm Speeds vertical 3 – 375 mm/min. Speeds cross 1,2 m/min. Speeds grindingwheel stepless 750 – 1400 omw/min Grindingstone: Ø 600 x Wide:100 x Bore: 200 mm Weight 18.000 kg Motor power 37 kW – 380 Volt Accessoiries Electro table 3000 x 400 mm Grinding unit with water cooling Filtering unit with paperfilter Profile grinding unit Condition Machine is in very good condition
Horizontal grinding machine ELB, magnet 500/350 mm, table 840/350 mm, mesh. No. 140030676
Used machine as good as new Grinding length: 600 mm Grinding width: 400 mm Workpiece height: 450 mm Table clamping area: 600 x 400 mm Grinding wheel dimensions: 300x50 mm Grinding spindle motor: 3.5 kW Table speed: 0 - 30 m/min Grinding wheel speed: 0 - 35 m/s Magnetic plate size: 600 x 400 mm Total power requirement: 15 kW Machine weight approx.: 4.5 t Room requirements approx.: 3.5 x 2.5 x 2.5 m 12 month warranty Paper filter machine Automatic table dressing with compensation 1 pc. flange Setting-up elements
Surface grinders - horizontal ELB-SCHLIFF perfect B-10 SPS Second-hand machine Grinding length: 1000 mm Grinding width: 400 mm Workpiece height: 450 mm Table size: 1000 x 400 mm Grinding wheel dimensions: 300 x 50 mm Grinding spindle motor: 3.5 kW Table speed: 2-30 m / min Grinding wheel speed: 1500 rpm Magnetic plate size: 1200 x 500 mm Total power: 15 kW Machine weight approx.: 4,5 t Space requirement approx.: 3.5 x 2.5 x 2.5 m General overhauled by 2015 with 12 month warranty Paper machine Magnetic clamping plate 1000 x 400 Automatic dressing device with compensation 1 flange Items put up
grinding length:450 mm grinding width:250 mm workpiece height:280 mm Table area:760 x 250 mm grinding spindle drive:2,5 kW grinding wheel dia. x width:250x 25 mm grinding spindle speed:1430/2900 U/min way of grinding spindle saddle, vertical:400 mm total power requirement:4,5 kW weight of the machine ca.:1,8 t dimensions of the machine ca.:1,8 x 1,4 x 2,0 m Machine equiped with magnetic plate - dresser
grinding length:450 mm grinding width:250 mm workpiece height:280 mm Table area:760 x 250 mm grinding spindle drive:2,5 kW grinding wheel dia. x width:250x 25 mm grinding spindle speed:1430/2900 U/min way of grinding spindle saddle, vertical:400 mm total power requirement:4,5 kW weight of the machine ca.:1,8 t dimensions of the machine ca.:1,8 x 1,4 x 2,0 m Machine equiped with magnetic plate - dresser
ELB SMART BD10 STC ist eine CNC-Flach/Profilschleifmaschine für hohe Präzision, Genauigkeit und Zuverlässigkeit. Kapazität: Tisch 1360×590 mm, X1100 Z670 Y400, Schleifmaß 1000×600 mm, Zuladung 1000 kg. Daten: Scheibe Ø400×100 mm (Bohrung127), 1450 U/min, Spindel 10 kW, Tisch 2–30 m/min, Vorschübe bis 2000/1500 mm/min, Eilgang Y 1 m/min, 3×400V, Gesamt 30 kW, Gewicht ~6900 kg, Abm. 3550×2410×2660 mm. Zubehör: Kühlung, Papierfilter, Ölnebelabsaugung, Magnetplatte 800×600, Abrichter, Profileinrollvorrichtung, Satz Scheiben/Flanschen, elektronisches Handrad. Ermöglicht enge Toleranzen; geeignet für Automotive, Luftfahrt, Werkzeugbau, Medizin, Uhren. Technische Daten ohne Gewähr
ELB SWH 5 NC-K ist eine Flachschleifmaschine mit hoher Präzision, Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch 750×200 mm; Schleiflänge 500×250 mm; Höhe 375 mm; Abstand Tisch–Spindel 525 mm. Daten: Tischgeschw. st.
ELB PERFEKT BD 8 SPS ist eine Flachschleifmaschine für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch 1360×590 mm; Schleiflänge 1250 mm; max 600×400 mm; Wege X900 Z540 Y400; Tischlast 900 kg. Daten: Schleifscheibe 400×100 mm, 1440 U/min, Bohrung 127 mm, Konus 60 mm; Schleifspindel 20 kW; Anschluss 3×400 V 50 Hz; Gesamtleistung 18,5 kW; Maschine ~5400 kg. Zubehör: Papierfilter, Elektro-Magnetspannplatte 1200×600 mm, Abrichtvorrichtung, Lampe, Zentralschmierung. Erreicht enge Toleranzen; Einsatz: Automotive, Luftfahrt, Werkzeugbau, Medizintechnik, Uhrmacherei. Technische Daten ohne Gewähr
ELB PERFEKT BD 8 SPS ist eine Flachschleifmaschine, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch 1360×590 mm, 1 T-Nut 16 mm, Schleiflänge 800 mm, Schleifbreite 600 mm, Schlefhöhe 400 mm, max. Werkstückgewicht 900 kg; Wege X 900 mm, Z 540 mm, Y 400 mm. Technische Daten: Schleifscheibe Ø400×100 mm (Bohrung 127) fix 1440 U/min, Spindelkonus 60 mm, Schleifspindelmotor 10 kW, Gesamtleistung 18,5 kW, Anschluss 3×400 V 50 Hz; Gewicht ~5400 kg; Abmessungen 3800×2900×2500 mm; Schaltschrank 1200×500×1900 mm. Zubehör: Papierfilteranlage, Elektro-Magnetspannplatte 800×600 mm, Abrichtvorrichtung, Lampe, Satz Flansche, Zentralschmierung, Kühlmittel-/Nebelsystem TEBARON. Ermöglicht enge Toleranzen; typisch für Automotive, Uhrenindustrie, Werkzeugbau, Luftfahrt, Medizintechnik Technische Daten ohne Gewähr
CONTROLS CNC controls SIEMENS 840 D WORKING RANGE SURFACE GRINDING grinding length: 1000 mm grinding width: 600 mm vertical travel: 350 mm TABLE (SURFACE GRINDING) table surface (left-right): 1360 mm table surface (front-back): 550 mm workpiece load (max): 1000 kg SPINDLESTOCK GRINDING SPINDLE spindle revolutions (min): 1000 /min spindle revolutions (max): 6500 /min GRINDING TOOL type of grinding tool: wheel diameter (min): 500 mm borehole: diameter: 203 mm width: 100 mm ELECTRICAL SPECIFICATIONS total power consumption: 91 kW mains voltage: 400 V mains frequency: 50 Hz ATTACHMENTS (GRINDING) coolant unit: yes - 4500 operating hours - Very good and well-maintained condition - Machine body: Meehanit cast iron - Linear guides - Diamond dressing roller: Ø135x100x52 - Automatic balancing system - Programmable slow, fast, ...
grinding length: 3000 mm grinding width: 900 mm workpiece height: 600 mm magnetic clamping plate, electical: 3000 x 900 mm Pole pitch: 18 mm grinding wheel size: Ø 500 100 mm control: Mitsubishi 520 total power requirement: 18,5 / 5,5 kW weight of the machine ca.: 19 t dimensions of the machine ca.: 9 x 4,5 x 3,5 m Packing: ca.13 x 2,5 x 3,5 m Retrofit 1999 EXW price / Ex Foundation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
grinding length: 600 mm grinding width: 400 mm workpiece height: 450/510 mm grinding spindle - swivable: 10 ° grinding spindle slide: 450 mm horizontal movement: 320 mm swivability (for helical bores): 1 ° surface area: 900 x 300 mm stroke: 50 mm clamping slots: 1 cross travel: 320 mm longitudinal feed: 600 mm table load: max 320 kg weight: 2.450 kg total power requirement: kW dimensions of the machine ca.: 2000 x 1900 x 2350 mm Grinding length: 600 mm Grinding width: 400 mm Max. workpiece height: 450 / 510 mm Swivelling grinding spindle: ±10° Grinding spindle slide travel: 450 mm Cross travel: 320 mm Table swivel (for angular grinding): ±1° Clamping surface: 900 × 300 mm Vertical travel: 50 mm T-slots: 1 Cross travel: 320 mm Longitudinal travel: 600 mm Max. table load: 320 kg Machine weight: 2,450 kg Space requirement (L × W × H): approx. 2,000 × 1,900 × 2,350 mm 16 A three-p ...
grinding length: 600 mm grinding width: 320 mm workpiece height: 525 mm surface area: 600 x 300 mm magnetic plate: 600 x 300 mm weight of the machine ca.: 2 t dimensions of the machine ca.: 2600 x 1500 x 2000 m total power requirement: kW Grinding length: 600 mm Grinding width: 320 mm Max. workpiece height: 525 mm Clamping surface: 600 × 300 mm Magnetic chuck: 600 × 300 mm Machine weight: approx. 2 t Space requirement (L × W × H): approx. 2,600 × 1,500 × 2,000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
grinding length: 400 mm grinding width: 250 mm workpiece height: 300 mm total power requirement: ? kW weight of the machine ca.: 2 t dimensions of the machine ca.: 222 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
grinding length: 400 mm grinding width: 250 mm workpiece height: 375 mm grinding wheel diameter: 300 mm weight of the machine ca.: 2.9 t Magnetic plate 400x250mm www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
grinding length: 1500 mm grinding width: 700 mm workpiece height: mm grinding height: mm table load capacity: 1200 kg table surface area: ca 1800 x 600 mm table speeds: 2 - 30 m/min stroke: Vertikal 400 mm spindle motor: 37 kW spindle speeds (infinitely variable): 100 - 6500 U/min grinding wheel size: 500 x 100 x 203 mm Control: Siemens 840D total power requirement: 52 kW weight of the machine ca.: - t dimensions of the machine ca.: - m CNC control Siemens Sinumerik 840 D The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
