boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793862

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Column drilling machine make ALZMETALL type AB 25 SVMachine -No: 1717 built in 1976Technical specifications:Drilling capacity in ST 60: 28 mmDrilling capacity in GG 20: 30 mmDrilling capacity in ST 60: 35 mmSpindle mount: MK 3Projection: 293 mmColumn diameter: 115 mmTable size: 500 x 400 mmClamping surface: 400 x 300 mmInfinitely variable spindle speeds: 130 - 480/480 - 1750 rpm.Spindle stroke: 160 mmautomatic feed: 0.14 mm / rev.Drive power: 2.2 kWMachine height approx .: 1860 mmWeight approx: 320 kgwith- stepless spindle speeds- height adjustable table- cooling device- R. + L. runused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156326688

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Werk Land-de

add to watchlist

: 26 mm: 30 mm: 30 mmthreading in St 60: M 20 threading in GG 20: M 24 : MK 3 : 120-2.200 U/min.throat: 293 mm: 514x360 mm: 2 x 14 x 224 mm: 90/675 mmcolumn diameter: 115 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/Utotal power requirement: 1,0/1,6 kWMachine height: 1865 mmweight: 380 kgStandard equipment:7 TFT LCD display with touch function: manual input of spindle speedSetpoint, actual speed display, integrated drilling depth display with touchZero point transfer, virtual drilling depth scale in the display, machineStatus displays and warnings in the display, service information, selectableUser language: DE / EN / FR / ES / IT / NL / RU- Thread cutting device, for thread cutting with stop, max. 6thThread / min (thread cutting performance dependent on spindle speed), thread depthadjustable via depth stop and in the TFT - LCD display (4 tools)- Infinitely variable speed setting b ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 163716215
New in: 2002

used

check Seller: Marcels Maschinen AG Schweiz
Location: Schweiz

add to watchlist

bore capacity in steel (diameter): 26 mmthroat: 290 mmbore stroke: 160 mmspindle turning speed - stepless: 120-2200 U/minweight of the machine ca.: 460 kgdimensions of the machine ca.: 500 x 800 x 1900 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156326800

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Werk Land-de

add to watchlist

: 26 mm: 30 mm: 30 mm: M 20 : M 24 : MK 3 : 120-2.200 U/min.throat: 293 mm: 515x360 mm: 2 x 14 x 224 mm: 90/675 mmcolumn diameter: 115 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/UMachine height: 1865 mmtotal power requirement: 1,0/1,6 kWStandard equipment:- Electromagnetic feed clutch with overload protection and electricalCross Handle Switches- Main switch lockable- Motor protection switch- Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel- Speed adjustment stepless- Speed display digital- Protection IP 54- Motor insulation class F- Spindle protection with electrical protectionPos. 20.1Tapping device with foot switch, for thread cutting withStop, max. 6 threads / min., (Tapping power dependent on spindle speed)The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 163374340
New in: 1981

used

check Seller: WMT GmbH & Co. KG
Location: 46342 Velen Land-de

add to watchlist

bore capacity in steel (diameter): 30 mmthroat: 290 mmbore stroke: 150 mmtaper MK: 3 MKtable-size: 320 x 370 mmthread boring diameter: mmfeeds: mm/Uturning speeds: 80 - 1400 U/mintotal power requirement: 2,0 KWweight of the machine ca.: 0,35 tdimensions: 0,6 x 0,8 x 1,95 mColumn drilling machine with:- variable spindle speed- Machine lightThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 163759455
New in: 1990

used

check Seller: WMT GmbH & Co. KG
Location: 46342 Velen

add to watchlist

bore capacity in steel (diameter): 40 mmthroat: 280 mmbore stroke: 180 mmtaper MK: 4 MKtable-size: 620 x 470 mmfeeds: 0,1 - 0,2 - 0,3 mm/Uturning speeds: 110 - 2900 U/mintotal power requirement: 1,9 KWweight of the machine ca.: 0,55 tdimensions: 1,2 x 0,8 x 2,1 mColumn drilling machine with:- Feed- variable spindle speed- Coolant pump- Machine lightThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793861

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Column drilling machine make ALZMETALL type AB 3 EYear of manufacture 1979Technical specifications:Drilling capacity up to: 32 mmSpindle mount: MK 3Infinitely variable spindle speeds: 65 - 1150 rpm.3 automatic feeds: 0.1 / 0.2 / 0.3 mm / rev.Throat: 280 mmColumn diameter: 150 mmTable size: 350 x 350 mmSpindle stroke: 150 mmDrive power: 2.2 kWPower connection: 380 V / 50 Hzwith- swiveling table- drill chucksused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 163510447

used

check Seller: A+B Werkzeug Maschinen Handels GmbH
Location: Ahaus

add to watchlist

Boring power: 32.0 mmbore capacity in cast iron: 35.0 mmmorse taper: MK 3 spindle stroke: 160 mmthroat: 293 mmcolumn diameter: 115 mmtable:: 400 x 500 mmturning speeds: 125 - 1050 U/mintotal power requirement: 0.55 / 0.80 kWweight: 200 kgrange L-W-H: 625 x 950 x 1840 mm from a training workshop maintained condition ()Furnishing:- V-belt operated column drilling machine- adjustable drilling depth stop- manual spindle feed via cross handle- Work table with 2x T-slots- Pole-changing drive motor- Table height adjustment via hand crank- Connection cable including 16A plug Machine link:http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno =1008-9103747The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793860

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Column drilling machine make ALZMETALL type AB 3 ESMachine -No: 16653Technical specifications:Drilling capacity: 28 mmSpindle mount: MK 3Projection: 293 mmColumn diameter: 115 mmTable size: 400 x 300 mmInfinitely variable spindle speeds: 65 - 1750 rpm.Spindle stroke: 160 mmDrive power: 0.9 / 1.3 kWExternal dimensions approx.: 500 x 900 x 2200 mmWeight approx: 330 kgwith- stepless spindle speeds- R + L run- cooling deviceusedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793864

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Column drilling machine make ALZMETALL type AB 3 ESMachine -No: 81978Technical specifications:Drilling capacity: 28 mmSpindle mount: MK 3Projection: 293 mmColumn diameter: 115 mmTable size: 400 x 300 mmInfinitely variable spindle speeds: 65 - 1750 rpm.Spindle stroke: 160 mmDrive power: 0.9 / 1.3 kWExternal dimensions approx.: 500 x 900 x 2200 mmWeight approx: 330 kgwith- stepless spindle speedsusedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 159664007
New in: 1981

used

check Seller: Sperling Werkzeugmaschinen
Location: Abgeber / NRW Land-de

add to watchlist

bore capacity in steel (diameter): 32 mmthroat: 295 mmbore stroke: 160 mmspindle turning speed - stepless: 110 - 2900 U/mincolumn diameter: 115 mmtable-size: 400 x 300 mmspindle taper MT: 3 bore capacity in cast iron: 40 mmtotal power requirement: 1,2 kWweight of the machine ca.: 330 kgdimensions of the machine ca.: 700 x 900 x 1850 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 163716193

used

check Seller: A+B Werkzeug Maschinen Handels GmbH
Location: Ahaus

add to watchlist

bore capacity in steel (diameter): 35.0 mmbore capacity in cast iron: 40.0 mmthroat: 295 mmbore stroke: 160 mmmorse taper: 3 MKtable:: 475 x 625 mmturning speeds: 130 - 1750 U/minfeed: 0.1 / 0.2 / 0.3 mm/Ucolumn diameter: 120 mmthreading: M 24 total power requirement: 1.5 kWweight: 400 kgrange L-W-H: 1050 x 850 x 1900 mmFurnishing :- robust column drilling machine MADE IN GERMANY Drive: V-belt - VARIO- automatic spindle feed (0.1 / 0.2 / 0.3 mm/rev)- R/L run of the work spindle = thread cutting device- Height-adjustable work table with T-slots, via hand crank- machined base plate with T-slots- adjustable drilling depth stop- Coolant device in the machine base- Connection cable + plug- User manual (PDF) Machine link:https://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machinen o=1008-9103757The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793849

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Box column drilling machine make ALZMETALL type AB 3 HSTMachine -No: 1752 Year 1984Drilling capacity in steel St 60:28 mmDrilling capacity in steel St 60:40 mmDrilling capacity in casting GG 20:35 mmThread cutting steel St 60: M 22Thread cutting in cast GG 20: M 33Spindle mount: MK 3Spindle speeds stepless: 130 - 1750 rpm.Discharge: 330 mmSpindle stroke: 160 mmTable size: 600 x 460 mm3 aut. Feed rates: 0.1 / 0.2 / 0.3 mm / revDrive power: 1.0 / 1.6 kWWeight approx.: 700 kgWith- electromag. feed clutch- Semi-automatic workflow- semi-automatic thread cutting- by 200 mm extended stand- Flange quill- Return spring- Tapping device- Revolver drill head grass type ARBO 20 -No: 243xa0xa0 with 6 spindles- aut. pivoting device d. turret- hydr. feed cylinder- Depth drill with 4 depth stops- Drilling depth program switching- electr. Two-hand controlused, in very good conditionPrice on request.Deli ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156326968

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Werk Land-de

add to watchlist

: 34 mm: 40 mm: 40 mmthreading in St 60: M 24 threading in GG 20: M 30 : MK 4 : 100-1.800 U/min.throat: 300 mm: 615x430 mm: 2 x 14 x 224 mm: 138/688 mmcolumn diameter: 145 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/Utotal power requirement: 1,4/2,2 kWMachine height: 1865 mmweight: 470 kgStandard equipment:7 TFT LCD display with touch function: manual input of spindle speedSetpoint, actual speed display, integrated drilling depth display with touchZero point transfer, virtual drilling depth scale in the display, machineStatus displays and warnings in the display, service information, selectableUser language: DE / EN / FR / ES / IT / NL / RU- Thread cutting device, for thread cutting with stop, max. 6thThread / min (thread cutting performance dependent on spindle speed), thread depthadjustable via depth stop and in the TFT - LCD display (4 tools)- Infinitely variable speed setting  ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 160004413

new

check Seller: Heinz Sanders GmbH
Location: 49779 Niederlangen Land-de

add to watchlist

bore capacity in steel (diameter): 34,0 mmthroat: 300 mmbore stroke: 160 mmmorse taper: 4 MKtable:: 615 x 430 mmturning speeds: 100 - 1.800 U/minengine output: 1,4 / 2,2 kWcolumn diameter: 145 mmthread: M24 ST60thread: M30 GG20feed: 0,1-0,2-0,3-0,4 mm/Uweight: 470 kgMachine height: 1865 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU.Furnishing:- Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - LCD display (3 tools).- Infinitely variable speed setting by  ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156797511

new

check Seller: A+B Werkzeug Maschinen Handels GmbH
Location: Ahaus Land-de

add to watchlist

bore capacity in steel (diameter): 34,0 mmthroat: 300 mmbore stroke: 160 mmmorse taper: 4 MKtable:: 615 x 430 mmturning speeds: 100 - 1.800 U/minengine output: 1,4 / 2,2 kWcolumn diameter: 145 mmthread: M24 ST60thread: M30 GG20weight: 470 kgMachine height: 1865 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU.Furnishing:- Thread cutting device for thread cutting with a stop max. 6 threads / min (thread cutting performance depends on the spindle speed) Thread depth adjustable via depth stop in the TFT - LCD display (3 tools).- Infinitely variable speed setting by means of an adjusting leve ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 160258192

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Günzburg Land-de

add to watchlist

: 34 mm: 40 mm: 40 mmthreading in St 60: M 24 threading in GG 20: M 30 : MK 4 : 100-1.800 U/min.throat: 300 mm: 615x430 mm: 2 x 14 x 224 mm: 138/688 mmcolumn diameter: 145 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/Utotal power requirement: 1,4/2,2 kWMachine height: 1865 mmweight: 605 kgStandard equipment:7 TFT LCD display with touch function: manual input of spindle speedSetpoint, actual speed display, integrated drilling depth display with touchZero point transfer, virtual drilling depth scale in the display, machineStatus displays and warnings in the display, service information, selectableUser language: DE / EN / FR / ES / IT / NL / RU- Thread cutting device, for thread cutting with stop, max. 6thThread / min (thread cutting performance dependent on spindle speed), thread depthadjustable via depth stop and in the TFT - LCD display (4 tools)- Infinitely variable speed setting  ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 157620874

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Werk Land-de

add to watchlist

: 34 mm: 40 mm: 40 mmthreading in St 60: M 24 threading in GG 20: M 30 : MK 4 : 100-1.800 U/min.throat: 300 mm: 615x430 mm: 2 x 14 x 224 mm: 138/688 mmcolumn diameter: 145 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/Utotal power requirement: 1,4/2,2 kWMachine height: 1865 mmweight: 470 kgStandard equipment:7 TFT LCD display with touch function: manual input of spindle speedSetpoint, actual speed display, integrated drilling depth display with touchZero point transfer, virtual drilling depth scale in the display, machineStatus displays and warnings in the display, service information, selectableUser language: DE / EN / FR / ES / IT / NL / RU- Thread cutting device, for thread cutting with stop, max. 6thThread / min (thread cutting performance dependent on spindle speed), thread depthadjustable via depth stop and in the TFT - LCD display (4 tools)- Infinitely variable speed setting  ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156326557

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Günzburg Land-de

add to watchlist

: 34 mm: 40 mm: 40 mm: MK 4 : 100-1.800 U/min.throat: 300 mm: 615x430 mm: 2 x 14 x 224 mm: 138/688 mmcolumn diameter: 145 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/UMachine height: 1865 mmtotal power requirement: 1,4/2,2 kWStandard equipment:- Electromagnetic feed clutch with overload protection and electricalCross Handle Switches- Main switch lockable- Motor protection switch- Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel- Speed adjustment stepless- Speed display digital- Protection class IP 54- Motor insulation class F- Spindle protection with electrical protectionPos. 20.1Tapping device with foot switch, for thread cutting withStop, max. 6 threads/min., (Tapping power dependent on spindle speed)Pos. 25.Coolant device B, consisting of: separate container (33 l), pump withMotor protection switch, complete fittingThe data for this ad was created with ModulM ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
ankerimg
item-No.: 163133363

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Werk Land-de

add to watchlist

: 34 mm: 40 mm: 40 mm: MK 4 : 100-1.800 U/min.throat: 300 mm: 615x430 mm: 2 x 14 x 224 mm: 138/688 mmcolumn diameter: 145 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/UMachine height: 1865 mmtotal power requirement: 1,4/2,2 kWStandard equipment:- Electromagnetic feed clutch with overload protection and electricalCross Handle Switches- Main switch lockable- Motor protection switch- Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel- Speed adjustment stepless- Speed display digital- Protection class IP 54- Motor insulation class F- Spindle protection with electrical protectionPos. 20.1Tapping device with foot switch, for thread cutting withStop, max. 6 threads/min., (Tapping power dependent on spindle speed)Pos. 25.Coolant device B, consisting of: separate container (33 l), pump withMotor protection switch, complete fittingThe data for this ad was created with ModulM ...

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793846

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Column Drilling Machine make ALZMETALL type AB 35 SMachine -No: 963 Year 1970Drilling capacity in steel 32 mmDrilling capacity in cast 40 mmDrilling capacity in steel 45 mmMorse taper MK 4Discharge 300 mmColumn diameter 145 mmStepless spindle speeds 55 - 1450 rpm.Quill stroke 160 mm3 automatic feeds 0.1; 0.2; 0.3 mm / revTable size 375 x 500 mmDrive power 1.4 / 2.2 kWPower connection 380 V, 50 HzDimensions L x W x H approx . 600 x 800 x 2000 mmusedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 04.03.2024 add to watchlist
approved
dealer
item-No.: 163503577
New in: 1991

used

check Seller: Venker Werkzeugmaschinen GmbH
Location: 33335 Gütersloh Land-de
Price: 4.400 € add to watchlist

Electromagnetic feed in 3 speeds Tool holder: MK 4 Speed display with infinitely variable adjustment Coolant pump 2 motor speeds

boring mills and machining centers / Column-Type Drilling Machines
date: 08.04.2024 add to watchlist
approved
dealer
item-No.: 161084711
New in: 1968

used

check Seller: Mieth Maschinenhandel
Location: 63322 Rödermark Land-de

add to watchlist

offer 22326 Specifications: - Drilling capacity in steel ST 60 35 mm - Drilling capacity in steel ST 60 40 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 170 mm - Projection 345 mm - Rotary table with 2 T-slots 550 mm - distance table – drilling spindle 650 mm - distance base plate – drilling spindle 1000 mm - Feed rates 0.09 - 0.16 - 0.28 mm/rev - AZ transmission continuously variable with manual transmission - Drilling spindle speeds infinitely adjustable 40 - 720 rpm -Right. - Left-hand rotation - Drive 400 V / 2.5 kW -Lighting - Coolant device - Space requirement approx. W 750 x H 1950 x D 1000 mm - Weight approx. 700 kg

boring mills and machining centers / Column-Type Drilling Machines
date: 21.03.2024 add to watchlist
approved
dealer
item-No.: 163624107
New in: 1956

used

check Seller: Mieth Maschinenhandel
Location: 63322 Rödermark Land-de

add to watchlist

Specifications: - Drilling capacity in steel ST 60 35 mm - Drilling capacity in steel ST 60 40 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 170 mm - Projection 345 mm - Rotary table with 2 T-slots 550 mm -Max. Distance table – drilling spindle 650 mm -Max. Distance base plate – drilling spindle 1000 mm - Feeds 0.09 - 0.16 - 0.28 mm/rev - AZ continuously variable transmission with manual transmission - Drilling spindle speeds infinitely variable 80 - 720 rpm - Drive 400 V / 2.5 kW -Lighting - Quick-action drill chuck - Space requirement approx. W 750 x H 1950 x D 1000 mm - Weight approx. 700 kg

boring mills and machining centers / Column-Type Drilling Machines
date: 14.02.2024 add to watchlist
approved
dealer
item-No.: 161923773

used

check Seller: Venker Werkzeugmaschinen GmbH
Location: 33335 Gütersloh Land-de
Price: 3.200 € add to watchlist

Feed in 3 speeds Tool holder: MK 4 Infinitely variable speed adjustment

boring mills and machining centers / Column-Type Drilling Machines
date: 08.04.2024 add to watchlist
approved
dealer
item-No.: 145170788
New in: 1987

used

check Seller: Mieth Maschinenhandel
Location: 63322 Rödermark Land-de

add to watchlist

High-performance column drilling machine Offer number: 17469 Make: ALZMETALL Type: AB 4 SV Machine No: 18498 Built: 1987 Technical data: - Drilling capacity in steel ST 60 40 mm - Drilling capacity in steel ST 60 50 mm - Thread cutting device - Drilling spindle holder MK 4 - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely adjustable with pre-bedding - Level 1 - 80 - 210 rpm - Level 2 - 210 - 765 rpm - Extension 330 mm - 3 feeds 0.1 - 0.2 - 0.3 rpm - hydr. Feed cylinder for semi-autom. Workflow + Rapid Response - Table with 2 T-slots 720 x 360 mm - height-adjustable via rack with hand crank - max. distance table - drilling spindle approx. 780 mm - maximum distance machined base plate - drilling spindle 1250 mm - Lighting - Coolant device - Swivel arm control panel - Drive 400 V 4 kW - Space requireme ...

boring mills and machining centers / Column-Type Drilling Machines
date: 28.03.2024 add to watchlist
approved
dealer
item-No.: 163673298
New in: 1955

used

check Seller: Kurt Steiger Werkzeugmaschinen GmbH
Location: 65197 Wiesbaden Land-de

add to watchlist

Drilling capacity steel/GG: 40/55 mm Spindle holder: 4 MK Projection: 345 mm Table size: 500 Ø mm Quill stroke: 170 mm Spindle speeds: 80 - 710 rpm Feeds: 0.09/0.16/0.28 mm Drive motor: 380 V, 2.2/2.5 kW Dimensions: 1070 x 500 x 1940 mm Weight: 620 kg

boring mills and machining centers / Column-Type Drilling Machines
date: 18.10.2023 add to watchlist
approved
dealer
item-No.: 161243508
New in: 1978

used

check Seller: Kurt Steiger Werkzeugmaschinen GmbH
Location: 65197 Wiesbaden Land-de

add to watchlist

Drilling capacity steel/GG: 40/55 mm Spindle holder: 4 MK Projection: 345 mm Table size: 450 x 600 mm Quill stroke: 180 mm Spindle speeds: 30 - 760 rpm Feeds: 0.15; 0,2; 0.3 & 0.36 mm Drive motor: 380 V, 2.3/3.4 kW Space requirement: 1150 x 730 x 2000 mm Weight: 600 kg

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156326991

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Werk Land-de

add to watchlist

: 40 mmbore capacity in cast iron: 46 mm: 50 mm: M 30 : M36 : MK 4 throat: 300 mm: 100-1600 U/min.: 615x430 mm: 2x14x224 mmDistance spindle/table max.: 147/688 mmcolumn diameter: 145 mmspindle stroke: 160 mmfeeds: 0,1-0,2-0,3-0,4 mm/Uheight of the machine: 1885 mmdrive motor: 1,8/2,9 kWweight of the machine ca.: 450 kgThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 14.02.2024 add to watchlist
approved
dealer
item-No.: 162022686
New in: 2010

used

check Seller: Venker Werkzeugmaschinen GmbH
Location: 33335 Gütersloh Land-de
Price: 7.500 € add to watchlist

Tool holder MK 40 Drilling capacity up to 40 mm steel Threading device Infinitely variable speed adjustment with digital display Digital drilling depth indicator Electromagnetic feed Coolant pump

boring mills and machining centers / Column-Type Drilling Machines
date: 08.04.2024 add to watchlist
approved
dealer
item-No.: 146729996
New in: 1980

used

check Seller: Mieth Maschinenhandel
Location: 63322 Rödermark Land-de

add to watchlist

Technical data: - Drilling capacity in steel ST 60 40 mm - Drilling capacity in steel ST 60 55 mm - Thread cutting device - Drilling spindle holder MK 4 - Drilling spindle stroke 180 mm - Extension 350 mm - Height-adjustable with 2 T-slots 720 x 560 mm - max. Distance table - drilling spindle 550 mm - max. Distance machined base plate - drilling spindle 1140 mm - Column diameter 200 mm - Feed-electromagnetic 0.15 0.2 - 0.3 - 0.36 mm/U with overload protection - Drilling spindle speeds infinitely adjustable 60 - 210 + 210 - 765 rpm - Drive 400 V / 2.3 / 3.4 kW - Lighting - Quick-release drilling chuck - Space requirement approx. W 750 x H 2050 x D 1050 mm - Weight approx. 850 kg

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 158275159
New in: 1956

used

Location: Land-de

add to watchlist

bore capacity in steel (diameter): 50 mmthroat: 385 mmbore stroke: 240 mmtable surface area: ø 500 mmspindle taper MT: 5 spindle turning speed range: 40 - 800 U/minfeeds: 0,1/0,14/0,2/0,28/0,4 mm/Ucolumn diameter: 220 mmdistance between table/spindle: max. 670 mmdistance spindle/base plate: 1180 mmtotal power requirement: 4 kWweight of the machine ca.: 1,4 tdimensions of machine L x W x H: 1,5 x 0,75 x 2,4 mAccessories: drill chuck, coolantThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 24.10.2023 add to watchlist
approved
dealer
item-No.: 131054142

used

check Seller: Catalano Werkzeugmaschinen AG
Location: Land-ch

add to watchlist

Drilling capacity in steel / cast iron 50/65 mm Drilling capacity in steel 70 mm Feed 0.1 - 0.54 mm / Rev Speed 62-1240 RPM Recording MK 5 spindle stroke (drilling depth) 240 mm Usable projection 385 mm Table 800 x 680 mm Spindle head diameter 70 mm Height 2350 mm the machine

boring mills and machining centers / Column-Type Drilling Machines
date: 21.12.2023 add to watchlist
approved
dealer
item-No.: 162646011

used

check Seller: Komplett-Konzept Verwertungs GmbH
Location: Land-de
Price: VB 3.780 € add to watchlist

Key data: 50 mm, 385 mm

Alzmetall AB 5/S Column Drilling Machine Infinitely variable speed via PIV chain drive with 2 gear stages, Speed range Level I 40 rpm to 180 rpm Speed range Stage II 150 rpm to 800 rpm Drilling capacity in steel: 50mm Feeds: 0.1 / 0.14 / 0.2 / 0.28 / 0.28 / 0.4 mm/revolution Quill stroke: 240mm Quill diameter : 85mm Column diameter : 220mm Projection : 385mm Recording: MK 5 Table surface 880mm x 670mm Rigid table with T grooves (19mm) mechanically clamped, height adjustable via rack and pinion Dimensions : 2650mm x 880mm x 1700mm More items - new and used - can be found in our shop! International shipping costs on request!.

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793847

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Column Drilling Machine make ALZMETALL type AB 50 HSTMachine -No: 340 Year 1982Drilling capacity in steel: 50 mmDrilling capacity in cast: 65 mmDrilling capacity in steel: 65 mmThread cutting in ST 60: M 60Thread cutting in cast: M 72Spindle mount: MK 5Projection: 400 mmTable size: 700 x 520 mmQuill stroke: 240 mm5 aut. Feed rates: 0.1-0.4 mm / rev.stepless speeds: 40-1600 rpm.Drive power: 3.0 / 5.0 kWTotal weight: 1400 kgWith- Box stand version- Thread cutting device- aut. feedsused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793865

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Pillar drilling machine make ALZMETALL type AB 60 HSTMachine -No: 203 built in 1985Technical specifications:Drilling capacity ST 60:65 mmDrilling capacity GG 20:75 mmSpindle mount: MK 5Projection: 400 mmTable size: 700 x 520 mmQuill stroke: 240 mmQuill diameter: 98 mm5 automatic feeds: 0.1 - 0.4 mmSpindle speeds infinitely variable: 40 - 1600 rpm.Drive power: 5 / 7.5 kWDimensions approx.: 2000 x 1000 x 2450 mmWeight approx.: 1500 kgWith- Thread cutting device- Table adjustment with hand crank- electric feed clutch- Cooling deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 18.03.2024 add to watchlist
approved
dealer
item-No.: 163601947
New in: 1981

used

check Seller: Alfred Feldmann Werkzeugmaschinen
Location: 64720 Michelstadt Land-de

add to watchlist

- Table size: 400 x 300 mm - Quill stroke: 180 mm - Drilling capacity: 35 mm - Speed range: 110 - 1450 rpm - Spindle mount: MK3 - Total power: 0.8 kW - Machine weight: 350 kg - Space requirements (W x D x H): 1.2 x 0.9 x 2.0 m - Condition: very good Details runs smoothly, can be used immediately Accessories Vice, 3 chucks

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156885243

used

check Seller: Marcels Maschinen AG Schweiz
Location: Schweiz Land-ch

add to watchlist

bore capacity in steel (diameter): 65 mmthroat: 390 mmbore stroke: 250 mmspindle taper MT: 5 table-size: 880x670 mmspindle turning speed - stepless: 40-800 U/minweight of the machine ca.: 1.2 twww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793852

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

Vertical drilling machine make ALZMETALL type Abomat 40Fabr. -No: 147 A built in 1968Drilling capacity in St / GG: 45/60 mmSpindle mount: MK 5Table size: 500 x 500 mm12 spindle speeds: 35 - 1400 rpm.7 automatic feeds: 0.04 - 0.3 mm / revSpindle head diameter: 62 mmDrilling carriage stroke: 400 mmDischarge: 330 mmMax. Distance table to spindle: 1165 mmMax. Distance base plate to spindle: 1550 mmDrive power: 4 hpDimensions L x W x H: 1350 x 600 x 2250 mmWeight approx. 1200 kgWith- semi-automatic workflow- electr. controlled jump feed- Two-hand releaseused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

boring mills and machining centers / Column-Type Drilling Machines
date: 25.04.2022 add to watchlist
approved
dealer
item-No.: 158793855

used

check Seller: WAHO Werkzeug- und Maschinenhandelsges. mbH
Location: Land-de

add to watchlist

CNC column drilling machine make ALZMETALL type AC 45Machine -No: 105 built in 1994Technical specifications:Drilling capacity in St: 45 mmDrilling capacity in St: 60 mmDrilling capacity in cast: 60 mmThread cutting capacity in St: M36Thread cutting capacity in cast: M42Tool holder: ISA 40Throat: 350 mmTable size: 750 x 550 mmColumn diameter: 200 mmstepless feed: 1 - 3000 mm / min.Infinitely variable spindle speeds: 35 - 3500 rpm.Drive power: 4.0 kWWeight about 1500 kgWith- Depth programming, rapid traverse, forward and reverse- Syncro tapping- Jump feed- deep hole drilling- Lowering / planning- Step drilling- Enter the drilling depth- Flow drillingused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always  ...

boring mills and machining centers / Column-Type Drilling Machines
date: 31.10.2023 add to watchlist
approved
dealer
item-No.: 161335575
New in: 1993

used

check Seller: CNC BOTE Johann Demmel
Location: 86971 Peiting Land-de

add to watchlist

General: Year of construction: 1993 Speed range 75 – 5,800 rpm Rapid traverses 3.5 m/min Clamping surface 390 x 420 mm Weight 380 kg

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 157865026

new

check Seller: A+B Werkzeug Maschinen Handels GmbH
Location: Ahaus Land-de

add to watchlist

bore capacity in steel (diameter): 30,0 mmthroat: 293 mmbore stroke: 140 mmmorse taper: 3 MKtable:: 514 x 360 mmturning speeds: 225 - 4.300 U/minengine output: 1,0 / 1,6 kWcolumn diameter: 115 mmweight: 260 kgMachine height: 1.790 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU.Furnishing:- Infinitely variable speed setting by means of an adjusting lever- Spindle protection with electrical fuse- Three separate buttons for clockwise rotation - counterclockwise rotation - stop- Mushroom pushbutton (latching) for EMERGENCY STOP- Main switch, lockable- Right and left rotation by contactor c ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 162948987

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Günzburg Land-de

add to watchlist

Drilling capacity in St 60: 30 mmthreading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 bore stroke: 140 mmthroat: 293 mmcolumn diameter: 115 mmMachine table - usable table surface: 514x360 mmT-Slots Amount - Width - Distance: 2 x 14 x 224 mmDistance spindle - machine table min./max.: 132/724 mmfeed: Hand spindle turning speed range: 225-4300 UpMtotal power requirement: 1,0/1,6 kWheight of the machine: 1790 mmweight of the machine ca.: 260 kgStandard equipment:- Mushroom pushbutton (latching) for EMERGENCY STOP- Reversing switch for right-left rotation- Motor protection switch- Speed adjustment stepless- Speed display digital- Protection IP 54- Connector (fully assembled, cable length 2 m)- Spindle protection with electrical protectionThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156326599

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Günzburg Land-de

add to watchlist

Drilling capacity in St 60: 30 mmthreading in St 60: M 16 threading in GG 20: M 20 Short spindle: MK 3 bore stroke: 140 mmthroat: 293 mmcolumn diameter: 115 mmMachine table - usable table surface: 514x360 mmT-Slots Amount - Width - Distance: 2 x 14 x 224 mmDistance spindle - machine table min./max.: 132/724 mmfeed: Hand spindle turning speed range: 225-4300 UpMheight of the machine: 1790 mmtotal power requirement: 1,0/1,6 kWweight of the machine ca.: 260 kgStandard equipment:- Mushroom pushbutton (latching) for EMERGENCY STOP- Reversing switch for right-left rotation- Motor protection switch- Speed adjustment stepless- Speed display digital- Protection IP 54- Connector (fully assembled, cable length 2 m)- Spindle protection with electrical protectionThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 162883802
New in: 1999

used

check Seller: Klaus Rosenboom GmbH
Location: Bremen Land-de

add to watchlist

bore capacity in steel (diameter): 40 mmthroat: 293 mmbore stroke: 120 mmbore capacity in cast iron (diameter): 38 mmthreading cutting capacity:: M20/M30 drive capacity - spindle motor: 1,9 kWspindle taper MT: 3 turning speed range: 160- 2250 U/mincolumn diameter: 115 mmtable surface area: 300 x 300 mmdistance spindle /table: 642 mmdistance spindle/base plate: 1207 mmdimensions: 0,7 x 0,45 x 1,85 mweight: 260 kgtotal power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mUsed Pillar Drilling Machine in very good condition.- stepless spindle speed- spindle left/right- Manual tapping (manual change direction of rotation)- Manuel Depth gaugeThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
ankerimg
item-No.: 163794475
New in: 1998

used

check Seller: Heinz Sanders GmbH
Location: Land-de

add to watchlist

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156797199

new

check Seller: A+B Werkzeug Maschinen Handels GmbH
Location: Ahaus Land-de

add to watchlist

bore capacity in steel (diameter): 40,0 mmthroat: 293 mmbore stroke: 120 mmmorse taper: 3 MKtable:: 514 x 360 mmturning speeds: 160 - 2250 U/minengine output: 1,45/1,90 kWcolumn diameter: 115 mmweight: 285 kgMachine height: 1840 mm NEW ALZMETALL MODEL RANGE 7 TFT - LCD display with touch function: Spindle speed setpoint Actual speed display Integrated drilling depth display with touch zero point transfer Virtual drilling depth scale in the display Machine status displays and warnings in the display Service information Selectable user language: DE / EN / FR / ES / IT / NL / RU.Furnishing:- Infinitely variable speed setting by means of an adjusting lever- automatic spindle feed with feed overload protection- Spindle protection with electrical fuse- Three separate buttons for clockwise rotation - counterclockwise rotation - stop- Mushroom pushbutton (latching) for EMERGENCY STOP- Main switc ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 157294210

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Günzburg Land-de

add to watchlist

Drilling capacity in St 60: 40 mmthreading in St 60: M 24 mmthreading in GG 20: M 30 bore stroke: 120 mmShort spindle: MK 3 throat: 293 mmcolumn diameter: 115 mmMachine table - usable table surface: 514x360 mmT-Slots Amount - Width - Distance: 2 x 14 x 224 mmDistance spindle - machine table min./max.: 117/701 mmfeed: 0,10 + 0,20 mm/Uspindle turning speed range: 160-2.250 UpMtotal power requirement: 1,45/1,9 kWheight of the machine: 1840 mmStandard equipment:- Mushroom pushbutton (latching) for EMERGENCY STOP- Reversing switch for right-left rotation- Motor protection switch- Speed adjustment stepless- Speed display digital- Feed overload protection- Protection IP 54- Connector (fully assembled, cable length 2 m)- Spindle protection with electrical protectionPos. 25Coolant device B, consisting of: separate container (33l),Pump with motor protection switch, complete fittingThe data for thi ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 156217765

new

check Seller: WMT GmbH & Co. KG
Location: Land-de

add to watchlist

Drilling capacity in St 60: 40 mmthreading in St 60: M 24 mmthreading in GG 20: M 30 bore stroke: 120 mmShort spindle: MK 3 throat: 293 mmcolumn diameter: 115 mmMachine table - usable table surface: 514 x 360 mmT-Slots Amount - Width - Distance: 2 x 14 x 224 mmDistance spindle - machine table min./max.: 117 / 701 mmfeed: 0,10 + 0,20 mm/Uspindle turning speed range: 160 - 2250 UpMtotal power requirement: 1,45 / 1,9 kWheight of the machine: 1840 mmweight of the machine ca.: 285 kgStandard equipment:- Mushroom pushbutton (latching) for EMERGENCY STOP- Reversing switch for right-left rotation- Motor protection switch- Speed adjustment stepless- Speed display digital- Feed overload protection- Protection IP 54- Connector (fully assembled, cable length 2 m)- Spindle protection with electrical protectionPos. 25Coolant device B, consisting of: separate container (33l),Pump with motor protection  ...

boring mills and machining centers / Column-Type Drilling Machines
date: 12.04.2024 add to watchlist
approved
dealer
item-No.: 163623146

new

check Seller: Bästlein Gebrauchtmaschinenhandel GmbH
Location: Günzburg

add to watchlist

Drilling capacity in St 60: 40 mmthreading in St 60: M 24 mmthreading in GG 20: M 30 bore stroke: 120 mmShort spindle: MK 3 throat: 293 mmcolumn diameter: 115 mmMachine table - usable table surface: 514x360 mmT-Slots Amount - Width - Distance: 2 x 14 x 224 mmDistance spindle - machine table min./max.: 117/701 mmfeed: 0,10 + 0,20 mm/Uspindle turning speed range: 160-2.250 UpMtotal power requirement: 1,45/1,9 kWheight of the machine: 1840 mmStandard equipment:- Mushroom pushbutton (latching) for EMERGENCY STOP- Reversing switch for right-left rotation- Motor protection switch- Speed adjustment stepless- Speed display digital- Feed overload protection- Protection IP 54- Connector (fully assembled, cable length 2 m)- Spindle protection with electrical protectionPos. 25Coolant device B, consisting of: separate container (33l),Pump with motor protection switch, complete fittingThe data for thi ...

You didn't find your wanted machine? send wanted inquiry to all dealers (no registration necessary)
Banner ad information
