Manufacturer:
(Category: 103-174)
used
x-travel: 300 mmy-travel: 135 mmz-travel: 300 mmspindle turning speed range: 100-2000 U/mintable-size: 590x210 mmweight of the machine ca.: 0.6 tDigital read-out 3 axeswww.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
universal milling machine ACIERA F3V Year of construction unknown with accessories
used
Procedures x way 500 mm y way 320 mm z-way 420 mm table 350 x 900 mm Speed 50-3400 RPM. Recording ISO 40
used
Description: 3 phase A.C. 380 V control voltage 220 V  ,Approx. Onsite Dimension. (l x w x h): 1,300 x 1,250 x 2,450 mm, weight approx.: 1,420 kg
used
Description: Mounting: MK 3 Drilling capacity (steel): 30 mm Drilling capacity (cast iron): 35 mm Thread cutting: max. M 24 Quill stroke: 200 mm Spindle speed: 100 - 3200 rpm Projection: 320 mm Travel distances: X-axis:450 mm Y-axis: 250 mm Drive power: 2 kWApprox. Onsite Dimension. (l x w x h): 1,000 x 1,000 x 2,300 mm, weight approx.: 600 kg
used
Description: Machine number: 1860 Spindle speed: 710 - 2840 rpm Operating voltage: 380 V Frequency: 50 Hz Table dimensions: 1200 x 700 mm With 6 grooves Travel distances: X: approx. 900 mm Y: approx. 500 mm Z: approx. 700 mm The machine is equipped with a digital display from the manufacturer HEIDENHAINApprox. Onsite Dimension. (l x w x h): 2,400 x 2,300 x 2,500 mm, weight approx.: 3,000 kg
used
Description: Table dimensions: 1200 x 700 mm With 6 grooves Travel distances: X: approx. 500 mm Y: approx. 500 mm Z: approx. 700 mm The machine is equipped with a three-axis digital readout from the manufacturer HEIDENHAIN Spindle speed: 45 - 2800 rpmApprox. Onsite Dimension. (l x w x h): 2,200 x 2,000 x 2,400 mm, weight approx.: 4,000 kg
used
Description: Table dimensions: 1200 x 700 mm With 6 grooves Spindle speed: 45 - 2800 rpm Travel distances: X: approx. 700 mm Y: approx. 500 mm Z: approx. 700 mm The machine is equipped with an ANILAM digital displayApprox. Onsite Dimension. (l x w x h): 2,400 x 2,300 x 2,500 mm, weight approx.: 3,000 kg
used
Description: Documentation available A second machine as a spare parts carrier is included in the package Approx. Onsite Dimension. (l x w x h): 2,200 x 1,900 x 2,200 mm, weight approx.: 2,300 kg
used
Description: BRIDGEPORT Milling MachineApprox. Onsite Dimension. (l x w x h): 1,300 x 1,400 x 2,100 mm, weight approx.: 940 kg
used
Description: Table dimensions: 610 x 260 mmApprox. Onsite Dimension. (l x w x h): 1,200 x 900 x 1,800 mm, weight approx.: 800 kg
used
Description: Groove width 16 mm x-travel 1000/1500 mm Projection 200 mm y-travel 150 mm z-travel 150 mm Spindle mount ISO 40 Spindle drive 3 kW Spindle speeds 300 - 3600 rpm Quill stroke 150 mm Quill diameter 100 mm Table surface 1800 x 250 mm Total power requirement 9.5 kW CNC Siemens 810 M 4-fold tool changer mounted on the table dividing apparatus various recordingsApprox. Onsite Dimension. (l x w x h): 3,500 x 2,700 x 2,500 mm, weight approx.: 2,700 kg
used
Description: Table dimensions: 650 x 250 mm Universal table dimensions: 300 x 200 mm Head travel: 400 mm Quill travel: 100 mm Cross stroke: 200 mm Spindle speeds: 350 - 3500 rpm Projection: 200 mm Drive: 9 kWApprox. Onsite Dimension. (l x w x h): 1,300 x 800 x 1,900 mm, weight approx.: 1,500 kg
used
CME FU2 universal milling machine. Table: 1400x300mm. Longitudinal travel: 1050mm. Cross travel: 300mm. Vertical travel: 500mm. ISO40. Hure head. Speeds range: 12. (40-1800rpm). Motor power: 7,5Kw. DRO Fagor for 3 axis.
used
Description: SPECIFICATIONS Character: Comu Type: B 1000 Order: Fagor Table length: 1,520 mm Table width: 425 mm X: 1,000 mm Y: 500 mm Z: 500 mm Speed: 400-4000 rpm Intake: ISO 40Approx. Onsite Dimension. (l x w x h): 2,500 x 2,800 x 2,600 mm, weight approx.: 3,600 kg
used
Universal tool milling machine DECKEL FP 1 with 3 axis active digital display Heidenhain TNC 113 Year of construction: 1987 Travel: X 300 Y 160 Z 340 Speed range: 40 – 2000 rpm With the following accessories: Universal table 600 mm x 250 mm clamping surface Movable vertical milling head Extendable drill quill Infinitely variable feed via potentiometer 1 machine vice 1 counter holder with counter bearing 1 pc. milling mandrel long 0 22 mm Various tool holders S 22 x 2 Bellows Z Axis Machine light Automatic central lubrication pump Chip collection plate Coolant system Operating instructions THE MACHINE IS IN VERY GOOD CONDITION
used
CONTROLS CNC controls DECKEL DIALOG 4 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 3 X-axis travel: 400 mm Y-axis travel: 320 mm Z-axis travel: 400 mmTABLE table surface (left-right): 700 mm table surface (front-back): 460 mm workpiece load (max): 350 kgSPINDLE / HEAD spindle revolutions (min): 63 /min spindle revolutions (max): 6300 /minAXIS DRIVES feed velocity (min): 2 mm/min feed velocity (max): 3600 mm/min rapid traverse: 4000 mm/minELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 3200 mm space requirements -front/back-: 3200 mm total weight approx.: 2000 kg
used
DECKEL Tool Milling Machine – Bed Milling Machine Type. FP 33 (no KLOPP; RECKERMANN) built approx. 1975 Condition: exceptionally good Table clamping surface: approx. 1200 x 640 mm Longitudinal travel: 1,000 mm Transverse travel: 400 mm Vertical travel: 600 mm Speed range: 31.5 – 1,600 rpm. Locker cone: SK 50 Spindle power: 5.5 kW Feed rates: 8 – 400 mm/min. Rapid traverses: 1600 mm/min. Approx. dimensions: 3,000 x 2,000 x 2,600 mm Weight: approx. 4,500 kg The machine is suitable for repair operation; Repair, toolmaking, Machining of large parts with heavy-duty machining Accessories: Digital; Electric hoist load capacity 500 kg, on swivel arm; coolant device; Central lubrication, adjusting shoes Price net plus VAT plus loading costs ...
used
x-travel: 300 mmy-travel: 150 mmz-travel: 340 mmtable-size: 600x260 mmspindle taper ISO: 40 spindle turning speed range: 40-2000 U/minweight of the machine ca.: 0.7 tVisit us on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
- X: 300 mm - Y: 150 mm - Z: 340 mm - Clamping surface: 600 x 210 mm - Speed range: 40 - 2000 rpm - Spindle mount: SK 40 - Spindle drive: 1.7 kW - Digital display: 3-axis DITRON Digital - Total power: 1.7 kW - Machine weight: 830 kg - Space requirements (W x D x H): 1.2 x 0.9 x 1.7 m - Condition: good Details good condition, ready for immediate use Accessories Counter holder, dividing head
used
fully functioning used 3 axis milling machine, brand lid, type FP2, with vice, and many accessories.
used
with digital read-out: Activ make: HEIDENHAIN for axes: 3 x-travel: 500 mmy-travel: 400 mmz-travel: 400 mmhorizontal milling head:: tool taper: ISO 40 vertical head:: tool taper: ISO 40 vertical movement of the milling spindle: 90 mmspindle turning speed range: 50-2500 U/minnumber: 18 feed stepless: 6.3-630 mm/minrapid motion -longitudinal/cross/vertical: 1.3 m/mintotal power requirement: 3.7/4.4 kWdimensions of the machine ca.: 1.3x2.0x2.0 mweight of the machine ca.: 1.8 tfixed working table:surface area: 800x460 mmvice: jaw width: 125 mmcollet chuck: 1 number of collets: 11 boring chuck: 1 milling arbors: 7 coolant: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: SPECIFICATIONS Feature: Deckel Type: FP5NC CNC Control: Dialog 4 Year of construction: 1986 Sheet size: 1,000 x 500 mm Spindle top name: ISO 40Approx. Onsite Dimension. (l x w x h): 2,300 x 3,800 x 2,500 mm, weight approx.: 6,000 kg
used
Milling machine from a training workshop in very good condition Manufacturer lid Type FP1 Active
used
Machine : Vert. Head Make : DECKEL, MAHO, WMW, ... Are all swivel and with quill ! A - Universal milling head, COVER, from FP3, SK40, with quill stroke 80mm, tool clamp with hydraulics and control panel. swivel, price: 1400,- B - Universal milling head, MAHO, SK40, with quill and autom. Tool clamping, swivelling, L-33cm, W-30, H-60, swivel device, flange φ approx. 250mm Price : 1600,- Would also have milling spindles - SK30 - SK40
used
Digital display Heidenhain. Carriage travel range Sledge travel longitudinal (X) 450 mm Sledge travel transverse (Y) 300 mm Sledge travel vertical (Z) 350 mm Clamping surfaces 800 x 400 mm Tool holder SK 40 Quill stroke 100 mm Swivelling vertical milling head ± 90° Speed range 50-2500 rpm Dimensions: Length 1485 mm Width 1475 mm Height 1475 mm Weight approx. 1500 kg
used
Description: Prism support length 500 mm Cutter head cutter diameter approx. 100 mm Speed range 1500 to 4500 rpm Table travel distance approx. 550 mmApprox. Onsite Dimension. (l x w x h): 900 x 400 x 600 mm, weight approx.: 60 kg
used
X-axis: 775 mm Y-axis: 250 mm Z-axis: 425 mm Table dimensions: 1100 x 240 mm Spindle Holder: ISO40 Spindle speeds: 48 - 1500 rpm. Equipped with: - Feed on all axes -Vice -Cap - Milling tools - Useful storage - Horizontal spindle Motor power: 2.2 kW Country of origin: Spain Machine LxWxH: 1600 x 1300 x 1600 mm Machine weight: 1200 kg
used
Technical data of the FPT Pragma M40 mobile column milling machine used: Longitudinal travel: 4000 mm Vertical travel: 1600 mm Transversal travel: 1200 mm Working feeds: 0-15000 mm/min Fast feed: 30000 mm/min Maximum thrust on axes (X,Y,Z): 2000 from N Spindle motor power (continuous service S1): 28 kW 38 hp Spindle motor power (intermittent service S6-60%): 35 kW 47,6 hp Constant torque spindle speed range: 0-312.5 g/min Spindle speed range at constant power. 312.5-5000 rpm Maximum spindle torque (continuous service S1): 856 Nm Maximum spindle torque (intermittent service S6-60%): 1070 Nm Supply voltage: 50Hz Current consumption: 119,2A Total installed power: 65 kW 88,4hp
used
Description: Cross table, voltage 380 V, serial number 70546, without further accessories and without CE certificateApprox. Onsite Dimension. (l x w x h): 1,200 x 800 x 1,500 mm, weight approx.: 120 kg
used
- workpiece diameter d680 - max workpiece length 3400 mm - max working lengths 2600 mm - with discs (d1100 mm) - required electric capacity 60 kW/h - under power, in use
used
Universal milling machine Speed 90 - 2000 rpm x 650 mm Y 300 mm Z 400 mm Feed rate in x electric Coolant pump Accessories Weight 1 ton
used
Description: Drilling and milling machine with Powerful 2-speed motor. Recording MC 3 - B16. Drill chuck 3 - 16 mm. Left/right switch. Spindle protection. Fine tuning. ejection wedge. Clamp the threaded rod for the tool Related tools. Drilling capacity in steel 32 mm Projection 200 mm Drilling stroke 70 mm Capacity of the end mill 16 mm Spindle mount MK3 Spindle speeds 50 - 3000 rpm Table adjustment transversely 220 mm Table adjustment lengthwise 425 mm Table clamping surface 700 x 210 mm Connection voltage Vmax. Distance between work table and spindle nose 470 mm Total power requirement 1.5 kW Machine weight approx. 230 kg Space requirement approx. 0.75 x 1.05 x 1.2 mApprox. Onsite Dimension. (l x w x h): 750 x 1,050 x 1,200 mm, weight approx.: 230 kg
used
Description: Drilling and milling machine with - Cross Support - Feed via hand crank - Chip protection - 16mm drill chuck - mechanical MK tool clamping Drilling capacity in steel (diameter) 16 mm Projection 180 mm Drilling stroke 85 mm Spindle mount MK 2 Spindle diameter 47 mm Spindle speeds 320 - 3300 rpm Table adjustment across 230 mm Table adjustment along 100 mm Table mounting surface 420 x 155 mm Connection voltage 230V Total power requirement 0.75 kWApprox. Onsite Dimension. (l x w x h): 900 x 600 x 300 mm, weight approx.: 80 kg
used
x-travel: 510 mmy-travel: 450 mmz-travel: 410 mmtable-size: 800 x 390 mmspindle taper ISO: 40 turning speed range - vertical: 50 - 2500 U/minquill stroke: 80 mmspindle drive: 3 KWweight of the machine ca.: 1,4 tdimensions of the machine ca.: 1,6 x 1,6 x 1,95 mNC tool milling machine- Heidenhain TNC 114B- hydr. Tool clamping- Machine light- Coolant deviceThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Universal milling machine Hermle UWF801 Year of construction ca 1990 Active Digital Display Heidenhain TNC114 Travel: X-travel: 500 mm Y-travel: 430 mm Z-travel: 400 mm Spindle holder ISO: SK40 Control: TNC 114 Spindle head swivels left and right: right/left = 90° ° Quill stroke vertical: 80 mm Speed range: 50 - 2500 / 18 rpm Feed rate: X/Y: 4 - 1600 mm/min Feed rate: Z: 4 - 1000 mm/min Rapid traverse: X/Y: 1.6 Rapid traverse Z: 1 m/min Spindle drive: 3 kW Weight approx.: 1500 kg Dimensions: LxWxH: 1.6 x 1.5 x 1.8 m Accessories/Equipment: - Angle table - Fixed table (table size: 800 x 395 mm) -Operating instructions - Machine feet - 4pcs tool holders - Chip drip tray - Hydraulic tool clamping - Coolant device - Machine light The machine has been technically tested and is fully functional Spindle concentricity 0.004mm Reversing ...
used
Table dimensions: 800 x 220 mm X-axis: 510 mm Y-axis: 450 mm Z-axis: 410 mm Spindle Adapter: ISO40 Speed range: 45 - 2000 rpm. 3-axis digital readout: Heidenhain Equipped with: - Spindle drill quill - Machine clamping - ISO recordings Country of origin: Germany Engine Power: Machine weight: 1400 kg Machine LxWxH: 230 x 230 x 170 cm
used
Machine type milling machine - universal brand HURON type MU 5 year 1975 control type conventional storage France country of origin France delivery immediately cargo base camp, free truck Technical details x way 1300 mm y path 700 mm z-way 550 mm table size 1500 x 460 mm spindle speeds 15-2500 RPM spindle retainer for SK 40 feed range x - direction 1,6-820 mm / min feed Empire z-direction 1,6-820 mm / min rapid traverse X + Z - axes 2.8 m/min rapid traverse y - direction of 2.8 m / m in power - spindle motor 10 kW total power 14 kW machine weight approx. 4.6 t additional information good condition with 3 axis of DIGITAL HEIDENHAIN SK 40 BUILT IN 1975
used
Description: Equipment: - Digital display - Horizontal spindle - Quill with hand feed - motor feed for X - Left/right running - Emergency stop switch - Drill head swiveling - Spindle protection - Machine light Drilling capacity in steel 25 mm Drilling stroke 150 mm Spindle mount ISO 40 Spindle speeds vertical 115 - 1750 mm Table adjustment transversely 600 mm Table adjustment lengthwise 350 mm Table adjustment vertical 350 mm Table clamping surface 800 x 240 mm Connection voltage 400 V Total power requirement 1.5 kW Machine weight approx. 0.7 t Space requirement approx. 1.6 x 1.4 x 2.1Approx. Onsite Dimension. (l x w x h): 1,600 x 1,400 x 2,100 mm, weight approx.: 700 kg
used
x-travel: 860 mmy-travel: 250 mmz-travel: 450 mmturning speed range - vertical: 50 - 1700 U/minmilling-head swivable +/-: Huronkopf spindle taper ISO: SK40 table surface area: 1100 x 250 mmtotal power requirement: 4,2 kWweight of the machine ca.: 1,4 tdimensions of the machine ca.: 1,7 x 1,4 x 1,8 mUniversal tool milling machine- Digital display- Central lubrication- Coolant system- Vise- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Sold without vice and accessories! Recording set, are not included in the price, but can be sold against bidding! The machines can be inspected by arrangement, be tried out and demonstrated! Shipping by Forwarding possible
used
Precision Deburring Faceting Milling Machine / Edge Milling Machine Specifications: Steel – stainless steel – aluminium – plastic – machining Deburring and faceting process is carried out with milling cutter Support angle - facet angle tiltable Facet angle adjustment 15 to 45 ° Facet width infinitely adjustable 0 to 7 mm Length of guide strip 500 mm Speed 2750 rpm Drive 400 V / 0.7 kW Space requirement approx. W 650 x D 600 x H 950 mm Weight approx. 30 kg
used
Condition depreciated, ready for use Horizontal manually swivelling spindle Travel X-axis :: 1,500 mm Y-axis travel : 500 mm Z-axis travel: 450 mm Digital Display :3 Axes Glass scales : 3 axes Tool holder: SK 50 Spindle speed: 28-1,400 rpm Input power: 9.2 kW Feed: infinitely variable Coolant basin and pump Tool holders Tools Weight approx.: 5.000kg Dimensions LxWxH approx.: 2,900 x 2400 x 2,400mm Space requirement LxW approx.: 4,400 x 2,400 mm
used
5 pcs. end mill MK , various , incl. SK50 mount For boring mill MK or milling machine SK50 , See also our post End Mills !
used
Description: 960 rpm, table approx. 900 x 300 mmApprox. Onsite Dimension. (l x w x h): 1,200 x 1,500 x 1,800 mm, weight approx.: 2,500 kg
used
Description: Table clamping surface: 2100 x 500 mm Max. table load capacity: 2000 kg T-slots, number: 4 pieces T-slots, distance: 100 mm T-slots, width: 20 mm Travel distances: X-axis: 1500 mm Y-axis: 670 mm Z-axis: 670 mm Vertical milling head: Spindle speed (vertical): 35 - 1345 rpm Spindle holder: ISO 50 Projection: 610 mm Distance vertical spindle - table surface: 670 mm Swivel range of milling head: 360 degrees Rapid traverse: X-axis: 3500 mm/min Y-axis: 3500 mm/min Z-axis: 1750 mm/min Feed speed: X-axis (infinitely variable): 20 - 1800 mm/min Y-axis (infinitely variable): 20 - 1800 mm/min Drive power: Main drive: 7.5 kW Feed: 2 kW Coolant pump: 0.55 kW Without further accessoriesApprox. Onsite Dimension. (l x w x h): 3,300 x 2,380 x 2,750 mm, weight approx.: 7,300 kg
used
Description: Travel distances: X-axis: 400 mm Y-axis: 380 mm Z-axis: 250 mm Spindle speeds: 50 - 1630 rpm Table dimensions: 800 x 250 mm Attention: Machine screw base is not part of the article!Approx. Onsite Dimension. (l x w x h): 1,400 x 1,100 x 2,100 mm, weight approx.: 1,000 kg
used
Description: Includes: Digital display Tool holder: SK40 Automatic feed in three axes Drill sleeve: 50 mm Rotating head Spindle speed: 45 - 1950 rpm Travel paths: X-axis: 310 mm Y-axis: 180 mm Z-axis: 310 mm Table dimensions: 600 x 250 mm Infinitely variable feed speed: 10 - 470 mm/min Power connection: 400 V, 10 AApprox. Onsite Dimension. (l x w x h): 1,100 x 1,000 x 1,600 mm, weight approx.: 800 kg
used
Description: Digital display: 3 axes Angled table dimensions: 800 x 340 mm Travel distances: X-axis: 500 mm Y-axis: 340 mm Z-axis: 500 mmApprox. Onsite Dimension. (l x w x h): 2,200 x 1,800 x 2,100 mm, weight approx.: 1,200 kg
used
x-travel: 600 mmy-travel: 410 mmz-travel: 200 mmturning speed range - horizontal: 30 - 1280 U/minturning speed range - vertical: 50 - 2150 U/minmilling-head swivable +/-: 90° spindle taper ISO: SK40 table surface area: 1000 x 315 mmtotal power requirement: 3,2 kWweight of the machine ca.: 1,44 tdimensions of the machine ca.: 1,6 x 1,7 x 2,1 mUniversal tool milling machine- Digital display- horizontally milling device- Coolant system- Vise- Operation manualThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
