Punching machine Trumpf TruMatic TC3000-1300 FMC Year of construction 2004 87500 hours (03.2021) In this case, the configuration : TruMatic TC3000-1300 FMC Year of construction 2004 Working range : 2550 x 1280 mm Standard: • Sturdy C-frame • Coordinate guidance with integrated linear magazine, 21 seats for tools and clamps • 2 clamps • Drives: Maintenance-free digital three-phase servo motors • Punching head: hydraulic system with closed control loop, hydraulic mono tool holder, 360° rotation for all Tools, automatic tool length compensation, programmable scraper movement • Programmable hold-down • Tool spray lubrication • Punch butt suction • Partial slide 500 x 500 mm • Control Bosch PNC-P, activity-oriented user interface, Online Help, Diagnostics, 3.5" Floppy Drive, RJ45 Network Connection • Graphics programming ToPs 2000 • ToP ...
1250 x 2500mm TLF 2000w Laser STOPA Sheet storage, SheetMaster, ToolMaster, SortMaster Year: 2005
Manufacturer TRUMPF Type L 3030 Year of construction 2005 Working range 3,000 x 1,500 x 115 mm Control Siemens Sinumerik 840D Laser power 2,700 watts Accuracy +/- 0.1 mm Equipment: Rotolas Closed machine frame PCS Automatic pallet changer Longitudinal conveyor belt for small parts/waste Laser Power Control Control Siemens: Open PC-based controller, simple operation, online help, diagnostic functions, maintenance hole book, technological data, teleservice Safety: Multi-beam photoelectric sensors, beam guidance fully encapsulated and ventilated, monitoring system, multi-chamber extraction and compact dust collector, protective cabin DIAS height control Automatic focus position adjustment AutoLas Plus Network connection (RJ45) by installation via teleservice The machine is in good condition. Location Germany, visit by appointment. Errors in the technical data and pri ...
220 V, 9.6 A, 2000 W MAXIMUM CHAMFER LENGTHS MAXIMUM CHAMFER LENGTH STEEL 400 N/MM² 15 mm MAXIMUM CHAMFER LENGTH STEEL 600 N/MM² 9 mm MAXIMUM CHAMFER LENGTH STEEL 800 N/MM² 6 mm RADII SMALLEST RADIUS 55 mm GENERAL WORKING SPEED 2 m/min STROKE RATE AT NOMINAL LOAD 370 1/min RATED POWER 2600 W SHEET THICKNESS 4 mm - 160 mm WEIGHT WEIGHT WITH HANDLE, WITHOUT CABLE 16.5 kg As good as new. Condition
Press brake TRUMPF TrumaBend V 85 Year of construction 1999 Machine specifications: working length 2050 mm - Stand passage 1750 mm - pressing force 850 kN - Distance table / plunger 410 mm - Stand projection 410 mm - Plunger stroke 285 mm - Lifting speeds - Downward speed rapid path 200 mm/sec - Upward speed 135 mm/sec - Downward press speed 1 - 11 mm/sec - Total drive power 13 kVA - Space requirement approx.B 3700 x H 2700 x D 2100 mm - Weight approx. 8000 kg
TECHNICAL DATA: Working area 3,000 x 1,500 x 115 mm Control Siemens Sinumerik 840 D Laser power 5,000 watts Max. sheet thickness structural steel 25 mm Max sheet thickness stainless steel 20 mm Max sheet thickness aluminium 12 mm Machine regularly serviced by TRUMPF! Standard: - Closed machine frame with integrated laser unit - TRUMPF laser TLF 5000 - Laser unit: CO2 laser, high-frequency excited, maintenance-free turboradial blower, cooling unit, logbook function - Automatic pallet changer and longitudinal conveyor belt - Drives: Gantry drive in combination with linear direct drives - Laser power control - Position laser diode - HI-LAS high-pressure cutting - Plasma sensor inges, PMS - Automatic sheet metal edge detection - Programmable performance cycles - Microweld - Automatic nozzle cleaning - Fast editing with SprintLas - ContourLas for making small ho ...
3000 x 1500mm / 5000w / Siemens 840 - Single Head Technology
3000 x 1500mm Truflow 5000w Auto nozzle changer Auto pallet changer
Servo Electric punching head Large format 3000 x 1500mm With Sheet Master & Duplex carts Year: 2015 Just under 19,000 hours! With tooling
Welding edge shaper Offer number: 20120 Make: TRUMPF Type: TKF 103 Machine Number: 454106 Built: ca.1992 Technical data: min. / max. material thickness 3 - 25.0 mm max. bevel length steel 400N/mm2 10 mm max. bevel length steel 600N/mm2 8 mm max. bevel length steel 800N/mm2 5 mm Working speed approx. 2.5 m/min Stroke number 400 rpm Drive 400 V / 2000 Watt Space requirement approx. W 550 x D 200 x H 300 mm Weight approx. 13 kg
Laser cutting machine Trumatic L3030 Manufacturer: trump BJ: 2005 Max workpiece length ... 3000mm Max. workpiece thickness ... 1500mm Max sheet thickness ... 12mm Laser power ... 2000w Total power demand ... 71kVA Machine weight ... 11500kg L x W x H ... 9800x5300x2000mm The machine is in good condition, possible to test under power.
For sale is a laser cutting machine TruLaser 3530. technical data: Additional details - Operating hours: Beam-On 2030 h/Laser-On 9814 h - X travel distance 3000 mm (max. 3104) - Y travel distance 1500 mm (max. 1580) - Xp travel 300 mm (max. 305 mm) - Z-travel distance 114 mm - maximum material thickness 20 mm - maintenance-free three-phase motors in X1, X2, Xp, Y1, Y2 and Z axes - maximum positioning speed axle parallel 120 m/min - Simultaneous 170 mm/min. - Acceleration when positioning X-axis 9 m/second - Xp + Y axis 15 m/second - Cutting X-axis 4 m/second - Cutting Xp and Y axis 15 m/sec. Standard - Closed machine frame with integrated laser resonator - Movement unit for optimal processing speeds - Additional highly dynamic Xp axis - Automatic pallet changer - Closed beam guide - NitroLine, high-pressure cutting - FocusLine, constant focus position - Comp ...
TECHNICAL DATA: Working range: 2,500 x 1,250 x 115 mm Control: Siemens Sinumerik 840 D Laser power: 2,000 watts Max sheet thickness structural steel: 20 mm Max sheet thickness stainless steel: 12 mm Max sheet thickness Aluminium: 8 mm STANDARD EQUIPMENT: â?¢ Closed machine frame with integrated laser unit â?¢ TRUMPF laser TLF 2000 â?¢ Laser unit: CO2 laser, high-frequency excited, cooling unit, logbook function â?¢ Automatic pallet changer and laengsfoerder tape â?¢ Drives: maintenance-free three-phase servo motors â?¢ Laser power control â?¢ HI-LAS high-pressure cutting â?¢ Plasma sensors PMS â?¢ Fast processing with SprintLas â?¢ ContourLas for the production of small loechers â?¢ Cutting gas pressure adjustment programmable â?¢ La ...
TECHNICAL DATA: Work area: 2,500 x 1,250 x 115 mm Control: Siemens Sinumerik 840 D Laser power: 3,200 watts Maximum sheet thickness mild steel: 20 mm Maximum sheet thickness stainless steel: 12 mm Maximum sheet thickness aluminium: 8 mm STANDARD equipment: -Closed machine frame with integrated laser unit -Automatic pallet changer -TFT color display -Position laser diode -Spraying device -Motion unit for high-precision machining -Additional highly dynamic axis YP -Drives with maintenance-free AC servo motors -Closed beam delivery -Conveyor for small parts and waste -NitroLine -FlyLine -Infeed end detection TRUMPF LASER: -CO2 laser TruFlow 4000 -High-frequency excitation -Maintenance-friendly Turbo centrifugal blower -Gas mixer (integrated) -Laser power control -Logbook function laser CUTTING HEAD: -Laserschneidopf with 5 "lens -Laserschneidopf ...
Alternative, new box bellows for Trumpf L3030 Siemens -from German production (it is not an original by Trump) -Y-axis (C) -Mapping: Trump ID: 1667805 / 939016 -New part
Trumpf cutting head 3.75 inch Trump ID: 911218 / 1261653 -used cutting head, technically and visually in very good condition suitable for Trumpf L3030/3050/3530/4030/4050/6030/6050
Control system: TRUMPF Power on: 35071 h Cutting time: 14638 h Laser power: 3 kW Table dimensions: 3000 x 1500 mm Travel distances: X: 3000 mm Y: 1500 mm Z: 115 mm Max. Thickness of material Mild steel: 20 mm Stainless steel: 12 mm Aluminum: 8 mm Machine dimensions: 9300 x 4600 x 2200 mm Machine weight: 12000 kg
Trumpf TKF 103 welding edge shaper. 220 Volt under electricity ready for use Special price
This 3-axis TRUMPF TruLaser450 was manufactured in 2006. It features a working area of 4000 x 2000 x 115 mm and a powerful 5000 W CO2 laser. The machine includes advanced automation with an automatic pallet changer and various cutting heads for high-speed and thick sheet cutting. If you are looking to get high-quality laser cutting capabilities, consider the TRUMPF TruLaser450 CO2 laser cutting machine we have for sale. Contact us for further details.
This 3-axis TRUMPF TruLaser L3050 was manufactured in 2003. It features a powerful TRUMPF TLF 5000 CO2 laser with a capacity of 5 kW, making it suitable for various cutting applications. The machine has been connected to power and is fully operational, with a history of maintenance ensuring reliability. If you are looking to get high-quality laser cutting capabilities, consider the TRUMPF TruLaser L3050 machine we have for sale. Contact us for further details.
This 6-axis TRUMPF TrumaBend V130 was manufactured in 2000. It features a bending length of 3,000 mm and a pressing force of 130 t. If you are looking to get high-quality bending capabilities, consider the TRUMPF TrumaBend V130 press brake we have for sale. Contact us for further details.
CNC punching machine manufactured in 2008. This TRUMPF TruPunch 5000 features a punching force of 220 kN and offers multifunction capabilities, including multi-shear, multi-bending, and thread-forming functions. It also incorporates deburring and rolling technology, along with a small-part sensor for programmable part guidance. If you are looking to get high-quality punching capabilities, consider the TRUMPF TruPunch 5000 machine we have for sale. Contact us for further details.
- CNC Crowning - Hydraulic MODUFIX Tool clamping - Hydraulic lower tool clamping - CNC Finger Backgauge Z1 and Z2 - 6 Axis backgauge X1/X2, R1/R2 and Z1/Z2 - Network card BNC-with RJ-45 Connector - ToPs 600 Software - Set Tooling
TRUMPF HL 54 P is a Impuls Schweissanlage, entwickelt für präzise, hochgenaue und zuverlässige Anwendungen. Arbeitskapazitäten nicht angegeben. Leistungsaufnahme 2.5 kW; Anschluss 50 Hz 3x 400 V; Gewicht ca. 220 kg; Abmessungen L600×B1020×H840 mm. Keine spezifischen Zubehörteile aufgeführt. Ermöglicht enge Toleranzen; typische Bereiche: Automotive, Luftfahrt, Uhren, Medizintechnik, Werkzeugmaschinen. Technische Daten ohne Gewähr
CNC punching machine manufactured in 2012. This TRUMPF TruPunch 3000 features a punching force of 18 tons and a maximum sheet thickness of 6.4 mm. The working area measures 3,000 x 1,500 mm, making it suitable for various applications. If you are looking to get high-quality punching capabilities, consider the TRUMPF TruPunch 3000 machine we have for sale. Contact us for further details.
Standard configuration Machine ⦁ Stable machine frame as all-steel construction ⦁ Ram, stress relief annealed: Highly resistant to torsional forces, of ample size ⦁ Spherical ram suspension, with ram tilt ⦁ Electro-hydraulic downstroking drive with 4-cylinder technology ⦁ Modern block hydraulics with control valves mounted on the cylinder ⦁ Electronic pressure balance ⦁ Measuring system ⦁ Control panel with LCD panel, footswitch für Emergency up, down and E-STOP ⦁ Oil cooler ⦁ Switch cabinet cooling (air-air heat exchanger) ⦁ Modern machine design Backgauge system ⦁ Backgauge system 2-axes ⦁ 2 pieces back gauge fingers Tool holder ⦁ Manual upper tool clamping ⦁ Hydraulic lower tool clamping Crowning ⦁ Manual crowning Lower tool shifting ⦁ Lower Tool Adjustment Safety ⦁ Standard Safety equipment: Emergency Stop button, manual roller shutte ...
Standard configuration Machine ⦁ Stable machine frame as all-steel construction ⦁ Ram, stress relief annealed ⦁ Spherical ram suspension, with ram tilt ⦁ Electro-hydraulic downstroking drive with 4-cylinder technology ⦁ Modern block hydraulics with control valves mounted on the cylinder ⦁ Electronic pressure balance ⦁ Measuring system ⦁ Hydraulic oil filled in the machine (lifetime lubrication) ⦁ Oil cooler ⦁ Switch cabinet cooling (air-air heat exchanger) ⦁ Modern machine design Backgauge system ⦁ Backgauge system 2-axes Tool holder ⦁ Manual upper tool clamping ⦁ Shifting: programmable Crowning ⦁ Manual crowning: Integrated in the table, manual adjustable crowning via wedges Lower Tool Adjustement ⦁ Lower tool adjustment CNC, programmable Safety ⦁ Standard Safety equipment Control ⦁ TRUMPF TASC 6000 Operation ⦁ Communication Track ...
