Model
(Manufacturer: SPINNER)
This 3-axis SPINNER VC 750 was manufactured in 2013. Ideal for precision CNC milling, this machine offers robust performance and reliability. Consider the opportunity to buy this SPINNER VC 750 CNC milling machine. Contact us for more information.
This 5-axis SPINNER U-1520 was manufactured in 2012. It features a Heidenhain iTNC630 control, a 3D measuring probe, and both internal and air cooling systems. The machine includes an 89-position tool changer with travels of X=1520mm, Y=700mm, and Z=600mm. If you are looking to get high-quality milling capabilities, consider the SPINNER U-1520 machine we have for sale. Contact us for more information.
Offered is a CNC lathe (sub-spindle, milling/C-axis, Y-axis). Equipped with bar feeder for balls 120mm, incl. Fanuc six-axis robot M-16iB with R-30iA control for automated loading and unloading as well as a bunker for raw material supply. Machine is operational. Inspection possible by prior arrangement.
x-travel: 1520 mm y-travel: 520 mm z-travel: 420 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Sinumerik 840D NC-swivel-rotary table (B-axis and C-axis) automatic tool changer for 30 tools coolant device chip conveyor Technische Daten / technical details: X-Weg / X-travel 1520 mm Y-Weg / Y-travel 520 mm Z-Weg / Z-travel 420 mm B-Achse Schwenktisch / B-axis swivel table -90 - +110 ° C-Achse Rundtisch / C-axis rotary table 360 ° NC-Schwenk-Rundtischdurchmesser / NC swivel-rotary table diameter 500 mm Starrtischaufspannfläche / fixed table clamping area 920 x 540 mm Spindelaufnahme / spindle taper SK40 Drehzahl Spindel / spindle speed 12000 Upm /rpm Eilgang / rapid feed 32 m/min Antriebsleistung Spindel / drive capacity spindle 25 kW Gewicht der Maschine ca. / weight 10500 kg Technische Daten, Zubehör un ...
Turning diameter: 120mm, turning length: 400mm, travel X/Z: 400mm/400mm, spindle bore: 42mm, speed: 8000rpm, chuck diameter: 150mm, tool stations: 12, tool interface: VDI 20. Machine dimensions X/Y/Z: approx. 2500mm/1400mm/1700mm, weight: approx. 2500kg. Documentation available. On-site inspection is possible.
turning diameter: 250 mm turning length: 600 mm control: FANUC Series 31i-Model A travel -x axis: 180 mm travel -y axis: +/-45 mm - - - - - Main spindle - - - - -: - - - - - - turning speeds: 0 - 5.000 U/min bar capacity: 65 mm --- Subspindle ---: - - - - - - turning speeds: 0 - 7.000 U/min bar capacity: 42 mm --- upper turret 1 ---: - - - - - - numbers of positions in the tool changer: 12 tool taper: BMT 45 Number of axles: X1 / Y1 / Z1 St. Tools speed: 8.000 U/min --- upper turret 2 ---: - - - numbers of positions in the tool changer: 12 tool taper: BMT 45 Tools speed: 8.000 U/min Number of axles: X3 /Y3 / Z3 St. --- lower turret 3 ---: - - - numbers of positions in the tool changer: 12 tool taper: BMT 45 Number of axles: X2 / Z2 St. Tools speed: 8.000 U/min CNC Turning- and Milling Center | SPINNER - TTS 65 Triplex equipped with a main spindle and a sub-spindle, each including a C-axi ...
A lathe (Universal Turning Solution) is offered, control: Fanuc, tool turret: 12-station, tailstock, 3-jaw chuck. Tool setting arm: Renishaw HPRA. Inspection is possible by arrangement.
A CNC milling machine Spinner is available. Travel X/Y/Z: 760mm/460mm/460mm, table dimensions X/Y: 900mm/410mm, max workpiece weight: 350kg, tool stations: 24, max tool weight: 8kg, max tool length: 200mm, speed: 12000rpm, max tool diameter: 80mm, tool holder: SK40. Machine dimensions X/Y/Z: approx. 2600mm/1600mm/2850mm, weight: approx. 4000kg. Including automation and robot M10. Documentation available. An on site inspection is possible.
turning diameter: 310 mm turning length: 600 mm control: Sinumerik 810 D PL Siemens turning diameter over bed: 425 mm Main spindle: turning speed range - main spindle: 500 - 4.500 min/-1 max. Torque: 280 Nm power capacity - main spindel: 16,5 kW Spindle diameter: 100 mm C-Axis: 360 ° chucking diameter: 210-52 mm spindle bearing diameter: 120 mm clamping cylinder: 65 mm Bar feed: max. 65 / (52) mm spindle nose: A8 DIN 55026 axis stroke:: x-axis: 230 mm z-axis: 740 mm rapid traverse X-axis: 15 m/min rapid traverse Z-axis: 24 m/min turret:: tool positions turret: 12 pos. driven statition: 12 pos. tool taper: VDI 30 DIN 69880 Spindle speed driven tools: 6.000 min -1 power capacity - driven tools: 3,7 kW max. Torque: 9,5 Nm tail stock: dia. of quill: MK 4 80 mm quill stroke: 120 mm tailstock adjustment: 475 mm tension force: 500 daN total power requirement: - kW weight of the machine ca. ...
Manufacturer: SPINNER Model: SERVO - LOAD 80 - 1200 Year of Manufacture: 2011 Voltage (U): 3/PE ~ 400 V Frequency (f): 50/60 Hz Input Current (Iᵍ): 5 A Fuse Rating (Iₙ): 10 A Find more here - / Contact us at -
X1-/ X3-axis: 180mm, X2-axis: 180mm, Y1-/ Y3-axis: ±45mm, Z1-/ Z3-axis: 704mm, Z2-axis: 620mm, E2-axis: 720mm, rapid traverse X, Y, Z-axis: 30m/min, spindle 1: max. speed: 5000/min, spindle bore: 65mm, chuck diameter: 210mm, spindle 2: max. speed: 7000/min, spindle bore: 42mm, max. chuck diameter: 140mm, spindle nose diameter: 110mm, max. chuck jaw weight: 1.25kg, number of stations: 2x12, number of driven tool stations: 2x12, max. speed: 8000/min, power S3 25%: 4.3kW, torque S3 25%: 13.6Nm. Length: 2880mm, width: 2130mm, height: 1990mm, weight: 7.5t, operating hours: 16,597.7h. Including bar feeder Top Automazioni X-FILES S, year of manufacture 2020, 4x tool holders, straight, left-right square mount, external coolant, 4x machine interface: BT45A, 1x milling head 90°/BMT 45 Spinner, angled milling head/ BMT45/ ESX-25 right and left twin-spindle, Spinner flat coupling, ER25 max. speed: ...
Manufacturer: Spinner Model: TG 52-MC Year of Manufacture:2004 Electrical Specifications: - Voltage: 400 V (3 Phase + PE) - Frequency: 50/60 Hz - Current (Nominal): 35 A - Current (Operating): 34 A The machine is equipped with an FMB bar loader 5-55. Find more here - / Contact us at -
turning diameter: max. 250 mm turning length: max. 900 mm control: FANUC SERIE 0-T turning spindle: Durchlass 75mm chuck diameter: 250 mm turning speeds: 0-3700 U/min transmission ratio: 2 tool numbers: 12 feed speeds: X/Z 15/20 mm/min quill stroke: 100 mm diameter of quill: 110 mm tool adaptor: MK 4 coolant tank: 130 l weight - pallet system: 5500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: max. 420 mm turning length: 1090 mm control: FANUC Serie 18i-TB turning spindle: Durchlass 108 mm : 250 / 315 turning speed range: 0-3750 U/min Feed speed: 18/24 m/min. workpiece: 12 quill stroke: 100 mm diameter of quill: 110 mm taper MK: 4 number of driven tools: 12 mm turning speeds: 3000 U/min : 22 nm coolant tank: 140 l total power requirement: 22/18,5 kW weight of the machine ca.: 6500 KG dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
A simultaneous turning center Spinner with three turrets and extensive accessories, spare parts and tools is available. Travel X1/X2/X3: 180mm, travel Y1/Y2: +/-45mm, travel Z1/Z3: 704mm, travel Z2/E2: 620mm/720mm, rapid traverse X/Y/Z: 30m/min, acceleration: 0.5g. Spindle 1: Speed: 5000rpm, nose: A6, bore: 65mm, chuck diameter: 210mm, power: 18kW, torque: 115Nm. Spindle 2: Speed: 700rpm, nose diameter: 110mm, bore: 42mm, max. chuck diameter: 140mm, max. chuck jaw weight: 1.25kg, power: 16.6kW, torque: 100Nm. Turret 1/2/3: Turret stations: 3x12, speed: 8000rpm, tool holder: BMT 45, power: 4.3kW, torque: 13.6Nm. Machine dimensions X/Y/Z: approx. 2880mm/2130mm/1990mm, weight: approx. 7500kg, operating hours: 27102h, control: Fanuc 31i. Including loading magazine Top Automazioni, cooling/high pressure system with 80bar, chip conveyor, fire extinguishing system, a comprehensive tool package ...
x-travel: 1520 mm y-travel: 520 mm z-travel: 460 mm Control: Siemens 840D turning speeds: 12.000 U/min tool change unit: 32-fach tool taper: SK 40 0: 19 kW rapid traverse: 32 m/min B-axis (table): +110 / -90 ° total power requirement: kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 3,5x2,6x3,0 m 5 axes simultaneous machining - CNC control Siemens 840D - 32-position tool changer (SK 40) - Blast air through spindle - Internal coolant supply 80 bar - Automatic door - Rotary and tilting table: 650x540mm, 500kg - Fixed table: 920x540mm approx. 5000h running hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 400 mm turning length: 730 mm control: FANUC 21i rapid traverse: 15/24 mm/min spindle turning speed range: 4000 U/min spindle motor: 19 kW x-axis: 240 mm z-axis: 640 mm rapid travel (x and z-axis): 18 /24 m/min spindle bore: 66 mm tailstock quill taper MT: 5 tailstock quill stroke: 120 mm total power requirement: 50 kVA weight of the machine ca.: 5,5 t dimensions of the machine ca.: 3 x 1,7 x 1,8 m - CNC control FANUC 21i-TB (with Manual Guide I) - hydraulic hollow clamping cylinder - 12-position tool turret, driven tools 4000 rpm, 2.8 kW - Tool monitoring - SMW Autoblok KNCS N225-65 chuck - C-axis (with disk brake for milling operation, Transmit software for end face machining and cylinder interpolation for shell machining) - B-axis - Tailstock (MK 5) - Chip conveyor - Coolant system with high-pressure pump - Parts catcher - Radial and axial milling heads Translated wi ...
turning diameter: 120 mm turning length: 380 mm control: Fanuc 18 iTB max. swing diameter: 300 mm : : 8000 min/-1 : 7,5 kW : 26 Nm spindle nose: 100 mm spindle passage: 32 mm A-Axis: : 8000 min/-1 : 5,5 kW : 23 Nm spindle nose: 100 mm spindle passage: 32 mm : : 12 pos. tool taper: VDI 16 Sub Spindle: x-axis: 400 mm z-axis: 400 mm feeds:: rapid traverse: 12 m/min total power requirement: 20 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,8 x 2 x 1,7 m 2022 New glass scale Heidenhain and replacement of smaller parts, new FANUC CNC Keyboard CNC - Ultra precision turning centre (X-, Z-, E-, C-Axe) - CNC control Fanuc 18iTB - Main and counter spindle - SAUTER tool turret 16-fold (0.5.480.510) VDI 16 - Linear tool slide - automatic doors - Chip tray - Coolant system with fine filter (high Pressure Pump) - 3 jaw chucks - Various clamping devices/pressure collets - Vari ...
Ref. -No.: 10304 Manufacturer: SPINNER Year of construction: 2007 Type of control: CNC Control: Siemens 840 D with SHOP Mill Storage location: Halberstadt Country of origin: Germany X-Travel: 1100 mm Y-Travel: 610 mm Z-Travel: 610 mm B-Axis: 0.001 prepared for 4 th axis ° Main spindle drive power: 25 kW Main spindle speed range: 6000 RPM Table surface: 1200 x 600 mm Table Load: 1000 kg Tool Taper: SK 50 Numbers Of Tools In Magazin: 24 axes: 4 Rapid Traverse X-Axis: 18 m / min Rapid Travel Y-Axis: 18 m / min Rapid Traverse Z-Axis: 15 m / min Main Drive: 25 kW Weight Of The Machine Ca.: 8 t Further information: - additional 4 axis (Dividing head)
