used Wire Cutting Spark Erosion Machine Tools for sale

Description: Wire diameter: 0.2 ÷ 0.33 mm X axis movement: 500 mm Y axis movement: 350 mm Z axis movement: 256 mm Workpiece X: 1050 mm Workpiece Y: 650 mm Workpiece Z: 250 mm Weight of workpiece: 800 kg Main electronic connection: 3x400 V Power consumption: 9kVA U/V axis: ± 70 / ± 70 mm Serial Number: 0004 Made in Switzerlandcontrol: Agievision, weight approx.: 3,460 kg, dimensions (l x w x h) approx.: 2,300 x 1,904 x 2,220 mm

The machine is in good technical condition, by prior arrangement the possibility of a test drive.

Description: - Serial number: 222 - Control system: AGIEMATIC CD - max. workpiece dimensions: 810 mm - max. workpiece width: 580 mm - max. workpiece height: 250 mm - Support surface: 560 x 445 mm - Travels: - X: 300 mm - Y: 200 mm - Z: 256 mm - Max. workpiece weight: 200 kg - Incl. AGIE type: DA-15/PF coolant system - Attention: the machine can be transported on a normal standard truckweight approx.: 5,000 kg, dimensions (l x w x h) approx.: 4,000 x 3,000 x 2,000 mm

Description: - Serial number: 351-001 - Operating voltage: 3 x 400 V - Frequency: 50/60 Hz - Power: 9.9/107 kVA - Rated current: 14,3/15,4 A - Control system: AGIEMATIC CF - Travels: - X: 300 mm - Y: 200 mm - Z: 251 mm - Workpiece weight max. with bath: 200 mm - without bath: 550 mm - max. threadable workpiece height: 250 mm - max. workpiece dimensions: 810 x 580 x 250 mm - Attention: the machine can be transported on a normal standard truckweight approx.: 5,000 kg, dimensions (l x w x h) approx.: 4,000 x 3,000 x 2,000 mm

Inv. Num. : 6086 Type: AGIECUT 150 HSS CE Producer: AGIE Created: 1977 Parameters: Control system: AGIEMATIC CF 50 SE Table dimensions: 560x445 mm travel length of the X-axis: 300 mm travel length of the Y-axis: 200 mm travel length of the Z-axis: 251 mm Feed length in the U-axis ( -): 30 mm Feed length in the V-axis ( -): 30 mm Maximum work part length: 810 mm Maximum workpiece height: 250 mm Maximum work part height: 580 mm workpiece weight: 450 kg Machine height: 2130 mm Machine length: 2325 mm Machine width: 1620 mm Machine weight: 2900 kg

Description: Workpiece size max. 860 x 580 x 250 mm, workpiece weight max. 4000 N Travel U and V coordinate head +/- 30 mm and +/- 30° Series number 038 For transportation, a standard truck is sufficientz-motion: 250 mm, x-motion: 400 mm, y-motion: 250 mm, control: AGIEMATIC-C, table surface area l x w : 680x500 mm, weight approx.: 4,000 kg, dimensions (l x w x h) approx.: 4,000 x 2,600 x 2,100 mm

Control system: AGIEVISION Max traversing length of the X-axis: 500 mm Max travel length of the Y-axis: 350 mm Max traversing length of the Z-axis: 256 mm Max workpiece dimensions: 1050x650x250 mm Max workpiece weight: 800 kg

x-axis: 500 mmy-axis: 350 mmampere: 45 Az-axis: 256 mmcontrol: AGIEVISION 3 weight of the machine ca.: 4,5 tdimensions of the machine ca.: 2800 x 2400 x 2220 mmThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 500 mmtable width: 350 mmampere: 65 AControl: AGIEVISION 5 CNC total power requirement: 20 kWweight of the machine ca.: 4000 kgdimensions of the machine ca.: mA G I E (Switzerland)CNC - Controlled Wire Cutting EDM Machine Model AGIECUT PROGRESS V 3, Year 2007Working range, X Y Z (=height) 500 x 350 x 426 mmWire head, U-V axis (helical/taper cuts) + / - 30 °/ +/- 70 mmResolution of axes 0.0001 mmSpeed for positioning the axes up to 3 m/Min.Tolerances (If machine is new) 4 µWorkpiece dimensions, L x W x H max. 1.050 x 650 x 420 mmMax.weight of workpiece with/w.o. Dieelektricum 400/800 kgClamping System Universal Beams with fixing holesCutting wire Ø  ...

CONTROLS  CNC controls WORKING RANGE -WIRE CUTTING-  worpiece length max.: 300 mm  worpiece width (max): 200 mm  workpiece height (max): 80 mm  X-axis travel: 220 mm  Y-axis travel: 160 mm  z-axis travel (vertical): 100 mm  conical operation for max.: 3 °  U-axis travel: 80 mm  V-axis travel: 80 mmELECTRICAL SPECIFICATIONS  mains voltage: 400 V  mains frequency: 50 HzDIMENSIONS / WEIGHTS  space requirements -left/right-: 2000 mm  space requirements -front/back-: 1600 mm  total height: 2000 mm  total weight approx.: 2700 kgmin. Wire diameter 0.03mm

Description: (3x) rolls of bedra topas plus H and (1x) WELOT eroding wire Technical specifications: Diameter: Ø0.250mm and Ø0.300mm Core Material: CuZn36 Sheath Material: Gamma Brass Tensile strength: 800MPa Elongation: >,1% Colour: grey-goldweight approx.: 40 kg, dimensions (l x w x h) approx.: 600 x 400 x 350 mm

Starthole drilling machine Make: CHARMILLES, Type: HD10, Year of construction: 2002, Serial number: 1000131, with 3-axis digital display, Fabr. HEIDENHAIN

Description: 5-Axis Wire EDM Machine Max. part dimensions: 1130 x 510 x 260 mm Max. part weight: 500 kg Travels X /Y / Z: 318 ,x 218 ,x 114 mm Travels axes U, V: +/- 48 mm Max. wear: +/- 30° Table dimensions: 560 x 440 mm Thread diameter: 0,05 - 0,3 mm Machine dimensions: 3690 x 2520 x 2295 mm Weight: 4.400 kg z-motion: 114 mm, x-motion: 318 mm, y-motion: 218 mm, table surface area l x w : 560x440 mm, weight approx.: 4,400 kg, dimensions (l x w x h) approx.: 3,690 x 2,520 x 2,295 mm

Machine: Charmilles Robofil 310 Year of manufacture 2001 Condition Very Good (8/10) Origin Switzerland Stock number 13118 Machine dimensions LWH 1800 x 1600 x 2230 mm Machine weight 2500 kg Max. work piece weight 1000 kg Max. work piece size: 850 x 500 x 400 mm X Y -travel 400 x 250 mm UV -travel 400 x 250 mm Programmable Z travel 0 to 400 mm Collision protection X Y Z U V Taper angle + ...

- X: 400 mm - Y: 300 mm - Z: 400 mm - U: 500 mm - V: 400 mm - Table size: 750 x 550 mm - Table load: 1000 kg - Workpiece size W x D x H: max. 900 x 600 x 400 mm - Working basin L x W x H: 900 x 600 mm - Konik: at 400 mm 30 ° - Operating hours: 38000 h - Wire diameter: 0.1 - 0.3 mm - Machine weight: 3500 kg - Space requirement (W x D x H): 1.8 x 2.0 x 2.3 m Details automatic water supply, external water cooling system ECKERT Accessories various wear parts, 4 x 16 kg brass wire 0.25mm, 2 x spare pumps (overhauled), 1 x submersible pump for tank filling (new), factory floppy disks, documentation, 10 x filter cartridges

Wire EDM machine Make: CHARMILLES, Type: ROBOFIL 440, Year of construction: 2003, Serial number: 930407, Weight 2.850 kg, Travel X/Y/Z 550 x 350 x 400 mm, Konikwinkel +- 30°, max. workpiece dimension 1.200 x 700 x x400 mm, max. workpiece weight 1.500 kg, machine weight 2.850 kg, container dielectric 400 kg, automatic wire threading, wire shredder, separate cooling unit, Fabr. Eckert

bore depth: 0,2 - 3,0 mmbore diameter: 300 mmtravel -z axis: 300 mmtravel -y axis: 300 mmtravel -x axis: 200 mmtable-size: 400 x 450 mmworkpiece weight: 200 kgdistance: 70-300 mmlength: Elektrode 300 mm0: 100 Literweight: 850 kgrange L-W-H: 1390 x 990 x 2080 mmDescription :- CNC start hole EDM drilling machine, with dielectric tank- Fast and particularly economical method for metalworking- Finest drilling via electrical spark erosion- smooth, burr-free and precise in almost all conductive materials- Start hole eroding is the basis of any precise eroding work- Starting points for later wire or sink EDM- various spare parts- User manual + documentation machine video :https://www.youtube.com/watch?v=dhyCfFi9wVkhttps://www.youtube.com/wa tch?v=jHyyyRpcsPsThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Charmilles Robofil 310 Wire EDM Machine Wire Wire diameter: 0.1 to 0.3 mm Speed: adjustable con 0 to 15 m/min Mechanical tension: adjustable from 0 to 30 N Free angle: shelfable from 0-30 degrees May height for threading: 300mm Automatic threading (Ø 2 mm) Coils: K125 (4kg) K160 (8 Kg) K200 (16 kg) Dielectric Deionization: resin mixture, 20 l Container -Skinning type: Waterproof sheet steel, welded -Dimensions: 1910 x 1085 -Capacity 300 l - Filter system (number of paper cartridges) 8 Flushing pressure adjustable from 0 - to 11.5 bar Machine Machine bed dimensions 1800x1600x2230 Weight with control cabinet - with dielectric: 2800 kg - without dielectric: 2500 kg Temperature stabilization time

Description: Serial number: P97X0C810 CNC: Fanuc 16-W Workpiece: metal of solid with condutive Capacity: Maximum size of workpiece (submerged): 650x420x170 mm Maximum size of workpiece (flushing): 680x420x170 mm Possible mass of workpiece (submerged): 165 kg Possible mass of workpiece (flushing): 250 kg Movement: Stroke X-axis: 320 mm Stroke Y-axis: 220 mm Stroke U-axis: +/- 60 mm Stroke V-axis: +/- 60 mm Stroke Z-axis: 180 mm Rapid traverse X+Y axis: 900 mm/min. Rapid traverse U+V+Z axis: 450 mm Controlled axis: Number controlled axis: 4 (Simultaneous) Wire: brass Wire diameter: 0,1/0,14/0,15/0,20/0,25/0,30 mm Wire feed: 1-15 m/min. Wire tension: 0-2500 N Machine dimensions: Required floor space: 3400 x 2430 mm Height: 1850 mm Weight: 2000 kg Including: Coolant tank z-motion: 180 mm, x-motion: 320 mm, y-motion: 220 mm, control: Fanuc 16-W, weight approx.: 2,000 kg, dimens ...

Description: Serial number: P9771C549 CNC: Fanuc 16-W Capacity: Workpiece: metal of solid with condutive Maximum size of workpiece (submerged): 790x730x275 mm Maximum size of workpiece (flushing): 790xx730x300 mm Possible mass of workpiece (submerged): 450 kg Possible mass of workpiece (flushing): 650 kg Movement: Stroke U-axis: +/- 60 mm Stroke V-axis: +/- 60 mm Rapid traverse X+Y axis: 900 mm/min. Rapid traverse U+V+Z axis: 450 mm Controlled axis simultaneous: 4 Wire: Wire: brass Wire diameter: 0,1/0,14/0,15/0,20/0,25/0,30 mm Wire feed: 1-15 m/min. Wire tension: 0-2500 N Machine dimensions: Required floor space: 400x2960 mm Height: 2200 mm Weight: 2800 kg Including: Coolant tank z-motion: 300 mm, x-motion: 520 mm, y-motion: 370 mm, weight approx.: 2,800 kg, dimensions (l x w x h) approx.: 4,000 x 2,200 x 2,960 mm

Control Fanuc 180is-WB Travel X/Y/Z: 550 x 370 x 310 mm Travel U/V: 120 x 120 mm workpiece weight: 1000 kg

z-motion: 180 mm, x-motion: 320 mm, y-motion: 220 mm, control: Fanuc series 18 i-w, table surface area l x w : 650x450 mm, weight approx.: 1,200 kg, dimensions (l x w x h) approx.: 3,400 x 1,900 x 2,450 mm

Control Fanuc Travels X / Y / Z: 520 x 370 x 410 mm Travels U / V: 120 x 120 mm cooling unit

Inv. Num. : 6099 Type: 203 Y Producer: Hitachi Created: 2002 Parameters: Operating hours: 39801 h travel length of the X-axis: 330 mm travel length of the Y-axis: 250 mm travel length of the Z-axis: 160 mm Machine weight: 300 kg

The machine is in good technical condition, by prior arrangement possibility of testing.

The machine is in good technical condition, by prior arrangement the possibility of a test drive. Wheel travel: X 350, Y 500, Z 300 mm U x V-travels: 200 x 200 mm Max workpiece dimensions: 350 x 500 x 300 mm Generator FFII AFW Cooling Dielectric Water bath AC generator

Travel routes: X: 350 mm Y: 500 mm Z: 300 mm Travel (U x H): 200x200 mm FFII Generator Awf Dielectric cooling Water tub X2 Generators

Description: - Serial number: 160916 - Operating voltage: 400 V - Frequency: 50/60 Hz - Connection: 4,5 kW - Control: WIRECUT EDM CONTROL SYSTEM - Table dimensions: 800 x 500 mm - Travel: X: 500 mm , Y: 400 mm - max. workpiece thickness: 500 mm - max. workpiece weight: 1000 kg - travels: U: 30°, V: 60° - max. cutting capacity: 180 mm²/min - Wire roll diameter: 0,12 - 0,22 mm - wire distance: 0,25 mm - Wire speed stepless - Wire drum dimensions: 157 x 180 mm - Max. wire drum movement: 230 mm - Motor power wire drum: 370 W -- see also videoweight approx.: 2,200 kg, dimensions (l x w x h) approx.: 1,820 x 1,530 x 2,000 mm

Max. size of workpiece 940 x 650 x 260 mm Longitudinal travel 600 mm Cross travel 400 mm Vertical travel 260 mm U + V Axe +/- 75 mm

CNC - Control Makino Travel x/y/z 370 mm / 270 mm / 220 mm workpiece dimensions L/W/H 790 mm / 670 mm / 220 mm Wire diameter range 0.1 mm – 0.25 mm workpiece weight 600 kg cone at 100 mm height +/- 15° Mitsubishi - Axle Drives

Description: - serial no.: P9911C309 - operating voltage: 380/400 V - frequency: 50/60 Hz - connected load: 11 kVA - control system: FANUC SERIES 16-W - travels: - X: 520 mm - Y: 370 mm - U: 120 mm - V: 120 mm - Z: 300 mm - feed rate: - X: 900 mm/min - Y: 900 mm/Min - U: 450 mm/min - V: 450 mm/min - Z: 450 mm/min - Max. workpiece weight: 650 kg - table dimensions: 740 x 590 mm - the machine is equipped with one coolant unit and several machine components - attention: the machine can be transported on a standard truckweight approx.: 3,500 kg, dimensions (l x w x h) approx.: 4,000 x 3,000 x 2,200 mm

Description: - serial no.: P00711760 - operating voltage: 380/400 V - frequency: 50/60 Hz - connected load: 13 kVA - control system: FANUC SERIES 18i-W - travels: - X: 520 mm - Y: 370 mm - U: 120 mm - V: 120 mm - Z: 310 mm - feed rate: - X: 900 mm/min - Y: 900 mm/min - U: 450 mm/min - V: 450 mm/min - Z: 900 mm/min - Max. workpiece weight: 1000 kg - table dimensions: 740 x 590 mm - the machine is equipped with one coolant unit as well as further several machine componentsweight approx.: 4,000 kg, dimensions (l x w x h) approx.: 4,000 x 3,000 x 2,200 mm

MACHINE YEAR: 2006 MACHINE YEAR 2005 BOTH IN AN VERY NICE WORKING CONDITION

Description: Workpiece dimensions max 10050 x 820 x 305 mm, max workpiece weight ,1500 kg Rapid traverse wheel of the table 1300 mm/min Electrode diameter 0.1 to 0.3 mm max. electrode feed rate 23 m/min Tension electrode wire 0.5 to 25 N !Attention available end of November!z-motion: 310 mm, x-motion: 600 mm, y-motion: 400 mm, table surface area l x w : 880 x 680 mm, weight approx.: 3,500 kg, dimensions (l x w x h) approx.: 2,700 x 2,900 x 2,200 mm

Travel x 350 mm y 250 mm z 220 mm Water bath machine Automatic wire threading Glass scales x / y incl. box for large coils incl. cooler incl. functional guarantee

Travel X 500 / Y 350 / Z 300, Water bath machine, automatic wire threading, incl. 20 KG option incl. cooler

Machine : Mitsubishi FA 20 Stock Nr 13117 YOM : 2001 CNC Control CNC (Mitsubishi 64-Bit) condition: used – excellent Table size : 1050 X 800 mm X axis travel : machining 500 mm Y axis travel: processing 350 mm Z axis travel: machining 295 mm U axis travel : 75 mm V axis travel: 75 mm Dimensions : 2.6m L x 2.65 m W x 2.1 m H Automatic Threading Cooler Wire spool 10 Kgs Wire chopper

Description: X-axis: 350 mm Y-axis: 250 mm Z-axis: 220 mm Table dimensions: 630 x 530 mm Max wire feed: 250 mm/s Wire tension 2-25 N Max. workpiece weight: 500 kg Taper: 15° / 100 mm Total power consumption: 220V / 13,.5 kVA. Dimensions: Machine: 1900 x 1200 x 2000 Control unit: 1300 x 650 x 2000 cladding: 1400 x 700 x 1300 Cooling unit: 1600 x 1000 x 1900weight approx.: 1,900 kg, dimensions (l x w x h) approx.: 3,600 x 1,900 x 2,000 mm

control Mitsubishi CNC travel X/Y/Z 500/350/300 mm max. workpiece weight 800 kg table size 780x630 mm

Travel distances: 400 x 300 x 220 mm [ X x Y x Z ] workpiece size X: 810 mm workpiece size Y: 700 mm workpiece size Z: 215 mm workpiece weight: 500 kg Table size X: 640 mm Table size Y: 450 mm with automatic wire threading U/V axis: +/- 60 mm x +/- 60 mm Cutting in a water bath Conicity: +/- 15° max 200 mm ITS Spindle MS 24 available April 2023

Description: Serial Number:55DR1663 Max. Workpiece dimensions: 800x600x215 mm Max. Workpiece weight: 500 kg Table dimensions: 640 x 540 mm Travels: X-axis: 400 mm Y-axis: 300 mm Z-axis: 220 mm Table rapid traverse rate: 1300 mm/min Wire diameter: 0,1 to 0,3 mm Max. Wire feed speed: 23 m/min Wire tension: 0,5 to 25 n Taper: OPTOLinear T/C device Taper angle: 15º (with 200mm plate thickness) Working Hours 24073 Dielectric Fluid Reservoir: Working tank volume: 550 litres Filtration flow rate: 50 l/min Water purifier: 10 litres Other features: Superfinishing Rugosity less than Ra 0.2 weight approx.: 2,980 kg, dimensions (l x w x h) approx.: 1,910 x 2,702 x 2,015 mm

Axis X ... 500mm Axis Y ... 350mm Axis Z ... 300mm workpiece weight ... 800kg Clamping table surface ... 780 x 875mm L x W x H ... 2310x1810x2050mm Machine weight ... 2550kg The price includes CAD/CAM SW Kovoprog.

Machine Details Warehouse number 1105-03686 Machine type Wire EDM machine Make ONA Type PRIMA 250 S AWF Year of construction 1999 Control type CNC Storage location FRANCE Country of origin spain Delivery time immediately Freight base EXW 'as available' Technical details Table length 450 mm Table width 350 mm Ampere 18 A - Travel X-axis 350 mm - Travel Y-axis 250 mm - Travel z (vertical) 200 mm - Clamping surface (left-right) 780 mm - Clamping surface (front-rear) 650 mm - Workpiece weight (max) 350 kg - Wire diameter (min) 0.03 mm - Wire diameter (max) 0.3 mm - Power consumption (total) 10 kW - Connected load 15.7 kVA - Connection voltage 380 V DIMENSIONS / WEIGHTS 2.T t - Space requirement length 3500 mm - Space requirement width 2500 mm Information IMMEDIATELY FREE with all documents and much more

Travel X/Y/Z 700/500/315 mm Travel U/V 100/100 mm Workpiece size 900x700x300 mm Workpiece weight 1000 kg Wire diameter 0.2-0.3 mm

Description: Table displacement (X axis):300 [mm] - table displacement (Y axis):200 [mm] - table displacement (Z axis):175 [mm] 5-180 [mm] - secondary table displacement (U and V axes):50 x 50 [mm] - maximum dimensions of the machinable workpiece:width 400 [mm] depth 300 [mm] height 175 [mm] - maximum height of the machinable workpiece for an immersed cutout:150 [mm] - maximum weight of the machinable workpiece:160 [kg] - wire diameter:0.1 - 0.3 [mm] - wire capacity:norm 3 [kg maxi 6 [kg] - wire drive maximum speed:250 [mm/s] - wire tension:0.2 - 2.8 [kg / force] - clearance angle:± 10° for a thickness 100 [mm] - machine dimensions:width 1 585 [mm] depth 1 850 [mm] length 1 800 [mm] - machine weight:1 500 [kg] - work table height compared to the floor:910 [mm] - cutout maximum speed:160 [mm/min] dielectric feed hopper - external dimensions:height 1 150 [mm] depth 620 [mm] width 940 [mm ...

Travel distances: 320 x 250 x 220 mm [ X x Y x Z ] workpiece size X: 780 mm workpiece size Y: 570 mm workpiece size Z: 200 mm workpiece weight: 350 kg with automatic wire threading U/V axis: 80 mm x 80 mm  Cutting in a water bath Conicity: +/- 15° at 120mm

Wire EDM machine Make: SODIK, Type: ALC600G, Year of construction: 2016, Serial number: T0048, Travel X/Y/Z 600 x 400 x 350 mm, Travel U/V 150 x 150 mm, Workpiece abm. 800 x 570 x 340 mm, workpiece weight max. 1,000 kg, Abm. Machine table 836 x 593 mm, machine table finish closed, distance machine table OK-corridor 995 mm, front door autom. 3-sided lowerable, dielectric, autom. Level control, measuring system Heidenhain absolute glass scales X/Y/U/V, measuring resolution 0.01 μ, wire running system, available wire Ø 0.1 - 0.3 mm, autom. Wire threading system, max. Weight wire rolls max. 25 kg, minimum Ø starting hole hole 0.30 mm, dielectric unit, type compressor cooling, capacity 800 l, high-pressure flushing 15 bar, EDM generator, type SPW Eco Cut High Speed Generator, cutting speed. 260 mm²/60 mm, numerical control, type SPW, 19" multi-touch screen, controlled axes X/Y/U/V/Z (W-a ...

X – Axis Travel (600 mm) Y – Axis Travel (400 mm) Z – Axis Travel (270 mm) U, V Axis Travel (80 x 80 mm) Wire Diameter Range (min ~ max) (0.10 ~ 0.30 mm) Work Tank Dimensions (W x D) (1040 x 780 mm) Maximum Workpiece Weight (850 kg)

Description: (4x) rolls of EDM wire Product content: bedra CobraCut - Ø0.20mm, 500MPa StammCut ZINCO900 - Ø0.25mm Mtenso 950 - Ø0.30mm BRASS 950 - Ø0.25mmweight approx.: 30 kg, dimensions (l x w x h) approx.: 600 x 400 x 350 mm

Description: (5x) rolls of EDM wire (1x) topaz plus H Diameter: Ø0.250mm Core Material: CuZn36 Sheath Material: Gamma Brass Tensile strength: 800MPa Elongation: >,1% Colour: grey-gold (3x) AC BRASS 900 Diameter: Ø0.200mm (1x) bedra BercoCut Diameter: Ø0.250mmweight approx.: 40 kg, dimensions (l x w x h) approx.: 600 x 400 x 350 mm
