Automatic machine for chest and back grinding of carbide-tipped circular saw blades; Refurbished and repainted
Automatic circular saw sharpening machine completely overhauled. For fully automatic sharpening of HM circular saw blades, of all common tooth shapes. Equipped for oil cooling, fire extinguishing equipment. Technical data: Circular saws Ø with robot 130 to 600, without robot 130 to 840 mm, tooth pitch with robot 8 to 50 mm, without robot 8 to 120 mm. Available on request with loader robot ND 230, extraction system.
Used grinding machine Vollmer CABG 50U – built in 1995 – Very good condition For sale is a fully automatic gang saw sharpening machine from the quality manufacturer Vollmer. The machine is in very good condition, is fully functional and can be used immediately. Ideal for sawmills or woodworking companies with regular sharpening needs. Specifications: Model: Vollmer CABG 50U Year of Make: 1995 Machine Type: Automatic Gang Saw Blade Sharpener Condition: Very good, regularly serviced Saw blade width: Up to approx. 200 mm Saw blade length: Up to approx. 1650 mm Rake angle adjustment: Approx. -10° to +25° Tooth pitch: Adjustable (depending on the type of saw blade) Abrasives: CBN or diamond grinding wheels Grinding cycle: Fully automatic incl. infeed and return Control: Electronic with program selection Cooling: Integrated coolant supply Connected load: 400 V / 50 Hz ...
Circular Saw Blade Sharpening Machine Vollmer Type CNS Suitable for CV circular saw blades for straight and bevel grinding Grinding wheel diameter maximum 150 mm Saw blade diameter 90 – 600 mm Sharpening speed 3 speeds 30/60/80 teeth per minute Drive warping disc motor power 0.2 kW Drive Feed 0.4 kW Dimensions 800 mm x 900 mm x H 1800 mm Weight approx. 250 kg
Vollmer CHHF 21 H - Machine for single-sided grinding Year of construction: 1989 S/N 907 Make: Vollmer Germany in good working condition The technical data of the CHHF 21H at a glance: Circular saw blades Outer diameter 80 to 700 mm Bore diameter 20 to 105 mm Tooth pitch from 8 mm Hook angle up to 30° Radial clearance angle -7° to +3° Tangential clearance angle up to 5° Connected load approx. 0.52 kW Weight approx. 85 kg Dimensions: 70 x 50 x 80 cm Cisei8tfrg This machine has been specially designed for the repair of lack of carbide teeth. Newly inserted tips are used in the existing teeth. With this tabletop version, VOLLMER offers a a particularly economical, space-saving solution. The CHHF 21 H works according to the wet grinding process. During the grinding process, the grinding unit manually moved over the tooth flanks, with the saw blade Saw blade ...
Gate Sharper Manufacturer Vollmer for Inclined and straight ground
Circular saw sharpening machine Vollmer Cne
total power requirement:0,55 kw Overall size:800 x 900 x 1600 mm Weight:220 kg accessories::mit Absaugung 0,2 kw
A Vollmer CNC 5-axis tool grinding machine for machining rotationally symmetrical solid carbide tools, milling cutters and drills is available. Grinding wheel interface: HSK50, max. workpiece diameter: 50mm, max. workpiece length: 265mm, max. grinding length: 200mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 350mm/450mm/500mm. Machine dimensions X/Y/Z: approx. 2200mm/2200mm/2800mm, weight: approx. 4900kg. Documentation available. An on-site inspection is possible.
A Vollmer CNC 5-axis tool grinding machine for the complete machining of solid carbide rotary tools is available. Tool holder: HSK50, tool positions: 8, max. workpiece length: 340mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 330mm/450mm/500mm, workpiece magazine: pallet magazine, workpiece capacity: 272. Machine dimensions X/Y/Z: approx. 2650mm/2800mm/2200mm, weight: approx. 5550kg, control: Vollmer. Including automatic HP160 workpiece magazine. Documentation available. An on-site inspection is possible.
A Vollmer CNC 5-axis tool grinding machine for the manufacture and regrinding of solid carbide rotary tools is available. Grinding spindle interface: HSK50, max. workpiece diameter: 100mm, max. workpiece length: 360mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 350mm/450mm/500mm, workpiece magazine: pallet magazine, workpiece capacity: 272. Machine dimensions X/Y/Z: approx. 2650mm/2800mm/2200mm, weight: approx. 5550kg, control system: Vollmer. Including automatic workpiece magazine HP160. Documentation available. An on-site inspection is possible.
A Vollmer CNC 5-axis tool grinding machine for the complete machining of solid carbide rotary tools is available. Tool holder: HSK50, tool positions: 8, max. workpiece length: 340mm, max. grinding wheel diameter: 150mm, travel X/Y/Z: 330mm/450mm/500mm, workpiece magazine: pallet magazine, workpiece capacity: 272. Machine dimensions X/Y/Z: approx. 2650mm/2800mm/2200mm, weight: approx. 5550kg, control: Vollmer. Including automatic HP160 workpiece magazine. Documentation available. An on-site inspection is possible.
Suitable for simultaneous, automatic grinding of both tooth flanks on carbide-tipped circular saw blades., Accessories:, Motorized rake angle adjustment,, Coolant system,, Automatic central lubrication,, Machine light,, 2 grinding wheel holders,, 1 sawblade mounting bolt., sheet thickness: up to 8 mm, Tooth pitch: 6 to 120 mm, rake angle: - 15° to + 25°, Tangential free angle: 0° to 6°, Radial free angle: - 4° to +6°, Connection value: ca. 1,1 kW (400 V / 50 Hz), Weight: about 1150 kg, Grinding wheel diameter: Max. 125 mm, Bore diameter: 32 mm, Dimensions L x W x H: 1340 x 1400 x 2000 mm, colour: green, Circular saw outer diameter: 80 to 460 mm
Suitable for automatic, double-sided tooth grinding of carbide-tipped circular saw blades., Accessories:, Wet grinding attachment,, Motorized rake angle adjustment,, 2 grinding wheel holders,, 1 mounting bolt., Circular saw blade outer diameter: 80 to 1270 mm, Circular saw drill diameter: 10 - 220 mm, sheet thickness: up to 14 mm, Tooth pitch: 6-120 mm, Grinding path: max. 16 mm, Cross angle : -15° to +40°, Tangential free angle: 0 to 5°, Grinding speed: 0.5 to 6 mm/s, grinding wheel diameter: 125 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Weight approx: 1300 kg, colour: green RAL 6011
Suitable for automatic, double-sided tooth grinding of carbide-tipped circular saw blades., Accessories:, Wet grinding attachment,, Motorized rake angle adjustment,, 2 grinding wheel holders,, 1 mounting bolt., Circular saw blade outer diameter: 80 to 1270 mm, Circular saw drill diameter: 10 - 220 mm, sheet thickness: up to 14 mm, Tooth pitch: 6-120 mm, Grinding path: max. 16 mm, Cross angle : -15° to +40°, Tangential free angle: 0 to 5°, Grinding speed: 0.5 to 6 mm/s, grinding wheel diameter: 125 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Weight approx: 1300 kg, colour: green RAL 6011
Suitable for the automatic machining of PCD-tipped milling cutters, shank tools, disc-shaped tools such as saws, milling cutters etc. using the wire-electro-erosion process., Accessories: Total enclosure, Integrated loading system and tool magazine Automatic machining of up to 12 HSK 63 tools, Program for erosion across the tool center at the cutting edge and for free erosion, Hardware and software for DNC service, Gripper fingers for workpiece automation SK40/HSK63-A,E/HSK63-B,F, Adaptation to the A-axis on HSK63-A,E including 25 mm diameter test mandrel (HSK63 A,E system), Grinding mist extraction N 181, Cooling unit for dielectric fluid, Automatic fire extinguishing system, Measuring probes, Machine lamp, Automatic central lubrication, Cutter outside diameter: Max. 250 mm, Cutting length: Max. 260 mm, Shank tool diameter: 10-250 mm, Tool weight: Max. 20 kg, traverse: X-axis 275 mm, Y- ...
Suitable for the automatic machining of PCD-tipped milling cutters, shank tools, disc-shaped tools such as saws, milling cutters etc. using the wire-electro-erosion process., Accessories: Total enclosure, Integrated loading system and tool magazine Automatic machining of up to 12 HSK 63 tools, Program for erosion across the tool center at the cutting edge and for free erosion, Hardware and software for DNC service, Gripper fingers for workpiece automation SK40/HSK63-A,E/HSK63-B,F, Adaptation to the A-axis on HSK63-A,E including 25 mm diameter test mandrel (HSK63 A,E system), Grinding mist extraction N 181, Cooling unit for dielectric fluid, Automatic fire extinguishing system, Measuring probes, Machine lamp, Automatic central lubrication, Tailstock, Cutter outside diameter: Max. 250 mm, Cutting length: Max. 260 mm, Shank tool diameter: 10-250 mm, Tool weight: Max. 20 kg, traverse: X-axis ...
Suitable for the complete machining of rotationally symmetrical workpieces with cutting edges made of ultra-hard cutting materials. The workpieces can be picked up on the fly or between the centres (option)., Accessories:, Total enclosure, HR workpiece magazine (round magazine) for up to 16 workpieces up to 130 mm in diameter, 20 kg, or up to 8 workpieces up to 230 mm in diameter, 20 kg., Magazine disk for 16/8 HSK63-A,E workpieces with a diameter of 130/230 mm, up to 20 kg., Adapter to the A axis for HSK63-A,E., Automatic fire extinguishing system., N282 extraction system with 600 m³/h air flow., Automatic cover flap., Automatic central lubrication., Measuring probe., Cooling unit for dielectric fluid including cooling unit., HSK-A63 test mandrel., Workpiece diameter: up to 320 mm, workpiece length: up to 500 mm, workpiece weight: up to 25 kg, Holding mandrel: SK 50, Wire diameter: 0.1 ...
Description: 4-axis CNC controlled grinding machine, suitable for the automatic grinding of tooth faces and tooth backs on carbide-tipped circular saw blades., Accessories:, Coolant system,, Total enclosure,, Automatic central lubrication,, Hollow face grinding unit, mist extractor N183, Motor driven rake and clearance angle adjustment,, Machine lamp,, Oscillation grinding at tooth face and tooth clearance,, Multifunctions handwheel,, 2 grinding wheel flanges for face and top grinding,, 1 centering ring 30 mm,, 1 mounting mandrel., Circular saw blade diameter: 80 to 840 mm, Circular saw hole diameter: 10 - 300 mm, sawblade centrebore: 10 - 180 mm, Sheet thickness: up to 8 mm, Tooth pitch: up to 100 mm, mass: approx. 1660 kg, Rake angle: -10 ° to + 40 °, Clearance angle: from 5 ° to 45 °, Angled grinding on the back of the tooth: up to 45 °, Angled grinding on the tooth face: up to 1 ...
Universal machine for eroding and grinding various PCD tools up to 250 mm in diameter and 200 mm in length in production and service. Accessories: Full enclosure Measuring probe for complete measurement of the tools Workpiece carrier adaptation A-axis from SK 50 to HSK 63 A Loader for up to 6 eroding disk sets (tool changer) Alphanumeric keyboard Standard programs for measuring, eroding Cooling and cleaning device for dielectric Automatic fire extinguishing device Extraction N183 1 exchange element 1 flushing set 1 measuring mandrel 1 mounting flange for rotating electrodes, X axis travel: 440 mm, B-axis: +/- 15°, Y axis travel: 876 mm, Z-axis travel: 420 mm, E-axis swivel range: 210°, A-axis rotation range: 360°, workpiece carrier base: SK 50, workpiece length max.: 200 mm, Workpiece diameter max.: 250 mm, workpiece weight: 15 kg, Connected load approx.: 6.7 kW 400V/50 Hz, Weight app ...
Suitable for automatic grinding of tooth faces, tooth backs, and bases on carbide-tipped circular saw blades in a single setup. All common tooth geometries (flat, alternate, trapezoidal, etc.) can be ground automatically and in a single pass. Accessories: Full enclosure Measuring probe Grinding device with oil cooling Automatic fire extinguishing system Grinding mist extraction system N 183 Alphanumeric keypad Oil drip tray Machine light, saw diameter: 80-840 mm, Bore diameter: from 10 mm, sheet thickness: < 8 mm, Tooth pitch: 6 - 120 mm, Cutting length:
Suitable for automatic, double-sided tooth flank grinding on carbide-tipped circular saw blades., Accessories:, Total enclosure., Coolant System,, Automatic central lubrication,, Expansion of diameter range from 80 – 1,430 mm, Circular sawblade outer diameter: 80 to 1430 mm, Circular sawblade bore diameter: 10 - 220 mm, sheet thickness: up to 14 mm, rake angle: -15° to +40°, Radial free angle: -6° to 6°, Tangential free angle: up to +8°, Grinding path: Max. 30 mm, Grinding speed: 0.5 - 20 mm/s, Tooth pitch: 6 - 120 mm, Grinding wheel diameter: 80 to 125 mm, Grinding wheel bore diameter: 32 mm, Connected load approx.: 3,6 kW (400 V / 50 Hz), Dimensions W x D x H approx.: 2395 x 1590 x 1970 mm, colour: green/grey, Weight approx: 1750 kg
Suitable for automatic machining of PCD-tipped milling cutters, shank tools, disc-shaped tools, and optionally profile tools using the disc electroerosion process. Accessories:, Total enclosure,, SK 40 or 50 workpiece carrier according to preference,, Cooling unit for dielectric,, Automatic fire extinguishing system,, Measuring probe,, SK 40 or 50 measuring mandrel depending on workpiece carrier,, Alphanumeric keyboard for data management,, Software package for peripheral machining of end mills and jointing cutters, linear machining in all common axis directions,, Software package for compact and radius machining, profile cutters in path-travel and plunge-cutting processes,, Software package for profile tools, 4-path program for peripheral electrodes,, Software package for circular saws for complete machining of tooth backs and flanks of all common geometries,, Automatic central lubricat ...
Suitable for automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters, etc. using the wire electro-erosion process. Accesories: Total enclosure,, Mist extractor, Probe,, Machine lamp,, Automatic central lubrication,, Coolant system dielectric fluid, Fire extinguishing system, Measuring mandrel, Alphanumeric keyboard, cutter outer diameter max: 250 mm, cutting length max.: 200 mm, shank tool diameter: 10 - 250 mm, cutting length: 200 mm, Outside diameter of disc-shaped tools max.: 250 mm, tool weight max.: 20 kg, X-axis travel: 220 mm, Y-axis travel: 300 mm, W axis travel: 200 mm, A-axis rotation range: 60 °, A-axis taper: ISO 40, E-axis swivel range: 120 °, number of revolutions: 80 - 2000 rpm., Dimensions L x W x H: 2235x2630x2130mm, mass: approx. 4500 kg, Connected load approx.: 400V / 50Hz / 4.5KW, colour: turquoise RAL 5021/gr ...
length: ~ 700 mm width: ~ 600 mm height: ~ 2.000 mm Vollmer Junior B automatic bandsaw sharpener for sharpening bandsaw blades. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Suitable for automatic, double-sided grinding of tooth flanks on circular saw blades with carbide tips., Accessories:, Partial enclosure,, 1 sawblade holder,, Coolant system., Circular saw outer diameter: 260 to 2200 mm, Circular saw bore diameter: 25 to 220 mm, sawblade thickness: up to 20 mm, Tooth pitch: from 10 mm, rake angle: any, Radial free angle: up to 6°, Tangential free angle: up to 6°, Grinding path: up to 75 mm, Grinding speed: 0.5 to 6 mm(s), Working speed: up to about 10 teeth/min, Grinding wheel diameter: 125 mm, Grinding wheel bore diameter: 32 mm, Grinding wheel peripheral speed: 26 m/s, Cooling lubricant pump capacity: 250 l/min, Coolant Tank Content: approx. 190 l, Connected load approx.: 6,5 kW (400 V / 50 Hz), Dimensions W x D x H =: 3050 x 1890 x 2050 mm, Weight approx.: 2160 kg, colour: green
Suitable for the automatic grinding of HM circular saw blades on the face and top in one setting. All known tooth geometries (flat, alternate, trapezoidal teeth, etc.) can be ground automatically and in one pass., Accessories:, Total enclosure,, Coolant system,, Equipment for robot operation with automatic loading door, ND 230 loader, Measuring device for measuring saw blades, Chip breaker grinding attachment, Stepless variable grinding speed of the two grinding spindles from 1600 to 5500 rpm., Grinding speed and grinding path stepless adjustable for each machining surface on the tooth., Automatic central lubrication, Software package for oscillation grinding at rake and clearance angles, Automatic shut-off flap, Automatic fire extinguishing system, Electrostatic oil mist separator N281, Measuring tool, Sawblade holder with guide bushing Ø 16 mm Saw holder >ø180, Sawblade holder with g ...
Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as saws, milling cutters etc. using the wire-electro-erosion process., Accessories:, Total enclosure,, Adaptation to A-axis on HSK63-A,E incl. test mandrel Ø 25 mm System HSK63 A,E, Integrated loading system and workpiece magazine for automated processing of up to 12 workpieces., Probe,, Automatic central lubrication,, Coolant system for dielectric fluid,, Automatic fire extinguishing system,, Mist extractor,, Machine lamp., Cutter outside diameter: Max. 320 mm, Shank tool diameter: 10-320 mm, Outside diameter disc-shaped tools: Max. 320 mm, Cutting length: max. 480 mm, Tool weight: max. 20 kg, X axis travel: 500 mm, Y-axis travel: 300 mm, W-axis travel: 200 mm, A-axis rotation range: 360 °, E-axis swivel range: 180 °, Required space for the machine: 2535 x 2200 x 2280 mm, Weight a ...
