Manufacturer:
(Category: 212)
Code: 0513 Brand: AL-KO - GERMANY Model: MOBIL JET 120 - CE Standard Wheeled dust collector for wood dust, for joinery workshops, carpentry workshops, sawmills and other applications – CE Standard Three-phase motor 2,2 Kw Suction inlet diameter 120 mm Air flow rate 1120 m³/h Manual filter cleaning Overall dimensions mm 1085 x 650 x 1974 h Weight kg 100
Volume flow 5,860m³/h Suction nozzle Ø 300 mm Filter cleaning automatically Radio control for 30 machines/sliders Motor power 5.5 kW (400V) 3 chip containers
NOLTING WFH 250 shredder chipper Loading hopper inlet 1260x800mm Rotor width 800mm Main Motor Power: 18.5kw Number of knives 19 Sieve diameter 12mm Extraction port fi200mm Net price
Gebr. 1-bag suction NESTRO Motor power: 2.2 kW (400V / 16A plug) Connection: 160 mm Chassis Height with filter bag in operation: approx. 275 cm
Chopper Osmeka Residual wood shredders Disc chippers Type 161A Year of manufacture 1985 Refurbished in 2023 Motor power 22 kW The rotor of the 161 series has 49 impact gauges, which are arranged in 2 rows all around. A primary crusher arm with an integrated pressure surface rotates above the blades Throughput capacity 300 – 1500 kg/h Granule size up to approx. 25 mm Fuse 63 Ampere Low-speed with filling hopper Cutting system with high resistance to metal parts Operating hours 7738 h Refurbished in 2023, almost no longer used after that Hopper 900 mm x 900 mm Mill height 2650 mm Plus hopper attachment 1000 mm With control cabinet For shredding wood, hardwood, beams, glulam beams, chipboard...
Cross Conveyors Consisting of 5 conveyor strings, each 9.5 m long, with driver blocks Distance between the carriers approx. 1 m Total width 6.50 m Drive rod approx. 6.50 m long Height approx. 0.50 m
Air consumption: 42,83 m³/minMotor output: 250 kWOverall size: 4000 x 2100 x 2500 mm0: min. 4 bar0: max. 13,5 barWeight: 20.000 kgDimensions (LxWxH): 13,00 x 2,95 x 2,90 mThe pneumatic container is used to provide oil-free dryCompressed air (42 m³/min max. 7.5 bar) for test facilities and consists ofa self-contained container functional unit, in which the followingMachines, as shown schematically in Figure 2, were integrated:- Compressor EKO 250 D- Refrigeration dryer HHDp 4500/HF 5-M/5- Activated carbon adsorber BEKO Clearpoint L 3400 V- Post-filter HF 6-60- Oil-water separator BEKO Öwamat 16- El. Steam trap BEKO 14The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Pressure vessel compressed air max 16 barWith pressure relief valveStanding modelContent: 1000 litres
Volume: 2000lGas: airMax pressure: 10.7 barMax temp: -15/55°C
Nominal lifting capacity: 5000kgCenter of gravity distance: 600mmTotal lifting height: 3.3mEngine: FORDTransmission: Grazziano
Motor: 5.5 kWSpeed: 2980 rpmInput diameter: 25 cmOutput dimensions: 30 x 20 cmWith mounting bracketWith control box
Boiler capacity 25 kW/hSpace to be heated: 600 m³Fan: 0.17 kWAir displacement: 2200 m³/hChimney connection diameter 180 mm
curved conveyor beltbend 90°width carpet 500 mmtotal width 700 mmmin/max height 890/990 mmlength inner size 2800 mmengine 0.55 kW
hydraulic lifting tabledimensions of the table (single): 2400 x 1050 mmheight min/max: 400 / 1600 mmmaximum charge: 3000 kg
Panel return system for single-sided edging machine in left-hand version with a length of approx. 12m50Panel length 240 to 2700 mmPanel width 60 to 1000 mmPanel thickness 8 to 80 mmMin/max panel dimensions with 4-sided machining: 240 x 80 mm, 2500 x 1000 mmWorking height 950 mmAt the machine outlet is a tilting air table that returns the workpieces on a conveyor belt to the machine operatorTilting air table with dimensions 2500 x 1400 mmAir table at the front of the machine inlet with dimensions 720 x 580 mmBrush cleaning of the return beltair table at the end of the return conveyor with dimensions 2500 x 1250 mm
Roller diameter: 90 mmRoller center distance: 155 mmRoller length: 1050 mmChain motor: 0.75 kWHeight: 290 mmRoller conveyor length: 1300 mm
Roller diameter: 90 mmRoller center distance: 155 mmRoller length: 1050 mmChain motor: 0.75 kWHeight: 290 mmRoller conveyor length: 5400 mm
Roller diameter: 90 mmRoller center distance: 155 mmRoller length: 1050 mmChain motor: 0.75 kWHeight: 290 mmRoller conveyor length: 3400 mm
RobotMaximum reach: 3195mmRated payload: 180kgMaximum payload: 230kgMaximum supplementary load, rotating column / link arm / arm: 300kg / 130kg / 150kgPose repeatability (ISO 9283): +-0,07mmNumber of axes: 5Mounting position: FloorFootprint: 754mm x 754mmWeight: 1017kgProtection rating (IEC 60529): IP65 Running hours: 5054hVacuumsystemDimensions: 1700mm x 900mm 350mmConstruction of 56 SCHMALZ cups dia 50 and 70mm with pushrod for loosen plateFESTO components for compressed air/vacuumEach cup separately controlled by FESTO controllerCommunication via Profibus
Fully automatic sorting and buffer cell installed between a boring cell and a carcass press. The cell collects all parts for each kitchen, then stacks them on pallets for assembly. Technical data: Robot: Fanuc R-2000iC/100P with controller, track driven by a Siemens Sinamics S210 servo Sorting rack: approx. 15 m wide x 4.5 m high x 1.4 m deep, buffer capacity for 6 kitchens (on average 115 parts per kitchen)Panel sizes in the rack: length 350–2500 mm, width 50–1000 mm, thickness 18–25 mmPanel sizes on the output pallet (not in the rack): up to 3000 x 1300 mm, thickness up to 40 mm Max. panel weight: 42 kgPallet size: 1200 x 800 mmIdeal for kitchen and furniture manufacturers who want to automate the step between CNC boring and carcass pressing: less handling, no searching for parts, and all parts arrive ready for assembly, order by order.
Extraction system Spänex -as good as new - SPÄNEX extraction, filter and transport system with clean air side Arranged extraction fan with max. 27000 m³/h air output Year of manufacture 2023 CE As good as new – only approx. 20 hours of operation Filter type: FA V/2000-VE-630-37-B-V-F-6-2,2 Filter area 180 m² Filter air flow max. 27000 m³/h Residual dust content less than 0.1 mg/m³ Mode of operation discontinuous Chip buffer volume 6 m³ Motors: 1 x vibration – 0.16 kW, 1 x discharge 2.2 kW, 400 V / 50 Hz Dimensions: L 2.9 x W 2.9 x H 7.3 m Built-in fan type: SU-630-A003-37-M Volume flow max. 30,000 m³/h Total pressure difference max. 4500 Pa Operating point 27000 m³/h Total pressure difference 3800 Pa Fan efficiency 86 % Power requirement 33.5 kW Exhaust fan soundproofed Motor power 37 kW 400 V/50 Hz, IE 3 Weight approx. 5800 kg (with filled chip contai ...
Intermediate conveyor belt / conveyor belt Type LTB 250-3500, S/N 81005, built in 1997 Length 3500 mm Width 250 mm Height 820-1000 mm Feed rate 20 m/min. with slip plate 3000 mm 2x pneum. Glass bead ejector Condition: technically and optically in very good functional condition Delivery: EXW Delivery time: at short notice by arrangement Viewing: by arrangement
Driven roller conveyor Length 3100 mm A total of 16 rolls Of which 14 are powered Diameter 80 mm Roll length 600 mm Working height 920 mm Feed speed 14 m/min. Motor power 0.55 kW Mobile on castors Dimensions 3400 mm x 740 mm x H 1050 mm Weight approx. 350 kg (Previously stood in front of four-sided planer copper mill)
