This baling line was made by AUTEFA in year 1999. The line has been used to press bales from a fibrous by-product from a pulp process, and is suitable for different kinds of man-made and natural materials, including cotton, wool, straw, paper, plastic etc. The baling system consists of four parallel infeed and pre-pressing lines, two main presses with wrapping and strapping functions, a two-lane rail system to and from the presses and an automated warehouse system in two floors including a lift for product bales, stackers, labelers and conveyors. The system can bale two different materials simultaneously, as each fiber line is assigned to a different pre-press.
The material is pneumatically conveyed via an air tube to a vertical dosing system. The material is separated from the transporting airflow and collected into a chamber, which cyclically releases the accumulated material into another collection chamber below it. Once the desired amount is collected to the second chamber, it is gravitationally released to a pre-pressing unit below. In the pre-pressing unit, the material is pressed into a bin, which is then transported via the rail system to the main press. The main press unit presses the bale into desired dimensions, removes the bin and wraps plastic straps and film around the bale. The bin is then transported back to pre-pressing unit and the bale to an automated warehouse via the two-lane rail system.
Manufacturer: Autefa Solutions
Type: Uni Box 2000
Capacity: 220 t/day
Control PLC: Allen Bradley
Number of pre-presses: 4
Number of main presses: 2
Number of operators: 1
Palletizing Line for Shrink Packages with Palletizing Robot
This palletizing line used to work with film tray shrink wrapped and carton wrapped consumer packages with glass bottles, line capacity 50000 bph. The line was originally built in 1998 but new palletizing robot was added in 2004. Operation was stopped in 2014 and all equipment are still installed and powered.
List of equipment
Pallet Conveyor System, KRONES PCS K 453-629 year 1998
Pallet Conveyor System, KETTNER 453S K 453-642 year 1998
Palletizing robot FANUC ROBOGRIP 450 R, K 450-244 year 2004
Empty Pallet Magazine KRONES LPMT, K 454-645 year 1998
Stretch Wrapper ERAPA DO 1600E K 902-399 year 1998
COMIL150-200-250 Packaging Machine Weight approx.: 3500 kgDimensions (l x w x h) approx.: 12000 x 2000 x 2000 mmDescription: Double belt conveyor whose width is 550 mm, length 3000 mm, upper and lower double filming machine, welding bar width 1500 mm, fee ...
Weight approx.: 3500 kg Dimensions (l x w x h) approx.: 12000 x 2000 x 2000 mm Description: Double belt conveyor whose width is 550 mm, length 3000 mm, upper and lower double filming machine, welding bar width 1500 mm, feedback oven with wire mesh conveyor belt, tunnel length 2500 mm, max. operating width 1300 mm, see photo
Bottle Washer Klinger NDS 1L with label extractor 4500 bph
This bottle washer was made by Austrian Klinger in 1989 and it has been refurbished by Kahl+Schlichterle in 2012. It has a label extractor and the machine is currently operational. The structure material is stainless steel and infeed and outfeed conveyors are included.
The refurbishment in 2012 included checking and refurbishing the bottle inlet and outlet system, all pumps, the heating system, label removing system, the complete spraying system and complete changement of bottle cells.
Make: Klinger Flaschenwaschsysteme GmbH, Austria
Type: NDS 1L
Year: 1989 / 2012
Capacity: 4.000 to 4.500 bph
Bottles per row: 10
Water consumption: 2.5 m3/h
Operating hours: Approx 40.000
Max bottle size: diameter 100 mm, height 330 mm
Voltage / Hz: 15 kW, 480 V, 60 Hz
PLC: Siemens S7/200
Dimensions: 7.0 x 1.84 x 3.3 m (LxWxH)
Weight: 15 tons (operational)
KRONESZLW F1M intermediate layers-aplicator with magazine description:\nVertical stroke of approx. 2000 mm incl. Vacuum pump and intermediate layer magazine for EURO and half pallets\n\nVertical stroke of approx. 2000 mm incl. Vacuum pump and intermediate layer magazine for EUR ...
description: \nVertical stroke of approx. 2000 mm incl. Vacuum pump and intermediate layer magazine for EURO and half pallets \n \nVertical stroke of approx. 2000 mm incl. Vacuum pump and intermediate layer magazine for EURO and half pallets \nheight: \n3000 mm \n \nlength: \n1520 mm \n \nserial number: \n2080467/017 \n \nwidth: \n1120 mm \n \n \n\r \nBesides buying and selling of conveyors and machines our strength lies particularly in services and project planning, as for example in rebuilding and adapting of your installation as well as in overhaul and relocation of machines. \r\nYou have a first idea or even a concrete plan? It does not matter how far your project is, we support you in every phase! \r\nOr do you want to sell or market your machine? We also buy machines or provide you with a marketing concept. \r\nAsk for your individual offer or visit us in Knetzgau. Concerning bigger projects we can of course also visit you in your company to do an on-site survey. \r\nOur DRINK technicians are working worldwide for our customers! \r\nWe are looking forward to hearing from you. \r\n \r\nAll information is supplied without guarantee.
This KLINGER Bottle washer (from Austria) has been re-installed in 2013 after a complete reconditioning by Karl + Schlihterie. It has been out of service from 2016, last major maintenance was in November 2015. It was used to wash returnable glass bottles. The machine has a label extractor, and all conveyors are included with their electrical motors. The equipment is in fair condition, dismantled and ready for immediate shipment.
Type: NDS 24/1/70
Built: UNKNOWN (Plate is missing)
Capacity: 4 800 – 11000 bph
Bottle handling: Glass 0.2 up to 1.0 ltr
Power / voltage 400 V / 60 Hz - 3 phase, 21 kW
Material: Stainless steel
Total pass through time: 11.2 min
Caustic soaking time: 7.3 min
Heating steam pressure: 1 bar
Heat consumption: 430 kW (operation), 500 kW (start-up)
Water consumption: 4.3 m3 / h
Dimensions: 8 400 x 2 600 x 4 000 mm
Weight: 16 000 kg (empty), 28 000 kg
ABG PACKMATZM 650-E-S/W24 Packaging Machine Weight approx.: 500 kgDimensions (l x w x h) approx.: 2000 x 2000 x 1800 mmDescription: Machinen number: 804-0-0268 750-0-00191 420-0-0002 45-Liter Bunker with feed system manual filling Counting machine ZM 650-E with co ...
Weight approx.: 500 kg Dimensions (l x w x h) approx.: 2000 x 2000 x 1800 mm Description: Machinen number: 804-0-0268 750-0-00191 420-0-0002 45-Liter Bunker with feed system manual filling Counting machine ZM 650-E with cone conveyor spiral
Pouch packaging Hoppers SPS Siemens S7-300 control max. beg width 280 mm max. beg length 200 mm Foil thickness 40 - 120 mm Dimensions: approx. 1300 x 1500 x 1700 mm (L x W x H)
Bag printing Thermal transfer printing system DPM3 Label Star Plus basic package Memorycard for DPM3
Automatic Crate Magazine Vertical Storage System SIMONAZZI
An automatic crate magazine storage system made by SASIB in 1998. The system consists of two magazine storages. The larger magazine stacks crates in three parallel rows, it has two infeed and two outfeed lanes of conveyors and the storage capacity is over 600 crates. The other magazine has the capacity of over 200 crates, is built upon a single conveyor lane and both the infeed and outfeed are from the same side. The storage magazines have been used as buffers between crate washer and packer and before palletizer. The capacity of the original line was 80.000 bph.
Crate Unloading and Loading System with ABB Industrial Robots
Automatic robot packaging system made by SASIB in 1998. The system is used for loading bottles in crates with the maximum capacity of 80.000 bph. It includes six floor-mounted robots and a control unit. The robots are made by ABB in 1998 and they are refurbished in 2010/2011. Production was stopped about one year after this refurbishment and therefore ABB robots are in good working order. ABB IRB 6400 robots have a 6-axis movement, a reach of 2.4 meters and maximum handling capacity of 200 kg. System includes complete conveyor systems and gripping tools for the robots.
System manufacturer: SASIB S.p.A., Italy
System model: ROBOKOMBI DECA 5-5T
Serial number: IBH 005 1226
Crate loading capacity: 80 000 bph
Crate unloading capacity: 20 000 bph
Robot manufacturer: ABB Robotics Products AB, Sweden
Robot type: IRB6400 M97A
Year of manufacture: 1998
Number of robots 6 pcs
Payload capacity Up to 200 kg
Serial number: 64-06736
Voltage: 3 x 400 V, 50 – 60 Hz
Electric power: 7.2 kVA
Maximum reach: 2.4 m
Manipulator weight: 2.050 kg
Controller weight: 250 kg
Axis velocities: 90 – 190 °/s, depending on axis
Axis velocity resolution: approx. 0.01 °/s each axis
CONTIMETACW 400 Fully automatic Strechfolienwickler Fully automatic Strechfolienwickler with free floating lever arm - used -: Site building site price: only EUR15.000.-(net), plus dismantling etc.! Manufacturer: Contimeta Year of construction: 2003 Type: CW 400 ...
Fully automatic Strechfolienwickler with free floating lever arm - used -:
Site building site price: only EUR15.000.-(net), plus dismantling etc.!
Manufacturer: Contimeta Year of construction: 2003 Type: CW 400 Winding speed: 25 coils/min Dimensions (max): L 1200 mm, B 1200 mm, 2000 mm Capacity: max 50 PCs. pallets/h Total width: approx. 3, 34 m Total height: approx. 4, 32 m Machine is fully functional and can be used to test! Condition: good, bought like visit! Available: available now Location: Serbia
Depalletizing Station Kettner with two depalletizer and pallet handling system
This depalletizing station was built in two phases by Krones Kettner, glass bottle depalletizer in 1998 and can depalletizer in 2002 with fully automated pallet handling system. Both depalletizers can be modified for other container types. Full can pallet carton corner frame has been manually removed. Both lines include pallet infeed and outfeed roller conveyors, container outfeed belt conveyors and pallet magazines. Empty pallet system is fully automated pallet stacking and roller conveyor transport system build as a own system. It collects and returns empty pallet back to warehouse area.
List of the main equipment
• Depalletizer Kettner Pressant Universal, year 1998, K R74-003 (Glass bottles)
• Empty Pallet Magazine Kettner Palmagazine, year 1998, K 454-635
• Depalletizer Kettner Pressant Universal 1A, year 2002, K R 74-089 (Can line)
• Empty pallet magazine Kettner K 454-E15 2002
• Infeed roller conveyors with loading station for both lines
• Empty pallet piling and return system
• Product discharge conveyors for both lines
Video 1: abcs://youtu.be/CF5Oh0TGcNU
Video 2: abcs://youtu.be/LI7-Cvoh2L4
ALLOXXEKH 455 Hood-Type Shrink Unit Weight approx.: 150 kgDimensions (l x w x h) approx.: 1300 x 900 x 1300 mmDescription: S/N H 1006030318, work table height 370 mm, device working height 910 mm, dimensions sealing 420 x 550 mm, current 3.77 kW, voltage 2 ...
Weight approx.: 150 kg Dimensions (l x w x h) approx.: 1300 x 900 x 1300 mm Description: S/N H 1006030318, work table height 370 mm, device working height 910 mm, dimensions sealing 420 x 550 mm, current 3.77 kW, voltage 230 V, packaging capacity min. 50 x 50 x 1 mm, max. 520 x 390 x 250 mm, foil size to be used for packaging: 600 x Ø 250 mm
Palletizer Kettner Pressant with pallet wrapper and conveyors
Complete palletizing line made by Krones in 2002 with Kettner palletizer and Robopac stretch wrapper infeed and transfer table as well as case turner. This line has been palletizing 0.33 and 0.5 liter aluminum cans but is is suitable for various containers. Line is sill installed and in good condition
This line consist of the following main equipment:
- Palletizer Kettner Pressant Universal 1N, year 2002, SN K R51-321
- Pallet conveyor system Kettner, year 2002, SN K 453-642
- Pallet stretcher Rotopac Helix HS 30, year 2002
- Safety fence and Siemens Simatic S 7 Controls with touch screen
BBK semi-automatic Keg labeling/banding machine capacity: 3 - 5 Stück/min Power consumption: 1,5 kWweight: 470 kgOperation / control: semi automaticBasic construction: on frame with wheels Semi-automatic labeling / banding machine to provide keg barrels on th ...
capacity: 3 - 5 Stück/min Power consumption: 1,5 kW weight: 470 kg Operation / control: semi automatic Basic construction: on frame with wheels Semi-automatic labeling / banding machine to provide keg barrels on the circumference with a bandarole.The label width is adjustable from 30-120 mm.
Depalletizer KHS Innopal AS-1-H with pallet magazine, year 2004
Accurate and flexible high performance depalletizer Innopal AS-1-H with pallet magazine by KHS (Germany), manufactured in year 2004, capacity 60 000 bph or 420 layers/hour. The Innopal AS-1-H is a bulk depalletizer is suitable for processing containers made of glass, plastic, or metal. Fast product changeover is achieved thanks to a motor-driven adjustable push-off carriage. The three-sided pallet in-feed area and the closed well in the push-off area makes the Innopal AS-1-H ideal for processing unstable containers. Control panel is KUKA and control system is Siemens Simatic S7. The delivery includes complete equipment for a depalletizing system. Equipment is in very good condition and ready for immediate delivery.
Machine type Innopal AS-1-H
Manufacturer year 2004
Capacity 60 000 bph or 420 layer/hour
Used bottle size 0.5-liter glass bottles
Max block height including pallet 3000 mm.
Pallet dimensions 800 x 1450 mm and 1000 x 1250 mm.
Machine dimensions 3610 x 3085 x 5725 mm.
Machine weight 7500 kg.
