used
Tool grinding machine make AGATHON type 175 DIAMachine -No: 8091723 built in 1984Technical specifications:Grinding wheels with double cup diameter: 175 mmSpindle speed: 2700 rpm.Workpiece infeed: 0.01 mmFine angle adjustment max .: 26 degreeConnected load: 1.7 kWWeight approx: 300 kgDimensions approx: 1000 x 600 x 1500 mmWith- cooling device- suction- Equipmentused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Sharpening machine for band saw blades Manafacture: Alber Sharpening machine for band saw blades Sharpening circuit Fabr. Alber Model: TB1 - AE2 Year of construction: 1978
used
Description: General Characteristics Grinding length 600 mm Wheel speed 3000 r.p.m. Ø max workpiece min/máx = 2/26 Ø Tool 150 mm Electrical Characteristics Total Power 1 hp Voltage 220/380V weight approx.: 200 kg, Approx. Onsite Dimension. (l x w x h): 1,300 x 760 x 1,200 mm
used
max. grinding diameter: / mmgrinding length: / mmworkpiece length: / mmtotal power requirement: / kWweight of the machine ca.: / trequired space: / mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: Tool clamping device for rectangular cross-sections up to 40x40 mm, cutting radius 0 to 16 mm, swivel angle 0 to 120° max., speed range 4500 rpm, grinding wheel holder between flange with inner taper grinding wheel diameter 125 mmweight approx.: 800 kg, Approx. Onsite Dimension. (l x w x h): 600 x 900 x 1,600 mm
used
Description: Universal tool grinding machine incl. suctionweight approx.: 450 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 1,600 mm
used
Lid S1 Tool Grinding Machine
used
Techn Data: Clamping range, Tips height of the part head, without /with swivel plate 65/95mm Largest cutter pass-through between the peaks 130mm Largest distance between the tips 250mm Largest cutter diameter at flying clamping 320mm Inner cone partial scopic spindle standard cone 40 or Morse 4 Largest bore of collet pliers 25mm Motion Longitudinal movement of the partial slide 260mm Cross-movement of the cross-loop guide Coarse 200mm Cross-movement of the cross-sled geese Fine 50mm Height adjustment of the vertical slide 50mm Swivelability of the table slide 360° Swivelcapability of the vertical slide guide 360° Swivel lingability of the swivel bearing around axis persethering to the partial spindle 220° Swivelability of the partial head slide guide around axis parallel to the partial spindle 30° Largest grinding length for spiral grinding 100mm Smallest and larg ...
used
Deckel S11 Tool grinding with lots of accessories
used
For sale: Lid Universal Tool Grinding Machine Type S12M-NC. The machine is in good condition. Still visible under power. With lots of accessories. Available at short notice
used
Grinding machine make DECKEL type SOMasch. -No: 89-24422 Year of construction 1989Technical specifications:gr. radius to be ground: 10 mmgr. lateral displacement of the milling cutter holders: 10 mmgr. Longitudinal displacement of the cutter holder: 40 mmgr. adjustable back grinding angle: 45 °gr.Bore of the collet: 17.5 mmGrinding spindle speed: 4500 rpm.Drive power: 0.25 kWDimensions L x W x H: 500 x 420 x 1400 mmWeight approx: 67 kgWith- baseused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Single-edge milling machine make DECKEL type SOMachine -No: 81659 built in 1981 (table model)Technical specifications:Tool holder: 17.5 mmTaper collets: MK 1 / MK 2 / GAGrinding spindle speed: 4500 rpm.Adjustment of the tool holder: 10 mmLongitudinal shift: 40 mmMax. Relief grinding angle: 45 °Drive power: 0.25 kWSpindle speed: 2800 rpm.Weight approx: 32 kgExternal dimensions approx: 510 x 565 x 290 mmWith- grinding wheel- several colletsused, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Single-edge milling machine make DECKEL type SOMachine -No: 0221 (table model)Technical specifications:Tool holder: 17.5 mmTaper collets: MK 1 / MK 2 / GAGrinding spindle speed: 4500 rpm.Adjustment of the tool holder: 10 mmLongitudinal shift: 40 mmMax. Relief grinding angle: 45 °Drive power: 0.25 kWSpindle speed: 2800 rpm.Weight approx: 32 kgExternal dimensions approx: 510 x 565 x 290 mmWith- grinding wheel- several colletsused, in very good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Engraving Cutter Fabr. DECKEL type SONMachine -No: 24196max. radius to be ground: 10 mmmax. lateral displacement of the cutter holders: 10 mmmax. Longitudinal displacement of the milling cutter holder: 40 mmmax. adjustable back grinding angle: 45 °Gr. bore of the collet: 17.5 mmSpeed of the grinding spindle: 4500 rpm.Drive power: 0.25 kWDimensions L x W x H: 500 x 420 x 1400 mmWeight approx .:67 kgused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Tool grinding machine make DOEBELI type combination grindingMachine -No: D400.42 Year 1993Dimensions of the grinding wheels: 175 x 22 mmMotor power: 0.25 kWPower connection: 380 V / 50 HzWeight approx. 180 kgOutside dimensions approx: 900 x 600 x 1600 mmWith- Underframe- Cooling device- tiltable and swiveling workpiece holderused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Tool Grinding Machine Twist Drill Pointing Machine Make EIGENBAUExternal dimensions W x D x H: 600 x 650 x 1500 mmlargest grinding wheel diameter: 200 mmThe machine has been prepared to tip out twist drills with MK2 shank.usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Description: Sharpening machine for milling tools, drills, blades and discs Serial number 3944 Speed 2800 r.p.m. Motor power 0.75 HP Table dimesions 600 x 150 mm Rack with content included (See pictures for more details)weight approx.: 350 kg, Approx. Onsite Dimension. (l x w x h): 1,050 x 1,650 x 2,000 mm
used
BN 102 C Producer Tos Swing 280 mm Distance between centres 630 mm Cross table adjustment 250 mm Longitudinal table adjustment 510 mm Vertical milling head adjustment 290 mm Machine weight 1000 kg
used
Control NUM 1060 / II Working distances: transverse axis x = 360 mm, height adjustment y = 150 mm, feed axis z = 230 mm, swivel axis B +/-100° Inclination of the grinding spindle from – 15° to +25° Rapid traverses x/y/z 10 m / min Grinding wheel speeds 1,000 rpm – 6,000 rpm Grinding wheel diameter max. 250 mm Machine weight 4.5 t Accessories: Ewamatic 3D measuring system for orienting and measuring the tools
used
Sell a tool grinding machine especially for grinding stools or similar. One side is equipped with a chuck that can be adjusted in all directions. The whole thing is on a cross support Dimensions 16001000'1500mm High Clamping range chuck 4040mm Grinding wheels diameter 175mm50mm and 320mm50mm Voltage probably 110V
used
Specifications: - Grinding wheel diameter approx. 175 mm - Disc speeds 2820 rpm - Support table left height adjustable + laterally movable + rotatable -Lighting - Drive 400 V / 0.75 kW - Space requirement approx. W 1050 x H 1350 x D 650 mm - Weight approx. 120 kg
used
Description: Fabrication number: 27/90 Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: 3.6 A Connection: 1.4 kW Table dimensions: 950 x 120 mm Grinding wheel diameter: approx. 100 mm Incl. various machine accessories suitable for the machine such as clamping elements, dividing heads and holdersweight approx.: 900 kg, Approx. Onsite Dimension. (l x w x h): 1,600 x 1,300 x 1,700 mm
used
Double grinder bench, make GREIF type D 30 - 5 - 5 KTMasch. -No: 208478, year of construction 1984Technical specifications:Grinding wheel size: 300 x 50 x 76 mmCut-out: 130 x 30 mmSpeeds: 1500 rpm.Drive power: 1.5 kWPower connection: 380 V / 50 HzWeight: 200 kgExternal dimensions: 1100 x 450 x 1500 mmWith- K 36 + K 60 grinding wheels- Tool support 260 x 165 mm- Tool support can be tilted- coolant device- Dry and wet grinding- Eye protection glassused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Tool Lapping and Grinding Machine make HAARMANN type DMPUFabr. -No: 1347 built in 1961Grinding wheel size: 200 x 50 mmRecess: 110 x 25 mmleft side table size: 175 x 400 mmleft side table inclinable and deliverableright side table size: 300 x 170 mmright side table tilt, tilt and height adjustablePower connection: 380 V, 50 HzMotor power: 0.55 kWDimensions L x W x H: 900 x 680 x 1300 mmused, from an operating resolution, despite the year of constructionin good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Tool grinding machine is equipped with two grinding wheels. Of which is a diamond disc. The two tables can be adjusted by loosening the clamping lever in their angles. The tool is set by a scaled handwheel. On one side, a swinging table on the other side is a handwheel. A coolant pump is installed in the foot
used
CONTROLS CNC controls SIEMENS 840 D SL TECHNISCHE DATEN .. max.: 18000 /min .. to: 30000 m/min .. to: 30000 m/minWORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 5 X-axis travel: 630 mm Y-axis travel: 465 mm Z-axis travel: 630 mm rotating range C-axis from: 70 ° rotating range C-axis up to: -250 °ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzX,Y,Z linear axes CU GentryA Rotation axis SK50 n=1000 1/minC axis = -70 +250Equipment:- Robot automation CU Fanuc M-10iA- Workpiece - Renishaw MP250 probe- Tool - Renishaw LP2 probe- Dittel balancing system P6001- Dittel structure-borne sound system DM6000- Haas-CU, including automation- Haas robot cell CU- Siemens 840 DSL handheld control unit- Expansion of pallet ...
used
Description: Serial number: 2786 Control: SIEMENS SINUMERIK 840D/additional program 'Sequence list' Technical data (without guarantee): Travel distances: X-axis: 400 mm Y-axis: 270 mm Z-axis: 250 mm A-axis (dividing head): 360° C-axis (spindle axis) Tool changer: Number of tools: 4 Grinding spindle: HSK 50/12 kW max./8000 rpm Incl. ram handling Incl. the tool clamping device (SK 50 holder) which can be seen in the last pictures Important note: without centrifuge and oil tank Coolant system not included in the scope of sale and delivery Also without the clamping device for workpieces shown in the photos and videosweight approx.: 7,500 kg, Approx. Onsite Dimension. (l x w x h): 2,350 x 1,750 x 2,800 mm
used
Description: Suitable for manual grinding of cutting, milling and drilling tools such as end mills, shell end mills, Radius milling cutters, end milling cutters, thread taps, step drills, etc. on the circumference, end face and spiral. Accesories : optical length and angle measuring device with measuring microscope cylindrical grinding device 1 dressing device for radii 3 grinding wheel guards 3 cover discs 2 dividing discs 10 grinding wheel mounts, Workpiece diameter between the centers: 238 mm, grinding stroke max.: 110 mm, Grinding stroke max.: 190 mm, Vertical adjustment of grinding head: 325 mm, Cross adjustment tool slide: 100 mm, Grinding head carrier swivelling: 360 °, Vertical adjustment of the grinding head: 325 mm, Tool carrier swivelling: 360 °, Grinding spindle speeds infinitely variable from: 2,000 - 10,000 rpm,, Connected load: 2.0kW (400V/50Hz), Dimensions L x W x H: 11 ...
used
Tool grinding machine make HAHN & KOLB type WS 54Year of construction 1975gr. workpiece diameter: 200 mmgr. clamping length between the tips: 230 mmMounting cone: MK 5Gr. grinding length: 110 mmCrossfeed: 140 mmPivoting the workpiece spindle head: +/- 7.5 °Swiveling the angle head horizontally and vertically: +/- 90 °Speeds of the grinding spindle: 4450 - 31000 rpm.Grinding wheel diameter: 125 mmMotor power: 0.55 kWDimensions L x W x H: 1400 x 1000 x 1500 mmMass. approx: 500 kgused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
max. grinding diameter: 400 mmgrinding length: 140 mmworkpiece length: 400 mmtotal power requirement: 3 kWweight of the machine ca.: 0,56 tdimensions of the machine ca.: 0,9x1,2x1,70 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Equipment: Precision Six-Jaw Chuck 1. Cylindrical grinding device Partial Setup Coolant system Instruction manual
used
Description: Saw blade grinding machine with: - Diamond grinding wheel for carbide circular saw blades - Rubber feet for damped and low-noise operation - Spacers for different saw blade holes Without saw blade Saw blade diameter 80 - 700 mm Workpiece headstock motor 0.25 kW Grinding wheel diameter 125 mm Speed 2850 U / min Grinding range -20 to +20 degrees Machine weight approx. 12 kg Space requirements approx. 700 x 400 x 300 mweight approx.: 12 kg, Approx. Onsite Dimension. (l x w x h): 700 x 400 x 300 mm
used
Description: Voltage: 380V Power: 0,26kW Collection on: 29/04/2024 or 30/04/2024 afternoon or 06/05/2024  ,  ,Collection times by arrangement  , IMPORTANT: Collection times may vary if separate collection times are explicitly stated in  ,in the item descriptionweight approx.: 150 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 1,100 x 1,000 mm
used
Tool Grinder (End Mill Grinder) Make HOSOI Grinder Machine Type S.T.E.CYear of construction 1982electrical connection: 380 V, 50 HzDrive power: 0.4 kWused, from an operational resolutionin good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
US 2305 young, with lots of accessories
used
Tool grinding machine Jungner US-450 Table: 800 x 114 mm Travels: -X: 450 mm -Y: 300 mm -Spindle vertical travel: 250 mm Spindle speed: 1400 / 2800 / 3500 / 7000 / 5600 / 11200 rpm 2-axis digitals No equipment with the machine Dimensions: -Length: 120 cm -Width: 140 cm -Height: 170 cm
used
max. grinding diameter: 250 mmgrinding length: 600 mmworkpiece length: 780 mmtable-size: 1030x214 mmspindle turning speed range: 2000-6000 U/minweight of the machine ca.: 1.2 tHydraulic executionUniversal dividing headRelief grinding attachmentHelical grinding attachmentLots of accessorieswww.marcels-maschinen.c The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
: 1640 weight: 280 kg: ja The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
CNC Tool grinder Makino Seki Mod.CNJ5u-H Year: 2009 Excellent condition, occasionally used by Samsung Electronics.
used
Description: Power of drive motor 0.25 kW, maximum 4500 rpm, largest bore of collet chuck 17.5 mm, inner taper of taper sleeves MK1 to MK2, largest radius to be ground 10 mm, coarse adjustment of dividing head support on pipe guide 100 mm, largest adjustable relief angle approx. 45°, largest lateral displacement of milling holder 10 mm, largest longitudinal displacement of milling holder 40 mm, number of notches on dividing wheel 12weight approx.: 60 kg, Approx. Onsite Dimension. (l x w x h): 500 x 600 x 300 mm
used
Description: Serial number: 1559 Grinding wheel diameter: approx. 100 mm Table dimensions: approx. 510 x 190 mm Max. Tool diameter between the tips: 130 mm Max. Tool diameter with flying clamping in the universal dividing head: 620 mm Max. Tool lengths between centers: 270 mm T-slot machine stand: 12 mm T-slots grinding head, tool slide and accessories: 8 mm Movement range: Working paths Sanding stroke: 190 mm Sanding stroke for twist sanding: 190 mm Cross adjustment of tool slide: 100 mm Vertical adjustment of sanding head: 325 mm Longitudinal adjustment of sanding spindle: 5 mm Coarse adjustment travel Tool carrier: 220 mm Grinding head support: 800 mm Universal dividing head on tool slide: 330 mm Swivel angle Sanding head support: 360° Sanding head: 360° Tool carrier: 360° Drive: Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: 14 A Te ...
used
Description: machine no.: 33 operating voltage: 400 V frequency: 50 Hz , nominal current: 16 A connected load: 11 kW speed: 3000 – 8000 rpm grinding body diameter: max. 150 mm , clamping and grinding ranges: , max. workpiece diameter: approx. 250 mm , max. workpiece diameter with counter bearing: approx. 125 mm , max. workpiece length without clamping shaft: approx. 450 mm , max. workpiece length with counter bearing without clamping shaft: approx. 250 mm , max. grinding length depending on workpiece position, grinding body holder: max. 340 mm , max. grinding length at ,working programs: approx. 280 mm , tool holder: SK 50 , tool weight: max. 50 kg , travel of X-axis: 340 mm , feed rate of X-axis: 7,5 m/min , direct measuring system resolution: 0,0005 mm , travel ,of Y-axis: 240 mm , feed rate: 7,5 m/min , direct ...
used
Description: Power of drive motor 0.25 kW, maximum 4500 rpm, largest bore of collet chuck 17.5 mm, inner taper of taper sleeves MK1 to MK2, largest radius to be ground 10 mm, coarse adjustment of dividing head support on tube guide 100 mm, largest adjustable relief angle approx. 45°, largest lateral displacement of milling holder 10 mm, largest longitudinal displacement of milling holder 40 mm, number of notches of dividing wheel 12weight approx.: 60 kg, Approx. Onsite Dimension. (l x w x h): 500 x 600 x 300 mm
used
Description: Power of drive motor 0.25 kW, maximum 4500 rpm, largest bore of collet 17.5 mm, inner taper of taper sleeves MK1 to MK2, largest radius to be ground 10 mm, coarse adjustment of dividing head support on tube guide 100 mm, largest adjustable relief angle approx. 45°, largest lateral displacement of milling cutter holder 10 mm, largest longitudinal displacement of milling cutter holder 40 mm, number of notches on dividing wheel 12weight approx.: 60 kg, Approx. Onsite Dimension. (l x w x h): 500 x 600 x 300 mm
used
PONAR KOWARY NUA 25 tool grinding machine was built by the Polish company PONAR KOWARY (LAKFAM) in 1984. A machine characterised by a robust construction of high stability, is used in tool shops and workshops for precision grinding of tools and tooling. Grinding of workpieces is performed on a table with a surface area (L x W) of 915 x 135 mm with two handwheels for manual longitudinal movement (X axis) and transverse movement (Z axis) of the work table. The reliable grinding wheel spindle moving at 3850 and 5635 rpm guarantees rapid and precise machining. The total weight of the machine is 910 kg. The machine is offered with the extensive range of equipment shown in the attached photos, which includes: – divider – angle vice 2 pcs. – moving tailstock: 2 pcs. – 3-jaw chuck fi 160 + spanner – workpiece centre positioning tool – fixed magnet – screw line tool – b ...
used
Tool grinding machine, Fabr. Reinecker, WZS 3, used, with extensive accessories Spiral sander Handpiece head Automatic part head Hydraulic table movement Cylindrical grinding device for exterior and interior
used
Lapping machine make REMA type SL 07Mash. -No: 069043Grinding wheel size: 125 mmTable size: 340 x 150 mmEngine speed: 2900 rpm.Power: 0.55 kWPower connection: 220V / 50 HzOutside dimensions approx.: 570 x 740 x 1350 mmWith- swinging table. tiltable and tiltable- without basevery little usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Lapping machine make REMA type SL 07Mash. -No: 028038Grinding wheel size: 125 mmTable size: 340 x 150 mmEngine speed: 2900 rpm.Power: 0.55 kWPower connection: 220V / 50 HzOutside dimensions approx.: 570 x 740 x 1350 mmWith- swinging table. tiltable and tiltable- Underframevery little usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
2-point tool grinding machine make REMA type ST 15/175Machine -No: 037376 built in 1976Technical specifications:Grinding wheel dimensions: 175 x 60 x 51 mmSize of the support table: 365 x 180 mmClamping range of the steel holder up to: 40 mmOscillation length of the grinding wheel: 80 mm2 speeds: 1450/2900 rpm.Drive power: 0.73 / 1.1 kWExternal dimensions approx .: 1400 x 700 x 1600 mmwith- tiltable table- oscillation- coolant pump- Coolant collecting panused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Description: Universal tool grinding machine Cylinder loose on one side, freely movable by handweight approx.: 650 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 1,600 mm
