thread milling machine used for sale

Milling machine from a training workshop in very good condition Manufacturer lid Type FP1 Active

Mikron WF31D Precision Milling and Drilling Machine Machine with chips and splash guard cabin Equipped with a Heidenhain TNC355 controller Technical Specification The WF 31 D is a precision milling and drilling machine for series production and CNC training. Driven by an automatically shifting step gearbox and Poly-V belts. Vertical spindle can be extended by 90 mm; Conversion from vertical to horizontal machining possible. Ball screws with DC drives allow simultaneous feed movements. Guides are protected against dust, chips and coolant. Specifications Manufacturer: Mikron Type WF31D Control: Heidenhain TNC 355 Longitudinal movement (X): 560 mm Transverse movement (Y): 500 mm Perpendicular movement (Z): 400 mm. Drive power: 3.3/4.0 kW Speed range: 40-4000 rpm Feed speed: 2-3000 mm/min Rapid traverse speed X/Y: 6000 mm/min, Z: 5000 mm/min. Electrical equip ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmBar diameter max.65 mmTurning diameter500 mmWork spindle (left)Diametre of spindle nose170h5 mmSpindle noseFlat flange Spindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

Universal tool milling machine, used universal milling machine, used Type FU 315 - V/2 Fabr. WMW Heckert Built: 1979 Table size/ table: 1250 x 315 mm Laengsmotion/ longit. move: X: 850 mm Horizontal movement/ horiz. Move: Y: 270 mm Vertical movement/ Vert. move : Z 355 mm Tool holder/taper: ISO 50 Spindle speeds R+L infinitely/ speeds of spindle ( left/right) 28 - 1400 rpm. Pre-shot stepless all axes X, Y and Z/ feeds all axis 10 - 630 mm/min / 250 mm/min Drive power/ load 3.8 kW Weight: 2 t

Demonstration article Condition: Mint Specifications: Drilling capacity in steel 50 mm Milling capacity face milling cutter 125 mm Milling capacity end mill 40 mm Spindle holder (turning spindle) ISO 40 Speed range 40 - 2000 rpm Speed levels infinitely variable Quill stroke 65 mm Milling table grooves / width x spacing 5 / 14 x 63 mm Verical table grooves / width x spacing 3 / 14 x 63 mm Spindle projection 180 - 485 mm Table load capacity 160 kg Milling head swivel range ± 45 ° Quill spacing table 50 - 450 mm Horizontal spindle distance table 145 - 545 mm Milling table area 750x320 mm Table path X x Z 405 x 305 mm Vertical table surface 890 x 225 mm Feeds X/Y/Z 10 - 1000 mm/min Feed stages X/Y/Z infinitely variable Motor power 3700 W Torque X-axis 7.7 Nm Y-Axis Torque: 7.7 Nm Torque Z-axis 1.7 Nm Mains connection 400/50 V/Hz Cubature 750x320x450 mm Len ...

Wanderer ISO 40

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaTurning diameter500 mmSwing diameter over guide ways500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

Universal milling machine vertically / horizontally from a training workshop Manufacturer Hermle Type FW801 Tool holder SK40 automatic feed in three axes Digital display in three axes Machine technically in very good condition under electricity ready for demonstration Technical data: Travel: x=350mm y=150mm z=220mm Spindle speeds from 50 to 3,150 rpm can be infinitely variable Feed speed infinitely adjustable via rotary pot from 10 to 5,000 mm/min, aisle Special price Used milling machine Hermle FW 801

KIMLA BPF 1530 CNC router was built in 2014 in Poland by POLCOM Przemysław Kimla. The machine, dedicated to both small and medium-sized businesses, is the perfect choice for precision machining of a wide range of materials. All machining processes, i.e. milling, cutting and engraving, are performed on a large vacuum table by a powerful high-speed spindle. X,Y,Z axes are, in turn, driven by reliable digital servo drives that provide the appropriate acceleration and speed in each direction. The BPF 1530 CNC milling machine is offered with an extensive range of equipment, consisting of, among others, a BECKER vacuum pump and a tool correction sensor. The machine has undergone regular maintenance and servicing. During the last service in the second half of 2024, the vanes in the vacuum pump were replaced. It is also possible to purchase an additional new spindle at a net price of 2250 EU ...

PLOT ELECTRONICS SENTINEL N 2160 CNC router was built in 2021 in Poland by PLOT Electronics. This extremely efficient machine is the perfect choice for precision machining of a wide range of materials, i.e. aluminium, plastics and wood. The machining process is performed on a large vacuum table by means of a reliable, high-speed spindle. X,Y,Z axes are in turn driven by reliable servo drives, which provide appropriate acceleration and speed in each direction. All this is complemented by a light, yet rigid design that eliminates any vibrations during even the most intense challenges. The offer price includes extensive equipment, consisting of, among others, a vacuum pump and advanced cncGraF Pro software. The SENTINEL N 2160 CNC milling machine weighs approximately 2000 kg. Technical specifications of the PLOT ELECTRONICS SENTINEL N 2160 milling machine - software: cncGraF Pro - mach ...

- travel range: X= 485, Y= 385, Z= 380 mm - table size: 800 x 460 mm - tool holder: SK 40 - dimensions LxWxH: 2440 x 1800 x 2100 mm - weight: ca. 2.000 kg

Table clamping area: 190 x 710 mm Table movement x: 390/360 mm Table movement y: 150 mm Table movement z: 280 mm Spindle holder: SK 40 Spindle speeds: 100 - 3100 rpm Feeds longitudinal 0 - 600 mm/min electr. Connection: 380 V, approx. 1.5 kW Space requirement: 1400 x 1200 x 1500 mm Weight: approx. 680 kg

CNC Model: Heidenhain CNC Version: ITNC 640 Head Type: Automatic Fourth and Fifth Axis Head Additional technical notes for the head: 0.001° positionable head Tool Mount: ISO 50 Spindle power: 38Kw Number of spindle speeds: 4000 Number of tools: 40 X-axis travel: 4000mm Y-axis travel: 1300mm Z-axis travel: 1500mm Fast feeds linear axes X Y Z: 20m/min Table dimensions: 4100 x 1100mm Table capacity: 12000Kg Guides: roller CNC divider: yes Rotation: Continuous Cutter type: fixed bench Chip conveyor: belt Machine equipment: optical scales :::D DIMENSIONS AND WEIGHT::: Length: 10560mm Width: 4200mm Weight: 26000Kg

SERON 1310 PRO CNC router was built in 2020 in Poland by SERON Sp. z o.o. Sp.k. The machine, designed for precision machining of a wide range of materials, is distinguished by a number of modern, carefully selected components with the best technical parameters. Materials such as mild metals, composites, plastics and solid wood are machined by means of a high-speed brushless spindle. The design, made entirely of stress-relieved steel profiles and sheets, in turn, ensures the long-term stability and dimensional precision of the machine. The operator has at his disposal an industrial, professional CNC control with many useful functions. Among them, there is for example the smooth vector analysis function, which ensures that the machine runs smoothly even with dynamic changes in direction and complex shapes. All equipment is integrated inside the security fence. The 1310 PRO CNC milling m ...

• max workpiece thickness: 55 mm • min. workpiece width: 80 mm • max profile depth: 80 mm • max edge thickness: 3 mm • Table size: 800 x 380 mm • Foot pedal operation • Adjustment via mechanical counters • Weight approx. 120 kg (Changes and errors in the technical data and prices reserved!)

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmMax. Turning Length1200 mmTurning diameter500 mmBar diameter max.65 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

Table length: 10.800 mm Table width: 1.000 mm Table height: 200 mm Load capacity: 10 t/m Power motor spindle: 22 Kw Max. speed of turning: 1.700 rpm X Axis travel: 7.000 mm Vertical axis travel: 2.000 mm RAM travel: 1.000 mm Total installed power: 60 Kw Rapid feed rate: 15 mt/min CNC ECS 4801 Chip conveyor

KIMLA BPF 2131 CNC router was built in 2014 in Poland by POLCOM Przemysław Kimla. The machine, dedicated to both small and medium-sized businesses, is the perfect choice for precision machining of a wide range of materials. All machining processes, i.e. milling, cutting and engraving, are performed on a large work table by means of a powerful, high-speed spindle. The offer also includes a set of tool holders. The KIMLA CNC milling machine weighs 3100 kg. Technical data of the KIMLA BPF 2131 milling machine - machined materials: mild metals, wood, wood-based materials, plastics, etc. - CNC controller - work table dimensions (L x W): 3100 x 2100 mm - air pressure: 8 bar - power: 14 kW - power supply: 400 V; 50 Hz - weight of the BPF 2131 machine: 3100 kg

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 100 mm - B-axis ±110° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 5 bar; 20l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor - USB interface, Ethernet interface; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length750 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range- 5000 rpmDrive power (40% DC)32 kWMax. torque (40% DC)360 NmC-Axis Speed-5000 rpmTorque of C-Axis (holding torque)280 NmT ...

Technical Specifications - Bridgeport Series I Table Size / Work Surface 9" × 49" (≈ 299 mm × 1245 mm) T-slots 3 pieces, spacing 2.5" (≈ 64 mm), groove width 0.625" (≈ 16 mm) Travel X (Transverse) without Power Feed: 36" (≈ 914 mm) with power feed: 33" (≈ 838 mm) Travel Y (Transverse to Feed) 12" (≈ 306 mm) Quill Stroke (Drilling Spindle Stroke) 5" (≈ 127 mm) Knee Lift (Z-Axis of Table) 16" (≈ 406 mm) Ram Adjustment (Head Stem on Ram Slide) 12" (≈ 306 mm) Min. / Max. distance spindle axis to table nose (spindle/table nose distance) min: 2.5" (≈ 64 mm) Max: 18.25" (≈ 463 mm) Min. / Max. distance spindle to column front (minimum/maximum internal width) min: 6.75" (≈ 171 mm) max: 18.75" (≈ 476 mm) Spindle / Quill Spindle Diameter: 1.875" (≈ 48 mm) Quill Diameter: 3.375" (≈ 86 mm) Spindle holder (standard): R-8 Spindle motor / power 30 minute ...

CNC Universal – Milling & Drilling Machine DECKEL MAHO DMU 80 P duoBlock With path control MILL PLUS iT Year of Make: 2006 Travel: X 800 Y 800 Z800 Speed range: 0 – 8,000 rpm infinitely variable ( SK 50 ) With the following accessories: NC rotary table 900 mm x 700 mm clamping surface (table load max. 1.4 t) Universal milling head with controlled B axis Universal tool changer with 40 magazine positions as a double gripper ( SK 50 ) Full protection cabin with sliding doors and interior lighting IKZ – 40 bar Conveyor Rotoclear Tool Measurement BLUM Laser 3 D Probe Heidenhain TS 641 Operating mode 3 + 4 Electronic handwheel 3-Piece Height Adjustable Machine Shoes Transport device Operating instructions

REALMECA MINI C3X-CNC VERTICAL 1 phase machining milling machine Used for teaching begginers. Perfect condition

MAHO MH-700 with numeric control X, Y Table size: 800x300 Working area: X-450,Y-250,Z-300 Spindle taper: MK3 Feed range: 7-250mm/min Vertical head swiveling 90 degreess Power: 3KW Dimensions: 1300x1200x1700

Automatic double copy milling machine - longitudinal copy milling machine Manufacturer: Wigo Model: 1075 Working length: Workpiece with straight end faces .. 1300mm Wersktück with rounded end faces .. 1000mm Working width: max. 200mm Working height: max. 130mm Feed continuously 0.5 - 12 m/min Milling units: 2 x 4 KW Hydraulic unit: 1.1 KW Additional 2 milling unit on the right side. Clamping cylinder pneumatic: 2 pcs.

Bessler - Wood Milling Machine Speed in 18mm Koskisen Grey consisting of a router table (X-axis), a portal (Y-axis), a Z-axis and a base frame filled with polymer concrete. Mechanics set: consisting of profile guides KPF-S 20 incl. carriage. Ball screw, for the Z-axis. Precision racks, with a gearing quality 8. Profile rails for the installation of limit switches. All sub-elements assembled. Machine feet adjustable. Control set: consisting of planetary gears, with a reduction ratio of 1:5 Stepper motors with 9.2NM, 4A. High-performance power amplifiers with 80V each, a 70V power supply and core transformer, completely pre-assembled in the control cabinet. Sensors for each axis. Protective device CE-compliant due to moving suction device. High-frequency spindle with 2.2KW incl. union nut, frequency converter, mains filter, brake resistor, as well as collet set. 21.5 ...

Notching cutter Wegoma Type: AKF 125 for milling plastic and aluminium profiles with profile stop on both sides swivel 60° Pneumatic clamping device Manual feed with hand lever of the three-phase milling motor Engine start directly at the hand lever Suction nozzle with a diameter of 100 mm running on the milling carriage Profile stop adjustable without tools with locking bolt for 90° and 45° on both sides Power milling motor 1.5 kW Speed milling motor 2800 rpm Milling path max. 380 mm Milling cutter diameter/height max. 210 mm/ 90 mm Milling spindle diameter 27 mm Dimensions: L 700 mm x W 500 mm x H 700 mm Weight approx. 50 kg

Operating hours: 600h Specifications: Travel in X/Y/Z: 450 / 350 / 400 mm Distance from spindle nose table: 230 - 630 mm (horizontal milling spindle) Rapid traverse speed X/Y/Z: 5000 / 5000 / 5000 mm/min Working feed X/Y/Z: 10 - 2000 mm/min infinitely variable Max. feed force in X/Y/Z: 10 / 10 / 15 kN Clamping surface: 800 x 400 mm (rigid angle table) Max. table load: 30 kg (rigid angle table) Vertical milling head: Speed range: 10 - 5000 1/min Power: 10 kW Dimensions (LxWxH), approx.: 1980 x 2030 x 1990 mm Weight, approx.: 2270kg Equipment: - Swivel control panel - Shafts and gears hardened and ground - Digital display Sinumerik 828D - Clockwise / counterclockwise rotation of the main spindle - Linear guides - Four-bearing milling spindle radial/axial - All pinch points eliminated by covers - Main motor with spindle brake

Lid FP 4 A Used machine (very good) Control mode Conventional Built in 1992 Operating hours approx. 500h Price 12,000 € net plus VAT Dimensions 2500x2500x1900 Weight 2000 kg Location Haiger Description Universal tool milling machine of the brand lid suitable for tooling, fixture construction, training as well as mold making Travel: 560/500/450mm Control : Dialog 11 Technical data Control CNC Dialog 11 Table 900x530mm Longitudinal path (X,Y,Z axis) 560/500/450mm Tool changer no Tool holder: ISO 40 Vertical spindle speeds: 31.5-5000rpm

Description Universal tooling machine from Lid suitable for tooling, fixture construction, training as well as mold making Technical data Year of construction / YOM 1991 Speeds / Spindle 63 - 6300 rpm Steuerung Control CNC Grundig Dialog 11 Vorschübe / Feeds 2 - 3000mm/min Tisch / Table 910 x 530mm Recording / Taper ISO 40 Way / Travel (X,Y,Z) 600x500x500mm Weight /Weight ca 1830kg Changer / Tool changer No Dimensions / Dimension 2500x2000x2000mm Travel: 600x500x500mm Speed: 31.5 - 6300 rpm The machine comes from a tool making and has been regularly serviced.

Edge flush milling machine JKO LT 750 with feed-in apparatus Masch. No. 1666 L x W x H: 1100 x 1000 x 1500 mm Built in 1966 Weight approx. 520 kg The machine is in good condition, ready for operation. Changes, mistakes, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

Cone slot milling machine Duko L x W x H: 1300 x 1000 x 1500 mm Weight approx. 800 kg Built in 1963 The machine is in good condition, ready for operation. Changes, mistakes, intermediate sale reserved ! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

CME FU2 universal milling machine. Table: 1400x300mm. Longitudinal travel: 1050mm. Cross travel: 300mm. Vertical travel: 500mm. ISO40. Hure head. Speeds range: 12. (40-1800rpm). Motor power: 7,5Kw. DRO Fagor for 3 axis.

Table clamping area: 290 x 1250 mm Table movement x: 800 mm Table movement y: 360 mm Table movement z: 450 mm Milling head pivotable: 90/45 ° Spindle holder: ISA 40 Spindle speeds: 56 - 4500 rpm Pinolene stroke: 125 mm Pinolene feeds: 0.035; 0,14; 0.7 mm/min Spindle drive: 1.8/2.4 kW Space requirement: 2000 x 1900 x 2300 mm Weight: 1700 kg

New drive shafts for Vertical and Universal Fraeshead FU 400 - FW 400 HECKERT Germany Price 900,-- Euro per square plus VAT

KIMLA BPF 2070 CNC router was built in 2010 in Poland by POLCOM Przemysław Kimla. The machine is used for precision machining of parts made of such materials as wood, plastics and aluminium. The machining process is performed on a large work table with a length of 7050 mm and a width of 2085 mm by means of a reliable, high-speed spindle. Process stability, on the other hand, is ensured by an extremely rigid design that effectively eliminates any vibration and oscillation during even the most intense challenges. All this is complemented by an industrial CNC controller with easy-to-use PC-CAM software. The BPF 2070 CNC milling machine weighs 6000 kg. Technical specifications of the KIMLA BPF 2070 milling machine - machinable materials: wood, plywood, polycarbonate, polymer plates, aluminium, etc. - feed in the X/Y/Z axis: 2085/7050/500 mm - work area (L x W): 7050 x 2085 mm - maxim ...

Qty. 1 Second-hand milling and scalping machine – Copper and brass strip – stopped in 2010 Mfc.: Torrington Type: FR1 Built: 1976 Milling and scalping from the upper and lowe sides Strip width: 508 - 770 mm Strip thickness: 10.0 – 13.5 mm Coil weight: 6.5 Ton Capacity: approx. 200 000 T/annum

x-travel: 10000 mm y-travel: 1500 mm z-travel: 1000 mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control Heidenhain TNC 640 Speed [rpm] 12000 Travel X/Y/Z [mm] 400/350/350 Spindle: Technology Direct Drive Speed 12,000 rpm Power (max.) 13 kW Torque (max.) 95 Nm Tool holder SK40 NC swivel rotary table: B-axis -50°/+110° C-axis 360° Clamping surface ø450 mm Table load (max.) 200 kg General: Tool magazine 48 stations Rapid traverse in X/Y/Z 48 m/min Equipment/accessories: Direct displacement measuring system (glass scales) in X/Y/Z Chip Management Chip Conveyor Coolant management IKZ system with filter and high pressure, 30 bar Workpiece Measurement Probe, Heidenhain TS740 Tool Measurement Laser, Renishaw NC4 TX Setup operation Electronic handwheel Other equipment spindle coolers Other accessories Div. gebr. Tool holders

Micron WF 61 C Equipped with a controlled round table Workspace X-axis: 800mm Y-axis: 500mm Z-axis: 460mm Table: 1000 x 500mm Number of working spindle speeds: 21 Speed range 40-4000 rpm Pinole movement vertical: 90mm Feed speed in all 3 axes: 1-3000 mm/min

Mikron VCP 800 2007 Built in 2007 Control Heidenhain iTNC 530 Travel X-800mm , Y-650mm , Z-500mm Working spindle: Spindle speed max. 12000rpm. Tool magazine: Number of tool slots 36 Machine table: Clamping area 800 x 650mm Accessories: Inner coolant supply - Belt filter system 20Bar Conveyor

Lid Maho DMC 80 U hi-dyn Workspace: X-axis: 800mm Y-axis: 700mm Z-axis: 600mm Workpiece weight: 800 kg Number of axes: 5

5 Axis Lid Maho DMU 200 P Built in 2000 The machine is in very good condition. Videos under power available ! Technical data: Travel: X 1800 mm Y 2000 mm Z 1100 mm NC Round Table: Table area: 1700 x 1400mm Permissible load: 5000 kg Number of grooves: 11 Axis (swivel range) : 360 x 0.001 degrees Motor spindle: 8,000 rpm (SK50) Tool holder: SK 50 Tool changer: 60 seats Max tool weight: 20 Kg Max tool length: 450mm Max tool diameter: 110mm

GeneralUniversal Milling Machining Centre - Linear pallet changer with 2 pallets - Coolant tank 2,500 lt / 660 gallon - Chip conveyor - Rotating clear-view window - Electronic handwheel; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical60000/30000/40000 mm/minRapid traverse longitudinal/transverse/vertical60/30/40 m/minWorking area 1Longitudinal3400 mmCross3400 mmVertical2000 mmTool changerType of magazineWheel Tool changer planevertical Type of gripperDouble gripper Clamping surface: 2,000 mm x 2,500 mm / 78.7 in x 98.4 in (DIN 55201 - A2) centre bore: d 100 mm H6 / d 4 in H6 level bush: d 25 mm H6 / d 0.9 in H6 Number of T-slots: 1x 22 H7 (alignment groove, table centre) 8x 22 H12 (clamping grooves) Distance betweeUniversal head with controlled B-axisContinuously positioning universal milling head (B axis) with integrated motor spindle for  ...

GeneralUniversal Milling Machining Centre - Linear pallet changer with 2 pallets - Coolant tank 2,500 lt / 660 gallon - Internal coolant supply 40 bar / 580 psi through spindle centre (AD) - Chip conveyor - Rotating clear-view window - Electronic handwheel; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical60000/30000/40000 mm/minRapid traverse longitudinal/transverse/vertical60/30/40 m/minWorking area 1Longitudinal3400 mmCross3400 mmVertical2000 mmTool changerType of magazineChain Tool changer planevertical Type of gripperDouble gripper Clamping surface: 2,000 mm x 2,500 mm / 78.7 in x 98.4 in (DIN 55201 - A2) centre bore: d 100 mm H6 / d 4 in H6 level bush: d 25 mm H6 / d 0.9 in H6 Number of T-slots: 1x 22 H7 (alignment groove, table centre) 8x 22 H12 (clamping grooves) Distance betweeCabineFull protection cabinExtension Z travel range to 2 ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 ...

Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmGeneral- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Work spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle speed-12000 rpmSpindle  ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 125 mm - B-axis ±120° with pneumatic locking - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 12 bar; 23l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length1200 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-12000 rpmDrive power (100% ...

Year of construction 80s Technical data: Travel X/Y/Z: 400 / 400 / 400 mm Tool holder: SK 40 Speed range: 40 - 4000 1/min Feed, step-by-step Adjustable: 2 - 360 mm/min Rapid traverse: 4000 mm/min Angle table: 700 x 460 mm, max. load 350 kg Tool Changer: Number of tools: 20 Max. tool diameter: 80 mm Max. tool length: 300 mm Max. tool weight: 6 kg Equipment: - Control: CNC path control lid Dialog 11 - Hydromechanical clamping system SK 40 with tightening bolt DIN 69872 - Vertical and horizontal working spindle - Milling head can be swivelled manually +/- 90° - Geometrically stepped direct transmission for maximum torque - Milling performance on the working spindle

From business abandonment: We are selling a CNC portal milling machine with a working area of 3200 x 1510 x 300 mm It is used, but is well maintained and runs well. It was used to mill sheet material. Very good e.g. for wood, façade panels or Eternit cuts. It has 3 axes with rack and pinion drive Spindle: Air Cooled HF Spindle ES915 3.8KW S1 4.6KW S6 60% Ceramic/Steel Bearing With ISO30 collets (we supply with) ATC from HSD with Automatic Tool Changer (Air Driven) TOP: A complete replacement spindle is also included, freshly serviced with new bearings! The controller is an eding control on Windows PC, PC is included. A conversion of the Y-axis to 2 x12 Nm closed-loop stepper motor with very precise German Wittenstein gearboxes took place 5 years ago. X-axis runs with 9 NM stepper motor, Z axis too, also has a brake built in to hold the axle. Important and outsta ...
