od used for sale

PE/PP thick Sheet/board extrusion line Capable to produce ABA multilayer sheet extrusion thickness from 3 to 30 mm Widthness 1500 mm Extuders; JWS D/L=150/35 vented single screw extruder and D/L=JWS 90/35 vented single screw extruder, Hydraulic screen exchanger, ABA Distributor, 3 roller calendars (ODXL=700X2100 mm) with Fully oil temperature controlled, 10 pieces of cooling rollers with drive and cooling water units, 5 rolls temperature controlling system with drive, Cooling bracket (Cast aluminum) and lamination unit, tunnel anneal oven, First Haul off unit, Cooling bracket (Cast aluminum), Second haul off unit, Film coating system, Length and Transverse cutter, Belt conveyor, electricity control all of electrical, electronic and mechanical components were chosen from named company brands. (Servo motors from Yaskawa brand-Japan, PLC-Siemens S7-200, screen-SiemensMP277, breake ...

The TRIAGI is the only equipment that solves in an optimized way, the processes of heating, premixing, addition, emulsion and dispersion, deaeration and cooling of the product, without transfers or intermediate manipulations to which are always at odds with manufacturing costs, productivity and cross contamination risks. It offers the following advantages, derived from its careful design and construction: ·There are no dead zones. ·The self-adjusting scrapers sweep the surface corresponding to the useful volume. ·The sealing system guarantees a perfect closure even when operating under vacuum. ·Possibility of interchange of high speed homogenizing turbines.

Machine is in excellent condition https://www.beckman/centrifuges/ultracentrifuges/optima-max-xp Platform Tabletop UCF Maximum Speed 150,000 rpm Maximum g-Force 1019000 x g BioSafe No Acceleration 10 acceleration profiles Deceleration 11 deceleration profiles Speed Control ± 50 rpm of set speed Max Capacity Volume Range 0 - 194.4 mL Refrigeration System Solid state (thermoelectric temperature control system with forced air; no coolant; no CFCs/ODCs) Temperature Control 2.00 °C of set temperature Drive Type Cooling Variable Frequency Induction Drive with rotor overspeed ID Temperature Range(s) Set temperature range: 0 to 40°C in 1°C increments Zonal Capability No Vacuum and Pump Moisture-purging vacuum system Display Full-color LCD touch screen Weight 105 kg(231.5 lb) Width 73.9 cm(29.1 in) Depth 61.7 cm(24.3 in) Height 39.4 cm(15.5 in) Clearances 7.6 cm: side  ...

Four-sided planer Profimat 23 E – German production, WEINIG brand – for 6 heads – technical documentation – universal spindle – odometer reading 7662.7 mth TECHNICAL PARAMETERS: planing width 230 mm planing height 160 mm 1 lower spindle 5.5 kW 2 right spindle 3 left spindle 11 kW 4 top spindle 11 kW 5 lower spindle 7.5 kW 6 universal spindle 3600 7.5 kW adjustable spindles spindle diameter 40 mm feed continuously adjustable 5-24 m/min feed motor power 4 kW pneumatic clamp four steel upper pulling rollers three upper pulling rubber rollers rubber roller in the top to pull electric height adjustment tabletop length 2480 mm spigot diameter 140 mm pneumatic lock of the universal head Dimensions 470x190x200 cm weight 2800 kg

Lippert belt conveyor GF 12730-750-600 RA2259 Technical data: Conveyor length (NL): 12730 mm Frame width (NB): approx. 750 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor, R37 DRE80M4/TH/Z Electrical data: 50Hz V380-500, kW 0.75 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 12730 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,75/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie  ...

Lippert belt conveyor GF 4450-750-600 RA2257 Technical data: Conveyor length (NL): 4450 mm Frame width (NB): approx. 750 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor Electrical data: 50Hz V380-500, kW 0.55 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 2427 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,55/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns  ...

Lippert belt conveyor GF 8000-750-600 RA2254 Technical data: Conveyor length (NL): 8000 mm Frame width (NB): approx. 750 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor Electrical data: 50Hz V380-500, kW 0.55 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 8000 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,55/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns  ...

Transnorm belt curve conveyor 30°-800-700 IR900 right RA2256 Technical data: Manufacturer: Transnorm Condition: good (used) Conveying angle: 30° Nominal/outer width (NB): 800 mm Belt width (GB): 700 mm Inner radius (IR): 900 mm Overall height (BH): 210 mm Motor height (MH): 450 mm Motor type: SEW geared motor, SA42 DT71D-4 Electrical data: 380-500 V, 0.37 kW Conveying speed: please contact us Scope of delivery: without supports (please enquire if required) Optional: Supports Side guides Frequency converter for infinitely variable speed control Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg Features: Construction year: 1992 condition: very good (used) Nominal / inner radius in mm: 900 Nominal / outside width in mm: 800 Belt width in mm: 700 angle: 30° Driven: YES Running direction: RIGHT Engine type: SEW Eurodrive KW: 0,37/S1 Conveyor speed m / s: bitte  ...

Lippert belt conveyor GF 7920-750-600 RA2253 Technical data: Conveyor length (NL): 7920 mm Frame width (NB): approx. 750 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor Electrical data: 50Hz V380-500, kW 0.55 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 7920 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,55/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns  ...

Lippert belt conveyor GF 900-750-600 RA2252 Technical data: Conveyor length (NL): 900 mm Frame width (NB): approx. 700 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor Electrical data: 50Hz V380-500, kW 0.37 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 900 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,37/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in  ...

Lippert belt conveyor GF 1000-700-600 RA2251 Technical data: Conveyor length (NL): 1000 mm Frame width (NB): approx. 700 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor, R17 DRS71M4/MM05 Electrical data: 50Hz V380-500, kW 0.55 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 1000 Nominal / outside width in mm: 700 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,55/S1 Ampere: 1,30 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung se ...

Lippert belt conveyor GF 1035-750-600 RA2260 Technical data: Conveyor length (NL): 1035 mm Frame width (NB): approx. 700 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor, S37 DRS71S4/TH/Z Electrical data: 50Hz V380-500, kW 0.37 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: condition: good (used) Conveying length in mm: 1035 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,37/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie sic ...

Lippert belt conveyor GF 2500-750-600 RA2261 Technical data: Conveyor length (NL): 2500 mm Frame width (NB): approx. 700 mm Belt width (GuB): 600 mm Overall height (BH): 105 mm Support feet optionally available Conveyor speed (v m/s): please contact us Drive: SEW geared motor Electrical data: 50Hz V380-500, kW 0.37 / S1 Return pulley (UR): Ø = 81 mm Drive drum (AT): Ø = 81 mm Optionally available: Supports Side guides Frequency converter for stepless speed control Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Construction year: 2015 condition: good (used) Conveying length in mm: 2500 Nominal / outside width in mm: 750 Belt width in mm: 600 Driven: YES Engine type: SEW Eurodrive KW: 0,37/S1 Conveyor speed m / s: bitte Kontaktieren scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten S ...

Transnorm curved belt conveyor right bend 180°-800-700 IR600 RA2280 Technical data: Manufacturer: Transnorm Condition: good (used) conveying angle: 180° nominal/external width (NB): 800 mm belt width (GB): 700 mm innerradius (IR): 600 mm overall height (BH): 210 mm motor height (MH): 450 mm Motor type: SEW gear motor, SA37/T DRS71M4/TH Electrical Data: 380-500 V, 0,55 kW Conveying speed: please contact us Scope of delivery: without supports (if required, please contact us) Optional: supports Side guides Frequency converter for stepless speed control Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg Features: Construction year: 2015 condition: very good (used) Nominal / inner radius in mm: 600 Nominal / outside width in mm: 800 Belt width in mm: 700 angle: 180° Driven: YES Running direction: RIGHT Engine type: SEW Eurodrive KW: 0,55/S1 Conveyor speed m / s: ...

Transnorm curved belt conveyor right bend 180°-700-600 IR400 RA2222 Technical data: Manufacturer: Transnorm Condition: good (used) conveying angle: 180° nominal/external width (NB): 700 mm belt width (GB): 600 mm innerradius (IR): 400 mm overall height (BH): 210 mm motor height (MH): 450 mm Motor type: SEW gear motor, SA37/T DT71D4/TH Electrical Data: 380-500 V, 0,37 kW Conveying speed: 0,67 m/s Scope of delivery: without supports (if required, please contact us) Optional: supports Side guides Frequency converter for stepless speed control Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg Features: Construction year: 2014 condition: very good (used) Nominal / inner radius in mm: 400 Nominal / outside width in mm: 700 Belt width in mm: 600 angle: 180° Driven: YES Running direction: RIGHT Engine type: SEW Eurodrive KW: 0,37/S1 Conveyor speed m / s: 0,67 scop ...

Transnorm curved belt conveyor right bend 180°-800-700 IR600 RA2223 Technical data: Manufacturer: Transnorm Condition: good (used) conveying angle: 180° nominal/external width (NB): 800 mm belt width (GB): 700 mm innerradius (IR): 600 mm overall height (BH): 210 mm motor height (MH): 450 mm Motor type: SEW gear motor, SA32/T DRS71S4/MM05/LN Electrical Data: 380-500 V, 0,55 kW Conveying speed: 0,67 m/s Scope of delivery: without supports (if required, please contact us) Optional: supports Side guides Frequency converter for stepless speed control Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg Features: Construction year: 2014 condition: very good (used) Nominal / inner radius in mm: 600 Nominal / outside width in mm: 800 Belt width in mm: 700 angle: 180° Driven: YES Running direction: RIGHT Engine type: SEW Eurodrive KW: 0,55/S1 Conveyor speed m / s: 0,6 ...

Transnorm belt curve conveyor 90°-890-800 IR600 right RA1170 Technical data: Manufacturer: Transnorm Condition: good (used) Conveying angle: 90° Nominal/outer width (NB): 890 mm Belt width (GB): 800 mm Inner radius (IR): 600 mm Overall height (BH): 210 mm Motor height (MH): 450 mm Motor type: SEW geared motor Electrical data: 380-500 V, 0.55 kW Conveying speed: 0.8 m/s Scope of delivery: without supports (please enquire if required) Optional: Supports Side guides Frequency converter for infinitely variable speed control Price plus VAT ex central warehouse Dr. Sonntag GmbH & Co. KG 97076 Würzburg Features: Construction year: 1991 condition: good (used) Nominal / inner radius in mm: 600 Nominal / outside width in mm: 890 Belt width in mm: 800 angle: 90° Driven: YES Running direction: RIGHT Engine type: SEW Eurodrive Conveyor speed m / s: 0,8 scope of delivery: without supports and sid ...

grinding diameter: 250,350,450 mm grinding length: 1000 mm centre height: 125,175,225 mm grinding wheel diameter: 400 mm grinding wheel width: 50 mm bore: 127 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm grinding head swivelling: 360 ° grinding spindle head - swivable: 180 + - ° grinding spindle speed: 1500,1700,2200 U/min : 0,001-0,030 mm/Ø : 0-0,95 mm/Ø : ±8 ° longitudinal feed of the table: 1300 mm table speeds: 0,02-6 m/min : 130 kg : 130 inkl. Spannugkg kg : mm grinding depth: mm : 70 mm total power requirement: 6,5 kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 4,2 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your machines.Version R: Maschine hat Zentral ...

die Steuerung ist vorbereitet für Kompressor-Gleichlaufsteuerung. inkl. · Drucktaupunkt-Steuerung ·Mit einer Drucktaupunkt-Steuerung können Sie den Trockner im starren oder variablen Zyklus betreiben. Im starren Zyklus erfolgt die Umschaltung nach einer festgelegten Zeit (in der Regel nach 5 Minuten). Im variablen Zyklus erfolgt die Umschaltung abhängig vom erreichten Drucktaupunkt und der Beladung des Trockenmittels. Die Adsorptionszeit im variablen Zyklus beträgt maximal 60 Minuten. Neugerät Achtung: Das Gerät wird ohne Vor-, und Nachfilter geliefert. Ein Vorfilter ist dringend erforderlich, falls nicht schon vorhanden.. Siehe Optionen unten. (Bild: Katalogbild)

die Steuerung ist vorbereitet für Kompressor-Gleichlaufsteuerung. inkl. · Drucktaupunkt-Steuerung ·Mit einer Drucktaupunkt-Steuerung können Sie den Trockner im starren oder variablen Zyklus betreiben. Im starren Zyklus erfolgt die Umschaltung nach einer festgelegten Zeit (in der Regel nach 5 Minuten). Im variablen Zyklus erfolgt die Umschaltung abhängig vom erreichten Drucktaupunkt und der Beladung des Trockenmittels. Die Adsorptionszeit im variablen Zyklus beträgt maximal 60 Minuten. Neugerät Achtung: Das Gerät wird ohne Vor-, und Nachfilter geliefert. Ein Vorfilter ist in den meisten Fällen dringend erforderlich. Siehe Optionen unten. (Bild: Katalogbild)

Caljan telescopic belt conveyor LJ-6-19-800 RA2284 Base part with 3 electrically extendable and retractable telescopic elements. The telescope can be extended continuously up to 19000 mm at the touch of a button. Year of manufacture: 1995 Condition: Good overall condition Rated voltage: 3 x 400 VAC + PE Frequency: 50 Hz Fuse: 16 A Length base: 6000 mm Width base: 1000/1470 mm Base transfer height: 1000 mm Height base take-off: 810-1000 mm, adjustable at the touch of a button Length of telescopic section: 13000 mm Total length: up to 19000 mm Belt width (GB): 800 mm Load/m: 50 kg With purchase of 2 pieces 7.650,00€/piece Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Construction year: 1995 condition: gut Conveying length in mm: 6000+13000 Nominal / outside width in mm: 1000 Belt width in mm: 800 Driven: YES Engine type: SEW Eurodrive Zent ...

: Dreh- und kippbar : für Schweißpistole oder : für Plasma condition: nicht geprüft Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Belt conveyor combination 2 x GG 750-760/650 consists of 2 piece belt conveyors each with separate drive Make: Dematic Each conveyor belt length: 750 mm Total length of the combination: 1,550 mm Width: 700 mm Belt width: 650 mm Overall width: 760 mm Conveyor speed: v = 0,7 m/sec without supports without Guide other conveyor speed frequency converter .. Please ask if needed Features: Construction year: 1999 condition: good (used) Conveying length in mm: 750 Nominal / outside width in mm: 700 Belt width in mm: 650 Driven: YES Engine type: SEW Eurodrive Conveyor speed m / s: 0,7 scope of delivery: without supports and side guides Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbindung. Kontaktieren Sie uns einfach telefonisch oder per Mail. Wir helfen Ihnen gerne bei der Planung und Umsetzung Ihrer Projekte. Wir freuen uns darauf von Ihnen zu hör ...

Description: Semi-automatic numerically controlled panel bending machine, software with cycles up to 8 sockets. Sheet metal gripping system with suction cups, equipped with rear SA blades for folding tabs.  , Main features:  , Folding dimensions Max. bendable length: 3123 mm Min. folding length: 80 mm Max. folding width: 3123 mm Min. folding width: 142 mm Max. fold size (minimum, depending on thickness): 140 mm  , Customised trolley with tool changer equipment, also supplied with spare parts and moulds for additional PSA arrangement. Further information can be found in the attached documentation, ,the measurements given are to be understood with the machine assembled. Around 26000 working hours visible on photo odometer. Approx. Onsite Dimension. (l x w x h): 6,400 x 2,700 x 2,600 mm, weight approx.: Unknown kg

Baujahr 2018Kubota KX080-4a aus 2018 mit 6483,5 Stunden mit englischen Schnellwechsler wird verkauft wie auf den Bildern zu sehen ist ohne Schaufeln. Betankungspumpe vorhanden!Fast nicht ausgeschlagen, nur beim Hauptzylinder unten die Buchse und eventuell der Bolzen.Klimaanlage vorhanden und funktionstüchtig sowie die Heizung.Hydrauliköl mit Filter wurde gewechselt bei knapp 6000 Std sowie der Luftfilter bei 6266 Stunden wie auf den Bildern zu erkennen ist. Bagger läuft ansonsten wie auf dem Video zu sehen ist.Eigengewicht8.19 tTransportlänge6.45 mTransportbreite2.2 mTransporthöhe2.54 mTieflöffel-Inhalt0.25 m³Kettenbreite450 mmAuslegerMBReichweite7.33 mGrabtiefe4.6 mAusbrechkraft65.2 kNTieflöffelbreite0.8 mSerienKXMotorherst.KubotaMotortypeV3307CR-TE4Motorleistung46.5 kWHubraum3.331 lDrehzahl bei max. Drehmoment2000 rpmZylinderanzahl4Zylinder Bohrung x Hub94x120 mmGerne anfragen  ...

grinding diameter:630 mm grinding length:2000 oder 3000 mm centre height:320 mm table speed -stepless-:0,005-5 m/min min/max. table longitudinal travel:5/ 3350 mm table speeds:8 m/min grinding spindle- cross travel:420 mm workpiece-spindlehead motor:3,0 kW output of wheelhead motor:22 kW motor internal grinding:3 kW lubrication pump motor:0,11 kW weight of the machine ca.:15700 kg dimensions of the machine ca.:H1970/B3100/L12650 mm 40 % advance payment, by order confirmation 60 % before loading the machine warranty: 12 month one general overhauled cylindrical grinding machine, make TOS, type BUT/BUC 63 x 3000 with new 2-axis CNC Teach In control K 51/2 or alternatively Siemens Sinumerik 840 D. Our general overhauling includes: regrinding and scraping of all guide ways including lower and upper side of the table. Replacement of all main components. Complete new electric including cabinet  ...

x-travel:1050 mm y-travel:600 mm z-travel:530 mm table-size:1100x600 mm T-slots:18x5 (Breite x Anz.) mm max. table load:800 kg distance spindle center to table:100-600 mm rapid traverse in x-y-z axis:48/48/48 m milling feed range:1-12.000 mm/min spindle speed:10000 1/min spindle taper:40 BT oder SK spindle drive:11/15 kW Tool changer:30 fach max. tool weight:7 kg tool diameter:89 (voll)/125 (angrenz. leer) mm workpiece length:250 mm dimensions:2780x2500x2810 mm weight of the machine ca.:7,1 t automatic tool changer:30 fach Tool setter:Option inner coolant:20 bar CNC controller:FANUC 0i-M + MANUAL GUIDE i FUNCTION + 10.4" LCD MONITOR control cabinet Siemens PLC:getrennter Schrank f. Hoch- und Niederspannung autom. lube system:von LHL Factory-new, immediately available, vertical CNC machining center with CNC control MANUAL GUIDE i FUNCTION + 10.4 "LCD MONITOR. Our Taiwanese supplier is th ...

x-travel:850 mm y-travel:600 mm z-travel:530 mm table-size:950x600 mm T-slots:18x5 (Breite x Anz.) mm max. table load:800 kg distance spindle center to table:100-600 mm rapid traverse in x-y-z axis:48/48/48 m milling feed range:1-12.000 mm/min spindle speed:8000 1/min spindle taper:40 BT spindle drive:15 kW Tool changer:24 fach max. tool weight:7 kg tool diameter:89 (voll)/125 (leer) mm workpiece length:250 mm dimensions:2870x2200x2810 mm weight of the machine ca.:6,3 t CNC controller:Fanuc 0i MD + MANUAL GUIDE i FUNCTION + 10.4" LCD MONITOR automatic tool changer:24 fach Metric, 400V 50Hz 3 Phase:mit Trafo Tool setter:Option von BLUM oder Renishaw inner coolant:Vorbereitung: ohne Pumpe, ohne Filter, ohne Tank (gegen Mehrpreis) Factory-new, immediately available, vertical CNC machining center with CNC control MANUAL GUIDE i FUNCTION + 10.4 "LCD MONITOR. Our Taiwanese supplier is the lar ...

x-travel:1020 mm y-travel:510 mm z-travel:600 mm table-size:1070x510 mm T-slots:18x5 (Breite x Anz.) mm max. table load:500 kg distance spindle center to table:100-700 mm rapid traverse in x-y-z axis:36/36/36 mm milling feed range:1-12.000 mm/min spindle speed:15.000 (direkt) 1/min spindle taper:40 BBT oder SK spindle drive:14.6 kw Tool changer:30 fach max. tool weight:7 kg tool diameter:89 (voll)/125 (leer) mm workpiece length:250 mm dimensions:2780x2500x2810 mm weight of the machine ca.:7,1 t CNC controller:SIEMENS 828D (10.4" LCD+SHOPMILL) oder FANUC coolant system:mit 320l Tank automatic tool changer:30 fach Tool setter:Option inner coolant:20 bar mit Filtersystem chip conveyor - auger:im Maschinenbett Factory-new, immediately available, vertical CNC machining center with CNC control MANUAL GUIDE i FUNCTION + 10.4 "LCD MONITOR. Our Taiwanese supplier is the largest manufacturer in T ...

x-travel:820 mm y-travel:510 mm z-travel:535 mm table-size:900 X 510 mm T-slots:18x5 (Breite x Anz.) mm max. table load:500 kg distance spindle center to table:100-635 mm rapid traverse in x-y-z axis:48/48/36 mm milling feed range:1-12.000 mm/min spindle speed:15.000 (direkt) 1/min spindle taper:40 BBT oder SK spindle drive:14,6 kw positioning accuracy:0,005 mm repeating accuracy:0,003 mm Tool changer:30 fach max. tool weight:7 kg tool diameter:89 (voll)/125 (leer) mm workpiece length:250 mm dimensions:2,200 × 2,692 × 2,745 mm weight of the machine ca.:5 t CNC controller:SIEMENS 828D (10.4" LCD+SHOPMILL) oder FANUC automatic tool changer:30 fach coolant system:mit 320l Tank Tool setter:Option inner coolant:20 bar mit Filtersystem chip conveyor - auger:im Maschinenbett Factory-new, immediately available, vertical CNC machining center with CNC control MANUAL GUIDE i FUNCTION + 10.4 "LCD ...

turning diameter:450 mm turning length:1500 mm control:Fagor 8055 oder Fanuc max. swing over slide:260 mm bed width:300 mm spindle taper:A2-6 spindle speeds:0-3000 1/min. spindle bore:65 mm transmission ratio:1 tailstock quill diameter:68 mm tailstock quill stroke:200 mm taper of tailstock quill:4 MK max. length of work piece:1500 mm rapid traverse x/z:12/15 m/min power requirement:9 kW weight of the machine ca.:1400 kg dimensions of the machine ca.:3300x1215x1750 mm automatic tool changer:8-fach (PRAGATI) CNC controller:Fagor 8055 tools:1 Satz Made in Europe For more information please see the attached documents

faceplate diameter:5700 mm swing diameter:6300 mm turning height:4000 mm total power requirement:DC 110 kW workpiece weight max.:100 t table speeds:0.2 ~ 20 U/min Torque:des Tisches 300 kN.m slide stroke:vertikal: 2000 mm ram diameter:280 mm rapid traverse:2000 mm/min control:CNC Siemens oder Fanuc _ head swivability:-15°?+30 ° weight of the machine ca.:127 t Rams:2 New CNC Vertical Turret Lathe - Double Column with Siemens 828D or Fanuc 0i TF and extensive accessories. Further technical details and accessories appearing in Appendix.

faceplate diameter:7100 mm swing diameter:8000 mm turning height:5000 mm total power requirement:DC 132 kW workpiece weight max.:180 t table speeds:0.2 ~ 20 U/min Torque:des Tisches 300 kN.m slide stroke:vertikal: 2500 mm ram diameter:320 mm rapid traverse:2000 mm/min control:CNC Siemens oder Fanuc _ head swivability:-15°~+30 ° weight of the machine ca.:127 t Rams:2 New CNC Vertical Turret Lathe - Double Column with Siemens 828D or Fanuc 0i TF and extensive accessories. Further technical details and accessories appearing in Appendix.

x-travel:510 mm y-travel:400 mm z-travel:350 mm table-size:600x400 mm spindle speeds:12000 (Motorspindel) 1/min. spindle drive:5,8 kw spindle taper:30 BBT oder SK rapid traverse in x-y-z axis:60 m/min Tool changer:16 fach weight of the machine ca.:2,8 t CNC controller:SIEMENS 828D (10.4" LCD+SHOPMILL) high speed directl spindle motor:12000 1/min inner coolant:20 bar chip conveyor - auger:im Bett Brandnew machine with: 1. CONTROL SYSTEM SIEMENS 828D (10.4" LCD+SHOPMILL) 2. WORKING TABLE SIZE: 600 X 400 MM 3. MAX. TABLE LOAD CAPACITY: 250 KGS 4. SPINDLE SPEED 12.000RPM (DIRECT DRIVEN TYP) 5. SPINDLE MOTOR 5.8 KW (1PH8087) 6. SPINDLE NOSE BBT 30 7. X/Y/Z STROKE 510/400/300 MM 8. X/Y/Z STROKE RAPID TRAVERSE: 60/60/60 M/MIN 9. ATC CAPACITY 16 TOOLS (DISC TYPE) 10. STANDARD SPLASH GUARD 11. ELECTRICAL CABINET WITH HEAT EXCHANGER 12. COOLANT UNIT 13. MANUAL PULSE GENERATOR 14. RIDGID TAPPING  ...

:KTH 400 | KTH 500 turning diameter:805 | 1010 mm turning length:1000/2000/3000/4000/5000 mm control:Siemens/Fanuc/Fagor max. swing over slide:515 | 718 mm bed width:425 | 500 mm spindle taper:A2-8 (opt. A2-11, A2-15 oder A2-20) spindle bore:105 (opt. 155/230) | 130 (opt. 155/230/310) mm transmission ratio:2 feed range:0-8500 (Z-Achse), 0-6000 (X-Achse) mm/min rapid traverse x/z:7,5/10 m/min tailstock quill diameter:106 | 120 mm tailstock quill stroke:215 | 300 mm taper of tailstock quill:6 MK power requirement:17 | 22 kW automatic tool changer:8-fach mit 4-Werkzeughaltern CNC controller:Siemens/Fanuc/Fagor tools:1 Satz :aus massiven Gusselementen CNC controls from:Siemens/Fanuc/Fagor New CNC lathe KRAFT ST 500/3000 with Fanuc Oi TD Made in Europe For more information please see the attached documents

:JAP 500 turning diameter:1010 mm turning length:2000/3000/4000/5000 mm control:Siemens/Fanuc/Fagor max. swing over slide:718 mm bed width:500 mm spindle taper:A2-11 (opt. A2-11, A2-15, A2-20) ASA spindle speeds:0-1400 (opt. 0-1000, 0-750, 0-560) 1/min. spindle bore:130 (opt. 155,230,310) mm transmission ratio:2 feed range:0-8500 (Z-Achse); 0-6000 (X-Achse) mm/min rapid traverse x/z:7,5/10 m/min tailstock quill diameter:120 mm tailstock quill stroke:300 mm taper of tailstock quill:6 MK power requirement:17 kW weight of the machine ca.:6400/7600/8800/10000 kg dimensions of the machine ca.:4600/5600/6600/7600 x 2270 x 2290 mm :gem. 8605 DIN automatic tool changer:8-fach (Schaft: 32x32mm und Bohrstange:Ø50mm), Hersteller Duplomatic oder Barufaldi mit 4 Haltern CNC controller:Siemens 828D/Fanuc 0iTF/Fagor 8060T tools:1 Satz gear box:von Barufaldi, 2-stufig spindle:Hochpräzisionsspindel CN ...

:SS-27 | SS-31 | SS-35 turning diameter:700|790|890 mm turning length:700/1200/1700/2200/3200/4200/5200 mm control:Siemens 828D spindle nose:A2-11/A2-15/A2-20/A2-28/A2-32 spindle bore:153/230/255/318/360/410/535/610 mm spindle speeds:20-1200/16-700/13-600/14-450/12-400/10-350/8-300/4-220 1/min speed steps work spindle:4-stufig (automatisch schaltend) cross feed:0,001~250 mm/min feed in z-axis:0,001~400 mm/min rapid travel - longitudinal/face:8/10 m/min dia of ball screw:45 mm in X-Achse / 60 mm in Z-Achse tool turret:10- oder 12-fach tool taper:VDI 40/50 oder Schaftaufnahme tool holder -shaft diameter:32x32 mm diameter tailstock quill:160 mm :200 mm tailstock quill taper MT:5 spindle drive:30/37 (37/45 opt.) kW servo motor X-axis:3,8 kw servo motor Z-axis:3,8 kw weight of the machine ca.:11t für Spitzenweite 700mm (weitere 500mm: 1,5t) t CNC controller:Siemens/Fanuc/Fagor steady rests:m ...

:SA-35 | SA-40 | SA-45 turning diameter:890|1020|1145 mm turning length:700/1200/1700/2200/3200/4200/5200 mm control:Siemens 828D spindle nose:A2-11/A2-15/A2-20/A2-28/A2-32 spindle bore:153/230/255/318/360/410/535/610 mm spindle speeds:20-1200/16-700/13-600/14-450/12-400/10-350/8-300/4-220 1/min rapid travel - longitudinal/face:8/10 m/min cross feed:0,001~250 mm/min. feed in z-axis:0,001~400 mm/min dia of ball screw:50 mm in X-Achse / 80 mm in Z-Achse tool turret:10-/12-fach tool taper:VDI 40/50 oder Schaft tool holder -shaft diameter:32x32 mm diameter tailstock quill:235 mm :200 mm tailstock quill taper MT:6 spindle drive:37/45 (50/60 opt.) kW servo motor X-axis:4,5 (6 opt.) servo motor Z-axis:4,5 (6 opt.) kw weight of the machine ca.:16,5t für Spitzenweite 700mm (weitere 500mm: 2,2t) t CNC controller:Siemens/Fanuc/Fagor steady rests:manuell und hydraulisch Solid slant bed esures the  ...

:LL-1250 | LL-1450 | LL-1650 turning diameter:1250 | 1450 | 1650 mm turning length:5000/6000/7000/8000/9000/12000/14000/16000 mm control:Siemens/Fanuc/Fagor center height over bed:705|805|905 mm width of cross cariage:600 mm bed width:1370 mm spindle bore:200 mm spindle nose:A2-15/A2-15/A2-20/A2-28 spindle speed:4-400 U/min spindle taper:6 MK spindle drive:22/26 (30/37 opt.) kW tool turret:4/8/12 hydraulisch oder elektrisch tool holder -shaft diameter:40 mm tailstock quill diameter:300 mm tailstock quill adjustment:250 mm taper in tailstock:7 MK tailstock movement:über Motor (Zahnstangenantrieb) travel -x axis:755 mm travel - z:= Spitzenweite mm servo motor X-axis:4 kw servo motor Z-axis:7 kw rapid power traverse in X-and Z direction:5 m/min hydraulic motor:1,4 (ab 9m: 3,6) kW coolant pump drive:15 bar weight of the machine ca.:auf Anfrage machine length:15150/16150/17150/18150/19150/20 ...

:LL 550 | LL 750 | LL950 turning diameter:550 | 750 | 950 mm turning length:3000/4000/5000/6000/7000/8000/9000/12000/14000 mm control:Siemens/Fanuc/Fagor center height over bed:475|575|675 mm bed width:990 mm spindle bore:153/230/305/405 mm spindle nose:A2-11/A2-15/A2-20/A2-28 spindle speed:9-600/9-500/7-400/5-250 U/min spindle taper:6 MK spindle drive:22/26 (30/37 opt.) kW tool turret:4/8/12 hydraulisch oder elektrisch tool holder -shaft diameter:32 (40 opt.) mm tailstock quill diameter:165|200 mm tailstock quill adjustment:250 mm taper in tailstock:6 MK tailstock movement:über Motor travel -x axis:370 | 480 mm travel - z:= Spitzenweite mm servo motor X-axis:3 | 4 kw servo motor Z-axis:4 | 7 kw rapid power traverse in X-and Z direction:5/4 m/min hydraulic motor:2,2 (2,9 opt.) kW coolant pump drive:3 (15 opt.) | 15 bar weight of the machine ca.:12,7/15,3/18/21,5/24/26,6 | 13,7/16,4/19/2 ...

x-travel:1050 mm y-travel:850 mm z-travel:970 mm distance spindle nose and table:100-950 mm distance spindle center to table:100-1070 mm table height over floor:1300 mm pallet table size:630x630 mm max. workpiece weight:1200x2 kg table - indexing:1° (optional 0,001°) max. workpiece height:1100x1100 mm spindle speeds:10000 1/min spindle drive:30/25 kW spindle speed steps:2 spindle nose:50 SK/BT rapid speed:50 m/min feeds:1-20000 mm/U tool taper:50 SK/BT Tool changer:60 fach tool diameter:125 mm weight of tools max.:25 kg workpiece length:610 mm number of pallets:2 weight of the machine ca.:21600 kg automatic tool changer:60 fach cnc rotary table:1 ° inner coolant:15 bar CNC controller:Siemens/Fanuc/Heidenhain Servo motors:vom Steuerungshersteller ATC:80/120 CTS:35 oder 70 bar CNC controls from:Siemens/Fanuc/Heidenhain tool measuring system:von RENISHAW workpiece measurement system:von  ...

x-travel:610 mm y-travel:580 mm z-travel:580 mm distance spindle nose and table:70-650 mm distance spindle center to table:80-660 mm table height over floor:1150 mm pallet table size:400x400 mm max. workpiece weight:400x2 kg table - indexing:1° (optional 0,001°) spindle speeds:12000 1/min spindle drive:22/25 kW spindle speed steps:2 spindle nose:40 SK/BT spindle bearing diameter:75 mm rapid speed:60 m/min feeds:1-20000 mm/U tool taper:40 SK/BT Tool changer:60 fach tool diameter:75 mm weight of tools max.:12 kg workpiece length:410 mm number of pallets:2 compressed air volume:400 l/min coolant tank:550 l hydraulic tank:30 l lubrication tank:2 l total power requirement:45 kva weight of the machine ca.:9500 kg CNC controller:Siemens/Fanuc/Heidenhain automatic tool changer:60 fach cnc rotary table:1 ° inner coolant:20 bar Servo motors:vom Steuerungshersteller ATC:80/120 CTS:35 oder 70 bar ...

x-travel:1200 mm y-travel:1000 mm z-travel:1000 mm distance spindle nose and table:100-1100 mm distance spindle center to table:200-1200 mm table height over floor:1350 mm pallet table size:800x800 mm max. workpiece weight:1800x2 kg table - indexing:1° (optional 0,001°) max. workpiece height:1300x1250 mm spindle speeds:10000 1/min spindle drive:30/25 kW spindle speed steps:2 spindle nose:50 SK/BT rapid speed:50 m/min feeds:1-20000 mm/U tool taper:50 SK/BT Tool changer:60 fach tool diameter:125 mm weight of tools max.:25 kg workpiece length:610 mm number of pallets:2 weight of the machine ca.:26000 kg automatic tool changer:60 fach cnc rotary table:1 ° inner coolant:15 bar Servo motors:vom Steuerungshersteller CNC controller:Siemens/Fanuc/Heidenhain ATC:80/120 CTS:35 oder 70 bar CNC controls from:Siemens/Fanuc/Heidenhain tool measuring system:von RENISHAW workpiece measurement system:v ...

x-travel:710 mm y-travel:680 mm z-travel:680 mm distance spindle nose and table:70-750 mm distance spindle center to table:80-760 mm table height over floor:1150 mm pallet table size:500x500 mm max. workpiece weight:500x2 kg table - indexing:1° (optional 0,001°) spindle speeds:12000 1/min spindle drive:22/25 kW spindle speed steps:2 spindle nose:40 SK/BT spindle bearing diameter:75 mm rapid speed:60 m/min feeds:1-20000 mm/U tool taper:40 SK/BT Tool changer:60 fach tool diameter:75 mm weight of tools max.:12 kg workpiece length:410 mm number of pallets:2 compressed air volume:400 l/min coolant tank:550 l hydraulic tank:30 l lubrication tank:2 l total power requirement:45 kva weight of the machine ca.:12200 kg automatic tool changer:60 fach cnc rotary table:1 ° inner coolant:20 bar CNC controller:Siemens/Fanuc/Heidenhain Servo motors:vom Steuerungshersteller ATC:80/120 CTS:35 oder 70 ba ...

faceplate diameter:6300 mm swing diameter:8000 mm turning height:4000 mm workpiece weight:120 t table speeds:0.2-16 U/min (2 Stufen) max. torque on the faceplate:200/460 k.Nm slide stroke:vertikal: 2500 mm slide stroke:horizontal: 4350 mm cross section of ram:280x280 mm Max. cutting force of tool head :links: 63 kN / rechts: 80 kN Cross rail travel :2000 mm rapid feed cross beam:300 mm/min feed stepless:X-Achse: 1-500 mm/min main drive:110 kW weight of the machine ca.:190 t Machine size (LxWxH):11000x9000x8000 mm control:Siemens 828D/Siemens 840D worktool support (A-axis):2 Stück :1 Stück Rams:1 Stück konventioneller und 1 Stück CNC-Stößel CE-design:inkl. Zertifikat European electric:Schneider, Siemens, ABB oder ähnlich Servo motors:von Siemens SPS machine control:von Siemens CNC controls from:Siemens/Fanuc/Fagor for more information please check attached pdf file on the right ha ...

Modell:SDM 630 | SDM 800 | SDM 1000 | SDM 1200 turning diameter over bed:630 | 800 | 1000 | 1200 mm turning diameter over slide rest:345|480|680|880 mm turning length:1000,2000,3000,4000,5000,6000,7000,8000~12000 mm travel of cross-slide cross:370|420|520|620 mm movement of the upper support:200 mm bed width:600 (Monoblock) mm spindle bore:105mm (130 oder 155 opt.) mm spindle nose:DIN 55029 Größe11 oder DIN 55027 Größe 11 spindle taper:Ø120mm/Konus 1:20 spindle speeds:7.5~1000|5,5~730|5,5~730|5,5~730 1/min metric threading:1~240 mm feeds - longitudinal:0.1~24,3 mm/min feeds - cross:0.05~12,5 mm/min rapid traverse longitudinal and cross:4000, 2000 mm/min turning tool - shaft cross cut:32 x 32 mm tailstock quill diameter:100 mm tailstock quill stroke:240 mm taper in tailstock:6 MK main drive motor:11 (15 kw opt.) kW max. workpiece weight between centers:3000 kg Weight approx.:4t bei  ...

internal diameter:250 mm swing diameter:455 mm workpiece length - max.:1200 mm table rotating:-4/+8 ° table speeds:0-4000 mm/min max. workpiece weight:80 kg workhead - center taper:5 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:4 kW coolant pump:2,2 kW Weight approx.:2,4 t machine dimensions:3200 x 2100 mm CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:250 (selbstschließend), 1 Satz harte Backen, 1 Satz weiche Backen, 1 Satz Innen mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:RPM 28.000, diam. 60 mm. Min. diam. cap. 25 mm. x Bohrung 50 mm, Max. diam. cap. 100 mm. x Bohrung 115 mm . internal grinding spindle: ...

internal diameter:300 mm swing diameter:300/350 mm workpiece length - max.:2300 mm table rotating:-2/+6 ° table speeds:0-4000 mm/min max. workpiece weight:400 (fliegend, 150mm von der Spindelnase) kg workhead - center taper:6 MK Rotation speed of workhead :0 - 400 1/min workhead motor:4 kw 3-jaw chuck:250 (selbstschließend) mm grinding motor:11 kW coolant pump:2,2 kW CNC controller:Siemens 840 D oder SPS von Siemens autom. sensing device for grinding wheel:Option linear scales and ballscrew:in allen Achsen face grinding attachement:Durchmesser 125 mm clamping chuck:350 (selbst zentrierend) mm frequency control main spindel engine:für die Innenschleifeinrichtung internal grinding spindle:auf Anfrage internal grinding spindle:auf Anfrage fixed steady rests:10-100 mm, 100-170 mm PERFORMANCE AND PRECISION DEGREE Robbi grinding machines are according to the international precision normes ...

:KVL-450 | KVL-600 | KVL-800| KVL-1100 turning diameter:450|600|800|1100 mm swing diameter:550|650|1000|1250 mm turning height:450|500|750/950|1000 mm spindle nose:A2-8|A2-8|A2-11|A2-15 table rotation speed:50-2500|50-2250|20-1500|20-600 U/min Travel of Ram (vertical):450|500|800 / 1000 (Opt.)|1000 mm Travel of ram (horiz.):300|340|500|700 mm rapid power traverse in X-and Z direction:20/24|20/24|20/20|10/10 m/min Tool changer:8/10/12 mit vertikaler oder horizontaler Scheibe tool taper:VDI40/VDI50 oder Schaftaufnahme drive capacity - spindle motor:11/15|15/18.5|18.5/22|37/45 kW Machine height:2600|2910|4020|4605 mm weight of the machine ca.:4500|6000|13000|18000 kg hydraulic motor:2,2 kW servo motor X-axis:1,6|1,6|4|7 kw servo motor Z-axis:3|3|7|7 kw coolant pump drive:0,75+1,1|0,75+1,1|0,75+0,75+1,1|0,75+0,75+1,1 kW :35|40|50|70 kva CNC controller:Siemens/Fanuc/Fagor CNC controls from:Si ...

x-travel:4000/7000/9000 mm y-travel:700 mm z-travel:300 mm spindle cone: 30 SK turning speeds:0/24000 U/min spindle drive:18 kW Weight approx.: 3200 (bei 4m in X) kg machine dimensions:6800x3100x3000 (bei 4m in X) mm automatic tool changer:8 optional 16 oder 30 CNC controller:mit Zyklen von Italmac :6 Klemmvorrichtungen automatisch verfahrbar
